2A5QJZENONESTUUSB/Bluetooth/SPDIF decoder

DC 5V SPDIF IN/OUT BALANCED EXTERNAL POWER LR One Studio Outputs Technology licensed from AMR-Audio, UK Assembled in China 6. Balanced 4.4mm fixed level analogue output For connection of 4.4mm to XLR or similarly balanced interconnects. Warning: Do not insert 4.4mm headphones to this source as the full volume is likely to damage your headphones or your hearing. 7. Digital coaxial input/output Input channel selector (item 2) determines the function of digital coaxial connector, which is: a) an output when item 2 is on Bluetooth or USB b) an input when item 2 is on S/PDIF 8. Balanced XLR analogue output This is a balanced analogue output. 9. USB-C input This USB-C port is intended for data transfer only, It connects the ZEN One Studio to the audio source. Tip: For firmware and driver downloads, please visit: www.ifi-audio.com/download-hub/ Note: For use with a PC, it is necessary to install drivers. 10. Antenna Please attach the enclosed antenna for highest signal quality. 11. Power cable anti-drop pendant Used to secure the power cable to prevent the power supply from falling out or coming loose. 12. Power supply LED When connected to an external power supply, the light will turn green. 13. DC 5V power Please connect the ZEN One Studio to the included power supply. The ZEN One Studio must ONLY be powered by 5 volts. 68791113 Thank you for purchasing the ZEN One Studio. The ZEN One Studio is a Bluetooth, USB, S/PDIF DAC with digital and analogue outputs. 1. Power switch Short press to turn on. Long press to turn off. 2. Input selector This button cycles through 3 inputs, see item 5 for LED colours. 3. Display The colour of the ‘iFi’ logo in the center of the front display represents the file format received: LED Format (Wired/Wireless) White PCM/HWA(LHDC) Cyan DSD/LDAC Green MQA/aptX Adaptive Blue MQA Studio/aptX Magenta Original Sample Rate*/aptX HD Yellow AAC OFF SBC *MQB 4. Audio format and INPUT LED (kHz) The LED colour scheme indicates the sampling frequency that the ZEN One Studio receives from the music source. LED Mode Yellow PCM 44.1/48kHz White PCM 88.2/96/176.4/192/352/384.8kHz Cyan DSD 64/128 Red DSD 256 Flashing LED See item 5 below 5. Bluetooth pairing and Display ON/OFF 1) Pairing (long press) After power-on, the ZEN One Studio searches for a previously paired device and flashes blue. If a stored device is not found, it automatically enters pairing mode and flashes between blue and red. The LED switches to blue flashing, and the device cannot be connected automatically after a timeout of 5 minutes. To enter pairing mode, press the button for 3 seconds until the light flashes between blue and red. To pair it with your phone or another device, look for ’iFi Hi-Res audio‘ on the list of available Bluetooth devices. The ZEN One Studio is able to store up to 8 paired Bluetooth devices. When the 9th device is paired, the oldest device in memory will be deleted. 2) Display screen ON/OFF (short press) Turns the display on or off. Ver1.0 ifi-audio.com kHz / 12435 1012 SPECIFICATIONS: Digital inputs: USB3.0 Type B (USB2.0 compatible) S/PDIF (3.5mm coaxial) TM Bluetooth 5.1 (aptX, aptX HD, aptX Adaptive, aptX LL, LDAC, LHDC/HWA, AAC and SBC codec) Formats: DSD 256 / 11.3MHz PCM 384kHz MQA Decoder Bluetooth 96kHz Chipset: Bit-Perfect DSD & DXD DAC by Burr Brown Qualcomm QCC 5100 Series Analogue outputs: Coaxial, Audio XLR L/R 4.4mm Balanced line out Frequency Response: 5Hz - 80kHz ±3dB Outputs: 4V / 2V max. (BAL/UnBAL) Output Impedance: ≤72Ω/36Ω (BAL/UnBAL) SNR: -105dB(A) @ 0dBFS (BAL/UnBAL) THD + N: <0.002% @ 0dBFS(BAL/UnBAL) Power supply requirement: DC 5V (centre pin +ve) Power consumption: No Signal ~0.7W / Max Signal ~1.0W Dimensions: 158 x 100 x 35 mm (6.2" x 3.9" x 1.4") Net weight: 500g (1.1 lbs) Limited Warranty: 12 months *12 months typical or as permitted/required by local reseller laws. **Specications are subject to change without notice. Bluetooth (Blue/Red) S/PDIF (Green) USB (Green) Studio One FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Abbingdon Global Limited Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name:Abbingdon Global Limited Address: 79 SCARISBRICK NEW ROAD SOUTHPORT ENGLAND PR&8 6LJ Product Name:USB/Bluetooth/SPDIF decoder FCC ID:2A5QJZENONESTU Model(s):ZEN One Studio 2.911(d)(5)(ii) Applicant filing We, [Abbingdon Global Limited] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name:Vincent Luke Date:2023-05-24 Title and Company name: Marketing manager/Abbingdon Global Limited NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the 2.911 (d)(5)(ii) Applicant Attestation v1.3

