2A5MD-ARCP01CORYPHAEUS TURN TABLE

www.ARKROCKET.com www.ARKROCKET.com 128 Card CORYPHAEUS TURNTABLE INSTRUCTION MANUAL ARCP01 ARCP01 Removin g Needle 1. Gentl y pu ll down the front edge of the needle. 2. Pull n ee dle forward. 3. Pull o ut and remove. In stall ing Needle 1. Position the need le with its tip facing down. 2. Li ne up the b ack of the needle wit h the cartridg e. 3. Insert the needle with its front en d at a downward ang le and gen tl y l ift the front of the needl e upwar d unti l it snaps into pla ce. Needle Replacement Read and understand this entire manual before us ing this product. Keep these instruc- tions for fut ure reference. Do not use this product near water. This product should be operated only by the type of power source indicated on the marking label or in this instruction manual. Do not defeat the safety purpose of the polarized plug. A polarized plug has two blades with one blade wider than the other. This plug will fit into the power outlet only one way. If you are unable to insert the plug fully into the outlet try reversing the plug. If the plug should still fail to fit, contact your electrician. Protect the power cord from being walked on or pinched particularly at plugs, conve- nience receptacles, and the point where they exit from the product. Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock. Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product. Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Do not use attachments not recommended by the product manufacturer as they may cause hazards. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating. Do not block or cover these openings. Unplug the product during lightning storm or when unused for long periods of time. 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. Safety Instructions Line in Port DC In Plug ARCP01 3.3 Bluetooth transmitter Operation: 1.Turn the function control to the Gramophone Transmit function,when a record player is working,the LED light will be flash. 2.Then units can be wireless connected with other device of buletooth speakers. 3.Once Paring successfull ,the LED light will show blue and stop flash. After finish the music transmit,you can listening record music with other device. NOTE:When transmit connected ,the volume control knob on main unit is not controlled. 4 5 3.6 3.7 A B C D E F G H I J K L M N O P Q R S T UV A:Turnatble B:Tone Arm Rest with Arm Locking Clip C:Spindle D:Tone Arm E:Adapter F:Counterweight G:Case H:Lever For Lifting Tone Arm I:Transmit ON/(Button J:USB REC USB Port L:Line lI Port M: Mode Selection Dial N:On/Off Switch And Volume Dial O:Operation Indictor Light P:Phone Headphone Port Q:Autostop Switch R:Speed Switch 78/45/33 S:Pickup With Stylus T:Speaker U: V: Bluetooth Transmitler Operation 3.7 KStop Rec 3 INCH FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc- tions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Reference No.: WTD23X03037181W Page 2 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTD23X03037181W Page 3 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTD23X03037181W Page 4 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTD23X03037181W Page 5 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7 EUT View 8

Reference No.: WTD23X03037181W Page 1 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: 2A5MD-ARCP01 Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTD23X03037181W Page 6 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTD23X03037181W Page 7 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTD23X03037181W Page 8 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 3 Solder Board-Component View 4 Reference No.: WTD23X03037181W Page 9 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 5 Solder Board-Component View 6 Reference No.: WTD23X03037181W Page 10 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Antenna View

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: HiFun Design and Trading, Inc Address of applicant: 4575 Webb Bridge Rd #4193, Alpharetta, GA, US Manufacturer: Shenzhen Bovi Electrical Appliance Co., Ltd. Address of manufacturer: 401 -501, No.32, Fulong Road, Gushu Community, Xixiang Subdistrict, Bao' an District, Shenzhen City, Guangdong Prov. General Description of EUT: Product Name: CORYPHAEUS TURN TABLE Trade Name / Model No.: ARCP01 Adding Model(s): / Rated Voltage: DC 5V Battery Capacity: / Adapter Model: MODEL: GKYPS0100050UL1 INPUT: AC100-240V~50/60Hz 0.5A OUTPUT: DC 5V 1000mA FCC ID: 2A5MD-ARCP01 Equipment Type: Mobile device Technical Characteristics of EUT: Bluetooth Bluetooth Version: V5.1(BR/EDR mode) Frequency Range: 2402-2480MHz RF Output Power: 0.99dBm (Conducted) Data Rate: 1Mbps, 2Mbps, 3Mbps Modulation: GFSK, π/4 DQPSK, 8DPSK Quantity of Channels: 79 Channel Separation: 1MHz Type of Antenna: PCB Antenna Antenna Gain: -0.85dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-Averaged Power ERP (MHz) (dBm) (dBi) (%) (dBm) (dBm) Bluetooth 2402 0.99 -0.85 100 1.00 -2.00 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2402 C 20.00 -2.00 0.63 768.00 0.01 Pass Note: 1. Time-Averaged Power=Output Power * Duty Cycle; ERP= Time-Averaged Power+ Antenna gain-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail -- -- -- -- -- -- Result: Pass

