ZRU-KSM100TWIRELESS SUB MIC

1. Basic Items KSM-100/T (solostar duet) 2 x AA Batterys 2. How to operate (1) Additional microphone for the solostar karaoke system (2) Simply plug and play, no additional hardware required (3) Rich stereo sound with TV or external audio system 3. Functions ■ LED ON state : Battery check "OK" Paiting Check "OK" ■ LED Flashing state : Prepared for connection ■ LED OFF state : Power Off ※ Check batteris in case that LED is not lighting when switching on the microphone. ■ Switch functions : ON , MUTE , OFF 4. Specifications GeneralModel No. : KSM-100/T Dimensions : 1.7 (Φ) x 10 (L) Inch Weight : 1.4 lb (without batteries) Modulation Freq. : 2.404 GHz, 2.438 GHz, 2.476 GHz (3 CH), FSK. Wireless Range : 16 ft. - 22 ft. (30 ft. Max.) PowerPower Supply : 3 V (2 x AA Battery 1.5 V) Battery Life : Up to 10 hours Power Consumption : 50 mA (140 mW) KSM-100/T USER Guide FCC notice to users and product statements This device complies with part15 of the FCC Rules. Operation is subject to the following two conditions; (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION : Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, There is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio / TV technician for help. Modifications not expressly approved by the manufacturer could void the user's authority to operated the equipment under FCC rules. This Device has been evaluated to comply with RF exposure requirement for general use limit in portable condition. IC Warning This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 April 26, 2012 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, KUMYOUNG. Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): WIRELESS SUB MIC / KSM-100/T (FCC ID: ZRU-KSM100T) We affirm that between SIEMIC and KUMYOUNG. Co., Ltd., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Young Hwan, Kim / General Manager KUMYOUNG. Co., Ltd. SEOUL_KY Bldg, 40-17 Hangangro, 3-ga, Yongsan-gu, Seoul, Korea 140-880

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 April 26, 2012 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: ZRU-KSM100T We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Circuit Diagram - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Young Hwan, Kim / General Manager KUMYOUNG. Co., Ltd. SEOUL_KY Bldg, 40-17 Hangangro, 3-ga, Yongsan-gu, Seoul, Korea 140-880

Appendix C. External Photographs Report no. ETLE120327.0398, Page C1 of C3 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T Front view of EUT Rear view of EUT Appendix C. External Photographs Report no. ETLE120327.0398, Page C2 of C3 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T Top view of EUT Bottom view of EUT Appendix C. External Photographs Report no. ETLE120327.0398, Page C3 of C3 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T Side view of EUT

Appendix A. FCC ID Label and Location Report no. ETLE120327.0398, Page A1 of A1 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T Product Label Sample with FCC Label information Following is a sample copy of the label that will be placed on the rear cabinet of the product. The FCC ID Label and compliance statement are marked in the product label. The warning statement and Information to the User are described in the user manual. KUMYOUNG. Co., Ltd. WIRELESS SUB MIC FCC ID : ZRU-KSM100T IC : 9774A-KSM100T Model No. : KSM-100/T Serial No. : Proto type Manufacturer: KUMYOUNG. Co., Ltd. Made in Korea Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Label here

Appendix D. Internal Photographs Report no. ETLE120327.0398, Page D1 of D6 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T Inside view of EUT #1 Appendix D. Internal Photographs Report no. ETLE120327.0398, Page D2 of D6 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T Inside view of EUT #1-1 Appendix D. Internal Photographs Report no. ETLE120327.0398, Page D3 of D6 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T Inside view of EUT #1-2 Appendix D. Internal Photographs Report no. ETLE120327.0398, Page D4 of D6 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T Top side view of main board Appendix D. Internal Photographs Report no. ETLE120327.0398, Page D5 of D6 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T Bottom side view of main board Appendix D. Internal Photographs Report no. ETLE120327.0398, Page D6 of D6 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T Top side view of Antenna

