INSIGNIA ™ USER MANUAL EXQUISITE DESIGN / INTIMATE LUXURY ENGLISH • 3 OVERVIEW Congratulations on purchasing one of the most advanced personal massagers ever made. As part of LELO’s landmark Insignia ™ line, Lyla ™ , Oden ™ and Tiani ™ , come with the same gorgeous, waterproof, and body-safe design aesthetic alongside revolutionary SenseMotion ™ Technology never before seen in products of this kind. SenseMotion ™ allows your Pleasure Object to respond to yours or your partner’s movements when holding the controller in the palm of your hand. More than this the controller can also act as an independent personal massager by delivering sensations of its own from the motor housed within, while allowing you to feel what a partner is experiencing. NOTE: Your Insignia ™ Pleasure Object may require charging upon purchase. To charge your Pleasure Object, please refer to the Charging section of this manual (pg. 16). You will also need to insert 2 x AAA batteries in your controller and establish the wireless connection with the massager before use. The shiny ABS face of your Insignia ™ wireless controller can be removed to expose the battery compartment. With the plastic key included with your Insignia ™ inserted into the slot on the battery compartment cover, do a 10 degree twist counterclockwise and remove the lid from the controller. After the batteries are inserted put the cover back in place and use the key to do another 10 degree twist clockwise. Always ensure the controller is fastened shut before using in water. INSERTING BATTERY IN CONTROLLER 2 • ENGLISH Open Close ESTABLISHING WIRELESS CONNECTION To establish wireless connection, you must first turn on your wireless controller by pressing the + button once. Your wireless controller is now active and sending a signal. Your Lyla ™ , Oden ™ or Tiani ™ also features an activation button, marked with a wireless symbol . Once your Pleasure Object is fully charged, press and hold this button for 1 second to activate your Pleasure Object and initiate its ‘seek’ mode, allowing it to connect with your wireless controller. It may take up to 10 seconds for your product to detect the controller, so please be patient. The white LED indicator on your Pleasure Object will flash every 2 seconds to indicate that it is functioning and receiving a signal from the wireless controller. ODEN ™ ENGLISH • 54 • ENGLISH Pleasure Point Turn On / Seek Base Attachment (turn counterclockwise to reveal DC port) Flexible Wearable Portion LYL A ™ TIANI ™ ENGLISH • 76 • ENGLISH Pleasure Point Pleasure Point Turn On / Seek Turn On / Seek Flexible Inserting Arm Base Attachment (turn counterclockwise to reveal DC port) Retraction Leash Base Attachment (turn counterclockwise to reveal DC port) USING SENSEMOTION ™ MODES Your Insignia ™ Pleasure Object features 2 SenseMotion ™ modes which respond to different movements. MODE 1 When your Pleasure Object and wireless controller are connected, hold the controller flat in the palm of your hand. A low vibration will come from your Lyla ™ , Oden ™ or Tiani ™ . By tilting the controller at an angle, you will feel the vibration intensity increase in both the massager and controller. Moving the controller from a horizontal position to a vertical position will increase vibration strength up to 100%. You can then tilt the controller back and forth as you please to change the vibration settings, creating your own patterns and finding the level that is right for yourself and/or your partner. When you wish to use the second SenseMotion ™ mode press the center button once. USING SENSEMOTION ™ MODE 1 ENGLISH • 98 • ENGLISH 10% Intensity 100% Intensity USING CONTROL INTERFACE (MODES 3-8) After activating and connecting your Pleasure Object to its wireless controller, you can proceed to standard remote control by pressing the center button twice. When not in SenseMotion ™ modes, using the control interface is as follows: • Pressing the + button will increase the vibration intensity of your Pleasure Object. • While your control interface is active, press the center button to cycle through the 8 stimulation modes, including both SenseMotion ™ control modes. • Pressing the – button will decrease vibration intensity. Continue holding the – button to turn off your wireless controller. You can then turn off your Pleasure Object by holding the . button for 1 second. When not receiving a signal from an active wireless controller, your Pleasure Object will go into standby for 1 hour before deactivating. NOTE: When using standard controls (modes 3-8), the motor inside your wireless controller can be turned off by pressing and holding the button for 3 seconds. Repeat this process to reactivate the motor in the controller. When using standard controls (modes 3-8), the LED on your wireless controller will not be illuminated. 10 • ENGLISH MODE 2 This mode gives you more freedom to explore – try moving the controller in circular motions or any way you choose. The faster you move the controller, the stronger the vibration intensity. Explore your options as the controller and Pleasure Object respond to your movements. To exit the SenseMotion ™ modes press the center button once more. NOTE: When using SenseMotion ™ (modes 1-2), the LED on your wireless controller will be illuminated. ENGLISH • 11 USING YOUR ODEN ™ Oden ™ is like no other couples’ ring in the world today, with a unique form that is easier to put on and remove compared to standard ring designs. While worn, Oden ™ transfers vibrations to both partners. HOW TO WEAR: With penis already erect, hold Oden ™ ’s curved base attachment between your thumb and forefinger and open the curved base to a suitable width. This can then be slipped around the penis with the flattened side of Oden ™ ’s pleasure point facing your abdomen and pointing upwards towards the navel. TIPS: Oden ™ is often most enjoyable with the vibrating pleasure point worn upwards to stimulate the clitoris when the woman is on top. USING YOUR…

Text truncated - open the document above for the full version.