Abbingdon Global Limited Section 2.911(d)(6)(i) Certification – Equipment Type Company name:Abbingdon Global Limited Address: 79 SCARISBRICK NEW ROAD SOUTHPORT ENGLAND PR&8 6LJ Product Name: USB/Bluetooth/SPDIF decoder FCC ID: 2A5QJZENONESTU Model(s): ZEN One Studio 2.911(d)(6)(i) Equipment Type We, [Abbingdon Global Limited] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Vincent Luke Date:2023-05-24 Title and Company name: Marketing manager /Abbingdon Global Limited NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the 2.911 (d)(6)(i) Equipment Type Attestation v1.2

Abbingdon Global Limited Section 2.911(d)(7) USA Agent for Service of Process Company name:Abbingdon Global Limited Address: 79 SCARISBRICK NEW ROAD SOUTHPORT ENGLAND PR&8 6LJ Product Name: USB/Bluetooth/SPDIF decoder FCC ID: 2A5QJZENONESTU Model(s): ZEN One Studio 2.911(d)(7) USA Designated Agent for Service of Process We, [Abbingdon Global Limited] (“the applicant”) designate [Abbingdon LC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name:Abbingdon LC Address:1211 Park Ave, Ste 102 San Jose, CA, 95126 FRN: 0033844564 Contact Name:Simon MAN Telephone No:669-500-8811 Email:[email protected] Applicant Company name:Abbingdon Global Limited Address: 79 SCARISBRICK NEW ROAD SOUTHPORT ENGLAND PR&8 6LJ FCC Grantee Code: 2A5QJ Contact Name: Vincent Luke Telephone No: 44(0)01704227204 Email:peter. [email protected] 2.911 (d)(7)USA Agent v1.3 Abbingdon Global Limited Signature: Title:Manager Signature: Title: Marketing manager Date:2023-05-24 Date:2023-05-24 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the 2.911 (d)(7)USA Agent v1.3

Abbingdon Global Limited Agent Authorization Company:Abbingdon Global Limited Address: 79 SCARISBRICK NEW ROAD SOUTHPORT ENGLAND PR&8 6LJ Product Name: USB/Bluetooth/SPDIF decoder Model Number(s): ZEN One Studio Product Description:Frequency in 2402-2480MHz, BT mode operation We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023-05-24 Name: Vince Luke Title: Marketing manager Company: Abbingdon Global Limited

Abbingdon Global Limited Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023-05-24 Subject; Request for Confidentiality FCC ID: 2A5QJZENONESTU To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely Signature: Name: Vincent Luke Title: marketing manager

