2A583-MFREADERSemiconductor RFID

Brillian Network & Automation Integrated System Co., Ltd. Brillian RFID System Multi-Function Reader MF Reader The reproduction of any part of this user manual, in any from (by photocopying, microfilming or any other process) or the processing and distribution of the contents by electronic means is prohibited without the expressed written consent of Brillian. It is prohibited to copy the software or use it for other purposes. it is expressly prohibited to distribute copies of the software to third parties. Violators will be held liable for damage. Manufacturer and publisher Brillian Network & Automation Integrated System Co.,Ltd Add: No.41, Keyi St., Zhunan Township, Miaoli County 350, Taiwan, R.O.C. Tel: 886-37-580708 Fax: 886-37-580728 Email：[email protected] Website：http://www.brillian.com.tw I Brillian Network & Automation Integrated System Co., Ltd. Contents 1 Introduction............................................................................................................................. - 1 - 2 FCC Rule ................................................................................................................................ - 1 - 3 MF Reader SPEC .................................................................................................................... - 3 - 4 MF Reader Module .................................................................................................................. - 4 - - 1 - Brillian Network & Automation Integrated System Co., Ltd. 1 Introduction The Brillian CIDRW(Carrier ID Reader/Writer)，is BRILLIAN’s RFID(Radio Frequency Identification) system. The way of basic setup: Put a Transponder(Tag) fixed on the goods which you need to get goods information. The Transponder has a data record for the goods’. During the Host computer sent a order message to the CIDRW through RS232，The CIDRW will sent back the goods information which read from the Transponder by radio frequency. 2 FCC Rule Un-license band: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user authority to operate the equipment. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ◆ Reorient or relocate the receiving antenna. ◆ Increase the separation between the equipment and receiver. ◆ Connect the equipment into an outlet on a circuit different from that to which the receiver is needed. ◆ Consult the dealer or an experienced radio/TV technician for help - 2 - Brillian Network & Automation Integrated System Co., Ltd. 3 FCC Rule Modular This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users. For laptop installations, the antenna must be installed to ensure that the proper spacing is maintained in the event the users places the device in their lap during use (i.e. positioning of antennas must be placed in the upper portion of the LCD panel only to ensure 20 cm will be maintained if the user places the device in their lap for use) and 2) The transmitter module may not be co-located with any other transmitter or antenna. As long as the 2 conditions above are met, further transmitter testing will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in devices where the antenna may be installed such that 20 cm may be maintained between the antenna and users (for example access points, routers, wireless ASDL modems, certain laptop configurations, and similar equipment). The final end product must be labeled in a visible area with the following: "Contains TX FCC ID: {2A583-MFREADER}". RF Exposure Manual Information That Must be Included The users manual for end users must include the following information in a prominent location "IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter."Additional Information That Must be Provided to OEM Integrators The end user should NOT be …

Text truncated - open the document above for the full version.

External photo of EUT External photo of EUT External photo of EUT

Model No：MFReader Input：DC24V FCC ID：2A583-MFREADER www.brillain.com.tw BrillianNetwork&Automation Made in Taiwan 50mm 36mm

