2A56X-WATCH8PROWatch 8Pro

Instruction Manual Thank you for choosing our smartwatch. You can fully understand the functions and operation methods of the equipment by reading this manual. This device is not a medical device, and the measurement data and results are for reference only, not as a basis for diagnosis and treatment. The company reserves the right to modify the contents of this manual without prior notice. Product configuration: one box, one manual, one host. This product supports IP68 waterproof, supports wearing in the rain, washing hands, cannot be worn in hot showers or saunas, and cannot resist water vapor. If water enters due to not used according to the instructions, our company will not provide free warranty. Key Description: Rotate the button on the upper side: You can zoom in and out the smart style menu and switch the dial up and down. Click to enter the main menu, and double-click to switch the menu style after entering the menu. Bottom key: long press to switch the machine, then short press to turn off the screen, short press to turn on the screen when the screen is off. Touch Instructions: Tap to enter, swipe right to go back. On the standby interface, swipe down to enter the status bar, swipe up to enter the message notification, swipe right to enter the main menu, swipe left to enter common functions, and swipe to the last + sign interface, click to enter to select common functions and set the order before and after. Charging instructions: This product uses a wireless charger, which supports mobile phone chargers within 5V and computer USB ports. Putting the watch on the concave side of the charging seat will automatically absorb and charge. It takes about 3 hours to fully charge. The connection between the watch and the mobile phone: First, the mobile phone needs to download the APP "MActivePro" to the mobile phone and install it. There are two ways. Scan the QR code below on your mobile browser to download, or search for "MActivePro" in the app market to download. During the installation process, you will be prompted to agree to the permission. Click to agree to all of them. After completion, open "MActivePro" and turn on the Bluetooth of your mobile phone. Click Devices - click to add a device at the top, search for "Watch 8Pro" and click connect. Turn on the GPS to find the Bluetooth name of the watch. How to set notification for incoming mail: Open "MActivePro" - Device - Message Reminder, select the corresponding software, and select Open. What should I do if I can't receive a notification? First of all, the notification function of the watch is only to synchronize the notification function of the mobile phone, such as incoming calls and QQ WeChat reminders. If your mobile phone does not receive the notification, the watch will not receive it either. You need to set the notification function on the mobile phone and find the corresponding notification. APP, turn Allow Notifications on. Reset the watch to factory settings, enter the Bluetooth settings of the mobile phone, and see if the connected device has "Watch 8Pro". If so, please cancel the pairing, turn off the Bluetooth of the mobile phone, and turn it on again to reconnect. 4. Delete "MActivePro" and download it again. Remember to agree to all the permissions when prompted during the installation process, and then reconnect. ● Firmware upgrade: When the Bluetooth connection is normal, enter "MActivePro", enter Device - Firmware Upgrade - Update, if the upgrade fails, you can re-operate. ● Sports: Click to enter multi-sport mode, select a mode, click to start, swipe right to enter the pause interface. Each sport data has the main function introduction: ● Call: Click the Bluetooth 3.0 icon in the drop-down menu, and the phone will enter Settings-Bluetooth-Search for "watch call" to pair it. Bluetooth 3.0 can be clicked to close and enter low power consumption mode, which can prolong the use time. ● Phonebook: After connecting to the mobile App, you can add 100 frequently used contacts from the App to the phonebook of the watch. ● Language time and date: When the watch is connected to the mobile APP, the time and date of the mobile phone will be synchronized. Please select the language of the watch when it is turned on for the first time. ● Standby interface: There are a total of multiple standby interfaces to choose from. On the standby interface, press and hold the screen for 3 seconds to switch the interface. You can download the watch face through the APP, and you can also set your favorite photo or picture as the watch face background. ●● Message: Swipe up on the standby interface to enter the message notification, and swipe down to exit, which can synchronize the notification function of the mobile phone, such as incoming letters from QQ WeChat. Recent news notifications. ● Step count, mileage, and calories: Display the steps, mileage, and calorie consumption of the day. The data will be saved at 12 o'clock every night and reset to 0 again. Exercise time, calorie consumption and heart rate, etc. ● Health: Heart rate: start monitoring immediately after entering, scan the changes of capillaries on the surface of the skin through green light, and get the heart rate value, swipe right to exit, normal heart rate is generally 60-90 beats/min, professional athletes will be lower than 60, and ordinary people are the highest Heart rate is 220-age. Long-term exercise can enhance cardiopulmonary function. Blood pressure: Enter the home page of the APP, enter the calibration value in the upper right corner of the blood pressure interface, and start monitoring immediately after entering. When monitoring, please lay your hand flat, and the data will be displayed after about tens of seconds. Generally speaking, the older you are, the higher the blood pressure, and the lower it is for women than for men. ECG: Start monitoring immediately after entering, using the combination of optical heart rate and ECG technology, it takes about tens of …

Text truncated - open the document above for the full version.

FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Appendix II EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT EUT FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT

FCC ID:2A56X-WATCH8PRO TB-RF-074-1.0 Appendix IFCC ID Label Size for the label: 20mm X 10mm Label Location FCC ID:2A56X-WATCH8PRO

FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Appendix III EUT Internal Photographs Photo 5 Internal of EUT Photo 6 Internal of EUT FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Photo 7 Appearance of PCB & Battery Photo 8 Appearance of PCB & Battery BT ANT. RX ANT. BLE ANT.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-2 Page: 1 of 4 TB-RF-074-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 RF Exposure Evaluation FCC ID:2A56X-WATCH8PRO 1. Client Information Applicant : NJY Technology Co., Limited Address : 5 Songpingshan Road, #201 JiaDa R&D Building Lobby B Shenzhen, 518057 China Manufacturer : NJY Technology Co., Limited Address : 5 Songpingshan Road, #201 JiaDa R&D Building Lobby B Shenzhen, 518057 China 2. General Description of EUT EUT Name : Watch 8Pro Model(s) No. : Watch 8Pro Product Description : RF Output Power: BLE: 0.398dBm (Max) BT: 0.823dBm (Max) Antenna Gain: 0.5dBi Internal Antenna Power Supply : Input: DC 5V, 100mA DC 3.7V by 240mAh Rechargeable Li-ion battery Software Version : NJY-N0B-1.0.7 Hardware Version : N02_MB_V1.2 Remark: The antenna gain provided by the applicant, the adapter and verified for the RF conduction test and adapter provided by TOBY test lab. Note: More test information about the EUT please refer the RF Test Report. Report No.: TBR-C-202207-0335-2 Page: 2 of 4 TB-RF-074-1.0 The RF Exposure Evaluation for FCC: SAR Test Exclusion Calculations 1. FCC: According to KDB 447498 D01 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies v06. (1) Clause 4.3: General SAR test reduction and exclusion guidance Sub clause 4.31: Standalone SAR test exclusion considerations 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6GHz at test separation distance≤5 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[√f (GHz) ] ≤3.0 for 1-g SAR [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[√f (GHz) ] ≤7.5.0 for 10-g SAR 2. Summary simultaneous transmission for SAR Exclusion The SAR exemption limits outlined in clause 4.3.2(b) of KDB 447498 have been derived based on an approximate SAR value of 0.4 W/kg using half-wave dipole antennas Footnote 1. As such, when simultaneous transmitter SAR evaluations include transmitters that have been exempt from routine SAR evaluation, the SAR must be estimating based on the ratio between the maximum tune-up tolerance limit of the transmitter that has been exempt and the exemption limit at the specific distance and frequency for that transmitter. This ratio must be multiplied by 0.4 W/kg(2.0 W/kg for controlled use and 1.0 W/kg for limb worn devices) in order to calculate the estimated SAR level. The estimate SAR value is calculated based the following equation: (maximum power level including tune-up tolerance for transmitter A / maximum power level of exemption at the same frequency and distance) * 0.4W/kg The [∑ of (the highest measured or estimated SAR for each standalone antenna configuration, adjusted for maximum tune-up tolerance) / 1.6 W/kg] + [∑ of MPE ratios] is ≤ 1.0. The SAR to peak location separation ratios of all simultaneously transmitting antenna pairs operating in portable device exposure conditions are all ≤ 0.04, and the [∑ of MPE ratios] is ≤ 1.0. Report No.: TBR-C-202207-0335-2 Page: 3 of 4 TB-RF-074-1.0 Calculation: Test separation: 5mm BT GFSK Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (dBm) Max power of tune up tolerance (mW) Limit P th (mW) 2.402 0.74 1±1 2 1.585 3 2.441 0.208 0±1 1 1.259 3 2.480 0.255 0±1 1 1.259 3 BT π/4-DQPSK Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (dBm) Max power of tune up tolerance (mW) Limit P th (mW) 2.402 0.103 0±1 1 1.259 3 2.441 -0.474 0±1 1 1.259 3 2.480 -0.402 0±1 1 1.259 3 BT 8-DPSK Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (dBm) Max power of tune up tolerance (mW) Limit P th (mW) 2.402 0.823 1±1 2 1.585 3 2.441 0.226 0±1 1 1.259 3 2.480 0.312 0±1 1 1.259 3 BLE(1Mbps) Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (dBm) Max power of tune up tolerance (mw) Limit P th (mW) 2.402 0.398 0±1 1 1.259 3 2.440 -0.294 0±1 1 1.259 3 2.480 -0.352 0±1 1 1.259 3 BLE(2Mbps) Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (dBm) Max power of tune up tolerance (mw) Limit P th (mW) 2.402 0.445 0±1 1 1.259 3 2.440 -0.238 0±1 1 1.259 3 2.480 -0.281 0±1 1 1.259 3 Report No.: TBR-C-202207-0335-2 Page: 4 of 4 TB-RF-074-1.0 Summary simultaneous transmission results Simultaneous Transmission for SAR Exclusion The sample support one BT modular and one BLE modular, they supports difference antenna, need consider simultaneous transmission; ∑ of (the highest measured or estimated SARBT+SARBLE)/1.6 = (0.1059+0.0033)/1.6 = 0.2 < 1.0; Conclusion: The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06, No SAR is required. -----END OF REPORT-----

