制作要求 此页不印刷 成品尺寸：142x210mm 展开尺寸：284x210mm 钉装：骑马钉 材质：铜版纸 版本：V1-20211013 USER MANUAL MP500 To make sure your personal safety, property security and user experience, please read this manual carefully before operating,and retain it for future reference. Before using your new Power Station MP500, plug it into a suitable power outlet until it is fully charged.Then you can start your exciting journey with it. CHARGE FIRST! Thank you for purchasing MP500 portable power station. 1 GENERAL SPECIFICATIONS General Specs Weight (net weight) Weight (including accessories) Product size Rated capacity Recharging input voltage Input Recharging input power 519.48Wh 12-26V ≈6.8kg ≈7.8kg 290mm*194mm*200mm 500W 3.7V/140400mAh 550±40W 110V±10V/60HZ pure sine wave QC3.0/18W PD60W 14V/8A 14V/4A 10W 14 to 113°F (-10 to 45°C) 32 to 104°F (0 to 40°C) Rated Output Power Standard capacity of cells Overload protection Power AC Output Voltage Output waveform USB output Output Type-C Cigarette Lighter Socket Output DC 55*2.5 output Wireless charger discharging Temperature Recharging Temperature Output Battery 100W AC/DC Adapter Solar Charge Input 100W MAX ,AC 100-240V (50Hz/60Hz) ,DC 25V ,4A 12-26V ,DC 6A MAX DC 12V ,100W MAX Car Charger SAFETY INSTRUCTIONS Read the following instructions to ensure safety before using. Improper use may result in fire, property damage or personal injury. 2 Product use: • DO NOT use any inappropriate power cords. DO NOT place the unit close to or in a fire on expose it to heat. Keep out of direct sunlight. DO NOT charge, use or store the unit in a bathroom or in an area exposed to rain or moisture. Do not drop the unit into the water. If the battery in the unit comes into contact with water, it may cause chemical decomposition of the battery. This may cause the battery to catch fire or explode. Never use or charge swollen, leaky, or damaged batteries. If your battery is abnormal, contact us to get support. Never install or remove a battery from the unit when it is turned on. DO NOT use the batteries in strong electrostatic or electromagnetic environments. Otherwise, the battery control board may malfunction and cause a serious accident. Never disassemble or pierce the product in any way. Otherwise, it may leak, catch on fire, or explode. DO NOT use the product if it was involved in a crash or a heavy bump. If the product falls into the water during use,take the product out immediately and put it in a safe and open area. Keep a safe distance from it until it is completely dry. Never use it again and dispose it properly as described in the Battery Disposal section below. If the product catches fire, it is recommended to use fire extinguishing equipment in the following order: water or water mist, sand, fire blanket, dry powder, carbon dioxide fire extinguisher. Do Not allow pins, wires or other metal pieces to insert to the device case, outlets or controls. Metal pieces may short circuit the product. Avoid collision. DO NOT place heavy objects on the machine. Use and store the unit only in a clean and dry environment. Do not use and store in dusty and wet environment. If there is dirt on any plug or outlet surface, use a dry cloth to clean it. Otherwise, it will cause abrasion and result in energy loss or inability to charge. DO NOT put the machine in a microwave oven or in a pressurized container. • • • • • • • • • • • • • Product Recharging: • DO NOT charge the unit via power supply systems that operate outside of 100-240V. DO NOT charge the unit via solar panel that operate voltage outside of DC12-26V. Always use approved attachment charging cables. we take no responsibility for any damage caused by using other brand charging cable. When charging, please place the product on the ground with no flammable or combustible materials around. To prevent accidents, never leave the machine unattended during charging. DO NOT charge a product immediately after a long heavy load, because the product's temperature may be too high. DO NOT charge a product until it cools down to room temperature. Only charge, use the unit within an ambient temperature of 0 to 40 °C (32~104°F). The ideal charging temperature range is 71ºF to 82ºF(22°C to 28°C). AC • • • • • Product Storage and Transportation: • Keep the product out of the reach of children. If any children accidentally swallow parts, please go to a doctor immediately. If a low-battery warning appears, charge the battery before store it. Store the product in dry environments. DO NOT place the product where it may contact with water. Make sure no small metal objects can fall on or around the product while in storage. Never transport a product with a battery power level higher than 30%. • • • • Product Maintenance: • Never store the product in environments below -20°C or above 45°C. Battery life may be reduced if not used for a long time. Fully charge and discharge the battery at least once every 3 months to maintain battery health. • • Note: No user-serviceable parts inside. Recommended to fully charge the MP500 before use. FEATURE DETAILS BUTTON FEATURE 3 A:MP500 Power ON/OFF Button B:SOS mode & LED light Button C:DC Output Power ON/OFF Button D:USB Output Power ON/OFF Button E: AC Output Power ON/OFF Button 1 2 3 4 Cigarette Lighter Output LCD Screen Display DC 5525 Output USB-C Output 6 7 8 9 500W Rated AC Output Anti-collision Strip DC Input PV Input 12 11 10 SOS MODE & LED light Folding Handle Air Intake Vent with Cooling Fan 5 USB-A Output 13 Wireless Charger 3 4 5 7 8 9 10 11 1 2 6 D C A B E 12 13 AC OUTPUT LCD FEATURES HOW TO CHARGE Do not connect device via ac output port while charge the MP500. recommend to disconnect the MP500 when fully charged. WHAT IT POWERS 4 H: Battery Level Indicator I: Input Status J:DC Outputs Status K:AC Outputs Status L:USB Outputs Status H I L J K Laptops (41.4Wh) Around 10 Recharges +MORE 32" TV(60W) Around 7 hours CPAP without heated humidifier (15W) 29 hours Gopro (5.9Wh) Around 74 Recharges Floodlight(4W) Around …