Report no. ETLE120327.0398, Page 2 of 26 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC TEST REPORT FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T Table of Contents FCC Measurement Report 1. Introduction 2. Product Information 3. Description of Tests 4. Test Condition 5. Test Results 5.1 Summary of Test Results 5.2 Channel Bandwidth 5.3 Fundamental Radiated Emission 5.4 Harmonic Radiated Emission 5.5 Spurious Emissions 5.6 Restricted Bands of Operation 6. Sample Calculation 7. List of test Equipment used for Measurement Appendix A. FCC ID Label and Location Appendix B. Test Setup Photographs Appendix C. External Photographs Appendix D. Internal Photographs Appendix E. Block Diagram Appendix F. Circuit Diagram Appendix G. User Manual Appendix H. Operational Description Appendix I. Antenna Requirement Report no. ETLE120327.0398, Page 3 of 26 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC TEST REPORT FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T FCC MEASUREMENT REPORT Scope – Measurement and determination of electromagnetic emission (EME) of radio frequency devices including intentional radiators and/or unintentional radiators for compliance with the technical rules and regulations of the U.S Federal Communications Commission(FCC) General Information  EUT Type : WIRELESS SUB MIC  Model Number : KSM-100/T  S/N : Proto type  Freq. Range : 2 404 MHz - 2 476 MHz  Modulation Technique : FSK  Frequency Channel : 2 404 MHz, 2 438 MHz, 2 476 MHz (3 Ch)  Antenna Type : Wire Antenna (Integral)  Antenna Gain : 3.85 dBi max  FCC Rule Part(s) : FCC Part 15 Subpart C RSS-210 Issue 8  Test Procedure : ANSI C63.4-2003  FCC Classification : DXX (Part 15 Low Power Communication Device Transmitter)  IC Equipment Category : RSS-210 Issue 8 - Category I Equipment, Annex 8  Place of Tests : ETL Inc. Testing Lab. Radiated Emission test; #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea Conducted Emission test; ETL Inc. Testing Lab. 371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Applicant Name : KUMYOUNG. Co., Ltd. Address : SEOUL_KY Bldg, 40-17 Hangangro, 3-ga, Yongsan-gu, Seoul, Korea 140-880 Attention : Young Hwan, Kim / General Manager Report no. ETLE120327.0398, Page 4 of 26 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC TEST REPORT FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T 1. INTRODUCTION The measurement test for radiated and conducted emission test was conducted at the ETL Inc. The site is constructed in conformance with the requirements of the ANSI C63.4-2003 and CISPR Publication 16. The ETL has site descriptions on file with the FCC for 3 m and 10 m site configurations. Detailed description of test facility was found to be in compliance with FCC Rules according to the ANSI C63.4-2003 and registered to the Federal Communications Commission (FCC Designation Number : KR0022). The measurement procedure described in American National Standard for Method of Measurement of Radio- Noise Emission from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz (ANSI C63.4-2003) was used in determining radiated and conducted emissions from the KUMYOUNG. Co., Ltd. Model: KSM-100/T Report no. ETLE120327.0398, Page 5 of 26 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC TEST REPORT FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T 2. PRODUCT INFORMATION 2.1 Equipment Description The Equipment Under Test (EUT) is the WIRELESS SUB MIC (model: KSM-100/T). 2.2 General Specification Item Specification Frequency Range 2.404 GHz ~ 2.476 GHz Data Rate 5 Mbps Occupied bandwidth 3.8 MHz Receiver sensitivity -83 dBm Selectivity 38 dB Audio sample rate (48.0 / 44.1 / 40.275 / 32.0) kHz Audio latency 768 ~ 2 048 samples Delay 16 ms (min) Current Consumption 50 mA Max. Crystal 48 MHz Battery 1.5 V x 2 (AA) Battery Life 60 hours Max. (at AA 1.5 V x 2/2 500 mA) Operating Temperature (22.5 ± 62.5) °C Report no. ETLE120327.0398, Page 6 of 26 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC TEST REPORT FCC ID: ZRU-KSM100T IC: 9774 A-KSM100T 3. DESCRIPTION OF TESTS The tests documented in this report were performed in accordance with ANSI C63.4-2003 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, 15.207, 15.209 and 15.249. IC Equipment Category: RSS-210 Issue 8 - Category I Equipment, Annex 8 3.1 Radiated Emission Measurement Radiated emission measurements were made in accordance with § 13 in ANSI C63.4-2003 "Measurement of Intentional radiators” The measurements were performed over the frequency range of 30 MHz to 40 GHz using antenna as the input transducer to a Spectrum analyzer or a Field Intensity Meter. The measurements were made with the detector set for "Peak, Quasi-peak, Average" within a bandwidth of 100 Hz, 9 kHz, 120 kHz and above 1 GHz is 1 MHz. Preliminary measurements were made at 3 m using broadband antennas, and spectrum analyzer to determine the frequency producing the maximum emission in shielded room. Appropriate precaution was taken to ensure that all emission from the EUT were maximized and investigated. The system configuration, mode of operation, turntable azimuth and height with respect to the antenna were noted for each frequency found. The spectrum was scanned from 9 kHz to 30 MHz using Loop antenna and 30 MHz to 1 000 MHz using Log-Bicon antenna. Above 1 GHz, linearly polarized double ridge horn antennas were used. Final measurements were made open site at 3 m. The test equipment was laced on a wooden turn-table. Sufficient time for the EUT, support equipment, and test equipment was allowed in order for them to warm up to their normal operating conditi…