Internal photo of EUT Internal photo of EUT

TEST REPORT of FCC MPE REQUIREMENT Product : Semiconductor RFID Brand Name: Brillian Model: MF Reader Model Difference: N/A Applicant: Brillian Network & Automation Integrated System Co.,Ltd Address: No. 41, Keyi St., Zhunan Township, Miaoli County 350402, Taiwan Test Performed by: International Standards Laboratory Corp. LT Lab. TEL: +886-3-263-8888 FAX: +886-3-263-8899 No. 120, Lane 180, Hsin Ho Rd., Lung-Tan Dist., Tao Yuan City 325, Taiwan Report No.: ISL-23LR0063FMPE Issue Date :2023/05/17 Test results given in this report apply only to the specific sample(s) tested and are traceable to national or international standard through calibration of the equipment and evaluating measurement uncertainty herein. The uncertainty of the measurement does not include in consideration of the test result unless the customer required the determination of uncertainty via the agreement, regulation or standard document specification. This test report shall not be reproduced except in full, without the written approval of International Standards Laboratory Corp. -2 of 16- International Standards Laboratory Corp. Report Number: ISL-23LR0063MPE VERIFICATION OF COMPLIANCE Applicant: Brillian Network & Automation Integrated System Co.,Ltd Product Description: Semiconductor RFID Brand Name: Brillian Model No.: MF Reader Model Difference: N/A Date of test: 2023/05/15 ~ 2023/05/17 Date of EUT Received: 2022/05/15 We hereby certify that: All the tests in this report have been performed and recorded in accordance with the standards described above and performed by an independent electromagnetic compatibility consultant, International Standards Laboratory Corp. The test results contained in this report accurately represent the measurements of the characteristics and the energy generated by sample equipment under test at the time of the test. The sample equipment tested as described in this report is in compliance with the limits of above standards. Test By: Date: 2023/05/17 Barry Lee / Senior Engineer Prepared By: Date: 2023/05/17 Gigi Yeh / Senior Engineer Approved By: Date: 2023/05/17 Jerry Liu / Technical Manager -3 of 16- International Standards Laboratory Corp. Report Number: ISL-23LR0063MPE Table of Contents 1. Description of Equipment under Test (EUT) ............................................................................... 4 2. Test Configuration ....................................................................................................................... 5 2.1 EUT Configuration .......................................................................................................... 5 2.2 EUT Exercise ................................................................................................................... 5 2.3 Measurement Equipment Used: ....................................................................................... 5 2.4 Configuration of Tested System ...................................................................................... 6 2.5 Description of Test Modes ............................................................................................... 7 2.6 Test Procedure.................................................................................................................. 7 3. Summary of Test Results ............................................................................................................. 8 4. Standard Applicable ..................................................................................................................... 9 5. Evaluation Result: ...................................................................................................................... 11 PHOTOGRAPHS OF SET UP .......................................................................................................... 12 -4 of 16- International Standards Laboratory Corp. Report Number: ISL-23LR0063MPE 1. Description of Equipment under Test (EUT) General: Product Name: Semiconductor RFID Brand Name: Brillian Model Name: MF Reader Model Difference: N/A Power Supply: 24Vdc Frequency Range: 134kHz Modulation Type FSK Antenna Type Brand Model Frequency Range Connector Type 1 Dipole Antenna Brillian SLC-1500 134kHz PH -5 of 16- International Standards Laboratory Corp. Report Number: ISL-23LR0063MPE 2. Test Configuration 2.1 EUT Configuration The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner which intends to maximize its emission characteristics in a continuous normal application. 2.2 EUT Exercise The EUT (Transmitter) was tested with a test program to fix the TX/RX frequency that was for the purpose of the measurements. For more information please see test data and APPENDIX 1 for set-up photographs. 2.3 Measurement Equipment Used: Equipment Name Brand Model S/N Last Cal. Date Next Cal. Date Magnetic Field probe WAVECONTROL SMP2 20SN1339 02/09/2022 08/09/2023 -6 of 16- International Standards Laboratory Corp. Report Number: ISL-23LR0063MPE 2.4 Configuration of Tested System Radiated Emission Table 1 Equipment Used in Tested System Item Equipment Mfr/Brand Model/ Type No. Series No. Data Cable Power Cord 1 NB Dell X02-00 20201014 10193 15cm N/A 2 PSU ABM 8185D N/A N/A 30cm 3 RS232 ATEN UC-232A Z3F7- 076BP- 1698 185 N/A Note: All the above equipment/cables were placed in worse case positions to maximize emission signals during emission test. Grounding: Grounding was in accordance with the manufacturer’s requirements and conditions for the intended use. PSU NB EUT RS232 -7 of 16- International Standards Laboratory Corp. Report Number: ISL-23LR0063MPE 2.5 Description of Test Modes Test program used to control the EUT for staying in continuous transmitting and receiving mode is programmed. Channel 134kHz with each modulation were chosen for full testing. Maximum Permissible Exposure (MPE) 2.6 Test Procedure 2.6.1 Radiated Emissions The EUT is a placed on as turn table…

Text truncated - open the document above for the full version.