FCC ID: 2A5QJZENONESTU FCC ID: 2A5QJZENONESTU FCC ID: 2A5QJZENONESTU ANT

FCC ID: 2A5QJZENONESTU

FCC ID: 2A5QJZENONESTU FCC ID: 2A5QJZENONESTU FCC ID: 2A5QJZENONESTU

RF Exposureevaluation Exposure category: General population/uncontrolledenvironmentEUT Type: ProductionUnit Device Type: MobileDevice Refer Standard: KDB 447498 D01 General RF Exposure Guidancev06FCC Part 2§2.1091 FCC ID: 2A5QJZENONESTU 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shallbeoperated in a manner that ensures that the public is not exposed to radio frequencyenergylevel in excess of the Commission’sguidelines. According to §1.1310 and §2.1091 RF exposure iscalculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures andEquipmentAuthorizationPolicies 2. Limit Limits for Maximum Permissible Exposure (MPE)/ControlledExposure Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) PowerDensity (mW/cm²) AveragingTime (minute) Limits for Occupational/ControlledExposure 0.3 –3.0 614 1.63 (100)* 6 3.0 –30 1842/f 4.89/f (900/f 2 )* 6 30 –300 61.4 0.163 1.0 6 300 –1500 / / f/300 6 1500 –100,000 / / 5 6 Limits for Maximum Permissible Exposure (MPE)/UncontrolledExposure Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) PowerDensity (mW/cm²) AveragingTime (minute) Limits for Occupational/ControlledExposure 0.3 –3.0 614 1.63 (100)* 30 3.0 –30 824/f 2.19/f (180/f 2 )* 30 30 –300 27.5 0.073 0.2 30 300 –1500 / / f/1500 30 1500 –100,000 / / 1.0 30 F=frequency inMHz *=Plane-wave equivalent powerdensity 3. MPE Calculation Method Predication of MPE limit at a givendistance Equation from page 18 of OET Bulletin 65, Edition97-01 S=PG/4πR² Where: S=powerdensity P=power input toantenna G=power gain of the antenna in the direction of interest relative to an isotropicradiator R=distance to the center of radiation of theantenna 4. Result As declared by the Applicant, the EUT is a wireless device used in a fix application, atleast20 cm from any body part of the user or nearby persons; from the maximum EUT RFoutputpower, the minimum separation distance, r =20cm, as well as the gain of the used BT antenna is 0.5dBi, the RF power density can beobtained. EDR Freq. (MHz) Output Power (dBm) Target powerW/ tolerance (dBm) Max tuneup power (dBm) Output power to antenna (mW) Ant Gain (dBi) Power Density at R=20cm (mW/cm2) Limit (mW/c m2) Result GFSK 2402 3.548 3±1.0 4 2.512 0.5 0.00056 1 Pass 2441 3.423 3±1.0 4 2.512 0.5 0.00056 1 Pass 2480 3.280 3±1.0 4 2.512 0.5 0.00056 1 Pass π/4DQPSK 2402 4.174 4±1.0 5 3.162 0.5 0.00071 1 Pass 2441 4.039 4±1.0 5 3.162 0.5 0.00071 1 Pass 2480 3.894 3±1.0 4 2.512 0.5 0.00056 1 Pass 8DPSK 2402 4.238 4±1.0 5 3.162 0.5 0.00071 1 Pass 2441 4.089 4±1.0 5 3.162 0.5 0.00071 1 Pass 2480 3.946 3±1.0 4 2.512 0.5 0.00056 1 Pass Note: The estimation distance is20cm 5. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for theuncontrolled RF Exposure of mobiledevice.

