2A4K9-T1PROProjector

Peringatan: Fokus otomatis akan diaktifkan setelah setiap pergeseran setelah dihidupkan dalam pengaturan. Peringatan: Jika Anda tidak puas dengan hasil koreksi keystone otomatis saat ini, Anda dapat memilih [Jalankan Keystone Otomatis] untuk mengkalibrasi ulang. Peringatan: Jika Anda tidak puas dengan hasil fokus otomatis saat ini, Anda dapat memilih [Jalankan Fokus Otomatis] untuk mengkalibrasi ulang. Peringatan: Jika gambar tetap buram, silakan pergi ke halaman beranda -> pilih Pengaturan [] -> pilih [Gambar] -> pilih [Pemfokusan Manual] -> Gunakan tombol panah atas dan bawah untuk mengatur FOKUS secara manual hingga gambar tajam. 6.3.1 Koreksi Keystone Otomatis Koreksi Keystone Otomatis pada T1 Pro secara otomatis mengoreksi distorsi trapezium, memastikan gambar tetap persegi tanpa penyesuaian manual. Anda dapat menemukan fitur ini di Pengaturan [] -> [Gambar] -> [Key- stone]. Peringatan: Jika gambar tetap buram, silakan coba mengatur jarak proyeksi dan pastikan jarak proyeksi berada dalam rentang yang tepat (Silakan periksa [ 7.3 ] untuk detail). 6.3 Koreksi Keystone 296 6.3.2 Koreksi Keystone Manual Jika Anda perlu menyesuaikan layar lebih lanjut, Anda dapat menggunakan fitur Koreksi Keystone Manual. Langkah 1: silakan pergi ke halaman beranda -> pilih Pengaturan [] -> pilih [Gambar] Langkah 2: Di [Gambar] -> pilih [Koreksi Empat Titik] -> sesuaikan layar dengan menyeret panah. 6.3.3 Koreksi Otomatis Setelah Boot Fungsi ini secara otomatis mendeteksi dan mengoreksi distorsi keystone ver- tikal dan horizontal dari gambar yang diproyeksikan setiap kali proyektor dinyalakan, memastikan Anda dapat segera menikmati gambar yang jelas dan berbentuk persegi panjang. 6.3.4 Penjajaran Layar Otomatis Fungsi ini secara otomatis mendeteksi batas layar dan menyesuaikan posisi gambar untuk memastikan penjajaran yang tepat dengan tepi layar, meng- hindari kelebihan gambar atau ruang kosong dan memungkinkan pemusa- tan tampilan yang cepat. 1 Layar latar belakang putih harus memiliki batas hitam atau jelas lainnya, sementara layar tahan cahaya tidak memiliki persyaratan batas. Peringatan: Koreksi Keystone Otomatis diaktifkan secara default saat mesin pertama kali digunakan. Jika Anda ingin mematikan- nya, silakan pergi ke halaman beranda -> pilih Pengaturan [] -> pilih [Gambar] -> Di [Keystone] -> pilih [Otomatis] -> tekan [OK] untuk mematikannya. 297 Peringatan: Pastikan proyektor tidak miring lebih dari 15 derajat secara vertikal atau horizontal. Pastikan fokus otomatis bekerja secara efektif. 2 Gambar yang diproyeksikan sebelum Penyesuaian Layar perlu lebih besar dari area layar. 3 Saat menggunakan fungsi Penyesuaian Layar, jangan memblokir pusat layar. Peringatan: Sebelum menggunakan fungsi Penyesuaian Layar Otomatis dan Penghindaran Hambatan Otomatis, pastikan fungsi Keystone Otomatis dan Fokus Otomatis diaktifkan. Penghindaran hambatan mungkin tidak berfungsi ketika ada objek putih atau berwarna terang lainnya dalam layar target. 