ANTE NNA SPECI FICA TION Summary ITEMANT SPEC Model Name2.4G ANT Antenna platePCB antenna Center Frequency HorizontalVertical 2400MHz2450MHz2500MHz2400MHz2450MHz2500MHz -1.66-0.850-6.16-3.65-2.21 MAX. Gain0 PolarizationHorizontal and Vertical Impedance50 Ohm ManufactureSHENZHENSHIXINZHONGXIN TECHNOLOGY.CO.,L TD Antenna Photo & Length (mm) THE FIRST, SECOND AND THIRD FLOORS OF BUILDING A1, EAST RING INDUSTRIAL ZONE, NO. 293, NANPU ROAD, SHANGLIAO COMMUNITY, XINQIAO STREET, BAO'AN DISTRICT, SHENZHEN, CHINA Address Horizontal:2400MHz2450MHz2500MHz Power(dBm) Max:0Min:-40Scale:5/div FrequencyGain(dBi) (MHz)Max.MinAvg. 2400-1.66179-30.2813-8.78713 2450-0.847811-38.7595-7.87812 2500-0.000000-23.6329-6.99139 Vertical:2400MHz2450MHz2500MHz Power(dBm) Max:0Min:-30Scale:5/div FrequencyGain(dBi) (MHz)Max.MinAvg. 2400-6.1623-23.1425-12.5295 2450-3.6534-26.2866-10.6699 2500-2.21101-29.4381-9.58526

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 64 TEST REPORT Reference No. .................... : WTD23X03037181W FCC ID ................................ : 2A5MD-ARCP01 Applicant ........................... : HiFun Design and Trading, Inc Address.............................. : 4575 Webb Bridge Rd #4193, Alpharetta, GA, US Manufacturer ..................... : Shenzhen Bovi Electrical Appliance Co., Ltd. Address.............................. : 401 -501, No.32, Fulong Road, Gushu Community, Xixiang Subdistrict, Bao' an District, Shenzhen City, Guangdong Prov. Product Name ................... : CORYPHAEUS TURN TABLE Model No... ......................... : ARCP01 Standards .......................... : FCC Part 15.247 Date of Receipt sample .... : 2023-03-02 Date of Test........................ : 2023-03-02 to 2023-03-13 Date of Issue ..................... : 2023-03-13 Test Report Form No. ....... : WTX_Part 15_247W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Jack Huang Silin Chen Reference No.: WTD23X03037181W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 64 TABLE OF CONTENTS 1. GENERAL INFORMATION ....................................................................................................................................5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .........................................................................5 1.2 TEST STANDARDS .................................................................................................................................................6 1.3 TEST METHODOLOGY ...........................................................................................................................................6 1.4 TEST FACILITY ......................................................................................................................................................6 1.5 EUT SETUP AND TEST MODE ..............................................................................................................................7 1.6 MEASUREMENT UNCERTAINTY .............................................................................................................................9 1.7 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................. 10 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 13 3. ANTENNA REQUIREMENT ................................................................................................................................. 14 3.1 STANDARD APPLICABLE ..................................................................................................................................... 14 3.2 EVALUATION INFORMATION ................................................................................................................................ 14 4. FREQUENCY HOPPING SYSTEM REQUIREMENTS .................................................................................... 15 4.1 STANDARD APPLICABLE ..................................................................................................................................... 15 4.2 FREQUENCY HOPPING SYSTEM ......................................................................................................................... 15 4.3 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ............................................................................... 16 5. QUANTITY OF HOPPING CHANNELS AND CHANNEL SEPARATION .................................................... 17 5.1 STANDARD APPLICABLE ..................................................................................................................................... 17 5.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 17 5.3 TEST PROCEDURE .............................................................................................................................................. 17 5.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 18 6. DWELL TIME OF HOPPING CHANNEL ........................................................................................................... 19 6.1 STANDARD APPLICABLE ..................................................................................................................................... 19 6.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 19 6.3 TEST PROCEDURE .............................................................................................................................................. 19 6.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 20 7. 20DB BANDWIDTH ............................................................................................................................................... 21 7.1 STANDARD APPLICABLE ...................................................................................................................…

Text truncated - open the document above for the full version.

Reference No.: WTD23X03037181W Page 11 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission Test Setup (Below 30MHz) Reference No.: WTD23X03037181W Page 12 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (30MHz to 1GHz) Radiation Emission Test Setup (1GHz to 18GHz) Reference No.: WTD23X03037181W Page 13 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (Above 18GHz) ***** END OF REPORT *****
