2A6KA-AB309Bluetooth Remote control

名称：说明书 型号：AB309 尺寸: 60x90mm 展开尺寸: 480x90mm 105克哑粉纸，单黑双面印刷, 风琴折 Portable Selfie Tripod Phone Clamp Unfolding Phone Securing Portrait/Landscape Adjustment First, flip the phone clamp upward to the top, then pull out the telescopic rod. Flip open the clamp arms and clamp the phone in place. The phone clamp supports 360° roll adjustment for portrait/ landscape switching and 180° tilt adjustment. Simultaneously press the release buttons on both sides of the top of the phone clamp to remove it, then use the 1/4" interface to attach other devices such as an action camera. Phone Clamp Removal for 1/4" Interface Access Phone Clamp to Lanyard Securing Tripod Deployment and Storage Tripod Deployment and Storage After removing the phone clamp, simultaneously press the release buttons on both sides of its top to secure it to the buckle of the lanyard. Deployment: Hold the selfie stick with its bottom facing up and flick gently to deploy the tripod legs. Specifications and Parameters Storage: Fold the tripod legs, then push them back into the selfie stick. Product Introduction Power button Tripod Indicator light Function button Shutter button Telescopic rod Phone clamp Rotating shaft Remote control 1/4" interface Product Introduction Lanyard Quick-release button User ManualAB309 Product Name: Swing-to-deploy tripod Product Model: AB309 Dimensions: 208*33*51mm Product Weight: 228g Connection Method: Bluetooth Remote Control Distance: 10m Product Materials: ABS+PC/Aluminum alloy Supported Systems: Android/IOS/HarmonyOS Battery Type: Lithium-manganese button cell Battery Model: CR1632 Battery Capacity: 110mAh Bluetooth Version: BT4.2 or above After-sales service commitment of SEAJIC: We provide three-warranty services for all products which are sold through the official channel or authorized channel of SEAJIC in strict accordance with Law of the People's Republic of China on Protection of Consumer Rights and Interests. For regions where special three-warranty regulations are executed, SEAJIC hereby undertakes to abide by the local regulations. Please keep the warranty card and effective purchase voucher properly in order to safeguard your legal rights. OSM (China) owns the right of interpretation of pictures and texts in the Manual。 User Information Name: Contact phone: Date of purchase: Purchase platform and shop name: Order No.: Product information Model: After-sales services of SEAJIC Warranty Card of SEAJIC OSM PASS Qualified Inspector 01 1.Mount the phone on the holder, then press and hold the power button for 3 seconds until the white indicator light flashes to enter Bluetooth pairing mode; 2.Open the Bluetooth settings on your phone, search for and connect to "AB309". When connected successfully, the white light stays on for 3 seconds and then turns off; 3.Press the selfie stick's shutter button to take photos. Press and hold the power button for 3 seconds to power off the selfie stick and exit Bluetooth pairing mode. AB309 Note: The selfie stick is set to automatically connect to the successfully paired phone. If you need to switch the connected device, please first unpair the Bluetooth connection on the currently paired phone, then pair with and connect to the new device. Bluetooth Connection to PhoneRemote Control Function InstructionsRemote Control Function Instructions Power Button: Press and hold for 3 seconds to turn on/off. Function Button: 1. Single click: Switch between front and rear camera once the camera app is opened; 2. Double click: Quickly put the phone into sleep mode (screen off ); 3. Press and hold: Enter camera interface when screen is locked; open camera app when screen is unlocked. Shutter Button: 1. Middle button - single click: Take photo, start/stop recording. Press and hold: Burst shooting or video recording (depending on phone model settings); 2. Push up once: Zoom in one step. Push up and hold: Zoom in continuously; 3. Push down once: Zoom out one step. Push down and hold: Zoom out continuously; 4. Push left once: Switch modes leftward in camera app. Push right once: Switch modes rightward in camera app. Power On: 1. Press and hold the power button for 3 seconds to turn on; 2. Enter pairing mode. The indicator light flashes white at 1Hz for 180 seconds; 3. Enter broadcasting mode. The white light flashes; 4. When connected successfully, the white light stays on for 3 seconds then turns off; 5. If not connected successfully, it enters sleep mode after 3 minutes. Sleep Mode: 1. After power-on and connection, it will automatically enter sleep mode after 5 minutes of inactivity; 2. When connected to the phone, if the distance becomes too large and the connection is lost, the remote enters sleep mode directly; 3. When connected to the phone, if the phone's Bluetooth is turned off, the remote enters sleep mode directly; 4. When connected to the phone, if the pairing is manually cancelled on the phone, the remote enters sleep mode directly. Paired Connection Status: White (Keycode mode) / Blue (touch mode), indicator light stays on for 3 seconds then turns off. HID/CMD Switching: Press and hold the function button together with zoom in/out button for 3 seconds. (Example: In HID mode, white light flashes 3 times then switches to CMD mode with blue light.) Wake from Sleep: In sleep mode, pressing any button triggers reconnection to the phone. Once connected successfully, the white light stays on for 3 seconds then turns off. If reconnection fails, the remote enters broadcasting mode with white light flashing. If not connected successfully, it enters sleep mode after 3 minutes. Turn-off Method: 1. Press and hold the power button for 3 seconds, the white indicator light flashes 3 times then turns off; 2. Automatically turns off after 15 minutes in sleep mode. Low Battery Indicator: 1. When the battery voltage is below 2.6V, each time the remote is powered on with no active pairing, it will pair or reconnect. After successful pairing, the white light stays on for 5 seconds, then t…

