ZY9-1201682Radio Alarm Clock with Bluetooth Speaker / Bluetooth Alarm Clock Radio

TM 234567 We hope you enjoy your Radio Alarm Clock with Bluetooth ® Speaker from RadioShack. This radio features a 1.2” blue LED display, dual alarm clock, built-in USB charging port, and auxiliary input jack. Bluetooth connectivity enables you to wirelessly stream music from your Bluetooth- enabled device. Please read this user’s guide before using your new radio alarm clock. Package Contents •Radio Alarm Clock •AC Adapter •User’s Guide Specifications Power Supply ....................................DC 5V, 2A adapter ......................2 × AAA backup batteries (not included) Output Power .......................................> 2W (10% THD) USB Output .......................................................DC 5V, 1A Frequency Range ............................FM 87.5 – 108 MHz Bluetooth Protocol .....................................................v4.0 Bluetooth Connection Range .........> 33 ft. (10.05m) Dimensions (WHD) ..............................5.6 × 3.4 × 3.2 in .............................................................(14.2 × 8.6 × 8.1 cm) Specifications are subject to change and improvement without notice. Actual product may vary from the images found in this document. Power Your Radio Install Backup Batteries Batteries provide backup power during power outages. Settings and data memory will be lost if both AC power and batteries are removed. 1. Open the battery cover. 2. Install two AAA batteries (not included) as indicated by the polarity symbols (+ and –) marked inside. 3. Replace the battery cover. Battery Notes: •Replace the batteries when the LED display dims or the sound becomes weak or distorted. •Dispose of batteries promptly and properly. Do not burn or bury them. •Use only fresh batteries of the required size and type. •Do not mix old and new batteries, different types of batteries (alkaline or rechargeable), or rechargeable batteries of different capacities. •If you do not plan to use the radio for a long time, remove the batteries. Batteries can leak chemicals that can damage electronic parts. Plug the AC Adapter Connect the supplied AC adapter barrel plug into the DC IN jack on the back of the radio, and plug the adapter into a standard AC outlet. The LED displays the time. 1201682 User’s Guide USB Charging Port Connect a portable device for charging using an USB charging cable (not included). FM •Press and hold to turn the radio or Bluetooth mode on/off. •Press to switch between radio and Bluetooth mode. §/snooze_dimmer/  •Answer/reject a call or play/pause playback (Bluetooth only). •Turn the alarm snooze on. •Toggle LED display brightness to high or low (selection disabled in Bluetooth or snooze mode, or when the alarm sounds). TIME Enter time-setting mode. AL1 / AL2 Turn the alarm on /off or set the alarm. DC IN Radio Alarm Clock with Bluetooth ® Speaker FM Antenna + / – •Volume control. •Set the time. Microphone  /  •Tune radio stations. •Previous/next track (Bluetooth only). Listen to Your Radio Listen to FM Radio 1. Press and hold FM for 2 seconds to turn on the radio. The red FM indicator lights. 2. Press  or  to tune a station, or press and hold  or  to scan available stations. 3. Press + or – to increase or decrease the volume. Listen to a Bluetooth Device 1. Press FM to switch to Bluetooth mode. The blue Bluetooth indicator flashes. 2. Activate your device’s Bluetooth function (refer to your device’s user’s guide). 3. When your device locates RS1201682, select it. When paired, the blue indicator lights steadily. 4. Turn on the audio source. You can control your radio through your device or with the radio’s  / , §/snooze_dimmer/  , and + / – buttons. •If you receive a call, you can answer the call by pressing §/snooze_dimmer/  and speaking into the microphone. PM Indicator (Green) Alarm 1 Indicator (Amber) Alarm 2 Indicator (Amber) FM Indicator (Red) Bluetooth Indicator (Blue) 891011121314 Listen to an AUX Device For an audio device without Bluetooth technology, use an ⅛ in. audio cable (not included) to connect it to the radio’s AUX IN jack. AUX appears on the display. Notes: •Bluetooth or FM radio mode is automatically deactivated when AUX IN is connected. •Use the controls on your connected device to control playback. Set the Clock In standby mode, the time is shown using a 12- hour clock with green PM indicator. 1. Press and hold TIME for 2 seconds to enter time-setting mode. The hour digits flash. 2. Press + or – to set the hour. •Press and hold §/snooze_dimmer/  for 2 seconds to reject the call. •When your device receives an incoming call, the Bluetooth connection is suspended and playback will pause. Note: If the connected device moves too far from the radio, you will lose the Bluetooth connection. Device Not Pairing? Many Bluetooth-enabled devices, such as speakers, remember the most recently paired source (music, smartphone, etc.) and automatically reconnect when turned on. This is convenient, but can prevent you from connecting to a new source. If you can’t pair your radio, you may need to disconnect it from its previous source. Disconnect Your Device To disconnect the paired device, press and hold the radio's §/snooze_dimmer/  for 2 seconds. The radio starts searching for another Bluetooth device. 3. Press TIME. The minute digits flash. 4. Press + or – to set the minute. 5. Press TIME to confirm and exit. Set the Alarm You can set one or two alarms. 1. Press and hold AL1 (or AL2) for 2 seconds to enter alarm-setting mode. The hour digits flash. 2. Press + or – to set the hour. 3. Press AL1 (or AL2). The minute digits flash. 4. Press + or – to set the minute. 5. Press AL1 (or AL2), then press + or – to set the alarm source: b (Beep) or F (Radio). 6. Press AL1 (or AL2) to confirm and exit. The amber AL indicator lights. 7. Press AL1 (or AL2) once to review the alarm time, press it again to turn the alarm on/off. When the Alarm Sounds •The respective Alarm 1 or Alarm 2 indicator flashes. The alarm will sound for 1 hour at the s…

