TBM-CBC5 DATA SHEET Monday, 29 September 2014 Version 1.1 Datasheet by Peter.huang TONLY 1 Correct 8DQPSK to 8DPSK2014291 21 10 Revision History Date Version Description Author 2013--V1.0 n First Release -09- V1. n 2 TBM–CBC5 Bluetooth Audio Module DESCRIPTION: TBM–CBC5 is first generation of TCL Bluetooth modules.It provides highest level of integration with integrated 2.4GHz radio, DSP, battery charger, stereo codec mono and , stereo audio applications.TBM–CBC5 is also ready to support the lates Bluetooth 3.0 standard The embedded DSP core allows enhancement of the product with features such as advanced audio decoding (MP3, AAC, AAC+), echo cancellation, noise reduction, and data manipulation. TCL’s TONLY flexible firmware enables device manufacturers to easily add wireless, secure, and standard - based Bluetooth connectivity into new or existing applications with very limited development and manufacturing effort. APPLICATIONS: • High quality wireless stereo headsets • Wireless mono headsets • Wireless speakers • USB multimedia dongles • MP3 players • VoIP handsets • Hands-free car kits FEATURES : • TBM–CBC5 Bluetooth module Solution For mono and Stereo Audio Solutions • Integrated DSP, Stereo Codec, and Battery Charger • Bluetooth 3.0 + EDR Compliant • Class 2 - Range up to 30 Meters • Temperature range from -30C to +85C • Low Power Consumption • TCL TONLY Firmware for Controlling Connections and Configuring Settings • Supported Bluetooth Profiles: A2DP, AVRCP, HFP, HFP-AG, SPP, OPP, FTP, HSP, DUN, PBAP and HID ect... Size: 13.5*21 mm 40-BTP518HFD4G 3 2 Block Diagram and Descriptions RAM Baseband DSP MCU KalimbaDSP 2.4 GHz Radio I/O BC05-MM XTAL Flash UART/USB PIO Audio In/Out PCM/I 2 S/SPDIF SPI Reset circuitry Figure 1: Block diagram of TBM–CBC5 BC05-MM The BlueCore05-MM is a single-chip radio and baseband IC for Bluetooth 2.4GHz systems. It provides a fully compliant Bluetooth system to v3.0+EDR of the specification for data and voice. BlueCore05-MM contains the Kalimba DSP co-processor with double the MIPS of BlueCore03-MM, supporting enhanced audio applications. BlueCore05-MM integrates a 16-bit stereo codec and it has a fully differential audio interface with a low noise microphone bias. Crystal The crystal oscillates at 26MHz. Flash Flash memory is used for storing the Bluetooth protocol stack and Virtual Machine applications. It can also be used as an optional external RAM for memory-intensive applications. Balanced Filter Combined balun and filter changes the balanced input/output signal of the module to unbalanced signal of the antenna. The filter is a band pass filter (ISM band). Antenna TBM–CBC5 uses ceramic chip anten na with high dielectric constant, which makes the antenna very insensitive to surrounding environment and thus gives high design freedom around the antenna. USB The USB interface is a full speed Universal Serial Bus (USB) interface for communicating with other compatible digital devices.TBM–CBC5 acts as a USB peripheral, responding to requests from a Master host controller such as a Personal Computer (PC). 4 Synchronous Serial Interface This interface is a synchronous serial port interface (SPI) for interfacing with other digital devices. The SPI port can be used for system debugging. It can also be used for programming the Flash memory. UART This interface is a standard Universal Asynchronous Receiver Transmitter (UART) interface for communicating with other serial devices. PCM / I 2 S / SPDIF Interface This interface is a bi-directional serial programmable audio interface supporting PCM, I2S and SPDIF formats. Audio Interface The audio interface of TBM–CBC5 has fully differential inputs and outputs and a microphone bi as output. A high-quality stereo audio Bluetooth application can be implemented with minimum amount of external components. Programmable I/O BTP518B has a total of 10 digital programmable I/O terminals. These are controlled by the firmware running on the device. Reset TBM–CBC5 has a reset circuitry that is used to reset the module in the startup to ensure proper operation of the flash memory. Alternatively, the reset can be externally driven by using a TBM–CBC5 reset pin. 802.11 Coexistence Interface Dedicated hardware is provided to implement a variety of coexistence schemes. Channel skipping AFH (Adaptive Frequency Hopping), priority signaling, channel signaling, and host passing of channel instructions are all supported. The features are configured in firmware. Since the details of some methods are proprietary (e.g. Intel WCS) 5 3 Electrical Characteristics Absolute maximum ratings Min Max Unit Storage temperature -40 85 °C Operating temperature -30 85 °C VDD_IO -0.4 3.6 V VDD_BAT -0.4 4.4 V VDD_CHG -0.4 6.5 V Terminal voltages -0.4 Vdd + 0,4 V The module should not continuously run under these conditions. Exposure to absolute maximum rating conditions for extended periods of time may affect reliability and cause permanent damage to the device. Table 1: Absolute maximum ratings Recommended operating conditions Min Max Unit Operating temperature -40 85 °C VDD_IO 1.7 3.6 V VDD_BAT 2.5 4.4 V VDD_CHG 0 6.5 V Terminal voltages 0 VDD V Table 2: Recommended operating conditions 6 Terminal characteristics Min Typ Max Unit I/O voltage levels V IL input logic level low -0.4 - 0.25xVDD V V IH input logic level high 0.625xVDD - Vdd + 0.3 V V OL output logic level low 0 - 0.125 V V OH output logic level high 0.75xVDD - VDD V Reset terminal V TH,res threshold voltage 0.64 0.85 1.5 V R IRES input resistance 220 kΩ C IRES input capacitance 220 nF Input and tri-state current with Strong pull-up -100 -40 -10 μΑ Strong pull-down 10 40 100 μΑ Weak pull-up -5 -1 -0.2 μΑ Weak pull-down 0.2 1 5 μΑ I/O pad leakage current -1 0 1 μΑ LED driver pad Off current - 1 2 μΑ On resistance (V PAD < 0.5 V) - 20 33 Ω On resistance, pad enabled by battery charger (V PAD < 0.5 V) - 20 50 Ω Table 3: Terminal characteristics 7 Battery charger Battery charger Min Typ Max Unit VD…

