User Manual LaserPecker 4 Scan QR code to download APP APP/PC Software Download 2 1 Scan the QR code to Download the Android or iOS APP Download the Windows/Mac software from the Official LaserPecker website. NOTE: After installing the APP, please read all warnings and instructions carefully to ensure safety and the correct operation of the product Apple App Google Play After-Sales Services Online User Community Technical support for this product is available globally. Please contact us if you encounter any problems with your LP4 and we will get back to you as soon as possible. LaserPecker’s huge online global community connects our diverse group of dedicated users and offers support, inspiration, and a showcase for sharing creativity. Email：[email protected] Tel: +86 0755-28913864 Facebook：LaserPecker 4 LaserPecker 4 VIP Group www.laserpecker.net 01 Contents . Contents & List of Included Parts Component Overview & Instructions Electric Stand Assembly Attaching the Laser Safety Shield Connecting Components Control Interface Options Focal Ranging Methods Touch Screen Function Oblique Positioning Attaching Alignment Fixtures Machine Maintenance Product Specifications User Safety Guide Precautions & Disclaimer Warning Warranty Terms FCC Requirement Copyright List of Included Parts Electric Stand *1Laser Unit *1 Field Lens *1 & Cover *1Safety Cover *1 AC Cord *1 & Power Adapter *1 1.5m Cable *1 & 0.6m Cable *1 Safety Goggles *1 Wrench M2.5 *1 & Screw M4X10 *4 Alignment Fixtures & Screw *4 Ruler *1 01 03 05 06 07 08 09 10 12 13 14 15 16 17 18 19 20 21 02 List of Included Parts Single-step Jaw * 3 Double-step Jaw * 3 Stud Component * 3 Riser Add-on*1 M3x6 Screw *6M3x10 Screw *4 Elevation Pad * 1 Rotary Headstock Head Support Module Rotary Headstock Baseplate Hex Key Cutting Pads *2Slide Axis *1 M3X6 Screw *6 Riser Add-on *1 1m USB-C Cable *1 Wrench * 1 Component Overview & Instructions 03 Laser Unit Touch Screen Emergency Stop Button LED Operations Indicator Red Focal Measuring Light Source Positioning Plate and Alignment Fixtures Field Lens / Lens Cover Electric Stand LED Indicator Up Button Long Press for Continuous Rise Short Press for 1 mm Rise Down Button Long Press for Continuous Decent Short Press for 1 mm Descent Component Overview & Instructions 04 USB-C Port for PC Software Connection Magnetic Safety Shield Mount USB Port for Electric Stand Cable USB Port for Accessory Cable DC Power Cable Input Base Tower Bracket & Connecting Bolt Angle Adjustment Knob Safety Cover & Exhaust Fan Electric Stand USB-C Power Input Electric Stand Assembly 12 Attach the tower to the base unit using the wrench and 4 screws. Attach the Laser Unit to the Electric Stand by aligning the underside threads with the bracket and securely tightening the knob. Turn clockwise to tighten bolt 05 12 Safety Cover in position. Place the Laser Cover under the Field Lens and gently guide it upwards until it attaches magnetically to the Laser Unit. Attaching the Laser Safety Cover Magnet adsorption 06 1.1. Connecting Components 07 LED Operations Indicator · Blinking Blue: Waiting for Bluetooth Connection · Solid Blue: Bluetooth is Connected · Streaming Green: Data is Transmitting · Multi Color: Job in Progress Connect to power supply with the AC Cord & Power Adapter Connect to Electric Stand with the 0.4m USB-C Cable Connect to Safety Cover & Exhaust Fan Bluetooth ConnectionUSB & LP Bluetooth Dongle Connection Download the LaserPecker APP and follow the onscreen instructions for registration and the optional guided tutorial. If you do not receive a registration confirmation email, check your junk/spam folder. Next, with your device’s Bluetooth enabled, search for and connect the APP to your LP4. Download and install the WINDOWS or Mac LaserPecker Software onto your computer. Use a USB-C cable or an LP Bluetooth Dongle to connect it to your LP4. Click the red "Device not connected" button and choose the right port to get connected. 08 Control Interface Options Focal Ranging Methods While in Preview Mode on the Mobile App or PC Software, set the focal range by adjusting the height of the Laser Unit until the 2 red dots align into 1 or touch each other on the surface of the material to be worked on. To set the focal range by distance, raise or lower the Laser Unit with the Electric Stand controls until the underside measures 150 mm from the top of the material to be worked on. Measurement FocusingRed Dot Focusing 09 Focal Distance 150 mm Indicates Optimal Focus LASER APERTURE AVOID EXPOSURE LASERRADIATION IS EMITTEDFROM THIS APERTURE ENSURE YOU HAVE SAFETY PROTECTIONS BEFORE USE Touch Screen Functions 1064nm Home Screen Swipe left & right to select laser type 450nm Home Screen File Selection Screen Tap for sleep mode Tap anywhere to wake Tap to select laser Home Screen Tap for File Selection Screen Tap to return to Home Screen Tap the desired file to proceed to the Work Setting Screen *Swipe up or down to locate files that have been transferred from the official app 10 Work Preview Screen Touch Screen Functions Continued Tap for Work Preview Screen Tap for Working Screen Slide to adjust the brightness of preview laser beam Tap to stop previewing Working Screen Pause engraving Tap to stop working Work Settings Screen 11 Oblique Angle Positioning Use the Angle Adjustment Knob to position the Laser Unit for working on an angle. Turn the bolt to adjust the Laser Unit to the corresponding angle of the work surface. 150 mm Focal Length 12 12 Example of attached Alignment FixturesTo secure materials during engraving and for accurate repeat placement, position the Alignment Fixtures to the desired location on the base plate and attach them by tightening the screws. Attaching Alignment Fixtures Tighten the screw 13 The Laser Unit’s dust screen is attached magnetically for easy cleaning. Machine Maintenance Original status of the Magnetic Dust Screen. Power off the Laser Unit before you clean the screen. Remove and clean the scre…
