ZSW-K340Feature Phone

K340 User Guide Dear customer, Thank you for choosing this mobile phone. This mobile phone incorporates the latest world advanced functions, enabling simple and convenient operation, satisfying your special requirements. The mobile phone supports T-FLASH (memory) card and Dual SIM standby. It integrates the following available functions: SMS, MP3, MP4, Camera, FM radio, Alarm, sound recorder and Calendar, enabling you arranging your work, study and life freely; with long standby duration, as well as calculator, your communication will be easier and smoother; powerful File manager allows you managing the files conveniently. In addition, the chord ringtone allows you selecting music to set as ringtone; the personalized appearance also can satisfy your selection. Note: User’s Manual is just to guide the user about the functionality of the phone. Some functions may vary due to modifications and upgrades of software or due to print mistake. - 1 - 1. SAFETY TIPS  Use of wireless hands-free system (headphone, headset) with a low power Bluetooth emitter.  Keep your calls short or send a text message (SMS) (instead. This advice applies especially to children, adolescents and pregnant women.  Use cell phone when the signal quality is good.  People having active medical implants should preferably keep the cell phone at least 15 cm away from the implant. - 2 - 2. Menu guide Phonebook Contacts saved in the mobile phone contain the following information: the telephone name and number. You can add new contacts to phone or SIM1/SIM2.  You can perform the following operations in this mode: View: View detailed information of the contact. Send text message: Send a message from SIM1/SIM2. Call: Make a call from SIM1/SIM2. Edit: Edit name and number of the contact. Delete: Delete the contact. Copy: Copy the contact to phone or SIM1/SIM2. Move: Move the contact to phone or SIM1/SIM2. Add to blacklist: Add the contact to block list. Add to SMS blacklist: Add the contact to SMS block list. Mark several: Mark several or mark all to send messages or delete. Groups: Add new group or edit existed groups. Phonebook settings: You can perform the following operations in this mode.  Preferred storage: Add a new contact to the SIM1/SIM2, Phone or All. - 3 -  Speed dial: Set on/off, you can edit and alter speed dial list.  My number: To set owner number.  Extra numbers: To set owner numbers and Fixed dial of SIM1/SIM2.  Memory status: To check phonebook memory status of SIM1/SIM2 and phone.  Copy contacts: To copy contacts from SIM1/SIM2 and phone to other paths respectively.  Move contacts: To copy contacts from SIM1/SIM2 and phone to other paths respectively.  Delete all contacts: Delete all contacts from SIM1/SIM2 and phone.  Enter the Contacts interface to perform the following operations: Quick search: In the input area where the cursor locates, enter the first letter to locate the first qualified entry in the contacts list. For example, to search for “Lisa”, enter letter “L”. Search name: Enter the desired name, and search the matched entry in the Contacts. - 4 - Messages Enter this menu, you can view: Write message, Inbox, Drafts, Outbox, Sent messages, Broadcast messages and SMS settings. Write message You can enter this function menu to write short messages.  Short message is a network service. To send or receive short messages, you may need to subscribe for this service from your network operator. The short messages are sent to the message center and then to the recipients (GSM subscribers). The short messages are saved in the network if the mobile phone of recipient isn’t switched on or can’t receive short messages (memory is full). The validity depends on user’s settings and network operator. With SMS, you can send and receive chain text messages, which may affect the charge of messaging. Please contact your network operator for details.  Each message may contain 160 characters. While editing the message, select the “Input method” option.  Press # key to switch the input method.  Press the right soft key to delete one character before the cursor, or hold right soft key long to clear all characters; press the End key to return to standby - 5 - mode; When writing messages, you can insert number and name in editing message.  When the editing message is finished, you can press direction up/down key to option: enter recipient or select contacts from phonebook or call history to send.  This mobile phone supports group messages with more than 600 characters each (the characters limit of common text message). If the message contains more than limited characters, the phone sends it in two or more messages.  If the memory is full, an icon will flash in the top line of the screen; since the mobile phone supports dual SIM cards, the messages are saved in SIM1 and SIM2 separately, and the prompts appear separately. To receive new messages normally, delete the short messages in corresponding SIM cards. If the recipient has received the message, the mobile phone sends an alert tone of message report (report is enabled) Note: When you send message via SMS service, the mobile phone may display “Sent”. It indicates that the message has been sent to the SMS center. But it doesn’t mean that the recipient has received the message. Contact your network operator for more information. Inbox - 6 - You can read the received short messages in the Inbox, including SIM1 messages and SIM2 messages. Press left soft key of options in messages list interface, you can perform the following operations: View: View the info of the message. Reply: Reply in text message by SIM1 or SIM2. Call sender: Call the sender by SIM1 or SIM2. Forward: Forward the message to another contact by SIM1 or SIM2. Delete: Delete the message. Delete same number: Delete same number the massage. Delete all: Delete all the messages in the Inbox of corresponding SIM cards; if SIM1 is selected. Save to Phonebook: You can save this sender to SIM1,SIM2 …
