ZQO-CX8753PBJukeBlox Networked Media Module

SMSC CX Module Revision 2.8 (09-30-12) SMSC CONFIDENTIAL JukeBlox Networked Media Module CX Series Datasheet • Complete audio networking system on a small module • Integrated Ethernet + USB 2.0 • WiFi-certified 802.11b/g • Built-in strip antenna • Optional 2X Diversity Antenna • Glueless audio, video and control ports • FCC certified • Ideal for enabling network and USB audio playback for iPod docks, audio systems, AV Receivers, active speaker systems, internet radios, network playback adaptors JukeBlox Networked Media Modules – CX Series Datasheet SMSC CX Module 2 Revision 2.8 (09-30-12) Copyright © 2012 SMSC or its subsidiaries. All rights reserved. Circuit diagrams and other information relating to SMSC products are included as a means of illustrating typical applications. Consequently, complete information sufficient for construction purposes is not necessarily given. Although the information has been checked and is believed to be accurate, no responsibility is assumed for inaccuracies. SMSC reserves the right to make changes to specifications and product descriptions at any time without notice. Contact your local SMSC sales office to obtain the latest specifications before placing your product order. The provision of this information does not convey to the purchaser of the described semiconductor devices any licenses under any patent rights or other intellectual property rights of SMSC or others. All sales are expressly conditional on your agreement to the terms and conditions of the most recently dated version of SMSC's standard Terms of Sale Agreement dated before the date of your order (the "Terms of Sale Agreement"). The product may contain design defects or errors known as anomalies which may cause the product's functions to deviate from published specifications. Anomaly sheets are available upon request. SMSC products are not designed, intended, authorized or warranted for use in any life support or other application where product failure could cause or contribute to personal injury or severe property damage. Any and all such uses without prior written approval of an Officer of SMSC and further testing and/or modification will be fully at the risk of the customer. Copies of this document or other SMSC literature, as well as the Terms of Sale Agreement, may be obtained by visiting SMSC’s website at http://www.smsc.com. SMSC is a registered trademark of Standard Microsystems Corporation (“SMSC”). Product names and company names are the trademarks of their respective holders. The Microchip name and logo, and the Microchip logo are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. SMSC DISCLAIMS AND EXCLUDES ANY AND ALL WARRANTIES, INCLUDING WITHOUT LIMITATION ANY AND ALL IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND AGAINST INFRINGEMENT AND THE LIKE, AND ANY AND ALL WARRANTIES ARISING FROM ANY COURSE OF DEALING OR USAGE OF TRADE. IN NO EVENT SHALL SMSC BE LIABLE FOR ANY DIRECT, INCIDENTAL, INDIRECT, SPECIAL, PUNITIVE, OR CONSEQUENTIAL DAMAGES; OR FOR LOST DATA, PROFITS, SAVINGS OR REVENUES OF ANY KIND; REGARDLESS OF THE FORM OF ACTION, WHETHER BASED ON CONTRACT; TORT; NEGLIGENCE OF SMSC OR OTHERS; STRICT LIABILITY; BREACH OF WARRANTY; OR OTHERWISE; WHETHER OR NOT ANY REMEDY OF BUYER IS HELD TO HAVE FAILED OF ITS ESSENTIAL PURPOSE, AND WHETHER OR NOT SMSC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. JukeBlox Networked Media Modules – CX Series Datasheet SMSC CX Module 3 Revision 2.8 (09-30-12) Table of Contents 1 INTRODUCTION............................................................................................................... 4 2 BLOCK DIAGRAM ............................................................................................................. 4 3 BOARD PICTURES ............................................................................................................ 5 3.1 TOP VIEW OF CX MODULE................................................................................................. 5 3.2 BOTTOM VIEW OF CX MODULE............................................................................................ 6 3.2.1 CX Module Bottom View w/64-pin Low Density Connector........................................... 6 3.2.2 CX Module Bottom View w/120-pin Media Connector ................................................. 6 3.3 PRODUCTION MODULE WITH TOP AND RF SHIELDS IN PLACE – TOP VIEW............................................. 7 3.4 PRODUCTION MODULE WITH 64-PIN CONNECTOR OPTION – SIDE VIEW.............................................. 7 3.5 EXAMPLE PRODUCTION MODULE SHOWING SOLDERED RF SHIELD..................................................... 8 3.6 PRODUCTION MODULE WITH BOTTOM SHIELD (PART NUMBERS WITH A “B” AFTER THE CONFIGURATION LETTER)9 3.6.1 Including J3 Low Density 64-pin connector – Bottom View.......................................... 9 3.6.2 Including J2 High Density 120-pin connector – Bottom View ....................................... 9 4 ORDERING GUIDE......................................................................................................... 10 4.1 PART NUMBER SYNTAX....................................................................................................10 5 ELECTRICAL SPECIFICATIONS....................................................................................... 11 5.1 ABSOLUTE MAXIMUM RATINGS............................................................................................12 5.2 OPERATING CONDITIONS..................................................................................................12 5.3 WIFI SPECIFICATION (CX870 ONLY) ...................................................................................13 6 REGULATORY COMPLIANCE AND QUALITY .................................................................... 14 6.0.1 Antenna Considerations ................................................................…

Text truncated - open the document above for the full version.