BrillianAnt ModelSLC Frequency134.2KHz Operating temperature -5°C~ -60°C Remark The LF antenna is composed of inductors, so the GAIN value cannot be provided Ant diagram Ant Photo

Brillian Network & Automation Integrated System Co.,Ltd TEST REPORT Model: MF Reader REPORT NUMBER 221000226THC-001 ISSUE DATE Apr. 17, 2023 PAGES 15 DOCUMENT CONTROL NUMBER GFT-OP-10h (28-Nov-2018) © 2020 Intertek Report No.: 221000226THC-001 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. GFT-OP-10h (28-Nov-2018) Page 1 of 15 Test Report 0597 Radio Spectrum TEST REPORT Applicant: Brillian Network & Automation Integrated System Co.,Ltd No. 41, Keyi St., Zhunan Township, Miaoli County 350402, Taiwan Product: Semiconductor RFID Model No.: MF Reader FCC ID: 2A583-MFREADER Test Method/ Standard: 47 CFR FCC Part 15.209 Test By: Intertek Testing Services Taiwan Ltd., Hsinchu Laboratory No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan Zero Chen Engineer Rico Deng Reviewer Report No.: 221000226THC-001 GFT-OP-10h (28-Nov-2018) Page 2 of 15 TEST REPORT Revision History Report No. Issue Date Revision Summary 221000226THC-001 Apr. 17, 2023 Original report Report No.: 221000226THC-001 GFT-OP-10h (28-Nov-2018) Page 3 of 15 TEST REPORT Table of Contents Summary of Test Data ................................................................................................................ 4 1. General Information ............................................................................................................... 5 1.1 Identification of the EUT .................................................................................................... 5 1.2 Antenna description ........................................................................................................... 5 2. Test specifications ................................................................................................................... 6 2.1 Test standard ...................................................................................................................... 6 2.2 Operation mode ................................................................................................................. 6 2.3 Peripherals equipment ....................................................................................................... 6 3. Radiated emission test FCC 15.209 ........................................................................................ 7 3.1 Operating environment ...................................................................................................... 7 3.2 Test setup & procedure ...................................................................................................... 7 3.3 Radiated emission limit ...................................................................................................... 9 3.3.1 General radiated emission limit ...................................................................................... 9 3.4 Radiated emission test data FCC 15.209 .......................................................................... 10 3.4.1 Measurement results: Fundamental emission ............................................................. 10 3.4.2 Measurement results: Frequencies equal to or less than 1 GHz .................................. 11 4. Conducted emission FCC 15.207 .......................................................................................... 13 Appendix A: Test equipment list ............................................................................................... 14 Appendix B: Measurement Uncertainty ................................................................................... 15 Report No.: 221000226THC-001 GFT-OP-10h (28-Nov-2018) Page 4 of 15 TEST REPORT Summary of Test Data Test Requirement Applicable Rule Result Radiated Emission test 15.209 Pass Conducted Emission test 15.207 N/A Antenna Requirement 15.203 Pass Note: Please note that the test results with statement of conformity, the decision rules which are based on: Safety Testing: the specification, standard or IEC Guide 115. Other Testing: the specification, standard and not taking into account the measurement uncertainty. Report No.: 221000226THC-001 GFT-OP-10h (28-Nov-2018) Page 5 of 15 TEST REPORT 1. General Information 1.1 Identification of the EUT Product: Semiconductor RFID Model No.: MF Reader Operating Frequency: 134kHz Rated Power: DC 24V Power Cord: N/A Sample receiving date: 2022/11/15 Sample condition: Workable Test Date(s): 2023/01/07 1.2 Antenna description Antenna Type : Dipole antenna Connector Type : PH Report No.: 221000226THC-001 GFT-OP-10h (28-Nov-2018) Page 6 of 15 TEST REPORT 2. Test specifications 2.1 Test standard The EUT was performed according to the requirement in FCC Part 15 Subpart C Section 15.209. 2.2 Operation mode The EUT connected to Notebook PC USB port, executing “Omron1ToNV1.0322.exe” and start. 2.3 Peripherals equipment Peripherals Brand Model No. Serial No. Data cable Notebook PC HP HP ProBook 440 G3 5CD8021S9H USB To RS232 Cable 3m USB to RS-232 (Customer provided) N/A N/A N/A N/A DC Power Supply Twintex TP-1603C N/A N/A Getway (Customer provided) N/A N/A N/A USB To RS232 Cable 3m Report No.: 221000226THC-001 GFT-OP-10h (28-Nov-2018…

Text truncated - open the document above for the full version.

Radiated Emission Test set-up photo 9kHz~30MHz Radiated Emission Test set-up photo 30MHz~1GHz