Text truncated - open the document above for the full version.

Modu Dear A TCL T your a requir 1, “Th not be 2,,“Th data in 3,“T U3(L D will co 4,“T 15.204 antenn 5, “Th typica 6, “Th Label instruc 7, “Th applic to exp instruc 8, “Th is com Best R Weiru Appro TCL T Tel: 0 Web E-m a ular Approval Requ Application Exam Technoly Electro authorization as a m rements of section he modular transm een shielded, pleas he modular transm nputs, it is integrat he modular transm DO_G9091-330T1 onvert 3.3V DC to he modular transm 4(c).” The EUT m na connector. The he modular transm al host device SRS he modular transm Sample for the FC ctions give to the O he modular transm cable to the transm plain any such requ ctions for maintain he modular transm mpliant with all app Regards. un, Peng obation Enginer Technoly Electro 0752-3270717 site: www.tonlv e ail:[email protected] uest Letter iner, onics(Huizhou) C modular approval 15.212 have been mitter must have it’ se see exhibition in mitter must have bu ted in chip S29AL mitter must have it 11U) in main boar o 1.8V DC by its c mitter must comply meets the FCC ante spurious emission mitter must be teste -X5 of SONY, ple mitter must be label CC ID of this mod OEM on how to la mitter must comply mitter and the manu uirement.” The EU ning compliance ar mitter must comply plicable RF exposu onics (Huizhou) C ele.com o.,Ltd, It’s Blueto specific to the mob met and shown on s own RF shieldin nternal photo. uffered modulation 016J70BFI020. ’s own power supp d provides 3.3V D hip IC BC57E687 y with antenna requ nna requirements, ns are shown in the d in a stand-alone ease see section ph led with it’s own F ule. And also in th abel the end produc with any specific ufacture must prov UT is compliant wi re given in the use with any applicab ure requirements. Co.,Ltd ooth module , FCC obile device such a n the following sta ng.”The radio porti n data inputs.” The ply regulation.” Th DC to TBM-CBC5 7C quirements of sectio it’s an integral PC e test report. configuration.” T h hotographs of test c FCC ID number.” P he exhibition User ct. rule or operating r vide adequate instru ith all applicable F ers Manual. ble RF exposure re RF exposure is ad C ID: ZVAPS0000 as SRS-X5. The atements. ion of this module e EUT has buffered he model, the Mode l on 15.203 and CB antenna and ha he EUT was tested configration in the Please see exhibiti Manual, there are requirements uctions along with FCC rules, detail equirements.” The ddressed in the test 012, would like to h have d l TBM-CBC5 ave no d in a e test report. ion h module EUT report. have

