2A6T2-X98KSmart TV box

HD Rockchip RK3528 CPU:Quad Core ARM Cortex A53 GPU:Mali-450 1. H.264/AVC BP/MP/HP profile@ level 5.1; H.264/AVC MVC; up to 4Kx2K@ 60fps 2. H.265/HEVC Main/Main10 profile@ level 5.1 High-tier; up to 4Kx2K@ 60fps 3. AVS2 4Kx2K@60fps RAM 2GB/4GB, 100/1000M Ethenet, 802.1 1a/b/g/n/ ac 2.4G and 5G Wi-Fi, Support BT(option). Android 13 OS, OTA upgrade supported. HD USBUSBCARD Power Adaptor Connect the TV Box with the power supply. Connect the TV Box to your TV with HD cable or AV cable. For wired connection, plug in Ethernet cable from the TV Box to your modem or router. For wireless, choose your Wi-Fi network and input the password. Introduction: The TV Box lets you play photos, music, and videos from your smart phone or tablet computer on your TV. Preparation: Make sure your device(s) and TV Box are connected to the same network. How to use: After your device(s) and TV Box are connected to the same network, the logo will show up in the related applications of your device(s). Click the and share the photos, music and videos on TV. Multi-screen InteractionThe Screen Casting Connection DiagramInstallation Steps Smart Phone Tablet PC Router TV This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. -This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: UGK-LVMUNITEDINC FRN: 0033476375 Contact Name: Jimmychen Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 Telephone No: 001-323-51 04660 Email: [email protected] Applicant: Company name: SHENZHEN AMEDIA TECHNOLOGY CO., LTD Grantee code: 2A6T2 FCC ID: 2A6T2-X98K FRN: 0032391765 Contact Name: bo yang Address: Room 201, Building 2, Stech Park, Gaofeng community, Dalang Street, Longhua District, Shenzhen, China Telephone: 13560746014 Fax: 0755-29028051 E-mail: [email protected] [SHENZHEN AMEDIA TECHNOLOGY CO., LTD] certifies that, as of the date of this filing of the application with the TCB, [UGK-LVMUNITEDINC] is our designated US agent for service of process for the above referenced FCC ID. [SHENZHEN AMEDIA TECHNOLOGY CO., LTD] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [UGK-LVMUNITEDINC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024/07/24 Applicant’s Name: bo yang US Agent’s Name: Jimmychen Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: SHENZHEN AMEDIA TECHNOLOGY CO., LTD Grantee code: 2A6T2 FCC ID: 2A6T2-X98K FRN: 0032391765 Contact Name: bo yang Address: Room 201, Building 2, Stech Park, Gaofeng community, Dalang Street, Longhua District, Shenzhen, China Telephone: 13560746014 Fax: 0755-29028051 E-mail: [email protected] i. [SHENZHEN AMEDIA TECHNOLOGY CO., LTD] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [SHENZHEN AMEDIA TECHNOLOGY CO., LTD] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [SHENZHEN AMEDIA TECHNOLOGY CO., LTD] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2024/07/24 Applicant’s Name: bo yang Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

SHENZHEN AMEDIA TECHNOLOGY CO., LTD Product Similarity Declaration Company: SHENZHEN AMEDIA TECHNOLOGY CO., LTD Address: Room 201, Building 2, Stech Park, Gaofeng community, Dalang Street, Longhua District, Shenzhen, China Product Name: Smart TV box Model Number: X98K, X98K Air, X98K plus, X98K Max, X98K+, X98K ultra, X98Kpura, X98K 5G FCC Identifier: 2A6T2-X98K We (SHENZHEN AMEDIA TECHNOLOGY CO., LTD) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name and appearance color. Client’s signature Name: bo yang Date: 2024-07-24 Title: Manager Signature of applicant:

SHENZHEN AMEDIA TECHNOLOGY CO., LTD 1/1 Letter of Authorization Company: SHENZHEN AMEDIA TECHNOLOGY CO., LTD Address: Room 201, Building 2, Stech Park, Gaofeng community, Dalang Street, Longhua District, Shenzhen, China Product Name: Smart TV box Model Number: X98K, X98K Air, X98K plus, X98K Max, X98K+, X98K ultra, X98Kpura, X98K 5G FCC Identifier: 2A6T2-X98K We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: bo yang Date: 2024-07-24 Title: Manager Signature of applicant:

SHENZHEN AMEDIA TECHNOLOGY CO., LTD 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-07-24 Subject: Request for Confidentiality FCC ID: 2A6T2-X98K To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: bo yang Title: Manager ☒

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(External Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Size: 28*6mm M/N: X98K FCC ID: 2A6T2-X98K Label location

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(Internal Photos) WIFI/BT ANT Reserved antenna Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