Text truncated - open the document above for the full version.

Aug 2026

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Dongguan OSM Digital Co., Ltd Grantee code: 2A6KA FRN: 0032288896 FCC ID: 2A6KA-AB309 Contact Name: Anmy cheng Address: Room 401, Building 2, No. 26, Tangxia Keyuan Road, Tangxia Town, Dongguan City, Guangdong Province, China Telephone No: 0769-38820219 Fax No: / Email: [email protected] i. [Dongguan OSM Digital Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Dongguan OSM Digital Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Dongguan OSM Digital Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment. Date: 2026/8/4 Applicant’s Name: Dongguan OSM Digital Co., Ltd Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Dongguan OSM Digital Co., Ltd Code 00018768 Ed. 2 Item 1. The device is able to install software/program installation? ☐ Yes, go to Item 2. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky cybersecurity or anti-virus software. Item 2. Technical Requirements for Kaspersky Cybersecurity Software: # General Requirements (For all Devices) Yes / No or N/A Comments 1 Internet connection for activation and updates (For all Operating Systems) N/A # General Requirements (For Windows Devices) Yes / No or N/A Comments 1 Storage: 1500 MB free space on the hard drive N/A Device Bluetooth Remote control Company name Dongguan OSM Digital Co., Ltd Grantee code 2A6KA FCC ID 2A6KA-AB309 FRN 0032288896 Contact name Anmy cheng Address Room 401, Building 2, No. 26, Tangxia Keyuan Road, Tangxia Town, Dongguan City, Guangdong Province, China Telephone number 0769-38820219 E-mail [email protected] Chipset/module information Bluetooth: WS8108 Operating System (if applicable) / Storage Capacity (hard drive or other permanent memory storage, if applicable) / 2 2 Operating System: Microsoft Windows 8, 8.1, 10 & 11 Home / Pro / Enterprise Microsoft Windows 7 Starter / Home Basic & Premium / Professional / Ultimate SP1 or higher N/A 3 Processor: 1 GHz or higher (x86 or x64) N/A 4 Memory (RAM)1 GB (32-bit) or 2 GB (64-bit) N/A 5 Screen Resolution: Minimum resolution of 1024 x 768 N/A # General Requirements (For macOS devices) Yes / No or N/A Comments 1 Operating System macOS® 13 – 14 N/A 2 Memory (RAM)4 GB N/A 3 Storage: 3455 MB free space on the hard drive N/A # General Requirements (For Android Devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: Android™ 10 – 14 N/A 3 Screen Resolution: Minimum resolution of 320 x 480 N/A # General Requirements (for iOS devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: iOS® 17 N/A After reviewed the technical requirements, is the device capable of supporting the installation of Kaspersky software? ☐ Yes, go to Item 3. 3 ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky software Item 3. Connectivity Capabilities: # Physical Interface Purpose Justification 1 1 # Wireless Interface Purpose Justification 1 1 After the review of this items, the device: ☒ Cannot support installation of any cybersecurity or anti-virus software on the covered list. ☐ Potentially can operate with any cybersecurity or anti-virus software on the covered list – additional third- party proof is provided to demonstrate compliance with requirements as of 2.911(d)5(i),(ii) – “Proof of Compliance with Covered List Software Requirements” of this document applies Signature: Name: Anmy cheng Date: 2026/8/4 1 The justification field is used to justify why the software cannot be received through that interface. Check the annex for more indications.

