Nomadix AP 6SA Access Point Hardware Installation and Reference Guide Document Version: V1.0 Date: 2022.6.10 Copyright statement Nomadix©2021 Nomadix reserves all copyrights of this document. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Nomadix is prohibited. Exemption statement This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Nomadix website. Nomadix endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors. I Preface Intended Audience This document is intended for:  Network engineers  Technical support and servicing engineers  Network administrators Obtaining Technical Assistance Nomadix Website: https://nomadix.com Service & Support Information: https://portal.nomadix.com Service Hotline: +1 818-575-2500 Conventions 1. Signs The symbols used in this document are described as follows: Danger An alert that calls attention to safety operation instructions that if not understood or followed when operating the device can result in physical injury. Warning An alert that calls attention to important rules and information that if not understood or followed can result in data loss or equipment damage. Caution An alert that calls attention to essential information that if not understood or followed can result in function failure or performance degradation. Note An alert that contains additional or supplementary information that if not understood or followed will not lead to serious consequences. Specification An alert that contains a description of product or version support. 2. Note This manual provides the device installation steps, hardware troubleshooting, module technical specifications, and specifications and usage guidelines for cables and connectors. It is intended for the users who have some II experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. I Contents Preface ................................................................................................................................................... I 1 Product Overview ............................................................................................................................ 1 1.1 Appearance .............................................................................................................................. 1 1.2 Package Contents .................................................................................................................... 3 1.3 Technical Specifications .......................................................................................................... 3 1.3.1 Size and Weight ........................................................................................................... 3 1.3.2 RF ................................................................................................................................... 4 1.3.3 Ports .............................................................................................................................. 5 1.3.4 Power Supply ................................................................................................................ 5 1.3.5 Environment and Reliability ........................................................................................ 6 1.4 LEDs and Button ...................................................................................................................... 6 1.5 SFP Modules ............................................................................................................................. 7 2 Preparing for Installation ................................................................................................................ 9 2.1 Safety Precautions ................................................................................................................... 9 2.1.1 General Safety Precautions ......................................................................................... 9 2.1.2 Handling Safety ............................................................................................................ 9 2.1.3 Electric Safety ............................................................................................................... 9 II 2.2 Installation Environment Requirements ............................................................................. 10 2.2.1 Bearing Requirements ............................................................................................... 10 2.2.2 Ventilation Requirements ......................................................................................... 10 2.2.3 Space Requirement ................................................................................................... 10 2.2.4 Temperature/Humidity Requirements ..................................................................... 10 2.2.5 Cleanliness Requirements ......................................................................................... 10 2.2.6 Anti-interference Requirements .............................................................................. 11 2.2.7 Lightning Protection Requirements ........................................................................ 12 2.2.8 Inspection of the Installation Site ................................................................................. 12 2.3 Tools ........................................................................................................................................ 12 3 Installing the Access Point ............................................................................…

Text truncated - open the document above for the full version.

Rev 1/26/2023 (Nomadix, Inc. ) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 02-13-2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2A3WK-AP6SA Nomadix, Inc. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) Richard E. Wagner Rev 1/26/2023 (Nomadix, Inc.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 02-13-2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2A3WK-AP6SA Nomadix, Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) Richard E. Wagner

Rev 1/26/2023 (Nomadix, Inc.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 02-22-2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID or Grantee Code: [2A3WK-AP6SA] [Nomadix, Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: FRN: 0031721350 Name: Nomadix, Inc. Address: 21600 Oxnard Street - 19th Floor, Woodland Hills, California, United States Contact Person: Richard E. Wagner Tel.: 818-575-2500 Email: [email protected] Sincerely, [Nomadix, Inc.] [Richard E. Wagner] [Applicant signature]

