ZSW-10-045Mobile Phone

Bmobile C41 USER MANUAL 1 Phone Layout 1 Left soft key 9 Receiver 2 Navigation key 10 Camera 3 Dial/Answer key 11 Flash light 4 Right soft key 12 Earphone connector 5 Center key 13 SOS key 6 End key 14 Speaker 7 Keypad 15 USB connector 8 LCD Display Bmobile C41 USER MANUAL 2 Insert SIM card 1. Power off the phone and remove other external power. 2. Take off the back cover and remove the battery of the phone. 3. Insert SIM card into the SIM card slot in the phone. Remove and Install the battery The attached Li-ion battery along with the phone can be used after unpacking. For the first three times, please use up the power and charger it fully for new battery to perform well. Install the battery 1. Put the battery in the battery compartment, note that the metal end of the battery should be firstly inserted. 2. Put on the back cover. Remove the Battery 1. Take off the back cover. 2. Put finger on the side finger grip, and then lift up the battery from the finger grip to remove the battery. Bmobile C41 USER MANUAL 3 Charging the battery Unplug the charger from the outlet and the phone when not in use. Do not leave a fully-charged handset connected to a charger because overcharging may shorten the lifetime of the battery. If unused, a fully charged battery will lose its charge over time. If the battery is completely discharged, the charging may not start immediately when you plug in the connector. Wait 10 to 15 minutes for the phone to begin charging Use the battery only for its intended purpose. Never use any charger or battery that is damaged. Use only Bmobile Charger & Battery. Note: The actual operation time of a battery varies based on the operation mode, network strength in different places and talk time. Audio player The songs you store in the memory card will appear in the audio player. Please check if you have stored the songs in “My Music” folder. You should also check whether default storage is memory card. Bmobile C41 USER MANUAL 4 Battery Saver For your battery long standby, you can enter menu-Battery Saver to enable the battery saver mode, this will make phone’s ringtone volume and brightness low and torch will be off. How to control volume When you call any number, music or watch the video you can control volume,press the up & down navigation key to adjust volume. Restore factory settings Reset the phone to default values (factory settings). The phone password is required, which is “1234” by default. Security settings When enter the security settings, you can set the phone lock function. The default passcode is “1234”, you also can change the passcode by yourself. When set the phone lock on, restart the phone. This work. You have 3 chances to input the passcode. If chances finished, the phone will power off. Bmobile C41 USER MANUAL 5 Privacy The Contacts/Call logs/Message/File manager/Camera/My files/Calendar/U Disk/Audio player/Video player, Set to open, every time need to enter the password into the corresponding function. to enter the main menu interface is set menu to input security code to enter. Services To access this menu, enter the Main Menu in the standby mode and then select Internet. You can use the network- Related services with this function. 15.19 Labeling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and(2) this device must accept any interference received, including interference that may cause undesired operation. 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Absorption Rate (SAR) information: This mobile phone meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. This device was tested for typical body-worn operations with the back of the handset kept 1.0cm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 1.0cm separation distance between the user's body and the back of the handset. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation dista…

Text truncated - open the document above for the full version.

b mobile HK Limited 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – EquipmentType Company name: b mobile HK Limited Address: Flat 18; 14/F Block 1; Golden Industrial Building;16-26 Kwai Tak Street; Kwai Chung; New Territories; Hong Kong, China Product Name: Mobile Phone FCC ID: ZSW-10-045 Model(s): C41 2.911(d)(5)(i) EquipmentType We, [b mobile HK Limited] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Carlos Lopez Date: 3/29/2023 Title and Company name: Manager / b mobile HK Limited NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

b mobile HK Limited 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: b mobile HK Limited Address: Flat 18; 14/F Block 1; Golden Industrial Building;16-26 Kwai Tak Street; Kwai Chung; New Territories; Hong Kong, China Product Name: Mobile Phone FCC ID: ZSW-10-045 Model(s): C41 2.911(d)(5)(ii) Applicant filing We, [b mobile HK Limited] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 ,established pursuant to §1.50002 of this chapter,as an entity producing coveredcommunications equipment. Yours sincerely, Name: Carlos Lopez Date: 3/29/2023 Title and Company name: Manager / b mobile HK Limited NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

THREE STONES MEDIA LLC U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: 03-29-2023 Ref: Attestation Statement – Part2.911(d)(7) filing FCC ID:ZSW-10-045 b mobile HK Limited (“the applicant”) certifies that, as of the date of the filing of the application, THREE STONES MEDIA LLC(“the agent”) is our designated U.S. agent for service of process for the abovereference FCC ID. The applicant accepts to maintain an agent for service of process in the United States forno less than one year after either the grantee has permanently terminated all marketing and importation of theapplicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicialproceeding involving the equipment, whichever is later. The applicant further acknowledges it is ourresponsibility to inform the FCC whenever the agent information changes. THREE STONES MEDIA LLC ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: THREE STONES MEDIA LLC FRN: 0033401761 GC: 2A99E Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Signature: Contact Person: Sijie Zhang Tel: +1 267 909 3692 Email: [email protected] Applicant Company Name: b mobile HK Limited Address: Flat 18; 14/F Block 1; Golden Industrial Building;16-26 Kwai Tak Street; Kwai Chung; New Territories; Hong Kong, China Signature: Contact Person: Carlos Lopez Tel:852-2728 7886 Email: [email protected]

b mobile HK Limited Agent Authorization Letter (2023-03-29) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park Sanwei, Xixiang, Bao'an District, Shenzhen, Guangdong, China Alex.li [email protected] to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Carlos Lopez / Manager Date/City: 2023-03-29 / HONG KONG Phone: 852-2728 7886 Fax: 852-2728 0468 E-mail: [email protected]

b mobile HK Limited Long Term Confidentiality Request Letter (2023-03-29) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Product: Mobile Phone Model No.: C41 FCC ID: ZSW-10-045 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the  Schematic Diagram  Block Diagram  Operational Description  Part List / BOM List / PCB Layout  Tune-up Procedure Required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Please contact me if there is any information you may need. Sincerely, Carlos Lopez / Manager Date/City: 2023-03-29 / HONG KONG Phone: 852-2728 7886 Fax: 852-2728 0468 E-mail: [email protected]

