ZRU-KHM500WIRELESS MICROPHONE

KUMYOUNG. Co., Ltd.

Click to zoom

Application Details

Equipment Class: TNF - Licensed Non-Broadcast Transmitter Held to Face
Date of Grant: Jul 28, 2011
Application Purpose: Original Equipment
Date of Application: Jul 28, 2011
Equipment Note: WIRELESS MICROPHONE
Frequency Range: 603.30000000 - 607.50000000
Company: KUMYOUNG. Co., Ltd.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

www.kumyoung.com Kumyoung co.,Ltd User Guide G {G GGGGkGOrot\WWPGG U ~GGG GGGG GGGGU i GGGGGGSGGG GG GGUGG wGGGGGG UGGGG G 2 Introduction 3 Table of Contents 1. Item Checklist Basic Items 5 Optional Items 5 2. Safety and Maintenance 2-1 Safety Symbols 6 2-2 Notes for Assembly 7 2-3 Safety Use 8 2-4 Using Batteries 11 2-5 System Maintenance 12 3. Introduction and Setup 3-1 System Overview KHM500 14 Wireless Microphone 16 Remote Control 17 3-2 Setup 18 3-3 Using the Remote Control 20 3-4 Connecting the Microphone 20 4. KHM500 Functions 4-1 Karaoke Mode 4-1-1 Basic Functions 22 4-1-2 Karaoke Functions 24 4-1-3 Special Karaoke Functions 33 4 4-2 Multimedia 4-2-1 Mode Select 35 4-2-2 MP3 Mode 35 4-2-3 Video Mode 39 4-2-4 Image Mode 42 4-2-5 Multimedia Mode Setup Menu 44 5. Miscellaneous 5-1 System Update 45 5-2 Installing Song Packs 46 5-3 Converting to HDMI or CVA Mode 47 6. Bundle Software 6-1 KHM500 Multimedia converter 48 6-2 Image Background 48 6-3 Video Background 50 7. Quick Troubleshooting 52 53 9. Product Warranty 54 ୙GwGGGGGGG Basic Items Optional 5 1. Item Checklist zGG |GnGMGzGs yjhGhG}Gj tGz yGj [GhhGVGYGhhhGi zGw {G~Gt j Gi hjGh the images. 6 2. Safety and Maintenance Ignoring the symbols below could lead to serious injury if the equipment is handled incorrectly. 2-1 Safety Symbols Electric Shock Caution Attention Fire Hazard Disassembly the power cord Leak System Damage Disassembly Electric Shock User Injury Do not disassemble Actions can Electric Shock Actions can cause injury to the user Electrical shock can occur Warning Danger, or Caution Mandatory disassemble (disconnecting the power plug with mandatory operation) Actions can cause Electrical or Battery Leak Actions can cause damage to the system Good Accepted Actions 7 Caution Ventilation manual of the other devices being connected to the player before installation. Improper use may cause a Using the wrong power adaptor may cause electric ! " # $ abrupt high or an uncomfortable volume level can cause permanent hearing loss. % # For optimal use, keep a 2 inch gap between the player and other devices, and a 4 inch gap from walls. & ' # should not be placed in a partitioned space that will * " & $ heat. ୙ # "&+/:;<= 2-2 Notes for Assembly 8 Power Cord/Voltage Temperature / Heat # "> " the device below the permitted voltage. & " $ malfunctions. & "# " at the same time. If several plugs are being used please maintain the total power consumption below 200W. Do not plug this system with a heat source, ; & '? # " shock. If the power cord is damaged (outing of internal line, disconnection etc), contact the store where you purchased it from. #""# '" " drawing, or heating the power cord. & damage to it. @ " thunder or lightening storm. & G " $ equipment distortion, or discoloration. & a radiator, heat registers, stoves or other devices G " # " or electric shock, place the power-supply cord away from heat sources. & " often occur. & 2-3 Safety Use 9 Water/Moisture Handling > off the power. Please use a pair of thick gloves for protection, disconnect the power plug from the outlet and call the service center. J " ' used for a long period of time. & It can cause a short circuit & % ' the player. It can cause electrical malfunctions. & ' #' " ' surfaces. Installing on unstable surfaces may cause the player to fall and cause damages. ' stepped or tripped on. > " the power plug from the electric outlet, and inform a local repair center. If you use it without any Q & '? & ; ' may cause damage to the player. Do not climb on the player or cling to the attached devices. # $ ' source of damage or injury. ' " 10 Handling ' " causes malfunction or deterioration of its capacity. " " pitch beep sound. & …

Text truncated - open the document above for the full version.

