ZSE-COOBAYHome Network Drive

COOBAY User manual Product instruction With the coming of the family Digital life, home and family are the center of digital photos, video and family members favorite Internet movie and hd movies, music, etc on storage space and convenience requirement is more and more big, the family more than internal digital content consumption source (all kinds of players, terminal) and source (various recording terminal, network), need to be in all sorts of equipment back and forth between, frequent mobile data to the computer hard disk or move hard disk storage and backup for individuals of storage ways, already no longer for a screen family. A new storage concept, "for centralized storage, also share, wireless transmission, simplify the management" become development trend. Coobay Personal Cloud Storage Device is designed for the SOHO and household design entry-level and economical network storage equipment, with more than one server of the function, and have low consumption electricity, high reliability and excellent performance of the system, etc. Carrying Marvell high-performance processor and 512 MB DDRII memory, in contrast to the traditional PC server the high power consumption, and cool the system operation of power consumption is extremely low, users consider environmental protection and energy saving is the first choice of plan. Cool the support of cross-platform work environment, besides backup function besides, with abundant server functions, in addition to general application of the FTP server, file servers, printers outside the server, at the same time is also more multimedia platform terminal video data storage center, as make digital family of good assistant. Built-in UPnP/DLNA media server, can support a series of DLNA multimedia video player, such as: SONY PS3, Microsoft psu on Xbox 360 game console, etc.; Can be compatible with NFS High Definition (High-Definition) multimedia video player do the union, the existence of the video streaming data berry cool to shown on TV High resolution video. In addition, the cool support of the high-speed BT/HTTP download, tie-in PC clients and the download WEB management management tools, more may at any time anywhere the management all download a task. Product use features： 1. Will the media and file storage on his personal cloud Create your own personal cloud, do not need to pay rental, grasps the trace of the data. Will the media and file storage in the hard drive, can safely access them via the Internet. Or in the translation of the computer or on a smartphone, through the mobile application to access them with ease. Mobile equipment is equivalent to get BaiWanZhao bytes extra storage space. 2.Support will content streaming to the hd TV On television daughter's birthday party enjoy video, or displaying the holiday slides. The built-in media server can will music, photos, and movie streaming DLNA ® to any authentication multimedia equipment, such as network media player, Blu-ray Disc ® player, psu on Xbox 360 ™ or PlayStation ® 3 and connection of television, through DLNA 1.5 and UPnP authentication. 3.All the sharing of computer storage device 1 Now the whole family can film, music, photos, and important documents stored in a location for each member of the home sharing. Only need to cool the equipment boot, can use the home any PC or Mac computer storage and access the file. 4.For all the computer provides automatic wireless backup Will all the PC computer wireless network backup to a reliable position, protect precious memory. Windows ® users can use the client software for backup. 5.Speed from bit effect The built-in high-speed CPU, with high performance, for all application with streaming remote access and support. This product USES the Ethernet chip field the most advanced technology, read speed leading products, beyond the traditional USB 2.0 hard drive. 6. Use iTunes music played Support iTunes server function, it can be the music and video collection on stored in together, and then use their iTunes streaming to Mac or PC computer. The character of our 1. IEEE 802.11 n 300 Mbps wireless transmission rate, provide high bandwidth wireless router function. 2.Adaptive 10/100/1000 Mbps network port, speed, not be bit effect. 3. Great capacity data storage center, will the media and file storage on his personal cloud 4. Provide many user management and permission levels function, can be divided for independent users illicit close storage interval, provide high security mechanism. 5. File sharing server functions, all the computer and mobile terminal of the Shared storage devices. Mobile phones, tablet computer, the notebook and desktop computers, TV sets and terminal more real-time sharing platform. 6. The built-in Web management function, provide the management interface Web form and file management. 7. Smart phone data, support the telephone, terminal email backup and restore function. 8. Seamless integration with iTunes, but through the iTunes software visit cool music files of the interior. 9. The built-in network to print the server, can will USB printer connected to the USB Port, through the network to share printers function. 10. Offline BT download function, don't have to open the personal computer, realize the large capacity movies and software download files. 11. The built-in media server, support DLNA compatibility digital multimedia equipment. 12. USB2.0 interface can be through expanded memory capacity, for external USB storage devices provide Internet access functions. 13. Provide high-speed copying function for the external USB storage devices and cool the data exchange offer high speed channel. 14. Support remote access, let you at any time, any place, can use a web browser remote access your files, and away at need to exchange data with very convenient. 2 Specifications: Support standards and protocols IEEE 802.11g、IEEE 802.11b、IEEE 802.11n、IEEE 802.3、IEEE 802.3u 、 IEEE 802.3x 、IEEE 802.1X 、TCP/IP、DHCP 、PPPoE LAN One 10/100…