298 Anda dapat menyesuaikan ukuran gambar sesuai dengan kebutuhan Anda. Langkah 1: silakan pergi ke halaman beranda -> pilih Pengaturan [ ] -> pilih [Gambar] Langkah 2: Di [Gambar] -> pilih [Zoom Gambar] -> Gunakan tombol panah atas dan bawah untuk mengatur Zoom secara manual hingga gambar diinginkan. 6.3.5 Penghindaran Hambatan Otomatis Fungsi ini secara otomatis mendeteksi hambatan dalam jalur proyeksi dan dengan cerdas menyesuaikan sudut atau posisi gambar untuk mencegah gangguan gambar, memastikan proyeksi yang jelas dan lengkap. Peringatan: Sebelum menggunakan fungsi Penyesuaian Layar Otomatis dan Penghindaran Hambatan Otomatis, pastikan fungsi Keystone Otomatis dan Fokus Otomatis diaktifkan. Penghindaran hambatan mungkin tidak berfungsi ketika ada objek putih atau berwarna terang lainnya dalam layar target. 6.4 Zoom Gambar 299 Anda dapat menyesuaikan Mode Gambar sesuai dengan kebutuhan Anda. Langkah 1: silakan pergi ke halaman beranda -> pilih Pengaturan [] -> pilih [Gambar] Langkah 2: Di [Gambar] -> pilih [Mode Gambar] 6.5 Tampilan Perhatian: Pengaturan warna gambar hanya akan berlaku saat memutar gambar atau video. Langkah 1: Tekan tombol Pengaturan [] -> Pilih [Jaringan & Internet] -> Nyalakan tombol [Koneksi Internet] -> Pilih [Wi-Fi] Langkah 2: Di daftar [Jaringan Tersedia] -> Cari jaringan Wi-Fi yang Anda inginkan -> masukkan kata sandi -> Pilih [OK] -> Tunggu hingga proyektor terhubung. 7.1 Pengaturan WiFi 7. Pencerminan Layar 300 Langkah 1: Pastikan Kompatibilitas dan Koneksi Jaringan: Pastikan perangkat iOS Anda dan T1 Pro terhubung ke jaringan Wi-Fi yang sama. Langkah 2: Pergi ke halaman beranda -> pilih menu [Aplikasi Saya] -> tekan [iPhone wireless on the same screen] -> Masuk dan tetap di halaman [iPhone wireless on the same screen]. Langkah 3: Buka [Pusat Kontrol] di perangkat iOS Anda -> Pilih fungsi pencer- minan layar -> Hubungkan penerima iOS Cast bernama [Yaber_T1Pro_xxxx] -> Sukses. 7.2 iOS Cast (Untuk Perangkat iOS) Peringatan: Kelancaran pencerminan layar akan dipengaruhi oleh lingkungan jaringan. Disarankan untuk menggunakan bandwidth yang lebih cepat. 301 Langkah 1: Silakan aktifkan fungsi Wi-Fi di ponsel Android Anda (Tidak perlu terhubung ke Wi-Fi). Langkah 2: Pergi ke halaman beranda -> pilih menu [Aplikasi Saya] -> tekan [Screencast] -> Masuk dan tetap di halaman [Berbagi Layar Android]. Langkah 3: Akses [Pusat Kontrol] di perangkat Android Anda -> Pilih [Pencermi- nan Layar/Smart View]. Pilih dan hubungkan penerima Miracast bernama [Y- aber_T1Pro_xxxx] -> Sukses. 7.3 Miracast (Untuk Perangkat Android) Peringatan: Beberapa perangkat seluler Google hanya men- dukung Chromecast dan tidak dapat dicerminkan oleh Airplay atau Miracast. Peringatan: Karena perlindungan hak cipta, beberapa konten berhak cipta (Netflix, Hulu, dll.) tidak dapat dicerminkan langsung dari ponsel. Perlu menggunakan TV stick. Jika Anda membutuhkan bantuan, silakan hubungi kami. 302 Peringatan: Pencerminan ponsel hanya dapat direalisasikan dengan masuk dan tetap bera…

Text truncated - open the document above for the full version.

