2A4A7-PTM-301Smart pet feeder

Manual Feeding WiFi icon Malfunction Icon status Indicate Red+flashing White+steady on White light+flashing Wait-to-connect Connected network Network fault Manual feeding Settings 2. Select the number of servings, then click the "Feed" option, and the feeder will p- -roduce 8 servings. 3. To activate the feeder, first press and hold the unlock button for 3 seconds. Then, press the RESET icon to the right and hold it for 5 seconds, and you'll notice that the WIFI icon will turn red and start flashing. Note: If you are using the battery as the sole power source for the feeder, the battery icon will be displayed. 4, in the app, find the "+" symbol on the right and click on it to add a new feeder to your account. 5. In the app, use the "Add Device" function to search for devices. Search for the device and click the "Add" button to continue. 6, when you connect to the network for the first time or switch to a new Wi-Fi network, you will be prompted to enter your Wi-Fi password. Please enter your password in the fields provided and click the "Next" button to continue. 7. Wait for the connection. The first conne- -ction is slow. 8. After the connection is successfully established, click Finish to complete the connection. You'll notice that the WIFI icon on the device will turn white and stop blinking. Attention: When connecting the console to a power outlet, please note that the middle menu bar of the device will automatically display for 10 seconds without user interaction. When the b- -attery is used as the only power supply, the entire screen will turn black after 30 seconds, to reactivate the screen, only need any button of the motor, it will light up again, it is rec- -ommended to use the power cord to connect the product for the first time. 3 3 3 Display function description Warranty Precautions for use Problem Solution Check whether the power cable is properly connected The feeder doesn't work Pause the battery and use the charging cable to see if it can continue to work Unplug the cord, use the new battery, see if it works No screen responseHold down for 3 seconds to unlock the display Check that the storage drum and outlet are kept dry Check that food is kept dry. Do not use wet food lf you are not using the power cord, replace the battery Machine card or display is not bright Product parameter Model Size Capacity 6 servings about 55gWeight Material Input Food Adapter Dry food and diameter less than 1.2CM You are advised to use a cable or spare battery 262X182.8 X182.8 mm 3 Remove the feeder and remove all accessories 4. Put the machine in position and lift the front side of the machine. Insert the plastic food bowl Install the machine. 5. Pour in dry pet food, pay attention to the size of 4-12mm, Do not put wet food and dry food that exceeds the size 6. After filling the pet food, rotate and close the lid Pr oduct assembly 3. Tur n the machine upside down, insert the charging cable into the bottom of the machine, if you need to use the batter y,Install 4 # 5 batteries as shown Note: Spar e batteries are not included in the package P TM-301 Instructions Smart Pet Feeder Unlock/lock Confirm/unlock Right buttonLeft button Batter y icon, The batter y icon is only available Displays when using batter y 1.If no operation is performed within 30 seconds, the screen will be locked 2. Hold down the release button for 3 seconds to unlock the feeder 1. Remove the charging cable before cleaning. 2. Open the grain storage bin, take it down, and pour out the remaining cat food. 4. Clean the food basin, grain storage bucket, stainless steel bowl and bowl holder. Product cleaning 1.Rotate the grain drum and the mixing base as shown in the figure 2.Rotate the grain drum and install the machine base according to the figure A 5. The base of the machine can only be cleaned with a soft dry cloth, and these parts are not waterproofThen air dry or wipe dry. 3. Press the A key as shown, rotate and remove the grain storage bucket 1, this feeder is recommended for pets over 6 months old. 2, this feeder is designed for indoor use only, to avoid direct sunlight and away from any potential fire or heat source. 3, please use the adapter provided with this product to power the feeder. Using any other adapter may result in machine failure or damage. 4, do not immerse the host in water or other liquids, it is important to keep the host dry. 5, In order to prevent pets from knocking over the feeder, it is recommended to place it against a wall or in a safe location. 6, children should use the feeder under adult supervision and guidance to ensure safe operation. 7. If the desiccant bag is found damaged, please stop using it immediately. Contact us for a replacement desiccant bag. 8, If you decide to stop using the feeder, remember to unplug the power cord and remove the battery located at the bottom of the feeder. stainless steel Connect APP The feeder supports 2.4GHz System requirementiPhone with iOS 10.0 or later, smartphone with Android 5.0 or later. Note: Install APP and complete account registration, authorization is required. After entering your mobile number/email address, you will receive a verification code, which must be entered before proceeding with setting your account password. 2, confirm that the Bluetooth function on the phone is turned on, then connect the phone to the Wi-Fi network and enable the GPS location service.2, confirm that the Bluetooth function on the phone is turned on, then connect the phone to the Wi-Fi network and enable the GPS location service. 1. After the phone is connected, the Settings menu will be opened automatically. Timed feeding setting 1, click the "feeding plan" option to enter the setting interface.Click the "Add" op- -tion to set the feeding schedule. 2 Select the number of feedings required during the week, select the feeding time, and specify the portion size for each fe- -eding After setting the feeding time, you will be given a schedule, as shown below: You can set the…

Text truncated - open the document above for the full version.