深圳市鑫恒阳科技有限公司 ShenzhenXinhengyangcommunicationTechnologyCo.,Ltd Projecttestreport 项目名称： Watch8Pro 时间： 2022.08.20 Overview Test Point ID .. Passive efficiency Efficienc y( %) Freq. (MHz) Gain (dBi) 2 - 3 - 4-5 u 6-7-8 - 9 - 10 - i [ 11-12-13-14-15_ ＿＿ 16-17-18-19-20_ ＿ [ 21- 2350.0 2360.0 2370.0 2380.0 2390.0 2400.0 2410.0 2420.0 2430.0 2440.0 2450.0 2460.0 2470.0 2480.0 2490.0 2500.0 2510.0 2520.0 2530.0 2540.0 2550.0 -1.86 -2.22 -2.31 -2.56 -2.47 -2.14 -2.45 -1.91 -1.34 -0.81 -0.66 -0.19 0.18 0.5 -0.23 - 0.18 -0.36 -0.66 -1.24 -1.52 18.00% 19.7% 20.0% 22.2% 21.8% 23.5% 23.3% 25.5% 27.4% 27.8% 28.6% 29.8% 29.0% 32.1% 26.8% 20.2% 20.0% 19.5% 15.7% 18.1% -2.07 14.3% Antenna Layout & module on the system board