Text truncated - open the document above for the full version.

Backup Battery LED Display DCInput DCInput DCInput DCInput Voltage Regulator FrontInput FrontInput Voice output DC input DC input BluetoothModule SignalInput U1 U2 U3 IC5 IC1 2.4~2.483GHZ CSR8615

INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (External) INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (External) INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (External)

凸字，字高0.2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 凸字，字高0.2 刻字 吴多健 SP021 10 1201682 Bluetooth Alarm Clock Radio Catalog No. 1201682 Frequency Range: FM 87.5 – 107.9 MHz Power: 5V 2A Backup Power: 2 × AAA Batteries FCC ID: ZY9-1201682 Custom Manufactured in China for General Wireless Operations Inc. dba RadioShack, Fort Worth, TX 76102

INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (Internal) INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (Internal) INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (Internal) INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (Internal) INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (Internal) INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (Internal) INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (Internal) INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (Internal) INTERTEK TESTING SERVICE Report No.: 15080865HKG-001 FCC ID: ZY9-1201682 Equipment Photographs Model : 1201682 (Internal)

Analysis Report The Equipment Under Test (EUT) is a Radio Alarm Clock with 2.4GHz Bluetooth 4.0/3.0/2.0 Speaker. For Bluetooth 4.0, the EUT occupies a frequency range from 2402MHz to 2480MHz (40 channels with channel spacing of 2MHz) For Bluetooth 3.0/2.0 ,the EUT operates in a frequency range from 2402MHz to 2480MHz (79 channels with channel spacing of 1MHz). The EUT can pair with smart device through Bluetooth for playing music. Also, It is able to play FM Radio. The EUT is powered by AC Adapter and 2 X 1.5 VDC AAA backup batteries. The USB portal is for charging to other mobile devices. Antenna Type: External integral antenna Antenna Gain: 0dBi Nominal rated field strength: 93.9dBμV/m at 3m Maximum allowed field strength of production tolerance: +/- 3dB According to the KDB 447498: Based on the Maximum allowed field strength of production tolerance was 96.9dBμV/ m at 3m in frequency 2.4GHz, thus; The EIRP = [(FS*D) ^2*1000 / 30] = 1.469mW Conducted power = Radiated Power (EIRP) – Antenna Gain So; Conducted Power =1.469mW. The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.48) mW = 9.53 mW Since the above conducted output power is well below the SAR Exclusion threshold level, so the EUT is considered to comply with SAR requirement without testing.

