2A5AQ-Q37Bluetooth Speaker

Bluetooth Speaker User Manual Thankyou for your choosethis product,Yourrecognitionhas alwaysbeenour drivingforce. 1:Instruction: Beforeusingthis productpls carefullyread the instructionfirst, to avoidany confused. 1: Firstlypleasepressthe swichon/offbuttonof this product.Thenopenyour smartdevices to connectthe bluetoothname”Stone135 ”, successfullyconnectedyou will hearingthe “Ding dong ” voicepromptfor paring. 2: Afterconnectedthe bluetooth,you can play any musicon yoursmartdevicesanytime anywherethen. 2:Howto using: Followspicturefor the productbuttonsinstruction. 1: Volumeup/Nextsongbutton.Shortpresswill be changeto next song.Longpresswill be volumeup. Dual pressfor FM radiofunction. 2: SwitchOn/Offbutton.Longpressof 3 secondfor Switchon/off.Shortpressfor Pause/Playfunction.Dual pressfor TWSfunction.Longpressof 8 secondfor Resetfunction. 3: Volumedown/Previoussongbutton.Shortpresswill be changeto previoussong.Long presswill be volumedown. 4: MicroUSBChargingport,you can connectthe USBcablefor get chargingif the unit batteryis low. 5: TF card slot, the unit can play musicafter TF card insert. 6: Mic position,help the unit get bettercommunicatesquality. FCC Caution: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) The device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement： Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. Thank you for your reading, hope you have a nice experience!

EUT EXTERNAL PHOTOGRAPHS EUT Photo 1 EUT Photo 2 EUT Photo 3 EUT Photo 4 EUT Photo 5 EUT Photo 6 EUT Photo 7 EUT Photo 8 ----------------The end----------------

FCC ID: 2A5AQ-Q37 RF exposure evaluation According to§15.247(i), §1.1307 (b) and KDB447498, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the commission’s guidance. The SAR-based exemption formula of §1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). F is in GHz, d is the separation distance (cm), and ERP20cm is per Formula (B.1). When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculate Portable device Antenna Gain: -0.58 dBi The maximun output power specified is: 1.21 dBm = 1.32 mW The source- based time-averaging conducted output power = 1.32* Duty factor mW (where Duty Factor≤1) = 1.32 mW The SAR Exclusion Threshold Level: 푃 th (mW) = ERP 20cm * (푑/20cm) 푥 (X= ) = 2.72 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing.

Inverted F Antenna Specification Summary ITEM ANT SPEC Model Name 2.4G ANT Horizontal Vertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.26 -0.76 -0.58 -5.25 -2.46 -1.86 MAX. Gain -0.58dB Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -5.2537 -22.1424 -12.4294 2450 -2.4652 -24.5837 -10.4702 2500 -1.86120 -29.5214 -9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd. 2400 MHz 2450 MHz 2500MHz

No.：BCTC/RF-EMC-005 Page: 1 of 44 Edition：A.5 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2304683716E Applicant: Shenzhen Hengchuang Intelligent Electronic Technology Co.,Ltd Product Name: Bluetooth Speaker Model/Type Reference: Stone 135 Tested Date: 2023-04-10 to 2023-04-13 Issued Date: 2023-04-26 Report No.: BCTC2304683716E No.：BCTC/RF-EMC-005 Page: 2 of 44 Edition：A.5 FCC ID:2A5AQ-Q37 The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Bluetooth Speaker Trademark: RSSIDOL, boAt Model/Type Ref.: Stone 135 Stone 105, Stone 200 Pro, Q37, H200, H200 Pro Prepared For: Shenzhen Hengchuang Intelligent Electronic Technology Co.,Ltd Address: No. 304, Staircase 1, No.125, Touyangtai New Villa Chiling Town, Gaofeng Community, DalangStreet, Longhua District, Shenzhen China Manufacturer: Shenzhen Hengchuang Intelligent Electronic Technology Co.,Ltd Address: No. 304, Staircase 1, No.125, Touyangtai New Villa Chiling Town, Gaofeng Community, DalangStreet, Longhua District, Shenzhen China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2023-04-10 Sample tested Date: 2023-04-10 to 2023-04-13 Report No.: BCTC2304683716E Test Standards: FCC Part15.247 ANSI C63.10-2013 Test Results: PASS Remark: This is Bluetooth BLE radio test report. Tested by: Approved by: Brave Zeng/ Project Handler Zero Zhou/Reviewer Report No.: BCTC2304683716E No.：BCTC/RF-EMC-005 Page: 3 of 44 Edition：A.5 Table of Content Test Report Declaration Page 1. Version .................................................................................................................. 5 2. Test Summary ....................................................................................................... 6 3. Measurement Uncertainty ..................................................................................... 7 4. Product Information And Test Setup ..................................................................... 8 4.1 Product Information ............................................................................................... 8 4.2 Test Setup Configuration ...................................................................................... 9 4.3 Support Equipment ............................................................................................... 9 4.4 Channel List ........................................................................................................ 10 4.5 Test Mode ........................................................................................................... 10 5. Test Facility And Test Instrument Used ............................................................... 11 5.1 Test Facility ......................................................................................................... 11 5.2 Test Instrument Used .......................................................................................... 11 6. Conducted Emissions .......................................................................................... 13 6.1 Block Diagram Of Test Setup .............................................................................. 13 6.2 Limit .................................................................................................................... 13 6.3 Test procedure .................................................................................................... 13 6.4 EUT Operating Conditions .................................................................................. 13 6.5 Test Result ............................................................................................................ 14 7. Radiated Emissions ............................................................................................. 16 7.1 Block Diagram Of Test Setup .............................................................................. 16 7.2 Limit .................................................................................................................... 17 7.3 Test procedure .................................................................................................... 18 7.4 EUT operating Conditions ................................................................................... 19 7.5 Test Result .......................................................................................................... 20 8. Radiated Band Emission Measurement and Restricted Bands Of Operation ...... 24 8.1 Block Diagram Of Test Setup .............................................................................. 24 8.2 Limit .................................................................................................................... 24 8.3 Test Procedure ................................................................................................... 25 8.4 EUT Operating Conditions .................................................................................. 25 8.5 Test Result .......................................................................................................... 26 9. Power Spectral Density Test ............................................................................... 27 9.1 Block Diagram Of Test Setup .............................................................................. 27 9.2 Limit .................................................................................................................... 27 9.3 Test procedure .................................................................................................... 27 9.4 EUT Operating Co…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS 1.1. Photos of Conducted Emission Measurement 1.2. Photos of Radiation Emission Measurement Spurious Emission Test Setup (Below 1GHz) Spurious Emission Test Setup (Above 1GHz) ----------------The end----------------