Nomadix, Inc. Supplier’s Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Manufacturer: Nomadix, Inc. , 21600 Oxnard Street - 19th floor, Woodland Hills, California, United States U.S. Responsible Party: Nomadix, Inc. , 21600 Oxnard Street - 19th floor, Woodland Hills, California, United States Contact Person: Tel.: 818-575-2500 Email: [email protected] Model: AP 6SA Classification: FCC Part 15B We hereby declare that the equipment bearing the trade name and model number specified above was tested conforming to the applicable FCC rule part(s) e.g. 15B and the most accurate measurement standards. We confirm that the necessary steps have been taken and are in force to assure that production units of the same equipment will continue to comply with the Commission’s requirements. 2023-02-22 Richard E. Wagner ------------- -------------------- Date: Signature: FCC ID: 2A3WK-AP6SA

Nomadix, Inc. Declaration of Authorization We Name: Nomadix, Inc. Address: 21600 Oxnard Street - 19th Floor, Woodland Hills, City: California, Country: United Statest Declare that: Name Representative of agent: Ms. Rose Liu Agent Company name: BTL Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification of the following product(s) and signing all the related documents including 731 forms: Product description: Wireless Access Point Type designation: AP 6SA Trademark: FCC ID: 2A3WK-AP6SA on our behalf. Date: 2023-02-09 City: California Name: Richard E. Wagner Function: Manager Signature:

Nomadix, Inc. Date: 2023-02-09 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2A3WK-AP6SA Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description 4. Schematics 5. Block Diagram 6. Operatinal Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature Richard E. Wagner

Nomadix, Inc. Wi-Fi Channel 12 and 13 Declaration Letter Date: 2023-02-09 We, the undersigned company Company Name: Nomadix, Inc. Address: 21600 Oxnard Street - 19th Floor, Woodland Hills, California, United States Declare that: Product description: Wireless Access Point Type designation: AP 6SA Brand: FCC ID: 2A3WK-AP6SA Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: Richard E. Wagner Tel: 818-575-2500 Email: [email protected]

Nomadix, Inc. Ad Hoc Mode Declaration Date: 2023-02-09 We, the undersigned company Company Name: Nomadix, Inc. Address: 21600 Oxnard Street - 19th Floor, Woodland Hills, California, United States Declare that: Product description: Wireless Access Point Type designation: AP 6SA Brand: FCC ID: 2A3WK-AP6SA 1. The EUT doesn’t have Ad Hoc Mode function on “non-US frequencies”. 802.11a/n Ad Hoc mode should not be supported even on US DFS frequencies (5.25 ~5.35GHz/5.47 ~5.725GHz). 2. In addition, the frequency selection feature is disabled by firmware for devices marketed to the US. The product meets all other requirements specified in Part 15E Section 15.407 and no configuration controls are provided to change the frequency of operations outside the grant of certification for US operation. 3. Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: Richard E. Wagner Tel: 818-575-2500 Email: [email protected]

Nomadix, Inc. Declaration Letter Date: 2023-02-09 We, the undersigned company Company Name: Nomadix, Inc. Address: 21600 Oxnard Street - 19th Floor, Woodland Hills, California, United States Declare that: Product description: Wireless Access Point Type designation: AP 6SA Brand: FCC ID: 2A3WK-AP6SA this device with Bridge and Mesh modes of operation are permitted to operate in the DFS band and employ a DFS function. The functionality of the Bridge mode as specified in §15.403(a) and the Mesh mode is validated in the DFS test report by performing a test statistical performance check on any one of the radar types. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: Richard E. Wagner Tel: 818-575-2500 Email: [email protected]

Page 1 of 4 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA APPENDIX PHOTOS OF EUT EXTERNAL PHOTOS EUT Photo EUT Photo Page 2 of 4 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 3 of 4 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo LAN/1G/PoE Console DC 48V Page 4 of 4 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo

Page 1 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA APPENDIX PHOTOS OF EUT INTERNAL PHOTOS EUT Photo EUT Photo 2.4Gwifi Ant1 2.4Gwifi Ant2 5Gwifi Ant2 5Gwifi Ant1 Page 2 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 3 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 4 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo BT Ant BT Ant Page 5 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 6 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 7 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 8 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 9 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 10 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 11 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 12 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 13 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 14 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 15 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo Page 16 of 16 FCC ID: 2A3WK-AP6SA IC: 28037-AP6SA EUT Photo EUT Photo