Authority to Act as Agent Date: 2013-9-9_ ______ American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: _Eddy Zong from SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd _______ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) , to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: 2014-9-8_____(Typically 8 – 12 months)_____ By: ___ _Michael Duff_________ (Signature 1 ) (Print name) Title: Director Engineering On behalf of: SUZHOU ARMOCON TECHNOLOGY CO., LTD (Company Name) 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD Request for Confidentiality Date: 2013-9-9 _ Subject: Confidentiality Request for: _FCC ID:ZT5-ARM215021______ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ Suzhou Armocon Technology Co.,Ltd. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Operation Support Manager _Michael Duff_____ __ (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1308001631RF －Appendix A Page: 1 of 4 Page 1 of 4 External Photos Application No.: SHEM1308001631HS Applicant: Suzhou Armocon Technology Co.,Ltd. Address of Applicant: 3-5/F No77 SuHong Middle Road SIP Jiangsu China Equipment Under Test (EUT): Product Name: TX: Remoto Controller RX: Massager Brand Name: LELO Model No.: TX: LELO Insigia-V3 RX: IDA, Lyla, Oden,Tiani FCC ID: ZT5-ARM215021 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1308001631RF －Appendix A Page: 2 of 4 Page 2 of 4 1 Contents Page 1 CONTENTS.......................................................................................................... 2 2 EXTERNAL PHOTOS ........................................................................................ 3 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1308001631RF －Appendix A Page: 3 of 4 Page 3 of 4 2 External Photos SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1308001631RF －Appendix A Page: 4 of 4 Page 4 of 4 End

SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1308001631RF －Appendix B Page: 1 of 4 Page 1 of 4 Internal Photos Application No.: SHEM1308001631HS Applicant: Suzhou Armocon Technology Co.,Ltd. Address of Applicant: 3-5/F No77 SuHong Middle Road SIP Jiangsu China Equipment Under Test (EUT): Product Name: TX: Remoto Controller RX: Massager Brand Name: LELO Model No.: TX: LELO Insigia-V3 RX: IDA, Lyla, Oden,Tiani FCC ID: ZT5-ARM215021 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1308001631RF －Appendix B Page: 2 of 4 Page 2 of 4 1 Contents Page 1 CONTENTS.......................................................................................................... 2 2 INTERNAL PHOTOS ......................................................................................... 3 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1308001631RF －Appendix B Page: 3 of 4 Page 3 of 4 2 Internal Photos SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1308001631RF －Appendix B Page: 4 of 4 Page 4 of 4 E EE En nn nd dd d

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 588 West Jindu Road,Songjiang District,Shanghai,China Telephone: +86 (0) 21 6191 5666 Fax: +86 (0) 21 6191 5678 [email protected] Report No.: SHEM130800163101 Page 1 of 22 Tony Wu E&E Section Manager SGS-CSTC (Shanghai) Co., Ltd. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only 1 Cover Page TEST REPORT Application No. : SHEM1308001631HS Applicant: Suzhou Armocon Technology Co.,Ltd. FCC ID: ZT5-ARM215021 Equipment Under Test (EUT): NOTE: The following sample(s) submitted was/were identified on behalf of the client as Product Name: TX: Remoto Controller RX: Massager Brand Name: LELO Model: TX: LELO Insigia-V3 RX: IDA, Lyla, Oden,Tiani Standards: FCC PART 15 Subpart C Section 15.249: 2012 ANSI C63.10: 2009 Date of Receipt: August 22, 2013 Date of Test: September 17, 2013 Date of Issue: September 22, 2013 Test Result : PASS * . * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM130800163101 Page: 2 of 22 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Version Revision Record Version Chapter Date Modifier Remark 00 / September 22, 2013 / Original Authorized for issue by: Engineer Eddy Zong Print Name Clerk Susie Liu Print Name Reviewer Keny Xu Print Name SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM130800163101 Page: 3 of 22 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 3 Test Summary Test Item FCC Requirement IC Requirement Test method Result Antenna Requirement Section 15.203 RSS-Gen 7.1.2 ANSI C63.10 (2009) PASS AC Power Line Conducted Emission Section 15.207 RSS-Gen Section 7.2.4 ANSI C63.10 (2009) N/A Field Strength of the Fundamental Signal Section 15.249 (a) RSS 210 A 2.9 （a） ANSI C63.10 (2009) PASS Spurious Emissions Section 15.249 (a)/15.209 R…
