ZWZ-ISL067ISL067R

Wireless RF Transceiver ISL067R User’s Guide This document contains information about the hardware interface between ISL067 transceiver and Receiver. Information includes the theory of operation, specifications, interface definitions, configuration information and mechanical drawings Proprietary Material The information and descriptions contained herein are the property of ISL. Such information and descriptions may not be copied or reproduced by any means, or disseminated or distributed without the express prior written permission of ISL. This document is for information purposes only and is subject to change without notice. Statement of Limited Warranty ISL warrants equipment of its manufacture, and bearing its identification to be free from defects in workmanship and material for a period of 12 months for electronics and 12 months for mechanical parts and Temperature probes from date of delivery from the factory or authorised distributor under normal use and service and otherwise when such equipment is used in accordance with instructions furnished by ISL and for the purposes disclosed in writing at the time of purchase, if any. ISL liability under this warranty shall be limited to replacement or repair of any defective equipment or part which, having been returned to ISL, has been inspected and determined by ISL to be defective, excluding battery cells. THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EITHER EXPRESS OR IMPLIED, AS TO DESCRIPTION, QUALITY, AND MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE OR USE, OR ANY OTHER MATTER. Revision History Issue Date Author Comments 0-1 02/05/14 C Boddy Initial Release 0-2 15/05/14 V Tambe Added FCC statement P6 Operation is subject to the following two conditions: this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation. Caution: any changes or modifications not expressly approved by the Manufacturer could void the user's authority to operate the equipment. Contents 1. Safety Information .......................................................................................................................................... 5 DECLARATION OF CONFORMITY .................................................................................................................. 9 2. ISL067........................................................................................................................................................... 10 3. Theory of operation ...................................................................................................................................... 10 3.1 Network Topologies ........................................................................................................................... 10 3.2 Point-To-Point .................................................................................................................................... 10 3.3 Point-to -Multipoint ............................................................................................................................ 11 3.4 Other network topologies ................................................................................................................... 12 4. Board Level Pin Assignments ...................................................................................................................... 14 5. Specifications ................................................................................................................................................ 15 1. Safety Information FCC WARNING This equipment generates or uses radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made Agency Identification Numbers Part # ID ISL067R ZWZ-ISL067 FCC ISL067R 12053A-ISL067 Industry Canada Approved Antenna List This radio transmitter ISL067R has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. Name / Model Gain Impedance 2J Antennae - 2J301M-300RG174-C143N 2dBi 50 ohms 2J Antennae - 2J310M-300RG174-C143N 5dBi 50 ohms 2J Antennae - 2JW031 0dBi 50 ohms 2J Antennae - 2J010 2.2dBi 50 ohms 2J Antennae - 2J020 2.2dBi 50 ohms The ISL067 has been designed with an internal PCB antenna and external approved 2J antennas listed in the above table with reverse polarity male plugs. Caution: Any changes or modifications not expressly approved by Invisible Systems could void the user’s authority to operate the equipment. FCC REQUIREMENTS NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does not cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Re-orient or relocate the receiving antenna • Increase the separation between the equipment and the receiver • Connect the equipment to an outlet on a circuit that is different from…

Text truncated - open the document above for the full version.

Letter of Agency Date: 19/05/14 TRaC Global Ltd. 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK To Whom It May Concern: We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application, is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Yours faithfully Invisible Systems Ltd Signature Pete Thompson Invisible Systems Ltd 9 Beetham Road ● Milnthorpe ● Cumbria ● LA7 7QL ● ENGLAND T: +44 (0) 1539 722 520 ● F: +44 (0) 1539 564 845 ● E: [email protected] ● W: www.invisible-systems.com Registered Office: ● 9 Beetham Road ● Milnthorpe ● Cumbria ● LA7 7QL ● No: 04911433