Report No.: FCC022022-05522RF14 Page 1 of 7 Product Name: Wireless Access Point Report No: FCC022022-05522RF14 Product Model: AP 6SA Security Classification: Open Version: V1.0 Total Page: 7 TIRT Testing Report Prepared By: Checked By: Approved By: Stone Tang Randy Lv Daniel Chen Report No.: FCC022022-05522RF14 Page 2 of 7 FCC RF EXPOSURE REPORT FCC ID: 2A3WK-AP6SA Project No. : 2022-05522 Equipment : Wireless Access Point Brand Name : Test Model : AP 6SA Series Model : N/A Applicant : Nomadix, Inc. Address : 21600 Oxnard Street - 19th floor, Woodland Hills, California, United States Manufacturer : Nomadix, Inc. Address : 21600 Oxnard Street - 19th floor, Woodland Hills, California, United States Date of Receipt : 2022.05.11 Date of Test : 2022.05.13-2022.07.14 2022.09.15-2022.09.28 Issued Date : 2022.10.24 Report Version : V1.0 Test Sample : Engineering Sample No.: 20220421018665 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 • The test result referred exclusively to the presented test model /sample. • Without written approval of TIRT Inc. the test report shall not reproduced except in full. Lab: Beijing TIRT Technology Service Co.,Ltd Shenzhen Add: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China TEL: +86-0755-27087573 Report No.: FCC022022-05522RF14 Page 3 of 7 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note FCC022022-05522RF14 R00 Original Report 2022.10.24 Valid Report No.: FCC022022-05522RF14 Page 4 of 7 1. TEST FACILITY Company: Beijing TIRT Technology Service Co.,Ltd Shenzhen Address: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China CNAS Registration Number: CNAS L14158 A2LA Registration Number: 6049.01 FCC Accredited Lab. Designation Number: CN1309 FCC Test Firm Registration Number: 825524 Telephone: +86-0755-27087573 Report No.: FCC022022-05522RF14 Page 5 of 7 2. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna For LE: Antenna Specification: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Internal N/A 2.14 Note: The antenna gain is provided by the manufacturer. For 2.4GHz: Antenna Specification: Ant. Brand P/N Antenna Type Connector Gain (dBi) 1 NDS-2.4G-WX-21 PIFA RF Generation Terminal 113 4.39 2 NDS-2.4G2-WX-21 PIFA RF Generation Terminal 113 2.75 Note: 1) This EUT supports CDD, and all antenna gains are not equal, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=4.39. For power spectral density measurements, N ANT =2, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=4.39+10log(2/1)dBi=7.40. 2) The antenna gain is provided by the manufacturer. Table for Antenna Configuration: Operating Mode TX Mode 2TX IEEE 802.11b V(Ant. 1 + Ant. 2) IEEE 802.11g V(Ant. 1 + Ant. 2) IEEE 802.11n(HT20) V(Ant. 1 + Ant. 2) IEEE 802.11n(HT40) V(Ant. 1 + Ant. 2) IEEE 802.11ax(HE20) V(Ant. 1 + Ant. 2) IEEE 802.11ax(HE40) V(Ant. 1 + Ant. 2) Report No.: FCC022022-05522RF14 Page 6 of 7 For 5GHz: Antenna Specification: Ant. Brand P/N Antenna Type Connector Gain (dBi) 1 NDS-5G-WX-21 PIFA RF Generation Terminal 113 3.62 2 C168-JL-3917 PIFA IPEX 4.67 Note: 1) This EUT supports CDD, and all antenna gains are not equal, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=4.67. For power spectral density measurements, N ANT =2, N SS = 1. Then the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=4.67+10log(2/1)dBi=7.68. 2) The antenna gain is provided by the manufacturer. Table for Antenna Configuration: Operating Mode TX Mode 2TX IEEE 802.11a V (Ant. 1 + Ant. 2) IEEE 802.11n(HT20) V (Ant. 1 + Ant. 2) IEEE 802.11n(HT40) V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT20) V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT40) V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT80) V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT160) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE20) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE40) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE80) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE160) V (Ant. 1 + Ant. 2) Report No.: FCC022022-05522RF14 Page 7 of 7 3. TEST RESULTS For BT LE: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.14 1.6368 8.35 6.8391 0.00223 1 Complies For 2.4GHz: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 4.39 2.7479 20.35 108.3927 0.05929 1 Complies For 5GHz: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 4.67 2.9309 17.79 60.1174 0.03507 1 Complies For the max simultaneous transmission MPE: Ratio Total Limit of Ratio Test Result BT LE 2.4GHz 5GHz 0.00223 0.05929 0.03507 0.09659 1 Complies Note: The calculated distance is 20 cm. End of Test Report

