2A482-WM02PROBaseus True Wireless Earphones

دليل المستخدم 取扱説明書 | Wireless Baseus Bowie WM02+ 制造商： 深圳市倍思科技有限公司 地址：深圳市龙岗区坂田街道岗头社区雪岗路2008号倍思智能园B栋二层 执行标准： GB 4943.1-2011 热线： 4000-712-711 网址： www.baseus.com Manufacturer: Shenzhen Baseus Technology Co., Ltd. Add: 2th Floor, Building B, Baseus Intelligence Park, No.2008, Xuegang Rd, Gangtou Community, Bantian Street, Longgang District, Shenzhen Hotline: +86-4000-712-711 Website: www.baseus.com PB3745Z-P0A0 1000051954 倍思设计/Designed by Baseus 中国制造/Made in China Warning

C5266091_X24_Ed.1 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Baseus Technology Co., Ltd. Grantee code: 2A482 FCC ID: 2A482-WM02PRO Contact Name: Zhang Mao Address: 2nd Floor, Building B, Baseus Intelligence Park, No.2008, Xuegang Rd, Gangtou Community, Bantian Street, Longgang District, Shenzhen. Telephone No: +86-18818848769 Fax No: +86-18098946792 Email: [email protected] i. [Shenzhen Baseus Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Baseus Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Date: 2.14.2023 Applicant’s Name: Zhang Mao Title: Certified Engineer Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C566091_X23_Ed1 1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: Oasis Compliance, Inc. FRN: 0033464157 Contact Name: James He Address: 3313 Verdi Dr, San Jose, CA 95111 Telephone Email: [email protected] Grantee code: FCC ID: Contact Name: This letter is to confirm that the US Agent for Service of Processaccepts responsibility to act as a local representativeon behalf of Shenzhen Baseus Technology Co., Ltd. TheUS Agent for Service of Processisaware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84,and clause § 2.911. Applicant: Company name: Shenzhen Baseus Technology Co., Ltd. Product Description: Baseus True Wireless Earphones Address: 2A482 2A482-WM02PRO Zhang Mao 2nd Floor, Building B, Baseus Intelligence Park, No.2008, Xuegang Rd, Gangtou Community, Bantian Street, Longgang District, Shenzhen. +86-18818848769 Telephone No: Email:[email protected] The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. This Agreement is valid until (product lifetime). US Agent for Service of Process’s Name: Applicant’s Name: Date:2.14.2023 Zhang Mao James He Title: Certified Engineer Title: Global Market Access Manager Signature Signature

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Shenzhen Baseus Technology Co., Ltd. Address: 2nd Floor, Building B, Baseus Intelligence Park, No.2008, Xuegang Rd, Gangtou Community, Bantian Street, Longgang District, Shenzhen. Product Name: Baseus True Wireless Earphones Model Number: Baseus Bowie WM02+ FCC Identifier: 2A482-WM02PRO We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Zhang Mao Date: 2/14/2023 Title: Certified Engineer Signature of applicant:

C5266091_X10_Ed.2 1/1 Shenzhen Baseus Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2/14/2023 Subject: Request for Confidentiality FCC ID: 2A482-WM02PRO To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Zhang Mao Title: Certified Engineer

Page 1 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - EUT Photos Model: Baseus Bowie WM02+ Page 2 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 4 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 5 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ----End of Report----

Shenzhen Baseus Technology Co., Ltd. version02 2/14/2023 Dear Sirs: We hereby declare that because the earphone size is too small, the FCC ID number is printed on the User Manual, hereby declare. FCC ID: 2A482-WM02PRO Sincerely, Signature: Name: Zhang Mao Title: Certified Engineer Company: Shenzhen Baseus Technology Co., Ltd.

Page 1 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - EUT Photos Model: Baseus Bowie WM02+ Page 2 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ----End of Report---- ANT

