ZSW-10-032Mobile Phone

User Manual 1. Preface Follow all safety warnings to avoid injury or property damage. Important Security Information 1. Risk of explosion if battery is replaced by an incorrect type. 2.Prohibited putting the battery into the fire,or otherwise the battery will explode. 3.Please use the adapter and the battery dedicated to or authorized for the phone 4.The device complies with RF specifications when the device used at 5mm from your your body. 5.Adapter:The plug considered as disconnect device of adapter Input: AC 100-240V, 50/ 60Hz, 0.2A,Output: 5V 500mA 6. Adapter shall be installed near the equipment and shall be easily accessible. 7. EUT Operating temperature range: -10° C to 40° C Kgtel hereby declares that this GSM Mobile Phone is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. This product is allowed to be used in all EU member states. 2.Introduction Key Function Call Key Make or answer a call to Sim1 & Sim2 View Calls Logs in standby mode. End/Power Key Pressing and holding to turn the phone on/off. End a call or reject an incoming call. Return to the idle mode. Left Soft Key Menu key and OK key for functions Right Soft Key Access the Name list in idle mode. Return to the previous menu. OK Key Press to enter main menu in idle mode. After inputting numbers, press this key to do options. Numeric key Enter numbers, letters or characters. Select a submenu item labeled with the corresponding number. In idle mode, press and hold 0 key to turn on/off power bank function. * Press to toggle between *, +, (pause character) P, and (wait character) W. Press to enter symbol when editing text. # Press to switch input modes when entering text. Press and hold to change sound profiles to Silent Mode and General mode. 3. Getting Started 3.1 Turning the phone on To turn the phone on, press and hold the Power key. If you have already enabled the Sim Lock function then enter the PIN code (the 4 to 8 digit secret code of your SIM card). It is preconfigured and provided to you by your network operator or retailer. If you enter an incorrect PIN code 3 times in succession, your SIM card will be locked. To unlock it, you must obtain the PUK code from your network operator. 3.2 Charging the Battery Ensure the battery is inserted in the handset. The battery symbol indicates the charging status. While charging, the charge indicators will scroll. When all the scroll bars are steady, the battery is fully charged. It takes about 4 hours to fully charge the battery. 3.3 Important Password Phone lock password is 1234. 3.4 Keypad Lock and Unlock Go to Settings>Security Setting>Auto Keypad Lock to select the time for keypad lock. In standby interface, if the time expires, the keypad will be locked automatically. Lock: press LSK then * key in standby interface. Unlock:press LSK and then press * key in standby interface. 3.5 Making an International Call  Press the ‘*’ Key twice until "+" appears on the screen.  Enter the country code.  Enter the area code (normally without the 0 before it) followed by the phone number.  Press the Dial Key to call the number 4.Safety Information and Notices Before using the phone, please read the safety precautions carefully and let your children know these, so that you can use your phone correctly and safely. Do not switch on your phone when phone use is prohibited or when phone use may cause interference or danger. Do not use your phone while driving. Follow the rules or regulations in hospitals and health care facilities. Switch off your phone near medical equipments Switch off your phone in an aircraft. The phone may cause interference to control signals of the aircraft. Switch off your phone near high-precision electronic devices. The phone may affect the performance of these devices. Do not attempt to disassemble your phone or its accessories. Only qualified personnel are allowed to service or repair the phone. Do not place your phone or its accessories in containers with strong electromagnetic field. Do not place magnetic storage media near your phone. Radiation from the phone may delete the information stored on them. Do not put your phone in a high-temperature place or use it in a place with flammable gas such as a gas station. Keep your phone and its accessories away from children. Do not allow children to use your phone without guidance. Use approved batteries and chargers only to avoid explosion. FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. SAR Information Statement Your wireless phone …

Text truncated - open the document above for the full version.

b mobile HK Limited DATE:2020-9-21 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent On our behalf, I appoint Shenzhen Zhongjian Nanfang Testing Co.,Ltd.; 1st Floor, Block No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China；Bruce.Zhang, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with b mobile HK Limited Flat 18; 14/F Block 1; Golden Industrial Building;16-26 Kwai Tak Street; Kwai Chung; New Territories; Hong Kong Dated this 2020-9-21 By: KA SHING LAM Signature Printed Title: Manager On behalf of : b mobile HK Limited Telephone: 852-2728 7886

b mobile HK Limited DATE :2020-9-21 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: ZSW-10-032 Product Name: Mobile Phone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description  BOM  Tune up These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2020-9-21 By: KA SHING LAM Signature Printed Title: Manager On behalf of : b mobile HK Limited Telephone: 852-2728 7886