REQUEST FOR CONFIDENTIALITY I N ACCORDANCE WITH FCC RULE 0.459 01/05/14 TRaC GLOBAL LTD. 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK RE: Certification Application FCC ID: ZWZISL067 To Whom It May Concern: Please be advised that the following information is to be held confidential on behalf of Invisible Systems Ltd. • BOM • Schematics • Block Diagram The application contains technical information which Invisible Systems Ltd deems to be trade secrets and propriety. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Yours faithfully Invisible Systems Ltd Signature Pete Thompson Invisible Systems Ltd 9 Beetham Road ● Milnthorpe ● Cumbria ● LA7 7QL ● ENGLAND T: +44 (0) 1539 722 520 ● F: +44 (0) 1539 564 845 ● E: [email protected] ● W: www.invisible-systems.com Registered Office: ● 9 Beetham Road ● Milnthorpe ● Cumbria ● LA7 7QL ● No: 04911433

Build Message Temp/ Pulse/Analogue including DeviceID Calculate 2 byte CRC Initiate the random number generator function rand () with a known seed. Generate a Random number between 0 and 50 Use this number as a pointer to the hop table to generate random Transmit Frequency setting. Transmit at this frequency. RF micro generates an interrupt after every 4 hops to change frequency using the hop table Transmit frequency hopping algorithm Call rand() to generate the next random number. Transmit at this frequency. Exit No Random Frequency Generation Random frequency generation is accomplished by generating a uniformly distributed random number between 0 and 50 using this as a pointer to the hop table. The hop table consists of 50 channels frequency pairs uniformly distributed across the ISM band and are spaced approximately 50 KHz apart. The random number generation is accomplished using the function rand () available in the C library. The function generates a random number between 0 and 32768; this is divided by 654.9 to generate a random number between 0 and 50. The receive-side frequency generation has to be synchronous with the transmit-side frequency generation. This is accomplished by generating random numbers with the same seed in the transmit and receive side firmware routines. The hop table is stored in the header file hop.h in the firmware. Every 5 minutes from powering up the device it transmits it’s payload to the receiver. The pre-amble detect sequence is initiated on the channel 0. The hopping sequence commences when the receive detects the pre-amble on channel 0. the payload is then sent over a random channel sequence defined below. Use this number as a pointer to the hop table to generate random Transmit Frequency setting. Packet Sent? Yes Receive frequency hopping algorithm The receiver Hops to the same frequencies in the same random order as the transmitter. This is accomplished by calling the rand () function with the same seed in both transmit and receive routines. The receiver changes frequency once a Pre-amble is detected . The time between each hop is the same on both transmit and receive as they are both using the same delay routine and same device platform. Build Message Temp/ Pulse/Analogue including DeviceID Calculate 2 byte CRC Initiate the random number generator function rand () with a known seed. Generate a Random number between 0 and 50 Use this number as a pointer to the hop table to generate random Transmit Frequency setting. Receive at this frequency. RF micro generates an interrupt after every 4 hops to change frequency using the hop table Call rand() to generate the next random number. Receive at this frequency. Exit No Use this number as a pointer to the hop table to generate random Transmit Frequency setting. Packet Rx? Yes const long HoppingFrequencies[] = { 911000000, 921000000, 921500000, 925500000, 917000000, 914500000, 918500000, 924000000, 903500000, 908000000, 925000000, 903000000, 920000000, 922500000, 907000000, 909000000, 907500000, 920500000, 904000000, 916500000, 917500000, 910500000, 926500000, 927500000, 905000000, 904500000, 918000000, 912000000, 912500000, 923500000, 905500000, 906500000, 909500000, 913000000, 916000000, 924500000, 906000000, 926000000, 908500000, 919000000, 919500000, 911500000, 915500000, 915000000, 913500000, 927000000, 923000000, 922000000, 910000000, 914000000, 911000000 }; Hop Table

