Solar-Powered Wireless Security Camera Kit User Manual JA-D300 ✉ [email protected]  +1 217-601-5050 Catalog We strive for the accuracy and completeness of the user manual, but due to product updates, there may be discrepancies with the actual application interface. Please refer to the live interface for the most current information. What's in the Box -----------------------------------------2 Product Overview ----------------------------------------3 Add the Camera Kits to the App ----------------------6 App Interface Introduction ----------------------------12 Mounting the Camera -----------------------------------16 FAQS ---------------------------------------------------------19 Notification of Compliance ----------------------------26 1 Setup Video Scan the QR code above to view the set up video Contact us If you have any questions about our products or services, please feel free to contact us: Email: [email protected] Phone: +1 217-601-5050 Very Important Tips *The Homebase requires continuous power supply using the included power adapter. *To ensure the systems best performance and normal function, please pay attention to the following: 1.Do not install the camera near a heat source. 2.Ensure that there are no reflective objects within 5 feet (1.5 meters) in front of the PIR sensor; otherwise, this may interfere with the PIR sensor. 3.To avoid false alarms, we recommend not installing the camera near shrubs, bushes, tall grass, or overhanging leaves within the PIR detection range. 4.Do not install the camera too far from the Homebase. The product needs to maintain a strong signal with the Homebase to function properly. 5.Once the camera is connected to the Homebase, all videos will be recorded on the memory card inside its Homebase. 2 What's in the Box Homebase x1 Network cable x1 Solar Panel Bracketx2 This product is available in two standard configurations. Actual accessories may vary depending on the kit model purchased: · 2-Camera Kit: HomeBase ×1 + Camera ×2 · 4-Camera Kit: HomeBase ×1 + Camera ×4 Positioning stickers x2 Power for Homebase x1 Type-C cable x2 Camera x2 Screw pack x4 Solar panel x2 User manual x1 3 Product Overview Camera： Antenna LED light & infrared light reset button Human Infrared Sensor(PIR) Working Indicator Light Slowly Blinking Red: Waiting for Homebase pairing Quickly Blinking Red: Wi-Fi is connecting Red Light Turns Blue: Wi-Fi connected Indicator light Microphone Lens 4 Homebase Sync Button❸ Network Indicator Light❶ IPC Indicator Light❷ Ethernet Port❻ TF Card Slot❹ Bottom of Homebase Power Port❺ 5 ❶ Network Indicator Light: Always on: The network connection is normal and smooth. Slow Flashing: Network connection error. Fast Flashing: The network connection is not connected. ❷ IPC Indicator Light: Always on: The camera is connected to the HomeBase normally. Slow Flashing: Abnormal connection between camera and HomeBase. Fast Flashing: The HomeBase is pairing the camera. Light not on: Camera is not added. ❸ Sync Button: Press and hold for 5s to enter the matching state. The HomeBase will search for cameras and establish connections with them. (Note: The HomeBase and camera of this system have been paired before shipped.) ❹ TF Card Slot:Supports up to 128 GBTF card. ❺ Power Port: Plug in the power cable to power the HomeBase. (Note: The Homebase requires continuous power supply using the included power adapter.) ❻ Ethernet Port: Plug in the network cable to connect to the network. 6 Add the Camera Kits to the App 1.Download "EseeCloud" App Search "EseeCloud" in App Store or Google Play, or scan the QR code below to download and install it on your smartphone. Scan to download the APP Note: To ensure the App's normal function, please allow the Notification/ Location permission on your smartphone. EseeCloud 7 2.Register Account New users need to register by email. The concrete steps are as follows: Step 1: Open the "EseeCloud" App to register an account. Go to the login interface then click "Register". Step 2: Enter your correct email address, click and check the circle below, then click "Register" Step 3: Finish safety certification and check your email to get the verification code. 8 Step 4: Enter the verification code and set your app log in password and then click "Confirm". For the security of your account, your password must be at least 6 characters long and must contain at least one uppercase letter, one lowercase letter and one number. Step 5: Congratulations! your app registration is complete. You can now start adding your device. 9 3.Connect the HomeBase to the Internet Step 1: Power On the HomeBase. Use the original power adapter (included in the box) to connect the HomeBase to a power source. For proper operation, ensure the power cable is securely plugged in and the HomeBase remains continuously powered Step 2: Connect the HomeBase to Your Router. Using the included Ethernet cable, connect the HomeBase to an available LAN port on your home router for stable data transmission. Note: Position the HomeBase at least 1 meter from the router to avoid signal interference. 4. Power on the Camera Switch on the power button to turn on the camera. When you hear the voice prompt, it means the camera is powered on. Then proceed to the next step to add HomeBase to the app power on/off 10 5.Connect HomeBase to the App Note: After power on the camera, when the Net indicator light and IPC indicator light of the HomeBase is steadily on, it indicates that the HomeBase is ready for connection. (If the Net indicator light is flashing, this signifies that the Ethernet cable is not properly connected. Please reinsert it until you hear a click sound.) Step 1: Open and log in to the "EseeCloud" app, then tap the "+" icon to add a device. Step 2: Select "Scan to Add" and scan the QR code on the HomeBase device. 11 Step 3: Wait for the device to automatically complete the network connection. Set the device name and purpose. Then, tap "Next" to confirm. Step 4: You have su…