表格编号：TCLAV-A4-2004003 版本： V1.4 表格修订日期：2014-04-08 序号： 拟制日期： 2011-6-1 TCL通力电子(惠州) 有限公司 惠州TCL音视频电子有限公司 深圳市通力科技开发有限公司 AGENCY AUTHORIZATION LETTER FCC ID:ZVAPS000012 Date: 2014.9.16 To whom it may concern: We, the undersigned, hereby authorize Audix Technology (ShenZhen) Co.,Ltd to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Audix within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, (Original written signature of authorized signer) Name of authorized signer):Weirun, Peng Title of authorized signer: Approbation Engineer Company Name: TCL Technoly Electronics (Huizhou) Co., Ltd Tel: 0752-3606710 Fax: 0752-3270728 Web site: www.tcl.com E-mail: [email protected]

表格编号：TCLAV-A4-2004003 版本： V1.4 表格修订日期：2014-04-08 序号： 拟制日期： 2011-6-1 TCL通力电子(惠州) 有限公司 惠州TCL音视频电子有限公司 深圳市通力科技开发有限公司 Date: 2014.9.16 Federal Communications Commission Authorization and Evaluation Division FCC ID: ZVAPS000012 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description 4. Sony brand Authorization Letter The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, (Original written signature of authorized signer) Name of authorized signer):Wei run, Peng Title of authorized signer :Approbation Engineer Company Name: TCL Technoly Electronics (Huizhou) Co., Ltd Tel: 0752-3606710 Fax: 0752-3270728 Web site: www.tcl.com E-mail: [email protected]

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 14-1 14. PHOTOGRAPH OF EUT Figure 1 Inside of the EUT Figure 2 Inside of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 14-2 Figure 3 Inside of the EUT Figure 4 Inside of the EUT

70mm76mm 26mm 位置：底壳

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 14-1 14. PHOTOGRAPH OF EUT Figure 1 Inside of the EUT Figure 2 Inside of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 14-2 Figure 3 Inside of the EUT Figure 4 Inside of the EUT

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of TCL Technoly Electronics (Huizhou) Co., Ltd. Bluetooth Module Brand NameModel No. Sony TBM-CBC5 FCC ID: ZVAPS000012 Prepared for : TCL Technoly Electronics (Huizhou) Co., Ltd. Secion 37, Zhongkai High-tech Development Zone, Huizhou City, Guangdong Province, P.R. China. Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755) 26639496 Report Number ACS-F14274 Date of Test Aug.11~20, 2014 Date of Report Oct.13, 2014 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 TABLE OF CONTENTS Description Page 1. SUMMARY OF STANDARDS AND RESULTS ......................................................... 1-1 1.1. Description of Standards and Results .................................................................................. 1-1 2. GENERAL INFORMATION ......................................................................................... 2-1 2.1. Description of Device (EUT) ............................................................................................... 2-1 2.2. Tested Supporting System Details ....................................................................................... 2-2 2.3. Block Diagram of connection between EUT and simulators ............................................... 2-2 2.4. Test information ................................................................................................................... 2-3 2.5. Test Facility.......................................................................................................................... 2-4 2.6. Measurement Uncertainty (95% confidence levels, k=2) .................................................... 2-4 3. POWER LINE CONDUCTED EMISSION MEASUREMENT ................................. 3-1 3.1. Test Equipment .................................................................................................................... 3-1 3.2. Block Diagram of Test Setup ............................................................................................... 3-1 3.3. Power Line Conducted Emission Test Limits...................................................................... 3-1 3.4. Configuration of EUT on Test ............................................................................................. 3-1 3.5. Operating Condition of EUT................................................................................................ 3-2 3.6. Test Procedure...................................................................................................................... 3-2 3.7. Conducted Emission at Mains Terminals Test Results ........................................................ 3-2 4. RADIATED EMISSION MEASUREMENT ................................................................ 4-1 4.1. Test Equipment .................................................................................................................... 4-1 4.2. Block Diagram of Test Setup ............................................................................................... 4-2 4.3. Radiated Emission Limit Standard: FCC 15.209 ................................................................. 4-3 4.4. EUT Configuration on Test.................................................................................................. 4-3 4.5. Operating Condition of EUT................................................................................................ 4-3 4.6. Test Procedure...................................................................................................................... 4-3 4.7. Radiated Emission Test Results ........................................................................................... 4-4 5. CONDUCTED SPURIOUS EMISSIONS ..................................................................... 5-1 5.1. Test Equipment .................................................................................................................... 5-1 5.2. Limit..................................................................................................................................... 5-1 5.3. Test Procedure...................................................................................................................... 5-1 5.4. Test result ............................................................................................................................. 5-1 6. CARRIER FREQUENCY SEPARATION TEST ........................................................ 6-1 6.1. Test Equipment .................................................................................................................... 6-1 6.2. Limit..................................................................................................................................... 6-1 6.3. Test Results. ......................................................................................................................... 6-1 7. 20 DB BANDWIDTH TEST ........................................................................................... 7-1 7.1. Test Equipment .................................................................................................................... 7-1 7.2. Limit..................................................................................................................................... 7-1 7.3. Test Results .......................................................................................................................... 7-1 8. NUMBER OF HOPPING FREQUENCY TEST .......................................................... 8-1 8.1. Test Equipment ...................................................................................................…

Text truncated - open the document above for the full version.