MODULAR APPROVAL REQUEST Date 05/06/2014 TRaC Global 100 Frobisher Business Park Leigh Sinton Road Malvern Worcestershire WR14 1BX UK RE: FCC Modular Approval FCC ID: ZWZ-ISL067 To Whom It May Concern: Please be advised that the manufacturer requests that the above-referenced model be approved for Licensed Modular Approval in accordance with the FCC Rules and Regulations. Our Product meets the FCC meet the FCC modular approval policies in the following ways: i The radio elements must have the radio frequency circuitry shielded. Physical/discrete and tuning capacitors may be located external to the shield, but must be on the module assembly; The radio frequency circuit is shielded by a CAN over the radio circuit ii The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal; The RF chip has buffers on in- and out-puts. If the RF-chip is decoupled properly on its power supply pins, the risk of having interference between the digital parts and the analog RF are kept to a minimum. iii The module must contain power supply regulation on the module; The power supply regulator is affixed to the module. iv The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b); The module has unique antenna connector which is UFL to RP SMA Male v The module must demonstrate compliance in a stand-alone configuration; The module has been fully testes to meet this requirement. Invisible Systems Ltd 9 Beetham Road ● Milnthorpe ● Cumbria ● LA7 7QL ● ENGLAND T: +44 (0) 1539 722 520 ● F: +44 (0) 1539 564 845 ● E: [email protected] ● W: www.invisible- systems.com Registered Office: ● 9 Beetham Road ● Milnthorpe ● Cumbria ● LA7 7QL ● No: 04911433 vi The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 997198 about labelling requirements); vii The module must comply with all specific rules applicable to the transmitter. The grantee must provide comprehensive instructions to explain compliance requirements; viii The module must comply with RF exposure requirements. For any transmitters intended for use in portable devices, SAR compliance must be demonstrated to be independent of the host device. See KDB Publication 447498 Item 2) as a guide to determine if a transmitter can be tested without being limited to a host device. If SAR compliance can only be demonstrated in specific host types or platforms, then the module type must be “limited.” Thank you for your attention to this matter. Yours faithfully Invisible Systems Ltd Pete Thompson Invisible Systems Ltd 9 Beetham Road ● Milnthorpe ● Cumbria ● LA7 7QL ● ENGLAND T: +44 (0) 1539 722 520 ● F: +44 (0) 1539 564 845 ● E: [email protected] ● W: www.invisible- systems.com Registered Office: ● 9 Beetham Road ● Milnthorpe ● Cumbria ● LA7 7QL ● No: 04911433

Front View Side View 60mm 56mm 16mm 16mm 48mm 44mm 218mm 48mm ISL067 Label Position Housing The label is self-adhesive, the Model No and ID’s will be affixed to the front face of the Tx housing

ISL067 Label Position PCB Model: ISL067 FCC ID: ZWZ ISL067 IC ID: 12 053A - ISL067 SN: 67000012 The label is self-adhesive, the Model No and ID’s will be affixed onto the CAN