ANT SPECIFICATION 1、 Test Environment condition: Ambient Temperature 19 to 25°C Antenna type Inverted‐F Antenna Antenna model B00012 Ambient Relative Humidity 45 to 55 % 2、 Technical Information Frequency Range 2400MHz ~2500MHz Test Frequencies 2402MHz 2441MHz 2480MHz 3、 Test Uncertainty item Uncertainty VSWR(S11) 0.2dB Gain 0.5dB

Shenzhen DL Testing Technology Co., Ltd.Report No.: DL-20230506004E Test ReportTel: 400-688-3552Web:www.dl-cert.comEmail: [email protected] 1 of 64 FCC Part 15C Test Report FCC ID: 2A5QJZENONESTU Applicant:Abbingdon Global Limited Address:79 SCARISBRICK NEW ROAD SOUTHPORT ENGLAND PR&8 6LJ Manufacturer:Abbingdon Global Limited Address:79 SCARISBRICK NEW ROAD SOUTHPORT ENGLAND PR&8 6LJ EUT:USB/Bluetooth/SPDIF decoder Trade Mark: Model Number:ZEN One Studio Date of Receipt:May 06, 2023 Test Date:May 07, 2023 - May 16, 2023 Date of Report:May 17, 2023 Prepared By:Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2013 Test Result:Pass Report Number:DL-20230506004E Prepared (Test Engineer):Pxing Huang Reviewer (Supervisor):Jack Bu Approved (Manager):Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd.Report No.: DL-20230506004E Test ReportTel: 400-688-3552Web:www.dl-cert.comEmail: [email protected] 2 of 64 Table of ContentsPage 1. SUMMARY OF TEST RESULTS5 1.1 TEST FACILITY6 1.2 MEASUREMENT UNCERTAINTY6 2. GENERAL INFORMATION7 2.1 GENERAL DESCRIPTION OF EUT7 2.2 DESCRIPTION OF TEST MODES8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED9 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE)9 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING9 2.6EQUIPMENTSLISTFORALLTESTITEMS10 3. EMC EMISSION TEST11 3.1 CONDUCTED EMISSION MEASUREMENT11 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS11 3.1.2 TEST PROCEDURE11 3.1.3 DEVIATION FROM TEST STANDARD11 3.1.4 TEST SETUP12 3.1.5 EUT OPERATING CONDITIONS12 3.1.6 TEST RESULTS12 3.2 RADIATED EMISSION MEASUREMENT15 3.2.1 RADIATED EMISSION LIMITS15 3.2.2 TEST PROCEDURE16 3.2.3 DEVIATION FROM TEST STANDARD16 3.2.4 TEST SETUP16 3.2.5 EUT OPERATING CONDITIONS17 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ)18 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ)19 3.2.8 TEST RESULTS (1GHZ~25GHZ)21 3.3 RADIATED BAND EMISSION MEASUREMENT22 3.3.1 TEST REQUIREMENT:22 3.3.2 TEST PROCEDURE22 3.3.3 DEVIATION FROM TEST STANDARD22 3.3.4 TEST SETUP23 3.3.5 EUT OPERATING CONDITIONS23 4. CONDUCTED BAND EDGE AND SPURIOUS EMISSION25 4.1 LIMIT25 4.1.1 TEST SETUP25 4.1.2 TEST PROCEDURE25 4.1.3 DEVIATION FROM STANDARD25 Shenzhen DL Testing Technology Co., Ltd.Report No.: DL-20230506004E Test ReportTel: 400-688-3552Web:www.dl-cert.comEmail: [email protected] 3 of 64 Table of ContentsPage 4.1.4 TEST RESULT26 5. PEAK OUTPUT POWER37 5.1 APPLIED PROCEDURES / LIMIT37 5.1.1 TEST PROCEDURE37 5.1.2 DEVIATION FROM STANDARD37 5.1.3 TEST SETUP37 5.1.4 EUT OPERATION CONDITIONS37 5.1.5 TEST RESULTS38 6. NUMBER OF HOPPING CHANNEL44 