DC 5V EJ DC 5.0V CRM301 蓝色时间LED显示 显示屏调节 High/Low 二档 Approval. /DATE:Audit. /DATE:Design./DATE: SHEET OF: 1/1 G & Y COMPANY LIMITED 。 DATE: CHK: APP: REV. MODIFICATION 1 PCB VER: IC:LED: MODEL:1201682(GGA114090) * DOC VER: TO FILE TITLE: COMPANY: DWG NO: 00 SCH Lin Jin 2015-9-1 CRM301GP19 00 4558 NC Radioshack NC NC NC NC XTAL1 32.768KHz 3 IN 2 OUT 1 GND IC5 3.3V C36 104 C3 15P C5 17P C24 104 BTL ALRM1 FM 2F 2A 2B 2E 2G 2C 2D COL1COL2 C4 104 3F 3A 3B 3E 3G 3C 3D 4F 4A 4B 4E 4G 4C 4D PM VDD GND CL DA C14 104 AL1 1B 1C R11 10R 5 GND1 4 GND 3 D+ 2 D- 1 VCC 6 GND1 USB 12 CN2 AL2 - UP FM/BT TIME SNOOZE/PALY DOWN + C2 104 12 MIC1 C6 15p C23 104 EC2 100uF C9 105 C17 15P R23 1K D7 123456 CN4 6PIN SPKL 4ohm/3W C18 225 C19 334 R26 4K7 R28 20K C20105 EC4 220uF R30 0R 1 SD 2 BYP 3 MODE 4 IN 5 VON 6 VDD 7 GND 8 VOP IC1 XPT6875 1 GND 2 GND 3 FMI 4 RFGND 5 AMI 6 GND 7 SCLK 8 SDIO 9 RCLK 10 VDD 20 LIN1 19 RIN1 18 LIN2 17 RIN2 16 EXTLNA 15 GPIO2 14 GPIO3 13 VA 12 LOUT 11 ROUT U1 BK1088 C1 10N L1 100nH C10 18P C15 104 C12 104 C11 105 FMANT1 D2 BAV99 C13 105 123456 CN1 6PIN R6 10K R2 10K BATT 3V D4 S4 D6 S4 R13 10R 1 PIO21 2 PI018 3 PIO17 4 PIO9 5 PIO7 6 PIO6 7 SPI_PCM 8 PIO4/CS 9 PIO3/MISO 10 PIO2/MOSI 11 PIO1/CLK 12 RST 13 VBAT 14 GND 15 VCHG 16 CHG_EXT 17 VBAT_SENSE 18 TX 19 RX 20 USB_N 21 USB_P 22 POWER_EN 23 1V8 24 LED0 25 LED1 26 LED2 27 LINE/MIC_AN 28 LINE/MIC_AP 29 MIC_BIAS 30 LINE_BN 31 LINE_BP 32 NC1 33 NC 34 SPK_LN 35 SPK_LP 36 GND2 37 RF 38 GND1 U3 F-3288-15 L2 15nH 1 1OUT 2 1IN- 3 1IN+ 4 GND 5 2IN+ 6 2IN- 7 2OUT 8 VCC U4 C16 105 C21 105 C7 104 C8 104 C28 104 C29 475 C26 105 C27 106 C22 33P C25 105 C30 NC C31 NC C32 OR FMANT2 1 P13/KEY3 2 P14/KEY4 3 P15/KEY5 4 P16/KEY6/DSCL 5 P17/KEY7/DSDA 6 VDD 78 VSS 9 8 10 P60/XOUT 11 P61/XIN 12 P62/RESETB 13 P63/SXIN 14 P64/SXOUT 15 LPF 16 P20/COM0 17 P21/COM1 18 P22/COM2/SEG0 19 P23/COM3/SEG1 20 P24/COM4/SEG2 21 P25/COM5/SEG3 22 P26/COM6/SEG4 23 P27/COM7/SEG5 24 P30/SEG6 25 P31/SEG7 26 P32/SEG8 27 P33/SEG9 28 P34/SEG10 29 P35/SEG11 30 P36/SEG12 31 P37/SEG13 32 P40/SEG14 33 P41/SEG15 34 P42/SEG16 35 P43/SEG17 36 P44/SEG18 37 P45/SEG19 38 P46/SEG20 39 P47/SEG21 40 P50/SEG22 41 P51/SEG23 42 P52/SEG24 43 P53/SEG25 44 P54/SEG26 45 P55/SEG27 46 P56/SCK/TXD/SEG28 47 P57/SO/RXD/SEG29 48 P00/EINT10 49 P01/EINT12/T2O/EC2 50 P02/BUZO 51 P03/REM 52 P10/KEY0 53 P11/KEY1 54 P12/KEY2 55 GND U2 ALRM2 R47 1K R48 1K R49 22K R50 22K C45 105 C46 105 RL EJ1-A EJ1-B R5 1K C33 105 Q2 9014 C34 104 R10 220R R34 R32 75K R35 49.9K R33 43.2K R36 49.9K Q1 9014 R16 1K R17 1.5K Q3 9014 R18 1K R20 1.5K Q4 9014 R21 1K R22 5.6K R14 1K R24 1.8K R12 180R R15 220R PROTECTOR1 110 