Cover Letter(s)

KUMYOUNG. Co., Ltd. SEOUL_KY Bldg, 40-17 Hangangro, 3-ga, Yongsan-gu, Seoul, Korea, 140-880 Tel. +82-2-6390-2213 Fax +82-2-6390-2554 July 15, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : KUMYOUNG. Co., Ltd. FCC ID : ZRU-KHM500 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, KUMYOUNG. Co., Ltd.. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give KUMYOUNG. Co., Ltd.. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name CONFIDENTIAL Schematics CONF APPENDIX ZRU-KHM500 SCH DIA.pdf Parts list CONF APPENDIX ZRU-KHM500 PL.pdf Block diagram CONF APPENDIX ZRU-KHM500 BLK DIA.pdf Operational description CONF APPENDIX ZRU-KHM500 OpDes.pdf SHORT-TERM CONFIDENTIAL External Photos SHORT-TERM CONF ZRU-KHM500 EXT Photo.pdf Internal Photos SHORT-TERM CONF ZRU-KHM500 INT Photo.pdf Test-Setup Photos SHORT-TERM CONF ZRU-KHM500 Test Photo.pdf User’s Manual SHORT-TERM CONF ZRU-KHM500 Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Young Hwan, Kim / General Manager KUMYOUNG. Co., Ltd.

External Photos

FCC ID: ZRU-KHM500 IC: 9774A-KHM500 Copyright ○ c 2011, LTA Co., Ltd. Page 1 of 3 M/N: ZRU-KHM500 Upper Lower FCC ID: ZRU-KHM500 IC: 9774A-KHM500 Copyright ○ c 2011, LTA Co., Ltd. Page 2 of 3 Front Rear FCC ID: ZRU-KHM500 IC: 9774A-KHM500 Copyright ○ c 2011, LTA Co., Ltd. Page 3 of 3 Wire ANTENNA

ID Label/Location Info

Internal Photos

FCC ID: ZRU-KHM500 IC: 9774A-KHM500 Copyright ○ c 2011, LTA Co., Ltd. Page 1 of 2 MainBoard - Front MainBoard - Rear FCC ID: ZRU-KHM500 IC: 9774A-KHM500 Copyright ○ c 2011, LTA Co., Ltd. Page 2 of 2 Keypad - Front Keypad - Rear

Parts List/Tune Up Info

TUNE-UP PROCEDURE Test frequency CH1 -> 603.3MHz CH2 -> 607.5MHz (1)Transmission frequency adjustment Connect RF output to a frequency counter ,then rotate the VC2 so that the transmission frequency can be adjusted with in ±1kHz for the nominal value at no modulation. (2)RF output adjustment a) Connect the RF power meter to the pot ANT (RF impedance50 ohm) b) Switch on the transmitter c) Check the Tx Power. d) Specification: 9dBm+/-1dBm (3)Maximum deviation adjustment Connect RF output to a modulation analyzer ,then adjust the MVR1 & MVR2 so that frequency deviation except tone signal becomes in the range of ±70±0.2kHz when modulation signal below is input from Mic input (LPF:20kHz,P-P/2)