Shenzhen Ipetmon Creative Technology Co., Ltd. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Shenzhen Ipetmon Creative Technology Co., Ltd. Address: Complete set of Building 10,Meibao Industrial Zone, Liantang Industrial Zone, Shangcun Community, Gongming Street, Guangming District, Shenzhen, China Product Name: Smart pet feeder FCC ID: 2A4A7-PTM-301 Model(s): PTM-301, PTM-311, PTM-321, PTM-331, PTM-341, PTM-351, PTM-361 2.911(d)(5)(i) Equipment Type We, [Shenzhen Ipetmon Creative Technology Co., Ltd.] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Deng Kaiqi Date: Jan. 27, 2024 Title and Company name: Manager; Shenzhen Ipetmon Creative Technology Co., Ltd. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen Ipetmon Creative Technology Co., Ltd. 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen Ipetmon Creative Technology Co., Ltd. Address: Complete set of Building 10,Meibao Industrial Zone, Liantang Industrial Zone, Shangcun Community, Gongming Street, Guangming District, Shenzhen, China Product Name: Smart pet feeder FCC ID: 2A4A7-PTM-301 Model(s): PTM-301, PTM-311, PTM-321, PTM-331, PTM-341, PTM-351, PTM-361 2.911(d)(5)(ii) Applicant filing We, [Shenzhen Ipetmon Creative Technology Co., Ltd.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Deng Kaiqi Date: Jan. 27, 2024 Title and Company name: Manager; Shenzhen Ipetmon Creative Technology Co., Ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen Ipetmon Creative Technology Co., Ltd. Agent Authorization Company: Shenzhen Ipetmon Creative Technology Co., Ltd. Address: Complete set of Building 10,Meibao Industrial Zone, Liantang Industrial Zone, Shangcun Community, Gongming Street, Guangming District, Shenzhen, China Product Name: Smart pet feeder Model Number(s): PTM-301, PTM-311, PTM-321, PTM-331, PTM-341, PTM-351, PTM-361 Product Description: Smart pet feeder We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Jan. 27, 2024 Name: Deng Kaiqi Title: Manager Company: Shenzhen Ipetmon Creative Technology Co., Ltd.

< Shenzhen Ipetmon Creative Technology Co., Ltd. > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD21046 Date: Jan. 27, 2024 Subject; Request for Long Term Confidentiality FCC ID: 2A4A7-PTM-301 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Deng Kaiqi Title: Manager

Model Difference Declaration To Whom It May Concern, We, Shenzhen Ipetmon Creative Technology Co., Ltd. Product name: Smart pet feeder Trade name: N/A Model name: PTM-301, PTM-311, PTM-321, PTM-331, PTM-341, PTM-351, PTM-361 All model’s the function, software and electric circuit are the same, only with a product color and model named different. Test sample model: PTM-301. Please contact me if you have any question. Name: Deng Kaiqi Date: Jan. 27, 2024 Title: Manager Signature of applicant:

Model: PTM-301 Model: PTM-301 Model: PTM-301 Model: PTM-301

FCC ID LABEL: Label Location: FCC ID: 2A4A7-PTM-301

Model: PTM-301 Model: PTM-301 Model: PTM-301 Model: PTM-301 PCB Antenna Model: PTM-301

MPE ESTIMATION FCC ID: 2A4A7-PTM-301 1. Limit for General Population/Uncontrolled Exposures Frequency Power Density(mW/cm2) Averaging Time(minutes) 300MHz-1.5GHz F/1500 30 1.5GHz-100GHz 1.0 30 Note: F= Frequency in MHz 2. Estimation Result BLE: Frequency (MHz) Reading result (dBμV) EIRP(dBm) Max Tune Up Power (mW) MPE (mW/cm²) Power Density (mW/cm2) Limit Result 2402 102.01 6.81 4.797 0.000955 1.0 PASS Note: Note: The estimation distance is 20cm. Note: Reading result see the test report UNIA24010236ER-61. EIRP= Reading result - 95.2 WIFI2.4G: Mode AV Output Power(dBm) Tune Up Power(dBm) Tune Up Power(mW) Antenna Gain(dBi) Antenna Gain (linear) MPE (mW/cm²) 11b 12.10 12±1(13) 16.218 2.54 1.7947 0.005793 11g 8.91 9±1(10) 7.780 2.54 1.7947 0.002779 11n/HT20 6.73 7±1(8) 4.710 2.54 1.7947 0.001683 Note: Note: The estimation distance is 20cm. Note: AV Output power=conducted power. Conducted power see the test report UNIA23101336ER-62, antenna gain=2.54dBi. ------The End------