TCBCALLpágina1 FileFCCID:2A6KA-AB309 PleaseuploadanexhibitthatexplainshowdoestheTCBverifythenewagentinformation: 1-IstheaddressoftheagentavalidphysicalUSmailingaddress(notaUSpostofficebox,notavirtualmailbox,notP.O.Boxes,notavacantlot,notapublicbuilding, etc.) ○Wehavecheckediftheaddressexistsinarealandpotentialbuilding(Googlemaps)+officialUSregister,afterthisverificationandtheevidencebelowwecan guaranteethefollowing: notaUSpostofficebox notavirtualmailbox notP.O.Boxes notavacantlot notapublicbuilding(note) ►WecheckedtheFCCFRNSearchbasedontheinformationprovidedbythegrantee. Maps Ontheofficialregister TCBCALLpágina2 TCBCALLpágina3 TCBCALLpágina4 ►CONCLUSIONbyTCB:TheASOPdefinedandprovidedbygranteeisVALIDandconfirmed.Thereforetheexhibit"SampleAttestationStatements-USagentv2" includedinthefileisok. 2-IstheagentphysicallylocatedatthatvalidUSaddresssuchthattheagentcanbelegallyservedatthataddress? Yes,checkabove 3-Hasthelistedagentclearlyagreedinwritingtoserveastheagentforthegranteeatthataddress? Yes,itisincludedintheexhibit"SampleAttestationStatements-USagentv2" >

C5266091_X10_Ed.2 1/1 Dongguan OSM Digital Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2026/8/4 Subject: Request for Confidentiality FCC ID: 2A6KA-AB309 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Anmy cheng Title: Manager

C5266091_X8_Ed.1 1/1 Letter of Authorization Dongguan OSM Digital Co., Ltd Company: Dongguan OSM Digital Co., Ltd Address: Room 401, Building 2, No. 26, Tangxia Keyuan Road, Tangxia Town, Dongguan City, Guangdong Province, China Product Name: Bluetooth Remote control Model Number: AB309 FCC Identifier: 2A6KA-AB309 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Anmy cheng Date: 2026/8/4 Title: Manager Signature of applicant:

Report No.: BCTC2607748308E External Photos Report No.: BCTC2607748308E Report No.: BCTC2607748308E Report No.: BCTC2607748308E

Label & Location FCC ID: 2A6KA-AB309

Report No.: BCTC2607748308E Internal Photos Report No.: BCTC2607748308E Report No.: BCTC2607748308E Antenna

RF EXPOSURE EVALUATION METHOD FCC ID: 2A6KA-AB309 Applicable standard： In accordance with FCC 47 CFR part 2 (2.1093) this device has been defined as a portable device which is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable devices must be evaluated using the specified in FCC 47 CFR part 2 (2.1093). Per FCC KDB 447498 D01 v06, the 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances s 50 mm are determined by: SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Modulation Frequency Maximum Conducted Output Power(PK) (MHz) (dBm) BLE 1M 2402 -1.08 2440 -0.54 2480 -0.70 max possible output power (PK, conducted)：0±1dBm 1dBm=1.26mW 2402MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 3.16/5*√2.402=0.391≤3.0 2440MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 1.26/5*√2.440=0.394≤3.0 2480MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 1.26/5*√2.48=0.397≤3.0 Conclusion: 1. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] < 3.0. 2. SAR Test Exclusion Thresholds is 3.0 for separation distance 5mm. Therefore, SAR test is not required.