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-1 5. CONDUCTED SPURIOUS EMISSIONS 5.1. Test Equipment Item Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Interval 1. Spectrum Agilent N9030A MY51380221Oct.31, 13 1Year 2. Attenuator (20dB) Agilent 8491B MY39262165Apr. 28,14 1 Year 3. RF Cable Hubersuhner SUCOFLEX10228620/2 Apr. 28,14 1 Year 5.2. Limit In any 100kHz bandwidth outside the frequency bands in which the spread spectrum intentional radiator in operating, the radio frequency power that is produced by the intentional radiator shall be at least 20dB below that in the 100kHz bandwidth within the band that contains the highest level of the desired power. 5.3. Test Procedure The transmitter output was connected to a spectrum analyzer, The resolution bandwidth is set to 100 kHz, The video bandwidth is set to 300 kHz and measure all the emissions detected. 5.4. Test result PASS (The testing data was attached in the next pages.) R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-1 GFSK Test Frequency: 2402MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-2 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-3 Test Frequency: 2441MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-4 Test Frequency: 2480MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-5 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-6 8-DPSK Test Frequency: 2402MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-7 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-8 Test Frequency: 2441MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-9 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-10 Test Frequency: 2480MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-11 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-12 Hopping on GFSK R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 5-13 8 DPSK R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 6-1 6. CARRIER FREQUENCY SEPARATION TEST 6.1. Test Equipment Item Equipment Manufacturer Model No.Serial No. Last Cal. Cal. Interval 1 Spectrum Analyzer Agilent N9030A MY51380221 Oct.31, 13 1Year 6.2. Limit Frequency hopping systems shall have hopping channel carrier frequency separated by a minimum of 25kHz or the 20dB bandwidth of the hopping channel, whichever is greater. Alternatively, frequency hopping systems operating in the 2400-2483.5 MHz band may have hopping channel carrier frequencies that are separated by 25 kHz or two-thirds of the 20 dB bandwidth of the hopping channel, whichever is greater, provided the systems operate with an output power no greater than 125 mW. 6.3. Test Results. EUT: Bluetooth Module M/N:TBM-CBC5 Test date: 2014-08-14 Pressure: 101.41.0 kpa Humidity: 52.73.0% Tested by: Kevin_Hu Test site: RF site Temperature:21.70.6 Test Mode Channel separation Conclusion 8-DPSK 1.0MHz PASS GFSK 1.0MHz PASS R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 6-2 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 7-1 7. 20 DB BANDWIDTH TEST 7.1. Test Equipment Item Equipment ManufacturerModel No. Serial No. Last Cal. Cal. Interval 1. Spectrum Agilent N9030A MY51380221 Oct.31, 131Year 2. Attenuator (20dB) Agilent 8491B MY39262165 Apr. 28,141 Year 3. RF Cable HubersuhnerSUCOFLEX10228620/2 Apr. 28,141 Year 7.2. Limit Intentional radiators operating under the alternative provisions to the general emission limits, as contained in §§ 15.217 through 15.257 and in Subpart E of this part, must be designed to ensure that the 20 dB bandwidth of the emission, or whatever bandwidth may otherwise be specified in the specific rule section under which the equipment operates, is contained within the frequency band designated in the rule section under which the equipment is operated. 7.3. Test Results EUT: Bluetooth Module M/N: TBM-CBC5 Test date: 2014-08-14 Pressure: 101.11.0 kpa Humidity: 50.33.0% Tested by: Kobe_Huang Test site: RF Site Temperature22 .50.6 Cable loss: 1.5 dB Attenuator loss: 0 dB Test Mode CH MHz 20dB bandwidth KHz Limit (KHz) 2402 827.6 N/A 2441 927.7 N/A GFSK 2480 925.2 N/A 2402 1205 N/A 2441 1259 N/A 8-DPSK 2480 1257 N/A ConclusionPASS R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 7-2 GFSK Test Frequency: 2402MHz Test Frequency: 2441MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 7-3 Test Frequency: 2480MHz 8-DPSK Test Frequency: 2402MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F14274 7-4 Test Frequency: 2441MHz Test Frequency: 2480MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:ZVAPS000012 page Audix Technology (Shenzhen) Co., Ltd. Report No. …