User Manual ProjectorT1 Pro/T1 Plus/T1 EN Contents English Deutsch Italiano Français Español Polski Русский ςϔϋϔϣιτ ͙ͱͱ͙ͬ͛ͱ͚ͫͣͷ͛ &HVWLQD %DKDVD,QGRQHVLD Turkce 8KǿV0CO 5WQOK 0QTIG &CPOCTM 5XGTKIG 01 21 43 65 87 109 131 152 174 196 221 243 265 287 309 331 353 375 397 419 Catalog 1. YABER Lifetime Professional Support 2. Important Precautions 3. Product Overview 4. Specification 5. Installation 6. Projection Settings 7. Screen Mirroring 8. Connectivity 9. Bluetooth Settings 10. Regular Cleaning 11. System Upgrade Dear Valued Customer, Thank you for choosing the Yaber T1 Pro Projector. Please read the Quick Start Guide (QSG) carefully before using your T1 Pro Projector. Scan the QR code on the next page to get detailed product user manual and video guideline.We encourage you to explore them in depth. 1. YABER Lifetime Professional Support 01 For safe and optimal use of the device, please follow these guidelines: • Do not face the lens towards eyes because the strong projector light may cause injury to the eyes. • Do not block the air inlet or outlet of the device to prevent overheating, hich could damage internal components. • Do not wipe the lens directly with cleaning tools such as paper or cloth. Instead, remove dust from the lens using clean air blowing. • Do not wash the device with chemicals, detergents, or any liquid as they may corrode the circuit board. • Keep the device and its components and accessories out of reach of children. We understand that you may encounter various questions and issues while using the projector. However, leaving a review on the product page will not help improve your experience. (Please let us help you! We truly appreciate your feedback and will promptly provide a satisfying solution.) If you encounter any issues, feel free to send your order number and the problems to us at [email protected]. (Title: US+T1 Pro+000-0000000-0000000+Issues) Rest assured, our service team will offer the solution to you within 24 hours. Your satisfaction is our top priority. If you encounter any problems, we sincerely hope that you will give us the opportunity to resolve them. We are dedicated to offering you the best possible solution. We appreciate your understanding and patience in advance. Yaber Projector Customer Service Team If you have any questions, please feel free to contact us. 2. Important Precautions [email protected] 02 • Make sure that the device is used in a dry, well-ventilated environment. • Do not store the device in excessively hot or cold places, as this can reduce the lifespan of electronic components. Use and store it within a temperature range of 0°C-40°C. • Do not put the device into any heating equipment (e.g., dryer or microwave) for drying. • Do not press down firmly on the device or place objects on top or behind it to avoid damage to the device. • Do not throw, drop, or strongly shake the device to protect its internal circuit board. • Make sure to clean the dust filter every six months to a year to keep the machine running cool. 3. Product Overview Lens IR Receiver Focus Camera Air Vent HDMI Turbo Sonic Audio out USB IR Receiver Power Button Bracket switch Power Port Handle Power Setting BackSource Home Arrow Keys INFO NETFLIX Prime Video Volume- Mute Focus Control YouTube Volume+ Air filter Audio 03 4. Specification 5. Installation ModelNo.T1Pro NativeResolution1920*1080LightSourceLED FocusAutoͭEletricKeystoneCorrection AutoͭManual Interface USB×1 HDMI×1 AudioOut×1 UnitDimension 10.5×11.5×24.5cm 4.13 ×4.53×9.65inches ProjectionRatio1.18:1ProjectionDistance Min1.07m~Max3.05m Min 40 ~Max 150inches PowerVoltage AC100-240Vͭ50-60Hz PowerConsumption75W ProjectorWeight 1.25kg 2.76lbs ProjectionMethod FrontͭRearonDesk FrontͭRearonCelling AspectRatio16:9 ProjectionZoom 50%-100% PictureFormat JPG,PNG,BMP,JPEG AudioFormat MP3,WAV,ASF,3GP,MP4,MPEG VideoFormat MKV,MP4,3GP,MPEG,ASF,WMV,WebM, USB FormatFAT32,NTFS,exFAT 5.1 How To Turn On The Projector Press the button and the projector pops up. The Yaber logo is facing the front, rotate the body in this direc- tion. Reverse rotation may cause damage. You can choose your projection angle between 0-180°. 