No.：BCTC/KJ-RF-ICT-001 Page 1 of 41 Edition：B.1 TEST REPORT Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC2607748308E Applicant: Dongguan OSM Digital Co., Ltd Product Name: Bluetooth Remote control Test Model: AB309 Tested Date: 2026-07-03 to 2026-07-10 Issued Date: 2026-07-11 Report No.: BCTC2607748308E No.：BCTC/KJ-RF-ICT-001 Page 2 of 41 Edition：B.1 FCC ID: 2A6KA-AB309 The test report is effective only with both signature and specialized stamp.This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Technology Co., Ltd, this report can’t be reproduced except in full.The tested sample(s) and the sample information are provided by the client. Product Name: Bluetooth Remote control Trademark: N/A Model/Type Ref.: AB309 Prepared For: Dongguan OSM Digital Co., Ltd Address: Room 401, Building 2, No. 26, Tangxia Keyuan Road, Tangxia Town, Dongguan City, Guangdong Province, China Manufacturer: Dongguan OSM Digital Co., Ltd Address: Room 401, Building 2, No. 26, Tangxia Keyuan Road, Tangxia Town, Dongguan City, Guangdong Province, China Prepared By: Shenzhen BCTC Technology Co., Ltd. Address: Room 101M, Unit 1, Building1, Pengyuan, No.18, Lilang Road, Shanglilang, Nanwan Subdistrict, Longgang District, Shenzhen, Guangdong, China. Sample Received Date: 2026-07-03 Sample tested Date: 2026-07-03 to 2026-07-10 Report No.: BCTC2607748308E Test Standards: 47 CFR Part 15 Subpart C (clause 15.247) ANSI C63.10-2020 + Cor.1-2023+C63.10a-2024 + Errata to C63.10a-2024 Test Results: PASS Remark: This is Bluetooth BLE radio test report. Prepared by : Reviewer by : Approved by: Louis Zeng /Editor Mike Zheng / Supervisor Sewen Guo/Manager Report No.: BCTC2607748308E No.：BCTC/KJ-RF-ICT-001 Page 3 of 41 Edition：B.1 Table of Content Test Report Declaration Page 1. Version .................................................................................................................. 5 2. Test Summary ....................................................................................................... 6 3. Measurement Uncertainty ..................................................................................... 7 4. Product Information And Test Setup ..................................................................... 8 4.1 Product Information ............................................................................................... 8 4.2 Test Setup Configuration ...................................................................................... 9 4.3 Support Equipment ............................................................................................... 9 4.4 Channel List ........................................................................................................ 10 4.5 Test Mode ........................................................................................................... 10 4.6 Table Of Parameters Of Text Software Setting ................................................... 10 5. Test Facility And Test Instrument Used ............................................................... 11 5.1 Test Facility ......................................................................................................... 11 5.2 Test Instrument Used .......................................................................................... 11 6. Conducted Emissions .......................................................................................... 13 6.1 Block Diagram Of Test Setup .............................................................................. 13 6.2 Limit .................................................................................................................... 13 6.3 Test procedure .................................................................................................... 13 6.4 EUT Operating Conditions .................................................................................. 13 6.5 Test Result ............................................................................................................ 13 7. Radiated Emissions ............................................................................................. 14 7.1 Block Diagram Of Test Setup .............................................................................. 14 7.2 Limit .................................................................................................................... 15 7.3 Test procedure .................................................................................................... 16 7.4 EUT operating Conditions ................................................................................... 17 7.5 Test Result .......................................................................................................... 18 8. Radiated Band Emission Measurement and Restricted Bands Of Operation ...... 22 8.1 Block Diagram Of Test Setup .............................................................................. 22 8.2 Limit .................................................................................................................... 22 8.3 Test Procedure ................................................................................................... 23 8.4 EUT Operating Conditions .................................................................................. 23 8.5 Test Result .......................................................................................................... 24 9. Power Spectral Density Test ............................................................................... 25 9.1 Block Diagram Of Test Setup .............................................................................. 25 9.2 Limit .................................................................................................................... 25 9.3 Test procedure .................................................................................................... 25 9.4…

Text truncated - open the document above for the full version.

1. Antenna Description Antenna plate PCB antenna Market name/Model name AB309 Antenna Max.Gain -2.74dBi Frequency Range 2402-2480MHz Connect Type Direct Connect VSWRV1 2.Picture of antenna 东莞欧森隆数码有限公司 Dongguan Ousenlong Digital Co.,Ltd. 广东省东莞市塘厦镇塘厦科苑路26号2栋401室 Room 401,Building 2,No. 26, Tangxia Keyuan Road, Tangxia Town, Dongguan City, Guangdong Province, China 3.Antennadata: FrequencyGain(dBi)Efficiency(%) 2400MHz-3.5021% 2410MHz-3.4621% 2420MHz-3.5621% 2430MHz-3.4222% 2440MHz-3.2622% 2450MHz-3.1922% 2460MHz-3.1022% 2470MHz-2.8623% 2480MHz-2.7424% 2490MHz-3.0323% 2500MHz-3.2523% 4.AntennaRadiationPattern: PHI=0 PHI=90 THETA=90 2400Mhz 2450Mhz 2500Mhz

Report No.: BCTC2607748308E Radiated Emission Measurement Photos