Page 1 of 75 Report No.: UNIA24010236ER-62 FCC RADIO TEST REPORT FCC ID: 2A4A7-PTM-301 Sample : Smart pet feeder Trade Mark : N/A Main Model : PTM-301 Additional Model : PTM-311, PTM-321, PTM-331, PTM-341, PTM-351, PTM-361 Report No. : UNIA24010236ER-62 Prepared for Shenzhen Ipetmon Creative Technology Co., Ltd. Complete set of Building 10,Meibao Industrial Zone, Liantang Industrial Zone, Shangcun Community, Gongming Street, Guangming District, Shenzhen, China Prepared by Shenzhen United Testing Technology Co., Ltd. D101&D401, No. 107, Kaicheng High-Tech Park, Taoyuan Community, Dalang Sub-District, Longhua District, Shenzhen, Guangdong, China Page 2 of 75 Report No.: UNIA24010236ER-62 TEST RESULT CERTIFICATION Applicant ............................... : Shenzhen Ipetmon Creative Technology Co., Ltd. Address .................................. : Complete set of Building 10,Meibao Industrial Zone, Liantang Industrial Zone, Shangcun Community, Gongming Street, Guangming District, Shenzhen, China Manufacturer ........................ : Shenzhen Ipetmon Creative Technology Co., Ltd. Address .................................. : Complete set of Building 10,Meibao Industrial Zone, Liantang Industrial Zone, Shangcun Community, Gongming Street, Guangming District, Shenzhen, China Product description Product ................................... : Smart pet feeder Trade Mark ............................. : N/A Model Name ........................... : PTM-301, PTM-311, PTM-321, PTM-331, PTM-341, PTM-351, PTM-361 Test Methods ........................ : FCC Rules and Regulations Part 15 Subpart C Section 15.247 ANSI C63.10: 2013 This device described above has been tested by Shenzhen United Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval, this document may be altered or revised by Shenzhen United Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : Jan. 04, 2024 ~ Feb. 05, 2024 Date of Issue .......................................... : Feb. 07, 2024 Test Result ............................................. : Pass Prepared by: Jason Ye/Editor Reviewer: Kelly Cheng/Supervisor Approved & Authorized Signer: Liuze/Manager Page 3 of 75 Report No.: UNIA24010236ER-62 Table of Contents Page 1 TEST SUMMARY 5 1.1 TEST PROCEDURES AND RESULTS 5 1.2 TEST FACILITY 6 1.3 MEASUREMENT UNCERTAINTY 7 1.4 ENVIRONMENTAL CONDITIONS 7 2 GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 CARRIER FREQUENCY OF CHANNELS 9 2.3 TEST MODE 9 2.4 DESCRIPTION OF THE TEST MODES 9 2.5 TEST SETUP 10 2.6 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 10 2.7 MEASUREMENT INSTRUMENTS LIST 11 3 CONDUCTED EMISSION 12 3.1 TEST LIMIT 12 3.2 TEST SETUP 12 3.3 TEST PROCEDURE 13 3.4 TEST RESULT 13 4 RADIATED EMISSION 16 4.1 TEST LIMIT 16 4.2 TEST SETUP 17 4.3 TEST PROCEDURE 18 4.4 TEST RESULT 18 5 BAND EDGE 30 5.1 TEST LIMIT 30 5.2 TEST SETUP 30 5.3 MEASUREMENT EQUIPMENT USED 30 5.4 TEST PROCEDURE 30 5.5 TEST RESULT 30 6 6dB BANDWIDTH 37 6.1 TEST LIMIT 37 6.2 TEST PROCEDURE 37 6.3 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) 37 6.4 MEASUREMENT EQUIPMENT USED 37 6.5 TEST RESULT 37 Page 4 of 75 Report No.: UNIA24010236ER-62 Table of Contents Page 7 POWER SPECTRAL DENSITY 44 7.1 TEST LIMIT 44 7.2 TEST PROCEDURE 44 7.3 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) 44 7.4 EQUIPMENT USED 44 7.5 TEST RESULT 44 8 AVERAGE OUTPUT POWER 51 8.1 TEST LIMIT 51 8.2 TEST PROCEDURE 51 8.3 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) 51 8.4 EQUIPMENT USED 51 8.5 TEST RESULT 52 9 OUT OF BAND EMISSIONS 60 9.1 TEST LIMIT 60 9.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) 60 9.3 TEST PROCEDURE 60 9.4 MEASUREMENT EQUIPMENT USED 60 9.5 TEST RESULT 60 10 ANTENNA REQUIREMENT 73 11 PHOTO OF TEST 74 Page 5 of 75 Report No.: UNIA24010236ER-62 1 TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS Note: “N/A” denotes test is not applicable in this Test Report. Item FCC Rules Description Of Test Result 1 FCC Part 15.207 Conducted Emission Pass 2 FCC Part 15.209(a) Radiated Emission Pass 3 FCC Part 15.247(d) Band Edge Pass 4 FCC Part 15.247(a)(2) Occupied Bandwidth Pass 5 FCC Part 15.247(e) Power Spectral Density Pass 6 FCC Part 15.247(b) Average Output Power Pass 7 FCC Part 15.247(d) Out Of Band Emissions Pass 8 FCC Part 15.247(d) Conducted Spurious Emission Pass 9 FCC Part 15.203 Antenna Requirement Pass Page 6 of 75 Report No.: UNIA24010236ER-62 1.2 TEST FACILITY Test Firm : Shenzhen United Testing Technology Co., Ltd. Address : D101&D401, No. 107, Kaicheng High-Tech Park, Taoyuan Community, Dalang Sub-District, Longhua District, Shenzhen, Guangdong, China The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19.The testing quality system of our laboratory meets with ISO/IEC-17025 requirements. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: A2LA Certificate Number: 4747.01 The EMC Laboratory has been accredited by A2LA, and in compliance with ISO/IEC 17025:2017 General Requirements for testing Laboratories. FCC Registration Number: 674885 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. IC Registration Number: 31584 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. Page 7 of 75 Report No.: UNIA24010236ER-62 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence …

Text truncated - open the document above for the full version.

AntennaSpecification Manufacture：TUYA ProductName：WBR3Antenna AntennaType：PCB TestDate：2019.05.20 Testedby：LongWang Approvedby：Licco Content 1.GeneralDescription.................................................................................1 2.TestConfigurations...................................................................................2 2.1TestEnvironment............................................................................2 2.2TestEquipment...............................................................................2 2.3TestPrinciple...................................................................................2 3.TestResults..............................................................................................3 3.1GainandEfficiency..........................................................................3 3.2RadiationPattern............................................................................4 4.AntennaDimensions................................................................................6 5.EUTPhoto................................................................................................6 6.TestSetupPhoto......................................................................................7 1 1.GeneralDescription ManufacturerHangzhouTuyaInformationTechnologyCo.,Ltd Address Room701,Building3,MoreCenter,No.87GuDunRoad, Hangzhou,Zhejiang,China TestLocation Room106,Building3,LetongSciencePark,No.500, QiuyiRoad,BinjiangDistrict,Hangzhou ProductNameWBR3Antenna Productmodel WBR3 AntennaType PCBAntenna TestItems Gain;Efficiency;RadiationPattern TestFrequency 2400-2500MHz TestStandard ANSI/IEEEStd149-1979 2 2.TestConfigurations 2.1TestEnvironment Temperature(°C)25 Humidity(%RH)60 AtmosphericPressure(kPa)100.5 2.2TestEquipment TestSystemTEM24Multi-probeMicrowaveChamber TestInstrumentAgilentE5071B 2.3TestPrinciple 3 3.TestResults 3.1GainandEfficiency Frequency(MHz)PeakGain(dBi)Efficiency(%) 2400 1.6252.29 2410 1.7152.17 2420 1.9353.14 2430 1.9854.16 2440 2.0057.62 2450 2.1759.64 2460 2.4561.55 2470 2.3860.64 2480 2.5462.86 2490 2.3059.85 2500 2.4960.41 4 3.2RadiationPattern Phi02D Phi902D 5 Theta902D 2480MHz3D 6 4.AntennaDimensions 5.EUTPhoto 7 6.TestSetupPhoto

Model: PTM-301 Radiated Emission test Model: PTM-301 Conducted Emission test RF Conducted test