Text truncated - open the document above for the full version.

Netac Technology Co., Ltd. March 10, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC ID: ZSE-COOBAY To Whom It May Concern: This letter is to ascertain that Netac Technology Co., Ltd. （Product：Home Network Drive Model name: COOBAY TM I）has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature: Client’s name / title: Kevin Liu / Quality System Engineer Contact information / address: 6F, Incubator Building, China Academy of Science & Tech Development, High-Tech Zone, Nanshan, Shenzhen, Guangdong, China

Netac Technology Co., Ltd. March 10, 2012 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ______ Netac Technology Co., Ltd. ___hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Description: Home Network Drive Model name: COOBAY TM I We affirm that between SIEMIC and _ Netac Technology Co., Ltd. __, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Kevin Liu / Quality System Engineer Contact information / address: 6F, Incubator Building, China Academy of Science & Tech Development, High-Tech Zone, Nanshan, Shenzhen, Guangdong, China

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 2.0 Netac Technology Co., Ltd. March 10, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: ZSE-COOBAY We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Kevin Liu / Quality System Engineer Contact information / address: 6F, Incubator Building, China Academy of Science & Tech Development, High-Tech Zone, Nanshan, Shenzhen, Guangdong, China

FCC Certification label Sample FCC ID: ZSE-COOBAY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired o peration.

FCC Certification label location Sample Label location

Antenna

1. RF EXPOSURE 1.1. The Requirement System operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See Section 15.247(b)(4) and Section 1.1307(b)(1) 1.2. Limit For Maximum Permissible Exposure (MPE) Limits for General Population/ Uncontrolled Exposure F = frequency in MHz, * Plane-wave equivalent power density 1.3. MPE Calculations E(V/m) = 30 P G d  , Power Density: S( 2 mW/cm) = 2 377 E Where E = Electric Field (V/m) P = Peak Output Power (mW) G = Antenna Numeric Gain (numeric) = 10 x , x = Antenna Gain(dBi) /10 d = Separation Distance (cm) Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) ( 2 mW/cm) Averaging Time 2 E, 2 H or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 f/1500 30 1500-100,000 1.0 30 We can change the formula to: S = 2 30 377 PG d   or, d = 30 377 PG S   Because the EUT is belong to general population/uncontrolled exposure. So 1.3.1. We considering the limit of minimum separation distance (d) is 20cm, Maximum Output Power = 53.95mW Antenna Gain = 2.5(dBi) = 1.78(numeric) S = 2 30 377 PG d   = 0.019 2 mW/cm < 1.0 2 mW/cm (limit) Calculated RF Exposure power density is 0.019 2 mW/cm , less than the limit. 1.3.2. We considering the limit of power density (S) is 1.0 2 mW/cm , Maximum Output Power = 53.95mW Antenna Gain = 2.5(dBi) = 1.78(numeric) d = 30 377 PG S   = 2.76cm < 20 cm Calculated RF Exposure separation distance is 2.76 cm, less than the minimum separation distance 1.3.3.FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna shall not be less than 20cm(8 inches) during normal operation. Proposed RF exposure safety information to include in User’s Manual.