123 180° 04 The projector can be mounted from the ceiling using a bracket and 1/4 Screw (not included) , or mounted on a tripod. The projection distance of the T1 Pro ranges from 1.5ft to 10.04ft. Note: Do not rotate the device directly, as this may cause damage. Note: To close the projector, align the body and press down until you hear a click. Notice: Make sure you have a universal mounting bracket that can fit the projector. Notice: T1 Pro does not support four-corner mount installation. 5.2 Projector Stand Mounting 5.3 Projection Distance Screw Hole 05 TipsThe recommended projection distance is about 6.78ft. 1.07m1.57m2.07m2.57m (1.51ft)(6.78ft)(8.43ft) 3.06m (10.04ft) 120“ 100“ When the projector is in power-on or speaker mode, turn the projector down- ward to automatically enter the ambience mode. 5.4 Ambient Light Mode 6. Projection Settings T1 Pro supports four projection modes, you can choose the preferred way. 6.1 Projection Mode 06 If you choosing ceiling mounting or rear projection, please go to homepage -> select the Settings [ ] -> select [Picture] -> In [Projection] select an ap- propriate projection mode -> press [OK] to switch projection mode. This function automatically detects the clarity of the projected image and optimizes the focal length in real time, ensuring the image remains sharp and clear at all times.You can find this feature in the Settings [ ] -> [Picture] -> [Focus]. 6.2 Auto Focus 07 Notice: Auto Focus will be activated after each shift once it is turned on in the setting. Notice: If you are unsatisfied with the current Auto Keystone Cor- rection result, you can select [Execute Auto Keystone] to recali- brate. Notice: If you are unsatisfied with the current Auto Focus result, you can select [Execute Auto Focus] to recalibrate. Notice: If picture remains blurry, please go to h…

Text truncated - open the document above for the full version.

V1.2 1/12 AntennaTestReport Productname:Wirelesstransceivermodule Productmodel:WXT6FK1111D80 Frequency:2.4GHz+5GHz Testdate:2025.3.3 Testpurpose:Antennaperformancetest Tobeprepared:ChenHaomin Review:TangHongjun ratify：Highlight testresult： Standingwave:WF2.4G1.1~2.1,5G2.2~2.4,BT1.6~2.3 Isolation:TheisolationlevelsofWFandBTrangefrom16.8to18.7dB. Directionpattern:Allantennadirectionpatternshaveslightangulardeviations. Efficiency:WF2.4Grangesfrom47%to58%,5Gfrom41%to46%,andBTfrom48%to56%. Gain(MAX):0.3~1.3dBiforWF2.4G,1.4~2.8dBifor5G,and0.3~1.5dBiforBT V1.2 2/12 Revisionhistory Edition Date state V1.02025-05-07 Firstedi- tion V1.12025-05-13 Add3Dgraph V1.22025-05-14 Addmodulecoordinatechartindicatortotestenviro- nment V1.2 3/12 Catalogue 1.AntennaPosition .............................................................................................................................4 1.1Moduleplacementrequirements ..........................................................................................4 2.TestEnvironment ............................................................................................................................4 2.1WFAntennaTestEnvironment ............................................................................................4 2.2BTAntennaTestEnvironment .............................................................................................5 3.AntennaMatching ...........................................................................................................................6 4.AntennaStandingWaveRatio ........................................................................................................6 4.1WF.........................................................................................................................................6 4.2BT..........................................................................................................................................7 5.Antennaisolation .............................................................................................................................7 5.1WF&BT..................................................................................................................................7 6.DirectionMap .................................................................................................................................8 6.1WFdirectionaldiagram ........................................................................................................8 6.2BTdirectionaldiagram .........................................................................................................8 7、3DEtotal........................................................................................................................................8 7.1WF3Dgraph .........................................................................................................................8 7.2BT3Dgraph .........................................................................................................................9 8.EfficiencyandGain .........................................................................................................................9 8.1WFefficiencyandgain .........................................................................................................9 8.2BTefficiencyandgain ........................................................................................................12 V1.2 4/12 1、AntennaPosition 1.1ModulePlacementRequirements WIFI:PCBantenna;BT:PCBantenna,freespacetest 2、TestingEnvironment 2.1WFAntennaTestEnvironment V1.2 5/12 2.2BTAntennaTestEnvironment V1.2 6/12 3、AntennaLoading Coil Matchdescription WFBT E1 0Ω0Ω E2NCNC E3NCNC 4、AntennaStandingWave Ratio 4.1WF V1.2 7/12 4.2BT 5、AntennaIsolation 5.1WF&BT V1.2 8/12 6、DirectionalDia- gram 6.1WFDirectionalDiag- ram Phi02DPhi902DTheta902D 6.2BTDirectionalDiag- ram Phi02DPhi902DTheta902D 7 、 3DEtotal 7.1WF3DGraph V1.2 9/12 7.2BT3DGraph 8、EfficiencyandGain 8.1WFEfficiencyandGain Frequency/Mhz Efficiency /dB Efficiency /%MaxGain/dBiAvgGain/dBi 2400-2.3458.341.36-2.34 2410-2.3458.341.24-2.34 2420-2.358.881.22-2.3 2430-2.3358.481.36-2.33 2440-2.4756.621.33-2.47 2450-2.753.71.1-2.7 2460-2.9251.050.89-2.92 2470-3.0949.090.55-3.09 2480-3.2147.750.34-3.21 2490-3.3746.030.1-3.37 2500-3.4345.390.09-3.43 5000-2.9151.171.56-2.91 5010-2.9450.82 1.44 -2.94 5020-3.01501.45-3.01 5030-3.0849.21.36-3.08 5040-3.1248.751.46-3.12 5050-3.0549.551.44-3.05 5060-3.0249.891.5-3.02 5070-3.0349.771.39-3.03 5080-3.0749.321.37-3.07 5090-3.0749.321.28-3.07 5100-3.0949.091.34-3.09 V1.2 10/12 5110-3.1947.971.24-3.19 5120-3.2147.751.34-3.21 5130-3.2247.641.4-3.22 5140-3.2347.531.45-3.23 5150-3.3246.561.41-3.32 5160-3.346.771.43-3.3 5170-3.2946.881.49-3.29 5180-3.3146.671.51-3.31 5190-3.3945.811.48-3.39 5200-3.3746.031.52-3.37 5210-3.3346.451.6-3.33 5220-3.3746.031.55-3.37 5230-3.3246.561.75-3.32 5240-3.3646.131.74-3.36 5250-3.445.711.72-3.4 5260-3.5144.571.63-3.51 5270-3.5943.751.61-3.59 5280-3.6842.851.51-3.68 5290-3.5843.851.68-3.58 5300-3.5444.261.7-3.54 5310-3.544.671.76-3.5 5320-3.5444.261.7-3.54 5330-3.6543.151.55-3.65 5340-3.742.661.47-3.7 5350-3.6842.851.45-3.68 5360-3.6343.351.57-3.63 5370-3.7342.361.47-3.73 5380-3.7542.171.59-3.75 5390-3.7741.981.58-3.77 5400-3.6742.951.69-3.67 5410-3.7342.361.57-3.73 5420-3.74 42.27 1.54-3.74 5430-3.841.691.47-3.8 5440-3.6443.251.6-3.64 5450-3.6842.851.59-3.68 5460-3.6942.761.63-3.69 5470-3.742.66 1.71 -3.7 5480-3.7841.88 1.72 -3.78 5490-3.7941.781.79-3.79 5500-3.8441.31.75-3.84 5510-3.7841.881.89-3.78 V1.2 11/12 5520-3.8141.591.78-3.81 5530-3.7342.361.91-3.73 5540-3.8141.591.76-3.81 5550-3.6742.951.94-3.67 5560-3.7242.461.89-3.72 5570-3.6942.761.95-3.69 5580-3.6842.852-3.68 5590-3.6443.252.07-3.64 5600-3.7442.272.03-3.74 5610-3.8341.41.94-3.83 5620-3.8441.31.97-3.84 5630-3.841.691.95-3.8 5640-3.742.662.1-3.7 5650-3.7642.071.98-3.76 5660-3.7941.782.01-3.79 5670-3.8641.111.95-3.86 …

Text truncated - open the document above for the full version.

