ZVP-V20MGSM dual band mobile phone

TorchlightON/ OFF button SMS-/Menu-Button - Slide up to go to the SMS Menu - Slide down to come into the Menu Volume Control & Control the handset volume incoming call: turn ringer off Alarm clock button -Up to activate alarm clock -Down to de-activate alarm clock 1 Controls Speaker Display (= Screen) Arrow Keys - On standby: : & : - In menu and phonebook: scrolling up/down In standby: Enter phone book contact list Pick-up/OK/Call list-Key - Calling: Enter the number, then press - Answering an incoming call: Press - In menu: Confirm selection - On standby: Enter call list (dialled, received, missed) - Key - In standby: Long press: activate/ deactivate silent mode • LED-Blinking: Charging • Press twice: + (for international prefix, e.g +44 for UK) - For SMS: Special characters: ( , . ‘ ‘ ? ; : ! “ ’ @ _ ~ & + - ( ) < > { } [ ] % = / \ # * $ § ...) - Key On Standby: - Press and hold to connect with voicemail (= answering machine) - For SMS: Space - Key - Standby: Press and hold to go to missed call list - SMS: Switch between capital, small letters & numbers - LED- Blinking: Missed Call End/Back/Delete/Menu/ On/Off-Key - In menu: One step back - Writing numbers or text: Delete - During a call: Terminate Dear Customer, Congratulations on buying this emporia mobile telephone. You have made the right decision. Content of delivery: Mobile telephone, charging adapter, battery, instructions, table charger. TALKcomfort Keylock: - Slide up to activate Keylock - Slide down to activate Keylock Table charger This Emporia product is warranted to be free from defects in materials or workmanship for one (1) year from the date of purchase. In addition, the Emporia batteries used in the product are warranted to be free from defects in materials or workmanship for ninety (90) days from the date of purchase of the product. Within this period, Emporia will, at its sole option, repair or replace any components that fail in normal use. Such repairs or replacement will be made at no charge to the customer for parts or labor, provided that the customer shall be responsible for any transportation cost. This warranty does not apply to: (i) cosmetic damage, such as scratches, nicks, and dents; (ii) consumable parts, such as batteries (other than as expressly set forth herein), unless product damage has occurred due to a defect in materials or workmanship; (iii) damage caused by accident, abuse, misuse, water, flood, fire, or other acts of nature or external causes; (iv) damage caused by service performed by anyone who is not an authorized service provider of Emporia; or (v) damage to a product that has been modified or altered without the written permission of Emporia. Further, the battery warranty covers batteries only if battery capacity falls below 80% of rated capacity or the battery leaks, and this warranty does not cover any battery if (i) the battery has been charged by a battery charger not specified or approved by Emporia for charging the battery; (ii) any of the seals on the battery are broken or show evidence of tampering; or (iii) the battery has been used in equipment other than the Emporia product for which it is specified. In addition, Emporia reserves the right to refuse warranty claims against products or services that are obtained and/or used in contravention of the laws of any country. This product is intended to be used only for mobile operation and must not be used for any other purpose. THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES EXPRESS, IMPLIED, OR STATUTORY, INCLUDING ANY LIABILITY ARISING UNDER ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, STATUTORY OR OTHERWISE. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, WHICH MAY VARY FROM STATE TO STATE. IN NO EVENT SHALL EMPORIA BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, INCLUDING, WITHOUT LIMITATION, DAMAGES FOR ANY LOSS OF USAGE, DATE OR INCOME, OPERATION OF THE DEVICE IN VIOLATION OF LAW OR OTHERWISE, WHETHER RESULTING FROM THE USE, MISUSE, OR INABILITY TO USE THE PRODUCT OR FROM DEFECTS IN THE PRODUCT. SOME STATES DO NOT ALLOW THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU. Emporia retains the exclusive right to repair or replace (with a new or newly-overhauled replacement product) the device or software or offer a full refund of the purchase price at its sole discretion. SUCH REMEDY SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY BREACH OF WARRANTY. To obtain warranty service, contact your local Emporia authorized dealer or call Emporia Product Support for shipping instructions and a racking number. Securely pack the device and a copy of the original sales receipt, which is required as the proof of purchase for warranty repairs. Write the tracking number clearly on the outside of the package. Send the device, freight charges prepaid, to Emporia. 16 LIMITED WARRANTY 17 INTENDED USE This mobile telephone is robust and intended for mobile use. It is to be protected from moisture (rain, bathroom...) and impacts. Do not expose to prolonged direct sunlight. Misuse as described above can lead to damage of product and is associated with further hazards such as electrical shock and fire. The entire product should not be altered, rebuilt, nor should the housing be opened. The power adaptor is designed for use in household wall outlets to public electricity grids with 230 volts / 50 Hz (10/16A) voltage. 18 TECHNICAL DATA dual band GSM 850/1900MHz size: 114 x 55 x 15,5mm weight: 80g battery: Li-Ion 3.7V / 1000mAh standby: 200 h talktime: 240 min http://www.emporiatelecom.com PartNo: 36233-US, AMERICAN, V20mb _20 1 206 Fig. 1: Remove battery cover (as shown). Fig. 2: Slide SIM card in with the gold contact facing down. 3 INSERT BATTERY AND CHARGING Fig 2 Fig 5 Fig 1 Fig 4 • Fig. 3: Insert battery (gold contacts on right front side). • Fig. 4: Close battery door: slide cover to closed position with a ‘…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 Emporia Telecom USA Inc. 16 th May, 2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Emporia Telecom USA Inc. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): GSM dual band mobile phone, V20mbu We affirm that between SIEMIC and Emporia Telecom USA Inc. , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature President 321 E. Glen Ave, New Jersey, United States