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] RF EXPOSURE Test Report Report No.: MTi230202002-01E2 Date of issue: 2023-02-13 Applicant: Shenzhen Baseus Technology Co., Ltd. Product name: Baseus True Wireless Earphones Model(s): Baseus Bowie WM02+ FCC ID: 2A482-WM02PRO Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 6- Report No.: MTi230202002-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. The report shall not be partially reproduced without the written consent of the laboratory; 2. The test results of this report are only responsible for the samples submitted; 3. This report is invalid without the seal and signature of the laboratory; 4. This report is invalid if transferred, altered or tampered with in any form without authorization; 5. Any objection to this report shall be submitted to the laboratory within 15 days from the date of receipt of the report. - Page 3 of 6- Report No.: MTi230202002-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] TEST RESULT CERTIFICATION Applicant’s name ............ Shenzhen Baseus Technology Co., Ltd. Address .......................... 2nd Floor, Building B, Baseus Intelligence Park, No.2008, Xuegang Rd, Gangtou Community, Bantian Street, Longgang District, Shenzhen. Manufacturer's Name ..... Shenzhen Baseus Technology Co., Ltd. Address .......................... 2nd Floor, Building B, Baseus Intelligence Park, No.2008, Xuegang Rd, Gangtou Community, Bantian Street, Longgang District, Shenzhen. Product description Product name ................... Baseus True Wireless Earphones Trademark ..................... Baseus Model Name .................. Baseus Bowie WM02+ Series Model .................. N/A Standards ....................... N/A Test procedure ............... KDB 447498 D01 v06 Date of Test Date (s) of performance of tests ............ : 2023-02-06 ~ 2023-02-13 Test Result ............................................. : Pass Testing Engineer : (Yanice Xie) Technical Manager : (Leon Chen) Authorized Signatory : (Tom Xue) - Page 4 of 6- Report No.: MTi230202002-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of Contents 1. STANDALONE SAR TEST EXCLUSION CONSIDERATIONS ............................................................................................ 5 2. SAR TEST EXCLUCSION THRESHOLDS ........................................................................................................................ 6 - Page 5 of 6- Report No.: MTi230202002-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] 1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance defined in 4.1 f) is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified, typically in the SAR measurement or SAR analysis report, by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting are required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions. a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where  f (GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison  The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determ…

Text truncated - open the document above for the full version.

Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230202002-01E1 Date of issue: 2023-02-13 Applicant: Shenzhen Baseus Technology Co., Ltd. Product: Baseus True Wireless Earphones Model(s): Baseus Bowie WM02+ FCC ID: 2A482-WM02PRO Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 56 Report No.: MTi230202002-01E1 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 56 Report No.: MTi230202002-01E1 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of contents 1 General Description ........................................................................................................................ 5 1.1 Description of the EUT ....................................................................................................................................... 5 1.2 Description of test modes ................................................................................................................................... 5 1.3 Test conditions .................................................................................................................................................... 7 1.4 Description of support units ................................................................................................................................ 7 2 Measurement uncertainty ............................................................................................................... 8 3 Summary of Test Result .................................................................................................................. 9 4 Test Laboratory ............................................................................................................................. 10 5 Equipment List .............................................................................................................................. 11 6 Test Result ..................................................................................................................................... 12 6.1 Antenna requirement ........................................................................................................................................ 12 6.2 AC power line conducted emissions................................................................................................................. 13 6.3 Radiated spurious emission ............................................................................................................................. 14 6.4 20dB emission bandwidth ................................................................................................................................ 23 6.5 Maximum conducted output power .................................................................................................................. 24 6.6 Carrier frequency separation ............................................................................................................................ 25 6.7 Time of occupancy............................................................................................................................................ 26 6.8 Number of hopping channels ........................................................................................................................... 27 6.9 Band edge (Conducted) ................................................................................................................................... 28 6.10 Conducted spurious emissions ...................................................................................................................... 29 Appendix A: 20dB Emission Bandwidth ............................................................................................. 30 Appendix B: Maximum conducted output power ............................................................................... 33 Appendix C: Carrier frequency separation ......................................................................................... 36 Appendix D: Time of occupancy ......................................................................................................... 38 Appendix E: Number of hopping channels......................................................................................... 43 Appendix F: Band edge measurements .............................................................................................. 45 Appendix G: Conducted Spurious Emission ...................................................................................... 48 Photographs of the Test Setup ............................................................................................................ 55 Photographs of the EUT....................................................................................................................... 56 Page 4 of 56 Report No.: MTi230202002-01E1 Address: 101, No.7, Zone 2, Xinxing Industri…

Text truncated - open the document above for the full version.