C onducted emissions Radiated Measurement Photos Spurious emissions

No.：BCTC/RF-ICT-005 Page: 1 of 25 Edition：C.0 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2506413442-5E Applicant: YABER TECHNOLOGIES CO., LIMITED Product Name: Projector Test Model: T1 Pro Tested Date: 2025-07-02 to 2025-08-01 Issued Date: 2025-08-08 Report No.: BCTC2506413442-5E No.：BCTC/RF-ICT-005 Page: 2 of 25 Edition：C.0 FCC ID: 2A4K9-T1PRO The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Projector Trademark: YABER Model/Type reference: T1 Pro T1, T1 Plus Prepared For: YABER TECHNOLOGIES CO., LIMITED Address: Room 406, 4 Floor, B Building, BanTian International Center, HuanCheng South Road, BanTian Street, LongGang District, Shenzhen, China Manufacturer: YABER TECHNOLOGIES CO., LIMITED Address: Room 406, 4 Floor, B Building, BanTian International Center, HuanCheng South Road, BanTian Street, LongGang District, Shenzhen, China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China. Sample Received Date: 2025-06-10 Sample tested Date: 2025-07-02 to 2025-08-01 Issue Date: 2025-08-08 Report No.: BCTC2506413442-5E Test Standards: 47 CFR FCC Part 15.407 KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02 KDB 905462 D03 UNII Clients Without Radar Detection New Rules v01r02 Test Results: PASS Remark: This is WIFI-5GHz band radio test report. Tested by: Approved by: Eric Yang/Project Handler Zero Zhou/Reviewer Report No.: BCTC2506413442-5E No.：BCTC/RF-ICT-005 Page: 3 of 25 Edition：C.0 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 4 2. Test Summary ....................................................................................................... 5 3. Measurement Uncertainty ..................................................................................... 6 4. Product Information And Test Setup ..................................................................... 7 4.1 Product Information ............................................................................................... 7 4.2 Test Setup Configuration ...................................................................................... 8 4.3 Test Setup Configuration ...................................................................................... 8 5. Test Facility And Test Instrument Used ................................................................. 9 5.1 Test Facility ........................................................................................................... 9 5.2 Test Instrument Used ............................................................................................ 9 6. Dynamic Frequency Selection (DFS) Test Result ............................................... 10 6.1 DFS Parameters ................................................................................................. 10 6.2 Applicability of DFS Requirements Prior to Use of a Channel ............................. 11 6.3 Applicability of DFS Requirements during Normal Operation .............................. 11 6.4 Uniform Spreading .............................................................................................. 12 6.5 User Access Restrictions .................................................................................... 12 6.6 Channel Loading/Data Streaming ....................................................................... 12 6.7 Radar Test Waveform Calibration ....................................................................... 13 6.8 UNII Detection Bandwidth ................................................................................... 17 6.9 In-service Monitoring ........................................................................................... 