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Emporia Telecom USA Inc 25 th May, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: ZVP-V20M We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title: Silva Hoo, President Contact information / address: 321 E. Glen Ave, New Jersey, United States

EMPORIA V20mb EMPORIA V20mb EMPORIA V20mb

EMPORIA V20mb EMPORIA V20mb EMPORIA V20mb EMPORIA V20mb EMPORIA V20mb

No.2012EEB00247-EMC Page 1 of 16 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2012EEB00247 for Emporia Telecom USA Inc. GSM dual band mobile phone Model Name: V20mbu Marketing Name: emporiaTALKcomfort FCC ID: ZVP-V20M IC ID: 10262A-V20M with Hardware Version: V20m-MB-V5.0 Software Version: V20mini_USA_ULC2_NW_R024 Issued Date: 2012-05-30 Test Laboratory: FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633-2678 , Fax:+86(0)10-62304633-2504 Email:[email protected]. www.emcite.com No.2012EEB00247-EMC Page 2 of 16 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ....................................... 5 3.4. EUT SET-UPS ................................................................................................................................... 5 4. REFERENCE DOCUMENTS .............................................................................................................6 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 6 5. LABORATORY ENVIRONMENT..................................................................................................... 7 6. SUMMARY OF TEST RESULTS ....................................................................................................... 8 7. TEST EQUIPMENTS UTILIZED ...................................................................................................... 9 ANNEX A: MEASUREMENT RESULTS................................................................................................ 10 No.2012EEB00247-EMC Page 4 of 16 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: Emporia Telecom USA Inc. Address /Post: 321 E. Glen Ave, Ridgewood City: New Jersey Postal Code: / Country: United States Telephone: (201) 962-5550 Fax: (201) 962-5550 2.2. Manufacturer Information Company Name: Emporia Telecom USA Inc. Address /Post: 321 E. Glen Ave, Ridgewood City: New Jersey Postal Code: / Country: United States Telephone: (201) 962-5550 Fax: (201) 962-5550 No.2012EEB00247-EMC Page 5 of 16 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description GSM dual band mobile phone Model Name V20mbu Marketing Name emporiaTALKcomfort FCC ID ZVP-V20M Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 350123456789110 V20m-MB-V5.0 V20mini_USA_ULC2_NW_R024 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Battery / AE2 Travel charger / AE3 USB cable / AE1 Model AK-RL2 Manufacturer Sunwoda Electronics Co., Ltd. Capacitance 1000mAh Nominal voltage 3.7V AE2 Model RL_V170US Manufacturer Kuantech Co., Ltd Length of cable 154cm AE3 Model / Manufacturer / Length of cable / *AE ID: is used to identify the test sample in the lab internally. 3.4. EUT set-ups EUT set-up No. Combination of EUT and AE Remarks Set.1 EUT1+ AE1 + AE2 Charging mode Set.2 EUT1+ AE1 + AE3 USB mode No.2012EEB00247-EMC Page 6 of 16 ©Copyright. All rights reserved by TMC Beijing. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version FCC Part 15, Subpart B Radio frequency devices 10-1-10 Edition ANSI C63.4 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 2003 ICES-003 Spectrum Management and Telecommunications Policy Interference-Causing Equipment Standard Digital Apparatus Issue 4 No.2012EEB00247-EMC Page 7 of 16 ©Copyright. All rights reserved by TMC Beijing. 5. LABORATORY ENVIRONMENT Semi-anechoic chamber (11.20 meters×6.10meters×5.…

Text truncated - open the document above for the full version.

Test setup photos 1. Part 15B conducted emission (charger) 2. Part 15B conducted emission (USB) 3. Part 15B radiated emission (charger) below 1 GHz 4. Part 15B Radiated emission (charger) above 1GHz 5. Part 15B Radiated emission (USB) below 1GHz 6. Part 15B Radiated emission (USB) above 1GHz