Model: ISL067R FCC ID: ZWZ-ISL067 670000123

Can removed

SX1276/77/78 www.semtech.comPage 1 WIRELESS & SENSING DATASHEET SX1276/77/78 - 137 MHz to 1020 MHz Low Power Long Range Transceiver Rev. 1 - September 2013 ©2013 Semtech Corporation The SX1276/77/78 transceivers feature the LoRa TM long range modem that provides ultra-long range spread spectrum communication and high interference immunity whilst minimising current consumption. Using Semtech’s patented LoRa TM modulation technique SX1276/77/78 can achieve a sensitivity of over -148dBm using a low cost crystal and bill of materials. The high sensitivity combined with the integrated +20 dBm power amplifier yields industry leading link budget making it optimal for any application requiring range or robustness. LoRa TM also provides significant advantages in both blocking and selectivity over conventional modulation techniques, solving the traditional design compromise between range, interference immunity and energy consumption. These devices also support high performance (G)FSK modes for systems including WMBus, IEEE802.15.4g. The SX1276/77/78 deliver exceptional phase noise, selectivity, receiver linearity and IIP3 for significantly lower current consumption than competing devices. QFN 28 Package - Operating Range [-40;+85°C] Pb-free, Halogen free, RoHS/WEEE compliant product LoRa TM Modem 168 dB maximum link budget +20 dBm - 100 mW constant RF output vs. V supply +14 dBm high efficiency PA Programmable bit rate up to 300 kbps High sensitivity: down to -148 dBm Bullet-proof front end: IIP3 = -11 dBm Excellent blocking immunity Low RX current of 9.9 mA, 200 nA register retention Fully integrated synthesizer with a resolution of 61 Hz FSK, GFSK, MSK, GMSK, LoRa TM and OOK modulation Built-in bit synchronizer for clock recovery Preamble detection 127 dB Dynamic Range RSSI Automatic RF Sense and CAD with ultra-fast AFC Packet engine up to 256 bytes with CRC Built-in temperature sensor and low battery indicator Automated Meter Reading. Home and Building Automation. Wireless Alarm and Security Systems. Industrial Monitoring and Control Long range Irrigation Systems GENERAL DESCRIPTION ORDERING INFORMATION Part NumberDeliveryMOQ / Multiple SX1276IMLTRTT&R3000 pieces SX1277IMLTRTT&R3000 pieces SX1278IMLTRTT&R3000 pieces KEY PRODUCT FEATURES APPLICATIONS www.semtech.comPage 2 SectionPage Table of contents SX1276/77/78 WIRELESS & SENSING DATASHEET Rev. 1 - September 2013 ©2013 Semtech Corporation 1. General Description ................................................................................................................................................. 9 1.1. Simplified Block Diagram ................................................................................................................................. 9 1.2. Product Versions ............................................................................................................................................10 1.3. Pin Diagram ................................................................................................................................................... 10 1.4. Pin Description ...............................................................................................................................................11 1.5. Package Marking ...........................................................................................................................................12 2. Electrical Characteristics ....................................................................................................................................... 13 2.1. ESD Notice .................................................................................................................................................... 13 2.2. Absolute Maximum Ratings ........................................................................................................................... 13 2.3. Operating Range............................................................................................................................................ 13 2.4. Thermal Properties ........................................................................................................................................ 13 2.5. Chip Specification ..........................................................................................................................................14 2.5.1. Power Consumption .................................................................................................................................. 14 2.5.2. Frequency Synthesis................................................................................................................................. 14 2.5.3. FSK/OOK Mode Receiver .........................................................................................................................16 2.5.4. FSK/OOK Mode Transmitter ..................................................................................................................... 17 2.5.5. Electrical Specification for LoRaTM Modulation ........................................................................................19 2.5.6. Digital Specification ...................................................................................................................................22 3. SX1276/77/78 Features......................................................................................................................................... 23 3.1. LoRaTM Modem ............................................................................................................................................ 24 3.2. FSK/OOK Modem .......................................................................................................................................... 24 4. SX1276/77/78 Digital Electronics ..............................................................................................................…

Text truncated - open the document above for the full version.