Report No.: FCC022022-05522RF1 Page 1 of 110 Product Name: Wireless Access Point Report No: FCC022022-05522RF1 Product Model: AP 6SA Security Classification: Open Version: V1.0 Total Page: 110 TIRT Testing Report Prepared By: Checked By: Approved By: Stone Tang Randy Lv Daniel Chen Report No.: FCC022022-05522RF1 Page 2 of 110 FCC Radio Test Report FCC ID: 2A3WK-AP6SA This report concerns: Original Grant Project No. : 2022-05522 Equipment : Wireless Access Point Brand Name : Test Model : AP 6SA Series Model : N/A Applicant : Nomadix, Inc. Address : 21600 Oxnard Street - 19th floor, Woodland Hills, California, United States Manufacturer : Nomadix, Inc. Address : 21600 Oxnard Street - 19th floor, Woodland Hills, California, United States Date of Receipt : 2022.05.11 Date of Test : 2022.05.13-2022.07.14 Issued Date : 2022.10.24 Report Version : V1.0 Test Sample : Engineering Sample No.: 20220421018665 Standard(s) : FCC CFR Title 47, Part 15, Subpart C FCC KDB 558074 D01 15.247 Meas Guidance v05r02 FCC KDB 662911 D01 Multiple Transmitter Output v02r01 ANSI C63.10-2013 • The test result referred exclusively to the presented test model /sample. • Without written approval of TIRT Inc. the test report shall not reproduced except in full. Lab: Beijing TIRT Technology Service Co.,Ltd Shenzhen Add: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China TEL: +86-0755-27087573 Report No.: FCC022022-05522RF1 Page 3 of 110 Table of Contents Page REPORT ISSUED HISTORY 5 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST LOCATION 7 1.2 MEASUREMENT UNCERTAINTY 7 1.3 TEST ENVIRONMENT CONDITIONS 7 2 . GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 10 2.3 PARAMETERS OF TEST SOFTWARE 12 2.4 DUTY CYCLE 13 2.5 SUPPORT UNITS 15 3 . AC POWER LINE CONDUCTED EMISSIONS 16 3.1 LIMIT 16 3.2 TEST PROCEDURE 16 3.3 DEVIATION FROM TEST STANDARD 16 3.4 TEST SETUP 17 3.5 EUT OPERATION CONDITIONS 17 3.6 TEST RESULTS 17 4 . RADIATED EMISSIONS 18 4.1 LIMIT 18 4.2 TEST PROCEDURE 19 4.3 DEVIATION FROM TEST STANDARD 20 4.4 TEST SETUP 20 4.5 EUT OPERATION CONDITIONS 21 4.6 TEST RESULTS - 9 KHZ TO 30 MHZ 21 4.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 21 4.8 TEST RESULTS - ABOVE 1000 MHZ 21 5 . BANDWIDTH 22 5.1 LIMIT 22 5.2 TEST PROCEDURE 22 5.3 DEVIATION FROM STANDARD 22 5.4 TEST SETUP 22 5.5 EUT OPERATION CONDITIONS 22 5.6 TEST RESULTS 22 Report No.: FCC022022-05522RF1 Page 4 of 110 Table of Contents Page 6 . MAXIMUM OUTPUT POWER & E.I.R.P. 23 6.1 LIMIT 23 6.2 TEST PROCEDURE 23 6.3 DEVIATION FROM STANDARD 23 6.4 TEST SETUP 23 6.5 EUT OPERATION CONDITIONS 23 6.6 TEST RESULTS 23 7 . CONDUCTED SPURIOUS EMISSIONS 24 7.1 LIMIT 24 7.2 TEST PROCEDURE 24 7.3 DEVIATION FROM STANDARD 24 7.4 TEST SETUP 24 7.5 EUT OPERATION CONDITIONS 24 7.6 TEST RESULTS 24 8 . POWER SPECTRAL DENSITY 