18 7. EUT Photographs ................................................................................................ 23 8. EUT Test Setup Photographs.............................................................................. 24 (Note: N/A Means Not Applicable) Report No.: BCTC2506413442-5E No.：BCTC/RF-ICT-005 Page: 4 of 25 Edition：C.0 1. Version Report No. Issue Date Description Approved BCTC2506413442-5E 2025-08-08 Original Valid Report No.: BCTC2506413442-5E No.：BCTC/RF-ICT-005 Page: 5 of 25 Edition：C.0 2. Test Summary The Product has been tested according to the following specifications: Items Description of Test Result Performance Requirements Check Initial Channel Availability Check Time (CAC) Not Applicable Radar Burst at the Beginning of the CAC Not Applicable Radar Burst at the End of the CAC Not Applicable In-Service Monitoring Channel Move Time Compliance Channel Closing Transmission Time Compliance Non-Occupancy Period Compliance Radar Detection Statistical Performance Check Not Applicable Note: EUT is client device without radar detection. Report No.: BCTC2506413442-5E No.：BCTC/RF-ICT-005 Page: 6 of 25 Edition：C.0 3. Measurement Uncertainty The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 In-service Monitoring ± 0.1 ms Report No.: BCTC2506413442-5E No.：BCTC/RF-ICT-005 Page: 7 of 25 Edition：C.0 4. Product Information And Test Setup 4.1 Product Information Model/Type Reference: T1 Pro, T1, T1 Plus Model Differences: All the model are the same circuit and RF module, except model names. Hardware Version: ZJ.T9266.PCT1 Pro Software Version: A1.0 Operation Frequency: Ban…

Text truncated - open the document above for the full version.

Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 259 of 323 Edition：B.2 Tx. Spurious NVNT ax20 5320MHz Emission Tx. Spurious NVNT ax40 5270MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 260 of 323 Edition：B.2 Tx. Spurious NVNT ax40 5310MHz Emission Tx. Spurious NVNT ax80 5290MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 261 of 323 Edition：B.2 Test Graphs Tx. Spurious NVNT a 5500MHz Emission Tx. Spurious NVNT a 5580MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 262 of 323 Edition：B.2 Tx. Spurious NVNT a 5700MHz Emission Tx. Spurious NVNT n20 5500MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 263 of 323 Edition：B.2 Tx. Spurious NVNT n20 5580MHz Emission Tx. Spurious NVNT n20 5700MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 264 of 323 Edition：B.2 Tx. Spurious NVNT n40 5510MHz Emission Tx. Spurious NVNT n40 5550MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 265 of 323 Edition：B.2 Tx. Spurious NVNT n40 5670MHz Emission Tx. Spurious NVNT ac20 5500MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 266 of 323 Edition：B.2 Tx. Spurious NVNT ac20 5580MHz Emission Tx. Spurious NVNT ac20 5700MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 267 of 323 Edition：B.2 Tx. Spurious NVNT ac40 5510MHz Emission Tx. Spurious NVNT ac40 5550MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 268 of 323 Edition：B.2 Tx. Spurious NVNT ac40 5670MHz Emission Tx. Spurious NVNT ac80 5530MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 269 of 323 Edition：B.2 Tx. Spurious NVNT ax20 5500MHz Emission Tx. Spurious NVNT ax20 5580MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 270 of 323 Edition：B.2 Tx. Spurious NVNT ax20 5700MHz Emission Tx. Spurious NVNT ax40 5510MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 271 of 323 Edition：B.2 Tx. Spurious NVNT ax40 5550MHz Emission Tx. Spurious NVNT ax40 5670MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 