6.1 APPLIED PROCEDURES / LIMIT44 6.1.1 TEST PROCEDURE44 6.1.2 DEVIATION FROM STANDARD44 6.1.3 TEST SETUP44 6.1.4 EUT OPERATION CONDITIONS44 6.1.5 TEST RESULTS44 7. BANDWIDTH TEST47 7.1 APPLIED PROCEDURES / LIMIT47 7.1.1 TEST PROCEDURE47 7.1.2 DEVIATION FROM STANDARD47 7.1.3 TEST SETUP47 7.1.4 EUT OPERATION CONDITIONS47 7.1.5 TEST RESULTS48 8. HOPPING CHANNEL SEPARATION MEASUREMENT53 8.1 APPLIED PROCEDURES / LIMIT53 8.1.1 TEST PROCEDURE53 8.1.2 DEVIATION FROM STANDARD53 8.1.3 TEST SETUP53 8.1.4 EUT OPERATION CONDITIONS53 8.1.5 TEST RESULTS53 9. DWELL TIME OF OCCUPANCY56 9.1 APPLIED PROCEDURES / LIMIT56 9.1.1 TEST PROCEDURE56 9.1.2 DEVIATION FROM STANDARD56 9.1.3 TEST SETUP56 9.1.4 EUT OPERATION CONDITIONS56 9.1.5 TEST RESULTS57 10. ANTENNA REQUIREMENT63 10.1 STANDARD REQUIREMENT63 Shenzhen DL Testing Technology Co., Ltd.Report No.: DL-20230506004E Test ReportTel: 400-688-3552Web:www.dl-cert.comEmail: [email protected] 4 of 64 Table of ContentsPage 10.2 EUT ANTENNA63 11. TEST SEUUP PHOTO64 12. EUT PHOTO64 Shenzhen DL Testing Technology Co., Ltd.Report No.: DL-20230506004E Test ReportTel: 400-688-3552Web:www.dl-cert.comEmail: [email protected] 5 of 64 . SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test ItemJudgmentRemark 15.207Conducted EmissionPASS 15.209(a)Radiated Spurious EmissionPASS 15.205Restricted Band EdgePASS 15.247(b)(1)Peak Output PowerPASS 15.247(a)(1)(iii)Number of Hopping FrequencyPASS 15.247(a)(1)(iii)Dwell TimePASS 15.247(a)(1)BandwidthPASS 15.247(a)(1)Hopping Channel SeparationPASS 15.247 (d) Conducted Unwanted Emissions and Bandedge PASS 15.203Antenna RequirementPASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen DL Testing Technology Co., Ltd.Report No.: DL-20230506004E Test ReportTel: 400-688-3552Web:www.dl-cert.comEmail: [email protected] 6 of 64 TEST FACILITY Shenzhen DL Testing Technology Co., Ltd. Add. : 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 ISED Registration number: 27485 IC Registered No.:CN0118 MEASUREMENT UNCERTAINTY The reported uncertainty of measurementy±U, where expended uncertaintyUis based on a standard uncertainty multiplied by a coverage factor ofk=2 ， providing a level of confidence of approximately95% 。 No.ItemUncertainty 1Conducted Emission Test±2.56dB 2RF power,conducted±0.42dB 3Spurious emissions,conducted±2.76dB 4 All emissions,radiated(<1G)±3.65dB 5 All emissions,radiated(>1G)±4.89dB 6Temperature±0.5°C 7Humidity±2% Shenzhen DL Testing Technology Co., Ltd.Report No.: DL-20230506004E Test ReportTel: 400-688-3552Web:www.dl-cert.comEmail: [email protected] 7 of 64 . GENERAL INFORMATION GENERAL DESCRIPTION OF EUT Product Name: USB/Bluetooth/SPDIF decoder Model No.: ZEN One Studio Sample ID: DL-20230506004E-1# Serial No.: N/A Model Diff…

Text truncated - open the document above for the full version.

FCC ID: 2A5QJZENONESTU RadiatedEmission(Below 1G) Radiated Emission (Above 1G) FCC ID: 2A5QJZENONESTU Conducted Emission
