说明书印刷要求： 尺寸：140*210mm 颜色：4C印刷 材质：封面封底200g铜版纸 内页105g铜版纸 装订要求：胶装 不可掉页、漏页，裁剪装订整齐 （此页不印刷） User Manual Walking Pad Treadmill HM3Model ACTIVATE YOUR WARRANTY CUSTOMER CARE CAUTION To register your product and activate your warranty today, go to support@ hometroshop.com. Please attach the following information: 1. Order number 2. "Activate Warranty" related characters For service at any time, go to [email protected] with your order number. The relevant operating video has been uploaded to the YouTube account: www.youtube.com/@homeTroSports Please have the following information ready when you need to replace a spare part: 1. Order number 2. Part description (preferably add a photo or video) 3. Date of purchase Read all precautions and instructions in this manual before using this equipment. Save this manual for future reference. FITSHOW Installation Procedure Please fill in the correct email or mobile phone number to make sure you can retrieve your password and username. Attentions 1. Scan the QR code on the right 2. http://fitshow.com/qr 5. Start Using FITSHOW 3. Jump to the App Store to download and install Open the App, allow permission based on the system prompt 4. Login to the App, please use the mobile number or email to register for the new user LANGUAGE English Deutsch Francais Espanol Italiano 06-20 21-38 39-55 56-73 74-91 06EN07EN CATALOG Important Precautions - - - - - - - - - - - - - - - - 07 Product Brief Introduction - - - - - - - - - - - - - - 08 Main Parameters and Part List- - - - - - - - - - - - 09 Installation Instructions - - - - - - - - - - - - - - - 10 How to Use the Treadmill - - - - - - - - - - - - - - 12 Remote Control Function Description - - - - - - - - 13 Sports Mode Function - - - - - - - - - - - - - - - - 14 Exercise Guidelines - - - - - - - - - - - - - - - - - 15 Maintenance - - - - - - - - - - - - - - - - - - - - 16 Common Troubleshooting Methods - - - - - - - - - 17 Warranty - - - - - - - - - - - - - - - - - - - - - - 20 Important Precautions WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. • Reserve a safety space of 0.8 meters on each side of the treadmill and a safety space of 2 meters (length) * 1 meter (width) behind the treadmill. • The treadmill is an indoor device, please do not use it outdoors. It should be placed in a clean and flat place, and be moisture-proof and waterproof. • Be careful not to place the treadmill on items such as thick carpets, so as not to affect the air circulation under the treadmill and cause heat dissipation problems. The electric treadmill is a special device, please do not modify it for other uses. • Only after confirming that the treadmill is installed in full accordance with the installation instructions can the power be turned on. • Plug the power cord into a power socket with a safety ground. The power cord of the electric treadmill is dedicated. If the power cord is damaged, please contact our company directly. • It is strictly forbidden to exercise barefoot on the treadmill. You need to stretch your whole body before exercising. Proper running or fitness shoes are recommended. • If you are using a treadmill for the first time, please start at a low speed until you gradually adapt and feel stable, then start to increase the speed. If you feel dizzy, chest pain, nausea, or shortness of breath during exercise, please stop exercising immediately and consult a fitness coach or doctor. • When using the treadmill, please do not let children get close to avoid danger. • Minors must be accompanied by adults when using the treadmill. • Do not remove the motor cover casually. If you need to open it for maintenance, be sure to unplug the power cord first. • After use, silicone oil must be stored out of the reach of children to avoid serious consequences from accidental ingestion. 08EN09EN Product Brief Introduction Product Model:HM3 Rear Roller Middle Foot Pad LED Digital Display Motor Cover Remote Control Running Belt Tail Cover Incline Adjustment Bracket Front Foot Pad Main Parameters and Part List The main technical parameters Serial numberParameter nameDescription 1Rated voltageUS: 100-120V/60Hz; UK:220-240V/50-60Hz 2Control methodRemote controller, APP 3 Product unfolded size 1153*485*169mm(L.*W.*H.) 4Package size 1225*560*125mm(L.*W.*H.) 5Product N.W.37.3LBS/16.9KG 6Product G.W.43.2 LBS/19.6KG 7Product functionSpeed, Time, Distance, Calories 8Speed0.6-5.0mph (1-8km/h) 9Running belt size980*380mm (L.*W.) Part List Treadmill Remote Control5MM Hex Wrench with Cross Screwdriver User ManualSilicone Oil 20mlFront Foot Pads 10EN11EN Installation Instructions Instructions for Use 1. Open the package, take out the accessories from the box, and place the treadmill flat on the ground. 2. Install the front foot pad of the treadmill as shown in the picture. Front Foot Pads 3.Incline adjustment: Lift the treadmill from the rear end and kick the incline adjustment bracket in the direction of the arrow in Figure 1, so that the treadmill can reach a higher incline, then rotate the middle foot pad downward until it is supported on the ground and maintain balance, as shown in Figure 2. Note: When adjusting the incline, be sure to disconnect the power supply to avoid accidentally touching the switch. If the incline is not required, just fold up the incline adjustment bracket. Figure 1 Figure 2 12EN13EN How to Use the Treadmill Support Wireless Bluetooth APP Remote Control LED Digital Display Function Bluetooth name: homeTroHM3 Motor Cover LED Screen (Rotating Display) 1.Speed 2. Time 3. Distance 4.Calories 4. Start using 1> Connect the power cord 2> Turn on the power switch 3> Use the remote control to control the treadmill. Operating Parameters 1. Rated voltage US: 100-120V/60Hz, UK: 220-240V/50-60Hz. 2. Minimum speed 0.6mph (1 km/h) . 3. Maximum speed 5.0mph (8 km/h). Remote Contro…