1 of 6 External Photos Model Number: CX875-3PB FCC ID: ZQO-CX8753PB IC: 2581A-CX8753PB EUT Different Description： This device has four versions, the different descriptions see below table. Parts Model Number A1 A2 A3 A4 Winbond W9812G6JH-6 9 9 SDRAM ESMT M12L128168A-6TG2N 9 9 MXIC MX29GL640EHT2I-70G 9 9 NOR Flash Winbond W29GL064CH7T 9 9 15pF 9 9 C196 Capacitor 18pF 9 9 15pF 9 9 C197 Capacitor 12pF 9 9 2 of 6 EUT Photo 1 ) EUT Photo 2 ) 3 of 6 EUT Photo 3 ) EUT Photo 4 ) 4 of 6 EUT Photo 5 ) EUT Photo 6 ) 5 of 6 EUT Photo 7 ) EUT Photo 8 ) 6 of 6 EUT Photo 9 ) EUT Photo 10 ) External Ant.

201-XXXXXX ZQO-CX8753PB IC:2581A-CX8753PB SMSC 谢丽丽 Anny 2012.12.17 A6 M113069007 M (HTLWJ50) CX875-3PB 此label只限试产期间用 201-XXXXXX ZQO-CX8753PB IC:2581A-CX8753PB CX875-3PB NM-104-BB (CX875-3PB MFG100)

1 of 5 Internal Photos Model Number: CX875-3PB FCC ID: ZQO-CX8753PB IC: 2581A-CX8753PB EUT Different Description： This device has four versions, the different descriptions see below table. Parts Model Number A1 A2 A3 A4 Winbond W9812G6JH-6 9 9 SDRAM ESMT M12L128168A-6TG2N 9 9 MXIC MX29GL640EHT2I-70G 9 9 NOR Flash Winbond W29GL064CH7T 9 9 15pF 9 9 C196 Capacitor 18pF 9 9 15pF 9 9 C197 Capacitor 12pF 9 9 2 of 5 EUT Photo 1 ) EUT Photo 2 ) 3 of 5 EUT Photo 3 ) EUT Photo 4 ) 4 of 5 EUT Photo 5 ) EUT Photo 6 ) 5 of 5 EUT Photo 7 ) EUT Photo 8 )