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 1 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 RF Test Data for Bluetooth LE (Conducted Measurements) General Description of EUT Product Name: Watch 8Pro Test Model: Watch 8Pro Sample ID: 202207-0335-02# Environmental Conditions Temperature: 25°C Relative Humidity: 55% Test Voltage: DC 3.7V Test Engineer: Huang jian ping Note: For a more detailed features description, please refer to the report TBR-C-202207-0335-31 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 2 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Contents 1. Duty Cycle ........................................................................................................................................................................................... 3 2. Maximum Conducted Output Power ................................................................................................................................................. 7 3. -6dB Bandwidth ................................................................................................................................................................................ 11 4. Occupied Channel Bandwidth ......................................................................................................................................................... 15 5. Maximum Power Spectral Density Level ......................................................................................................................................... 19 6. Band Edge ........................................................................................................................................................................................ 23 7. Conducted RF Spurious Emission .................................................................................................................................................. 28 8. Restrict Band .................................................................................................................................................................................... 35 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 3 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT BLE 1Mbps 2402 Ant1 85.6 0.68 0.47 NVNT BLE 1Mbps 2440 Ant1 85.6 0.68 0.47 NVNT BLE 1Mbps 2480 Ant1 85.6 0.68 0.47 NVNT BLE 2Mbps 2402 Ant1 57.45 2.41 0.93 NVNT BLE 2Mbps 2440 Ant1 57.75 2.38 0.93 NVNT BLE 2Mbps 2480 Ant1 57.45 2.41 0.93 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 4 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Test Graphs Duty Cycle NVNT BLE 1Mbps 2402MHz Ant1 Duty Cycle NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 5 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Duty Cycle NVNT BLE 1Mbps 2480MHz Ant1 Duty Cycle NVNT BLE 2Mbps 2402MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 6 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Duty Cycle NVNT BLE 2Mbps 2440MHz Ant1 Duty Cycle NVNT BLE 2Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 7 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT BLE 1Mbps 2402 Ant1 0.398 30 Pass NVNT BLE 1Mbps 2440 Ant1 -0.294 30 Pass NVNT BLE 1Mbps 2480 Ant1 -0.352 30 Pass NVNT BLE 2Mbps 2402 Ant1 0.445 30 Pass NVNT BLE 2Mbps 2440 Ant1 -0.238 30 Pass NVNT BLE 2Mbps 2480 Ant1 -0.281 30 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 8 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Test Graphs Power NVNT BLE 1Mbps 2402MHz Ant1 Power NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 9 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Power NVNT BLE 1Mbps 2480MHz Ant1 Power NVNT BLE 2Mbps 2402MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 10 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Power NVNT BLE 2Mbps 2440MHz Ant1 Power NVNT BLE 2Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 11 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 3. -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 1Mbps 2402 Ant1 0.64 0.5 Pass NVNT BLE 1Mbps 2440 Ant1 0.66 0.5 Pass NVNT BLE 1Mbps 2480 Ant1 0.67 0.5 Pass NVNT BLE 2Mbps 2402 Ant1 1.1 0.5 Pass NVNT BLE 2Mbps 2440 Ant1 1.06 0.5 Pass NVNT BLE 2Mbps 2480 Ant1 1.07 0.5 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 12 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Test Graphs -6dB Bandwidth NVNT BLE 1Mbps 2402MHz Ant1 -6dB Bandwidth NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 13 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 -6dB Bandwidth NVNT BLE 1Mbps 2480MHz Ant1 -6dB Bandwidth NVNT BLE 2Mbps 2402MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 14 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 -6dB Bandwidth NVNT BLE 2Mbps 2440MHz Ant1 -6dB Bandwidth NVNT BLE 2Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 15 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 4. Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT BLE 1Mbps 2402 Ant1 1.034 NVNT BLE 1Mbps 2440 Ant1 1.049 NVNT BLE 1Mbps 2480 Ant1 1.034 NVNT BLE 2Mbps 2402 Ant1 2.06 NVNT BLE 2Mbps 2440 Ant1 2.068 NVNT BLE 2Mbps 2480 Ant1 2.042 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 16 of 40 FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Test Graphs OBW NVNT BLE 1Mbps 2402MHz Ant1 OBW NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202207-0335-31 Page: 1 of 35 TB-RF-074-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 Radio Test Report FCC ID:2A56X-WATCH8PRO Report No. : TBR-C-202207-0335-31 Applicant : NJY Technology Co., Limited Equipment Under Test (EUT) EUT Name : Watch 8Pro Model No. : Watch 8Pro Series Model No. : ---- Brand Name : ---- Sample ID : 202207-0335-01# & 202207-0335-02# Receipt Date : 2022-08-02 Test Date : 2022-08-02 to 2022-09-09 Issue Date : 2022-09-09 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2013 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Witness Engineer : Camille Li Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202207-0335-31 Page: 2 of 35 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 8 1.8 Test Facility ........................................................................................................................... 9 2. TEST SUMMARY ..................................................................................................................... 10 3. TEST SOFTWARE ................................................................................................................... 10 4. TEST EQUIPMENT .................................................................................................................. 11 5. CONDUCTED EMISSION ....................................................................................................... 12 5.1 Test Standard and Limit .................................................................................................... 12 5.2 Test Setup ........................................................................................................................... 12 5.3 Test Procedure ................................................................................................................... 12 5.4 Deviation From Test Standard ......................................................................................... 13 5.5 EUT Operating Mode ........................................................................................................ 13 5.6 Test Data ............................................................................................................................. 13 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 14 6.1 Test Standard and Limit .................................................................................................... 14 6.2 Test Setup ........................................................................................................................... 15 6.3 Test Procedure ................................................................................................................... 16 6.4 Deviation From Test Standard ......................................................................................... 17 6.5 EUT Operating Mode ........................................................................................................ 17 6.6 Test Data ............................................................................................................................. 17 7. RESTRICTED BANDS REQUIREMENT ............................................................................. 18 7.1 Test Standard and Limit .................................................................................................... 18 7.2 Test Setup ........................................................................................................................... 18 7.3 Test Procedure ................................................................................................................... 19 7.4 Deviation From Test Standard ......................................................................................... 20 7.5 EUT Operating Mode ........................................................................................................ 20 7.6 Test Data ............................................................................................................................. 20 8. BANDWIDTH TEST ................................................................................................................. 21 8.1 Test Standard and Limit .................................................................................................... 21 8.2 Test Setup .............................................................................................................…

Text truncated - open the document above for the full version.

FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Appendix V EUT Test Photographs 15C Test Setup Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Below 1 GHz) FCC ID: 2A56X-WATCH8PRO TB-RF-074-1.0 Photo of Setup for Conducted Emission -----END OF REPORT-----