R31 100K EC1 100uF L4 2.5K@100MHz R84 1K R80 12K R81 12K R8210K R83 10K R3 10K R19 1K R1 2.2K R91 100K R90 100K R7 10K R9 10K R8 10K R4 470K L3 5.1R R25 1K R27 1K ESD2 NC ESD1 NC ESD4 NC R39 0R Q5 R29 R37 R38 3.0V AL F2 3.3V F1 2FE7 1E F4 F5F7C2C0 D0 C1 C4 LIGHT1 E3 BTLED+ LED0 E4 F0 E5 SDIO D4 A/D DOWN F0 D4 K2 DC_DET F6 C3 K0 D2 K1 MUTE D5 D1 F4 F4 1E F2 F1 E5 E7 2F A/D F5 F7 D0 C0 C1 C2 F6 C5 D3 D2 C6 D1 C4 C3 D3 C6 D6 C5 5.0V A GPIO2 GPIO3 K0 K1K2 E4E3 SCLK BT_EN GPIO2 GPIO3 K2 K1 K0 K2 K1K0 LED0BT_EN 3.3V UP PLAY RCLK D6 MUTE 5.0V BT_MUTE SCLK SDIO RCLK R_OUT BT_OUT R_OUT 3.3V AL DC_DET 3.0V BA+ GPIO3 GPIO2 PLAY DOWN UP BT_MUTE GND GND GND GND GND 5.0V BT_OUT GPIO2 D5 AUX_DET AUX_DET GPIO3 BTLED+ GND GND LIGHT1 LIGHT1 LIGHT1 LIGHT1 5.0V GND GND GND GND LIGHT1 2402-2480MHz RFBPF608070AWT 24C64 12 BT_RF 4 0 V R E N A B L E _ E N 4 2 V C H G 4 3 C H G _ E X T 4 4 V B A T _ S E N S E 4 5 V B A T 4 8 S M P _ V B A T 4 1 V O U T _ 3 V 3 4 9 S M P _ B Y P 5 4 V D D _ U S B 4 7 L X _ 1 V 8 5 3 S M P S _ 1 V 8 _ S E N S E 1 5 V D D _ A U X _ 1 V 8 1 6 V D D 1 _ A U X _ 1 V 8 8 V D D _ A U D I O _ D R V 3 V D D _ A U D I O 1 4 V D D _ A U X 5 0 L V _ 1 V 3 5 5 2 L V _ 1 V 3 5 _ S E N S E 1 7 V D D _ A N A 1 3 V D D _ B T _ L O 1 1 V D D _ B T _ R A D I O 3 9 V R E G I N _ D I G 3 8 V D D _ D I G _ M E M 3 3 V D D _ P A D S 1 6 3 V D D _ P A D S 2 19 XTAL_IN 18 XTAL_OUT 37 LED0 36 LED1 66 LED2 59 RX 60 TX 62 PIO6 57 PIO7 61 UART_RTS 58 UART_CTS 65 PIO18 64 PIO21 30 MOSI 28 MISO 24 CS 34 CLK 29 SPI_PCM 22 I2C_WP 25 I2C_SCL 26 I2C_SDA 31 PIO13 23 PIO14 21 PIO15 27 PIO16 32 PIO17 7 S P K _ R P 6 S P K _ R N 1 0 S P K _ L P 9 S P K _ L N 4 L I N E _ B N 5 L I N E _ B P 2 M I C _ B I A S 6 8 L I N E / M I C _ A P 6 7 L I N E / M I C _ A N 1 A U _ R E F 5 1 V S S _ S M P S _ 1 V 3 5 4 6 V S S _ S M P S _ 1 V 8 6 9 G N D _ P A D D L E 20 AIO0 56 USB_P 55 USB_N 35 RST U1 P O W E R _ E N V C H G C H G _ E X T V B A T _ S E N S E V B A T LED0 LED1 LED2 RX TX M0SI MISO CS CLK PCM RST USB_N USB_P PIO21 PIO18 PIO6 PIO7 S P K _ R P S P K _ R N S P K _ L P S P K _ L N L I N E _ B N L I N E _ B P L I N E _ A P L I N E _ A N GND 1 V 8 XT1 26M C1 2U2 3 OUT 1 IN 2 GND 4 GND1 U2 BPF C5 2U2 C6 2U2 C7 2U2 C8 10n L 1 4 . 7 U H C9 10n C10 4.7uF L 2 4 . 7 U H C11 15p C12 2.2u C13 470n C14 100n 1 E0 2 E1 3 E2 4 VSS 8 VCC 7 /WC 6 SCL 5 SDA U3 R 1 2 . 2 K R 2 2 . 2 K R 3 2 . 2 K C 1 5 1 0 n R4 0R C16 2U2 8 VDD 5 SI 2 SO 3 WP 7 SIO3 1 CE 6 SCK 4 VSS U4 SPI C 1 7 1 0 n PIO17 PIO9 R F A G N D A G N D 1 V 3 5 1 V 8 1V8 1 V 8 PIO12 PIO10 PIO11 P I O 1 2 1 V 8 PIO11 PIO13 1V8 PIO12 PIO10 PIO13 PIO10 PIO11 CSR8615