A Test Lab Techno Corp. Changan Lab：No. 140 -1, Changan Street, Bade City, Taoyuan County, Taiwan R.O.C. Te l：886-3-271-0188 / Fax：886-3-271-0190 MPE Report Test Report No. ： 1301FS12-01 Applicant ： STANDARD MICROSYSTEMS CORPORATION Manufacturer ： DONG GUAN G-COM COMPUTER CO., LTD Product Type ： JukeBlox Networked Media Module Trade Name ： PICO Module Model Number ： CX875-3PB Date of Received ： Dec.27, 2012 Test Period ： Jan.08 ~ Jan. 15, 2013 Date of Issued ： Jan. 24, 2013 Test Specification ： 47 CFR § 2.1091 47 CFR §1.1310 ANSI / IEEE Std.C95.1-1992 H46-2/99-237E Location of Test Lab. ： Chang-an Lab. 1. The test operations have to be performed with cautious behavior, the test results are as attached. 2. The test results are under chamber environment of A Test Lab Techno Corp. A Test Lab Techno Corp. does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples. 3. The measurement report has to be written approval of A Test Lab Techno Corp. It may only be reproduced or published in full. This report shall not be reproduced except in full, without the written approval of A Test Lab Techno Corp. 4. This document may be altered or revised by A Test Lab Techno. Corp. personnel only, and shall be noted in the revision section of the document. Approved By ： Tested By ： (Yung Tan Tsai ) (Bill Hu) ©2012 A Test Lab Techno Corp. Report Number: 1301FS12-01Page 1 of 5 Contents 1. Description of Equipment under Test (EUT) ............................................................... 3 2. Human Exposure Assessment..................................................................................... 4 3. RF Output Power........................................................................................................... 5 4. Test Result .....................................................................................................................5 ©2012 A Test Lab Techno Corp. Report Number: 1301FS12-01Page 2 of 5 1. Description of Equipment under Test (EUT) Applicant STANDARD MICROSYSTEMS CORPORATION Applicant Address 3930, EAST RAY ROAD SUITE 200, PHOENIX, ARIZONA, 85044-7176,UNITED STATES Manufacturer DONG GUAN G-COM COMPUTER CO., LTD Manufacturer Address 1st Row, Yin Shan Road, Yin Hwu Industrial Area, Qingxi Town, DongGuan City, GuangDong, China Product Type JukeBlox Networked Media Module Trade Name PICO Module Model Number CX875-3PB FCC ID ZQO-CX8753PB IC 2581A-CX8753PB Frequency Range IEEE 802.11 b / 802.11g: 2412 - 2462 MHz Transmit Power IEEE 802.11 b: 0.051 W / 17.10 dBm (AVG. Conducted Power) IEEE 802.11 g: 0.037 W / 15.67 dBm Antenna used Trade name: MAG.LAYERS, Model number: EDA-8709-2G4C1-A66 Antenna Type External Antenna Antenna Gain 2.0 dBi Temperature Range -30 ~ +70°C The above equipment was tested by A Test Lab Techno Corp. For compliance with the requirements set forth in 47 CFR § 2.1091 & 47 CFR § 1.1310. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties EUT Different Description： This device has four versions, the different descriptions see below table. Parts Model Number A1 A2 A3 A4 Winbond W9812G6JH-6 9 9 SDRAM ESMT M12L128168A-6TG2N 9 9 MXIC MX29GL640EHT2I-70G 9 9 NOR Flash Winbond W29GL064CH7T 9 9 15pF 9 9 C196 Capacitor 18pF 9 9 15pF 9 9 C197 Capacitor 12pF 9 9 ©2012 A Test Lab Techno Corp. Report Number: 1301FS12-01Page 3 of 5 2. Human Exposure Assessment Due to the design and installation of this product, it is not possible to conduct SAR evaluation. This is because client either manufactures or supplies the antenna(s) that will be used in the installation of this product. Therefore, this product will be evaluated as a mobile device per 47 CFR §1.1310 titled “Radiofrequency radiation exposure limits”, generally referred to as MPE limits. In 47 CFR § 2.1091, paragraph (b) defines a mobile device as “a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 cm is normally maintained between the transmitter’s radiating structure(s) and the body of the user or nearby persons. ” This product is intended to be installed into a vehicle such that the unit is physically secured at one location. In the installation guide supplied with the product, Client has made the following statement: “IMPORTANT: To meet the FCC’s RF Exposure Guidelines, the antenna should be installed so there is at least 20 cm of separation between the body of the user and nearby persons and the antenna”. Based on the installation of the transceiver and the antenna, the transmitters radiating structure is more than 20 cm from the user. Thus, this product is a “mobile device” as defined in section § 2.1091 paragraph (b). Exposure evaluation Equation from page 18 of OET Bulletin 65, Edition 97-01 2 4R PG S π = Where S: power density P: power input to the antenna G: power gain of the antenna in the direction of interest relative to an isotropic radiator. R: distance to the center of radiation of the antenna. Note: For evaluated 2G system, the transmission power P + G should be consider duty cycle. ©2012 A Test Lab Techno Corp. Report Number: 1301FS12-01Page 4 of 5 3. RF Output Power Conducted power (dBm) CON 1 CON 2 Band Date Rate CH Frequency (MHz) Avg. Peak Avg. Peak Worst Case 01 2412 17.38 20.01 17.46 20.18 □ 06 2437 --- --- 17.53 20.27 □ IEEE 802.11b 1 M 11 2462 --- --- 17.65 20.34 ■ 01 2412 15.99 24.03 15.79 23.85 ■ 06 2437 15.89 23.86 --- --- □ IEEE 802.11g 6 M 11 2462 12.85 22.59 --- --- □ Note: Find worst case between ant1 and ant2,and check with lowest data rate. 4. Test Result Band Data Rate Frequency (MHz) Limit (mw/cm 2 ) Distance (cm) [R] Tune-up power (dBm) [P] ANT Gain (dBi) [G] [P]+ [G] (W) [TP] Power Density [S] (mw/cm 2 ) Min. distance (cm) 2412 1…

Text truncated - open the document above for the full version.