25 8.1 LIMIT 25 8.2 TEST PROCEDURE 25 8.3 DEVIATION FROM STANDARD 25 8.4 TEST SETUP 25 8.5 EUT OPERATION CONDITIONS 25 8.6 TEST RESULTS 25 9 . MEASUREMENT INSTRUMENTS LIST 26 10 . EUT TEST PHOTO 27 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 32 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 35 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 37 APPENDIX D - RADIATED EMISSION- ABOVE 1000 MHZ 40 APPENDIX E - BANDWIDTH 77 APPENDIX F - MAXIMUM OUTPUT POWER 84 APPENDIX G - CONDUCTED SPURIOUS EMISSIONS 91 APPENDIX H - POWER SPECTRAL DENSITY 104 Report No.: FCC022022-05522RF1 Page 5 of 110 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note FCC022022-05522RF1 V1.0 Original Report. 2022.10.24 Valid Report No.: FCC022022-05522RF1 Page 6 of 110 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC CFR Title 47, Part 15, Subpart C Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX E PASS ------ 15.247(b)(3) Maximum Output Power APPENDIX F PASS ------ 15.247(d) Conducted Spurious Emissions APPENDIX G PASS ------ 15.247(e) Power Spectral Density APPENDIX H PASS ------ 15.203 Antenna Requirement ------ PASS Note(2) Note: (1) “N/A” denotes test is not applicable in this test report. (2) The device what use a permanently attached antenna were considered sufficient to comply with the provisions of 15.203. Report No.: FCC022022-05522RF1 Page 7 of 110 1.1 TEST LOCATION Company: Beijing TIRT Technology Service Co.,Ltd Shenzhen Address: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China CNAS Registration Number: CNAS L14158 A2LA Registration Number: 6049.01 FCC Accredited Lab. Designation Number: CN1309 FCC Test Firm Registration Number: 825524 Telephone: +86-0755-27087573 1.2 MEASUREMENT UNCERTAINTY ISO/IEC 17025 requires that an estimate of the measurement uncertainties associated with the emissions test results be included in the report. The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)) The TIRT measurement uncertainty as below table: Uncertainty Parameter Uncertainty Occupied Channel Bandwidth ±142.12 kHz RF power conducted ±0.74 dB RF power radiated ±3.25 dB Spurious emissions, conducted ±1.78 dB Spurious emissions, radiated (30MHz~1GHz) ±4.6 dB Spurious emissions, radiated (1GHz~18GHz) ±4.9 dB Conduction Emissions(150kHz~30MHz) ±3.1 dB Humidity ±4.6 % Temprature ±0.7 °C Time ±1.2 % Note: Unless specifically mentioned, the uncertainty of measurement has not been taken into account to declare the compliance or non-compliance to the specification. 1.3 TEST ENVIRONMENT CONDITIONS Test Item Temperature Humidity Test Voltage Tested By AC Power Line Conducted Emissions 25°C 56% AC 120V/60Hz Stone Tang Radiated Emissions-9kHz to 30 MHz 24°C 62% PoE 48V Stone Tang Radiated Emissions-30MHz to 1000MHz 24°C 54% PoE 48V Stone Tang Radiat…