272 of 323 Edition：B.2 Tx. Spurious NVNT ax80 5530MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 273 of 323 Edition：B.2 Test Graphs Tx. Spurious NVNT a 5745MHz Emission Tx. Spurious NVNT a 5785MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 274 of 323 Edition：B.2 Tx. Spurious NVNT a 5825MHz Emission Tx. Spurious NVNT n20 5745MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 275 of 323 Edition：B.2 Tx. Spurious NVNT n20 5785MHz Emission Tx. Spurious NVNT n20 5825MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 276 of 323 Edition：B.2 Tx. Spurious NVNT n40 5755MHz Emission Tx. Spurious NVNT n40 5795MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 277 of 323 Edition：B.2 Tx. Spurious NVNT ac20 5745MHz Emission Tx. Spurious NVNT ac20 5785MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 278 of 323 Edition：B.2 Tx. Spurious NVNT ac20 5825MHz Emission Tx. Spurious NVNT ac40 5755MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 279 of 323 Edition：B.2 Tx. Spurious NVNT ac40 5795MHz Emission Tx. Spurious NVNT ac80 5775MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 280 of 323 Edition：B.2 Tx. Spurious NVNT ax20 5745MHz Emission Tx. Spurious NVNT ax20 5785MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 281 of 323 Edition：B.2 Tx. Spurious NVNT ax20 5825MHz Emission Tx. Spurious NVNT ax40 5755MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 282 of 323 Edition：B.2 Tx. Spurious NVNT ax40 5795MHz Emission Tx. Spurious NVNT ax80 5775MHz Emission Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 283 of 323 Edition：B.2 13. Frequency Stability Measurement 13.1 Block Diagram Of Test Setup 13.2 Limit Manufactures of U-NII devices are responsible for ensuring frequency stability such that an emission is maintained within the band of operation under all conditions of normal operation as specified in the user’s manual. The transmitter center frequency tolerance shall be ± 20 ppm maximum for the 5 GHz band (IEEE 802.11n specification).. 13.3 Test Procedure 1. The transmitter output (antenna port) was connected to the spectrum analyzer. 2. EUT have transmitted absence of modulation signal and fixed channelize. 3. Set the spectrum analyzer span to view the entire absence of modulation emissions bandwidth. 4. Set RBW = 10 kHz, VBW = 10 kHz with peak detector and maxhold settings. 5. fc is declaring of channel frequency. Then the frequency error formula is (fc-f)/fc × 106 ppm and he limit is less than ±20ppm (IEEE 802.11nspecification). 6. The test extreme voltage is to change the primary supply voltage from 85 to 115 percent of the nominal value 7. Extreme temperature is -20°C~70°C. Report No.: BCTC2506413442-4E No.：BCTC/RF-EMC-005 Page: 284 of 323 Edition：B.2 13.4 Test Result Temperature: 26 °C Relative Humidity: 54%RH Pressure: 101KPa Test Voltage: DC 3.7V Test Mode: TX (5.1G) Mode Frequency U-NII-1 (5180-5240MHz) Voltage vs. Frequency Stability TEST CONDITIONS Reference Frequency:5180MHz f fc Max. Deviation (MHz) Max. Deviation (ppm) T nom (°C) 20 V nom (V) 3.70 5180.0023 5180 0.0023 0.4440 V max (V) 4.26 5180.0023 5180 0.0023 0.4440 V min (V) 3.15 5180.0031 5180 0.0031 0.5985 Limits 5150-5250 MHz Result Complies Temperature vs. Frequency Stability TEST CONDITIONS Reference Frequency:5180MHz f fc Max. Deviation (MHz) Max. Deviation (ppm) V nom (V) 3.3 T (°C) -20 5180.0091 5180 0.0091 1.7568 T (°C) -10 5180.0103 5180 0.0103 1.9884 T (°C) 0 5180.0026 5180 0.0026 0.5019 T (°C) 10 5180.0055 5180 0.0055 1.0618 T (°C) 20 5180.0052 5180 0.0052 1.0039 T (°C) 30 5180.0093 5180 0.0093 1.7954 T (°C) 40 5180.0002 5180 0.0002 0.0386 T (°C) 50 5180.0018 5180 0.0018 0.3475 T (°C) 60 …