FCC 47 CFR PART 15 SUBPART C Product Type ： JukeBlox Networked Media Module Applicant ： STANDARD MICROSYSTEMS CORPORATION Address ： 3930, EAST RAY ROAD SUITE 200, PHOENIX, ARIZONA, 85044-7176,UNITED STATES Trade Name ： PICO Module Model Number ： CX875-3PB Test Specification ： FCC 47 CFR PART 15 SUBPART C: Oct., 2012 Canada RSS-210 ISSUE 8: Dec., 2010 Canada RSS-Gen ISSUE 3: Dec., 2010 ANSI C63.4-2009 Receive Date ： Dec. 27, 2012 Test Period ： Jan. 02 ~ Jan. 08, 2013 Issue Date ： Jan. 24, 2013 Issue by A Test Lab Techno Corp. No. 140-1, Changan Street, Bade City, Taoyuan County 334, Taiwan R.O.C. Te l：+886-3-2710188 / Fax：+886-3-2710190 T aiwan Accreditation Foundation accreditation number: 1330 Note: This report shall not be reproduced except in full, without the written approval of A Test Lab Techno Corp. This document may be altered or revised by A Test Lab Techno Corp. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, or any government agencies. The test results in the report only apply to the tested sample. A Test Lab Techno Corp. Report Number: 1301FR12-01 1 of 47 A Test Lab Techno Corp. Report Number: 1301FR12-01 2 of 47 Revision History Rev. Issue Date Revisions Revised By 00 Jan. 16, 2013 Initial Issue 01 Jan. 24, 2013 Revised Antenna description Nico Peng Verification of Compliance Issued Date: 01/24/2013 Product Type : JukeBlox Networked Media Module Applicant : STANDARD MICROSYSTEMS CORPORATION Address : 3930, EAST RAY ROAD SUITE 200, PHOENIX, ARIZONA, 85044-7176,UNITED STATES Trade Name : PICO Module Model Number : CX875-3PB FCC ID : ZQO-CX8753PB IC : 2581A-CX8753PB EUT Rated Voltage : DC 1.2V / 1.9V / 3.3V Test Voltage : 120 Vac / 60 Hz Applicable Standard : FCC 47 CFR PART 15 SUBPART C: Oct., 2012 Canada RSS-210 ISSUE 8: Dec., 2010 Canada RSS-Gen ISSUE 3: Dec., 2010 ANSI C63.4-2009 Test Result : Complied Performing Lab. : A Test Lab Techno Corp. No. 140-1, Changan Street, Bade City, Taoyuan County 334, Taiwan R.O.C. Te l：+886-3-2710188 / Fax：+886-3-2710190 T aiwan Accreditation Foundation accreditation number: 1330 http://www.atl-lab.com.tw/e-index.htm The above equipment was tested by A Test Lab Techno Corp. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2009 and the energy emitted by the sample tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247 . The test results of this report relate only to the tested sample identified in this report. Approved By ： Reviewed By ： (Manager) (Murphy Wang) (Testing Engineer) (Fly Lu) A Test Lab Techno Corp. Report Number: 1301FR12-01 3 of 47 TABLE OF CONTENTS 1 General Information ....................................................................................................................................... 6 2 EUT Description ............................................................................................................................................. 7 3 Test Methodology .......................................................................................................................................... 8 3.1. Mode of Operation.................................................................................................................................. 8 3.2. EUT Exercise Software.......................................................................................................................... 8 3.3. Configuration of Test System Details ..................................................................................................... 9 3.4. Test Site Environment ............................................................................................................................ 9 4 Conducted Emission Measurement ........................................................................................................... 10 4.1. Limit ...................................................................................................................................................... 10 4.2. Test Instruments ................................................................................................................................... 10 4.3. Test Setup............................................................................................................................................. 10 4.4. Test Procedure ......................................................................................................................................11 4.5. Test Result............................................................................................................................................ 12 5 Radiated Emission Measurement............................................................................................................... 14 5.1. Limit ...................................................................................................................................................... 14 5.2. Test Instruments ................................................................................................................................... 14 5.3. Setup .................................................................................................................................................... 15 5.4. Test Procedure ..................................................................................................................................... 16 5.5. Test Result............................................................................................................................................ 18 6 Maximum Conducted Output Power Measurement.................................................................................. 23 6.1. Limit .......................................................…

Text truncated - open the document above for the full version.

Part 15C & RSS-210 Test Setup Photographs Conducted Emissions Test Configuration: Front View Rear View A Test Lab Techno Corp. Report Number: 1301FR12-01 1 of 4 Radiated Emissions Test Configuration: Below 1GHz _ Front View Below 1GHz _ Rear View A Test Lab Techno Corp. Report Number: 1301FR12-01 2 of 4 Above 1GHz _ Front View Above 1GHz _ Rear View A Test Lab Techno Corp. Report Number: 1301FR12-01 3 of 4 Close View A Test Lab Techno Corp. Report Number: 1301FR12-01 4 of 4