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 BT ANT Photo 11 Photo 12 Photo 13 GSM/WCDMA/LTE Ant

Report No.: S22120507102001 Version.1.2 Page 1 of 19 FCC Test Report FCC ID: ZSW-10-045 Product: Mobile Phone Trade Mark: Bmobile Model Number: C41 Family Model: N/A Report No.: S22120507102001 Prepared for b mobile HK Limited Flat 18; 14/F Block 1; Golden Industrial Building;16-26 Kwai Tak Street; Kwai Chung; New Territories; Hong Kong, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website:http://www.ntek.org.cn Report No.: S22120507102001 Version.1.2 Page 2 of 19 TEST RESULT CERTIFICATION Applicant’s name.................. : b mobile HK Limited Address .................................. : Flat 18; 14/F Block 1; Golden Industrial Building;16-26 Kwai Tak Street; Kwai Chung; New Territories; Hong Kong, China Manufacturer's Name ........... : b mobile HK Limited Address .................................. : Flat 18; 14/F Block 1; Golden Industrial Building;16-26 Kwai Tak Street; Kwai Chung; New Territories; Hong Kong, China Product description Test Sample Number .............. : S221205071002 Product name ......................... : Mobile Phone Model and/or type reference : C41 Family Model .......................... : N/A Standards .............................. : FCC Part15B ANSI C63.4:2014 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with Part 15 of FCC Rules. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : 07 Dec. 2022 ~ 10 Jan, 2023 Date of Issue .......................................... : 11 Jan, 2023 Test Result .............................................. : Pass Testing Engineer : (Allen Liu) Authorized Signatory : (Alex Li) Report No.: S22120507102001 Version.1.2 Page 3 of 19 Table of Contents Page 1 . TEST SUMMARY 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST SETUP 8 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 9 2.4 MEASUREMENT INSTRUMENTS LIST 10 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION 11 3.1.2 TEST PROCEDURE 12 3.1.3 TEST SETUP 12 3.1.4 EUT OPERATING CONDITIONS 12 3.1.5 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 15 3.2.2 TEST PROCEDURE 15 3.2.3 TEST SETUP 16 3.2.4 TEST RESULTS 17 3.2.5 TEST RESULTS(1000~18000MHz) 19 Report No.: S22120507102001 Version.1.2 Page 4 of 19 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item Limit Judgment Remark FCC Part15B ANSI C63.4: 2014 Conducted Emission Class B PASS Radiated Emission Class B PASS NOTE: (1) ’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Report No.: S22120507102001 Version.1.2 Page 5 of 19 1.1 TEST FACILITY Shenzhen NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. IC-Registration The Certificate Registration Number is 9270A. CAB identifier:CN0074 FCC- Accredited Test Firm Registration Number: 463705. Designation Number: CN1184 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKC01 ANSI 150 KHz ~ 30MHz ±2.80dB B. Radiated Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKA01 ANSI 30MHz~1000MHz ±2.64dB 1GHz~6GHz ±2.40dB 6GHz~26.5GHz ±2.52dB Report No.: S22120507102001 Version.1.2 Page 6 of 19 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Mobile Phone Trade Mark Bmobile Model Name C41 Family Model N/A Model Difference N/A Product Description Connecting I/O port: Micro USB, Earphone Operation Frequency: 2.4GHz Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Adapter INPUT: AC 100-240V~50-60Hz 0.15A OUTPUT: DC 5.0V550mA Battery DC 3.8V/1400mAh Power supply DC 3.8V from battery or DC 5V from Adapter. HW Version C41_HW_V1.0 SW Version Bmobile_C41_TEM_MX_V001 Report No.: S22120507102001 Version.1.2 Page 7 of 19 2.1.1 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 USB Data Transmission Mode 2 TF card Playing Mode 3 REC Mode 4 FM Mode 5 GPS For Conducted Test Final Test Mode Description Mode 1 USB Data Transmission Mode 2 TF card Playing Mode 3 REC Mode 4 FM Mode 5 GPS For Radiated Test Final Test Mode Description Mode 1 USB Data Transmission Mode 2 TF card Playing Mode 3 REC Mode 4 FM Mode 5 GPS Note: Final Test Mode: Through Pre-scan, find the mode 1 is the worst case. Only the worst case mode is recorded in the report. Report No.: S22120507102001 Version.1.2 Page 8 of 19 2.2 DESCRIPTION OF TEST SETUP CE RE 0.8m 1.5m EUT C-4 AE-1 PC C-1 AE-4 Monitor C-3 AE-3 Mouse C…

Text truncated - open the document above for the full version.

Radiated Measurement Photos AC Conducted Measurement Photos