Test Report

Ref. No.: LR500111107K Copyright ○ c 2011, LTA Co., Ltd. Page 1 of 22 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: July 04 ~ 14, 2011 Test Report S/N: LR500111107K Test Site : LTA CO., LTD. CERTIFICATIO OF COMPLIANCE FCC ID IC APPLICANT Equipment Class : Part 74 Licensed Non-Broadcast Transmitter Held to Face (TNF) Manufacturing Description : Wireless Microphone Manufacturer : KUMYOUNG. CO., Ltd. Model name : KHM-500T Test Device Serial No.: : Identical prototype FCC Rule Part(s) : FCC Part 74 Subpart H; ANSI C-63.4-2003 RSS-123 and ISSUE No. :2 Date :2011 Frequency : 603.3 MHz, 607.5MHz RF Output Power : Max 0.00607W - Radiated Data of issue : July 19, 2006 This test report is issued under the authority of: The test was supervised by: Hyun-Chae You, Manager Il-Shin kim, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. NVLAP LAB Code.: 200723-0 ZRU-KHM500 9774A-KHM500 KUMYOUNG. CO., Ltd. Ref. No.: LR500111107K Copyright ○ c 2011, LTA Co., Ltd. Page 2 of 22 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TRANSMITTER REQUIREMENTS --------------------------------------------------------------- 3.2.1 RF POWER OUTPUT -------------------------------------------------------------------------- 3.2.2 MODULATION CHARACTERISTICS ------------------------------------------------------ 3.2.2.1 FREQUENCY RESPONSE ----------------------------------------------------------------- 3.2.2.2 MODULATION LIMITING ---------------------------------------------------------------- 3.2.3 OCCUPIED BANDWIDTH -------------------------------------------------------------------- 3.2.4 FIELD STRENGTH OF HARMONICS -------------------------------------------------------- 3.2.5 FIELD STRENGTH OF HARMONICS - RECEIVER -------------------------------------- 3.2.6 FREQUENCY STABILITY -------------------------------------------------------------------- 3.2.7 AC CONDUCTED EMISSIONS ---------------------------------------------------------------- APPENDIX APPENDIX 1 TEST EQUIPMENT USED FOR TESTS ------------------------------------------ 3 4 5 5 6 6 9 9 10 11 14 17 18 20 21 Ref. No.: LR500111107K Copyright ○ c 2011, LTA Co., Ltd. Page 3 of 22 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2011-09-30 ECT accredited Lab. KCC KOREA KR0049 2013-04-24 EMC accredited Lab. FCC U.S.A 610755 2014-04-27 FCC filing FCC U.S.A 649054 2013-04-13 FCC CAB VCCI JAPAN R2133(10m), C2307 2014-06-21 VCCI registration VCCI JAPAN T-2009 2013-12-23 VCCI registration IC CANADA IC5799 2012-05-14 IC filing Ref. No.: LR500111107K Copyright ○ c 2011, LTA Co., Ltd. Page 4 of 22 2. Information’s about test item 2-1 Client & Manufacturer Company name : KUMYOUNG. Co., Ltd. Address : SEOUL_KY Bldg, 40-17 Hangangro, 3-ga, Yongsan-gu Seoul 140-880, Korea Telephone / Facsimile : +82-2-6390-2213 / +82-2-6390-2554 2-2 Equipment Under Test (EUT) Trade name : Wireless Microphone Model name : KHM-500T Serial number : Identical prototype Date of receipt : June 30, 2011 EUT condition : Pre-production, not damaged Antenna type : Wire Antenna(Length : 100mm) Frequency : 603.3MHz, 607.5MHz RF output power : Max. 0.00607W - Radiated Power source : 3.0Vdc from Alkaline battery( AA * 2EA) Low Mid High Frequency (MHz) 603.3 - 607.5 2-4 Test at Extremes of Temperature and Voltage Temperature Test Conditions Voltage Test Conditions T nom Per ambient conditionsV nom 3.0 T cold -30 V min 2.55 T hot +50 V max 3.45 Ref. No.: LR500111107K Copyright ○ c 2011, LTA Co., Ltd. Page 5 of 22 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) 2.1046 / 74.861(e)(1)(ii) RF Output Power 250mW Radiated C 2.1047 / 74.861(e)(3) Modulation Characteristics. – Frequency response - Conducted C 2.1047 Modulation Characteristics. – Modulation Limiting +/- 75kHz C 2.1049 / 74.861(e)(5) Occupied Bandwidth 200kHz C 74.861 Unwanted radiation (spectrum mask) - C 2.1055 / 74.861(e)(4) Frequency Stability 0.005% C 2.1051 / 74.861(e)(6)(iii) Field Strength of Spurious Radiation -13dBm Radiated C 2.1051 / 74.861(e)(6)(iii) Recevier spurious emissions - NA 4 15.207 / 15.107 AC Conducted Emissions EN 55022 Line Conducted NA 3 Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The data in this test report are traceable to the national or international standards. Note3: This device is only operated by DC Note4: This device is only Transmiter Note 1 : The sample was tested according to the following specification: FCC Parts 2, Subpart J and Part 74, Subpart H; ANSI C-63.4-2003 RSS-123 and ISSUE No.: 2 Date: 2011 Ref. No.: LR500111107K Copyright ○ c 2011, LTA Co., Ltd. Page 6 of 22 3.2 Transmitter requirements 3.2.1 Carrier Output Power (Conducted) Definition: - Th…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: ZRU-KHM500 IC: 9774A-KHM500 Copyright ○ c 2011, LTA Co., Ltd. Page 1 of 1 Radiated Emission