A RADIO TEST REPORT FOR INVISIBLE SYSTEMS ON ISL067R DOCUMENT NO. TRA-017840-00-47-00-B Total number of pages : 66 TRaC Wireless Test Report : TRA-017840-00-47-00-B Applicant : Invisible Systems Apparatus : ISL067R Specification(s) : CFR47 Part 15.247 & RSS-210 Annex 8 FCCID : ZWZISL067R Certification Number : 12053A-ISL067R Purpose of Test : Certification Authorised by : : Radio Product Manager Issue Date :4 th July 2014 Authorised Copy Number : PDF TRaC Global Test Report: TRA-017840-00-47-00-B 3 Contents Section 1: Introduction 4 1.1 General 4 1.2 Tests Requested By 5 1.3 Manufacturer 5 1.4 Apparatus Assessed 5 1.5 Test Result Summary 6 1.6 Notes Relating To The Assessment 7 1.7 Deviations from Test Standards 7 1.8 Test Site 7 Section 2: Measurement Uncertainty 8 2.1 Measurement Uncertainty Values 8 Section 3: Modifications 10 3.1 Modifications Performed During Assessment 10 Appendix A: Formal Emission Test Results 11 A1 Transmitter Peak Output Power 12 A2 RF Antenna Conducted Spurious Emissions 13 A3 Radiated Electric Field Emissions 15 A4 Power Line Conducted Emissions 20 A5 20 dB Bandwidth and Carrier Frequency Separation 22 A6 Hopping frequencies 23 A7 Channel Occupancy 24 A8 Antenna Gain 25 A9 Unintentional Radiated Electric Field Emissions 26 Appendix B: Supporting Graphical Data 27 Appendix C: Additional Test and Sample Details 51 Appendix D: Additional Information 57 Appendix E: Calculation of the duty cycle correction factor 58 Appendix F: Photographs and Figures 59 Appendix G: MPE Calculation 65 Radio Test Report: TRA-017840-00-47-00-B 4 Section 1: Introduction 1.1 General This report contains an assessment of an apparatus against Electromagnetic Compatibility Standards based upon tests carried out on samples submitted to the Laboratory. Test performed by: TRaC Global [ ] Unit E South Orbital Trading Park Hedon Road Hull, HU9 1NJ. United Kingdom. Telephone: +44 (0) 1482 801801 Fax: +44 (0) 1482 801806 TRaC Global [X] Unit 1 Pendle Place Skelmersdale West Lancashire, WN8 9PN United Kingdom Telephone: +44 (0) 1695 556666 Fax: +44 (0) 1695 577077 Email: [email protected] Web site: http://www.tracglobal.com Tests performed by: D Winstanley Report author: D Winstanley This report must not be reproduced except in full without prior written permission from TRaC Global. Radio Test Report: TRA-017840-00-47-00-B 5 1.2 Tests Requested By This testing in this report was requested by : Invisible Systems 9 Beetham Road Milnthorpe Cumbria LA7 7QL 1.3 Manufacturer As Above 1.4 Apparatus Assessed The following apparatus was assessed between 13 th – 16 th May 2014 ISL067R The above equipment is a FHSS modular transmitter operating in the 902-928 MHz band. Testing was performed where required with the following antennas PCB Antenna (0 dBi Gain ) External antenna (2dBi Gain External antenna (5dBi Gain) Radio Test Report: TRA-017840-00-47-00-B 6 1.5 Test Result Summary Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. The statements relating to compliance with the standards below apply ONLY as qualified in the notes and deviations stated in sections 1.6 to 1.7 of this test report. Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. Test Type Regulation Measurement standard Result Title 47 of the CFR: Part 15 Subpart (c) RSS – 210 Issue 8, December 2010 Radiated spurious emissions (Restricted bands) 15.247 Annex 8, A8.5 ANSI C63.10:2009 Pass Conducted spurious emissions (Non-restricted bands) 15.247 Annex 8, A8.5 ANSI C63.10:2009 Pass AC Power conducted emissions 15.207 Section 7.2.2 ANSI C63.10:2009 Pass 20dB Bandwidth and Channel Spacing 15.247(a)(1)(i) Annex 8, A8.1(b) ANSI C63.10:2009 Pass Conducted Carrier Power 15.247(b)(2) Annex 8, A8.4(2) ANSI C63.10:2009 Pass Hopping Frequencies 15.247(a)(1) Annex 8, A8.1(d) ANSI C63.10:2009 Pass Channel Occupancy 15.247(a)(1)(i) Annex 8, A8.1(d) ANSI C63.10:2009 Pass Unintentional Radiated Spurious Emissions 15.109 Section 7.2.3 ANSI C63.10:2009 Pass Extrapolation Factor: 15.31(f) RSS-Gen Issue 3 7.2.7 - - Maximum Frequency of Search: 15.33 RSS-Gen Issue 3 4.9 - - Antenna Arrangements Integral: 15.203 RSS-Gen Issue 3 7.1.2 - - Antenna Arrangements External Connector: 15.204 RSS-Gen Issue 3 7.1.2 - - Restricted Bands: 15.205 RSS-Gen Issue 3 7.2.2 - - Abbreviations used in the above table: ANSI C 63.10:2009 is outside the scope of the laboratories UKAS accreditation. Mod : Modification RSS : Radio Standards Specification CFR : Code of Federal Regulations ANSI : American National Standards Institution REFE : Radiated Electric Field Emissions PLCE : Power Line Conducted Emissions Radio Test Report: TRA-017840-00-47-00-B 7 1.6 Notes Relating To The Assessment With regard to this assessment, the following points should be noted: The results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. The apparatus was set up and exercised using the configurations, modes of operation and arrangements defined in this report only. Particular operating modes, apparatus monitoring methods and performance criteria required by the standards tested to have been performed except where identified in Section 1.7 of this test report (Deviations from Test Standards). For emissions testing, throughout this test report, “Pass” indicates that the results for the sample as tested were below the specified limit (refer also to Section 2, Measurement Uncertainty). Where relevant, the apparatus was only assessed using the monitoring methods and susceptibility criteria defined in this report. All testing with the exception of testing at the Open Area Test Site was performed under the following environmental conditions: Temperature : 17 to 23 °C Humidity : 45 to 75 % Barometric Pressure : 86 to 106 kPa All dates used in this r…