版本： A0 环保标准： RoHS2.0 REACH EC16P 版本 A0 公司名称： 地 址： 邮 编： 联系电话： 联系人： E-mail: 保存年限：2年 表单编号：MX-SIP0010-05 送样确认 M6-6976D8 1.11.99770139 盖 章 客户名称 客户品名 客户料号 产品编号 变更履历 深圳市宝安区新安街道留仙二路 美生创谷科技园 夏谷 504-505 室 13691823164 徐水 [email protected] 日 期制 订审 核核 准 供应商信息： 深圳市艾特诺通讯设备有限公司 客户承认 日 期零 件 承 认审 核核 准 零 件 承 认 书 东莞市思行智能设备制造有限公司 变更单号变更原因变更内容 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.LTD 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.,LTD 承 认 书 SPECIFICATION FOR APPROVL 客 户： CUSTOMER： 思行 客 户 编 号： CUSTOMER P/N： M6-6976D8 本 厂 编 号： OUR MODEL NO： ATN1311 规 格： SPECIFICATIONS： 2.4G-2.48G 样 品 数： Q’TY： 1 SET 日 期： DATE： 20 22.03.21 深圳市艾特诺通讯设备有限公司 客户 工程 Engineering 品保 Quality 核准 Approved 工程 Engineering 品保 Quality 核准 Approved 地址：深圳市宝安区新安街道留仙二路美生创谷科技园夏谷504-505室 电话：0755-29308863 传真：0755-29308861 Page 1 Version：1.0 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.LTD 目 录 封面 .................................... 1 目录 .................................... 2 一、测试设备 .................................... 3 二、产品规格 .................................... 4 三、匹配电路 .................................... 4 四、性能测试数据 .................................... 5 五、装配要求 .................................... 7 六、工程图纸 .................................... 8 七、盐雾测试报告 .................................... 9 八、样品尺寸检测报告 .................................... 10 九、包装方式 .................................... 11 变更记录 发行/变更日期 变更原因 变更内容 版本 备注 2022.03.21 新版发行 新版发行 V1.0 Page 2 Version：1.0 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.LTD 一、测试设备 1. 网络分析仪（Network Analyzers） Agilent Technologies E5071B 2. 综合测试仪 （Communications Test Set） CMW500 3. 3D暗室测试系统 （3D Chanber Test System） Page 3 Version：1.0 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.LTD 二、产品规格 1、材料&物料性能Material&Mechanical Characteristics 材料Material FPC 尺寸Dimension mm 2、储存和使用温度 使用温度 Operation Temperature -20°C~+80°C 储存温度Storage Temperature -20°C~+80°C 三、匹配电路 Page 4 Version：1.0 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.LTD 四、性能测试数据 4.1 S11 Parameter 4.2 Gain&Efficiency Page 5 Version：1.0 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.LTD 4.2.1 Radiation patten Page 6 Version：1.0 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.LTD 4.3 OTA测试数据 4.4 实测距离 五、装配要求 Page 7 Version：1.0 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.LTD 六、工程图纸 Page 8 Version：1.0 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.LTD 七、盐雾测试报告 项目 M6 品名： 蓝牙天线 试样情况 试样数量：5PCS 基材：单面/一对半/电解铜 沉层：沉黄金≥1U" 试验条件 盐溶液：5% PH:7.0 箱内温度：35°C 相对湿度：5% 喷雾方式： ■ 连续 □ 间歇 压缩空气压力：1kg/cm² 盐雾沉降率： 雾液收集：PH7.0nac 试验周期：__1__个循环 喷雾时间： 24 h 试验结果 试验后的外观：外观完整无损，无明显变化。 镀层：无剥落、无锈蚀 表面喷涂、丝印：无脱落、无气泡。 说明： 1、盐雾试验作业标准依照中华人民共和国国家标准GB/T2423.17-2008执行 2、试件结果判定标准依照中华人民共和国国家标准GB/T6461-02执行 Page 9 Version：1.0 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.LTD 八、样品尺寸检测报告 深圳市艾特诺通讯设备有限公司 尺寸检验报告 文件编号：FWF-FM-QC-019 Ver.:1.0 项目：M6 品名： 蓝牙天线 类别：FPC 数量：5 个 日期：2022.03.14 检验依据标准： ■工程图纸 □标准样板 □限度样品 □其它 检验项目 样品测验值 判定 结果 备注 1 2 3 4 5 外观 检验 1、油污等 √ √ √ √ √ OK 2、划痕、压伤等 √ √ √ √ √ OK 3、其它 尺寸 检验 1 14.06±0.15 14.08 14.12 14.1 14.12 14.14 OK 2 8.06±0.15 8.12 8.1 8.14 8.12 8.12 OK 3 4.27±0.15 4.3 4.3 4.28 4.34 4.34 OK 4 2.17±0.15 2.12 2.1 2.14 2.12 2.12 OK 5 0.7±0.15 0.66 0.64 0.66 0.68 0.64 OK 6 4.0±0.15 3.94 3.96 3.98 3.96 3.96 OK 7 2.89±0.15 2.84 2.86 2.84 2.88 2.86 OK 8 5.8±0.15 5.76 5.78 5.74 5.76 7.78 OK 制作：刘子龙 Page 10 Version：1.0 深圳市艾特诺通讯设备有限公司 SHENZHEN ATN COMMUNICATION EQUIPMENT CO.LTD 九、包装方式 深圳市艾特诺通讯设备有限公司 产品包装 品名规格：M6 版本：V1.0 页码：1/1 1.离型纸隔层摆放保护天线 2.密封袋封装效果(100张/包) 3.纸箱封箱效果（贴出货标签和ROHS标签） 制作：刘子龙 Page 11 Version：1.0

Page 1 of 1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - Test Setup Photos Model: Baseus Bowie WM02+ Radiated emissions –Below 1 GHz Radiated emissions –Above 1 GHz ----End of Report----