FCC ID: 2A6T2-X98K RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. EIRP=EMeas+20log(dMeas)-104.7 EIRP is the equivalent isotropically radiated power, in dBm EMeas is the field strength of the emission at the measurement distance, in dBμV/m dMeas is the measurement distance, in m Test Result of RF Exposure Evaluation wifi 2.4G mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 16.931 49.3287 0.01644 1.0 PASS 802.11g 13.594 22.8770 0.00762 1.0 PASS 802.11n HT20 14.592 28.7872 0.00959 1.0 PASS 802.11n HT40 13.542 22.6048 0.00753 1.0 PASS Remark: antenna gain=2.24dBi wifi 5G mode: Band Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Band 1 802.11a 10.747 11.8768 0.00489 1.0 PASS 802.11n HT20 10.699 11.7463 0.00484 1.0 PASS 802.11n HT40 10.157 10.3681 0.00427 1.0 PASS 802.11ac HT20 10.814 12.0615 0.00497 1.0 PASS 802.11ac HT40 9.724 9.3843 0.00386 1.0 PASS 802.11ac HT80 9.396 8.7016 0.00358 1.0 PASS Band 4 802.11a 13.592 22.8665 0.00942 1.0 PASS 802.11n HT20 13.317 21.4635 0.00884 1.0 PASS 802.11n HT40 13.608 22.9509 0.00945 1.0 PASS 802.11ac HT20 13.463 22.1973 0.00914 1.0 PASS 802.11ac HT40 13.705 23.4693 0.00967 1.0 PASS 802.11ac HT80 13.522 22.5009 0.00927 1.0 PASS Remark: antenna gain=3.16dBi For BT Field strength (dBuV/m) EIRP (dBm) Max tune-up (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 84.68 -10.5 0.0891 0.00003 1.0 PASS Remark: antenna gain=2.24dBi For Simultaneous transmitting, 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits =0.01644/1 +0.00967/1 + 0.00003/1 = 0.02614< 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations.

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240521027ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 76 FCC Part 15E Test Report FCC ID: 2A6T2-X98K Applicant: SHENZHEN AMEDIA TECHNOLOGY CO., LTD Address: Room 201, Building 2, Stech Park, Gaofeng community, Dalang Street, Longhua District, Shenzhen, China Manufacturer: SHENZHEN AMEDIA TECHNOLOGY CO., LTD Address: Room 201, Building 2, Stech Park, Gaofeng community, Dalang Street, Longhua District, Shenzhen, China EUT: Smart TV box Trade Mark: N/A Model Number: X98K X98K Air, X98K plus, X98K Max, X98K+, X98K ultra, X98Kpura, X98K 5G Date of Receipt: May. 21, 2024 Test Date: May. 21, 2024 - Jul. 12, 2024 Date of Report: Jul. 12, 2024 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 E 15.407 ANSI C63.10:2013 Test Result: Pass Report Number: DL-240521027ER Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240521027ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 76 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 10 3.1.3 DEVIATION FROM TEST STANDARD 10 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 16 3.2.5 EUT OPERATING CONDITIONS 17 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 18 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 19 3.2.8 TEST RESULTS (1GHZ~40GHZ) 21 3.3 RADIATED BAND EMISSION MEASUREMENT 39 3.3.1 TEST REQUIREMENT: 39 3.3.2 TEST PROCEDURE 39 3.3.3 DEVIATION FROM TEST STANDARD 39 3.3.4 TEST SETUP 39 3.3.5 EUT OPERATING CONDITIONS 39 4 . PEAK OUTPUT POWER 44 4.1 APPLIED PROCEDURES / LIMIT 44 4.1.1 TEST PROCEDURE 44 4.1.2 DEVIATION FROM STANDARD 44 4.1.3 TEST SETUP 44 4.1.4 EUT OPERATION CONDITIONS 44 4.1.5 TEST RESULTS 45 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240521027ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 76 Table of Contents Page 5 . POWER SPECTRAL DENSITY TEST 52 5.1 APPLIED PROCEDURES / LIMIT 52 5.1.1 TEST PROCEDURE 52 5.1.2 DEVIATION FROM STANDARD 52 5.1.3 TEST SETUP 52 5.1.4 EUT OPERATION CONDITIONS 52 5.1.5 TEST RESULTS 53 6 . 6DB&26DB&99% BANDWIDTH TEST 60 6.1 APPLIED PROCEDURES / LIMIT 60 6.1.1 TEST PROCEDURE 60 6.1.2 DEVIATION FROM STANDARD 60 6.1.3 TEST SETUP 60 6.1.4 EUT OPERATION CONDITIONS 61 6.1.5 TEST RESULTS 61 7 . DUTY CYCLE TEST SIGNAL 68 7.1 APPLIED PROCEDURES / LIMIT 68 7.1.1 TEST PROCEDURE 68 7.1.2 DEVIATION FROM STANDARD 68 7.1.3 TEST SETUP 68 7.1.4 EUT OPERATION CONDITIONS 68 7.1.5 TEST RESULTS 69 8 . FREQUENCY STABILITY 72 8.1 APPLIED PROCEDURES / LIMIT 72 8.1.1 TEST PROCEDURE 72 8.1.2 DEVIATION FROM STANDARD 72 8.1.3 TEST SETUP 72 8.1.4 EUT OPERATION CONDITIONS 72 8.1.5 TEST RESULTS 73 9 . TRANSMISSION IN THE ABSENCE OF DATA 76 9.1 STANDARD REQUIREMENT 76 9.2 TEST RESULT 76 10 . ANTENNA REQUIREMENT 76 10.1 STANDARD REQUIREMENT 76 10.2 EUT ANTENNA 76 11 . TEST SEUUP PHOTO 76 12 . EUT PHOTO 76 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240521027ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 76 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.407) , Subpart E Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.407(b), 15.209 Radiated Spurious Emission PASS 15.407 (b) Band Edge Emission PASS 15.407 (a) Peak Output Power PASS 15.407 (a) Power Spectral Density PASS 15.403(i) 15.407(e) 26dB bandwidth and 99%dB Bandwidth 6dB bandwidth and 99%dB Bandwidth PASS 15.407(g) Frequency Stability PASS 15.407(c) Transmission in case of Absence of Information PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 Bandwidth ±0.2MHz Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240521027ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 76 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: Smart TV box Trademark N/A Model No.: X98K X98K Air, X98K plus, X98K Max, X98K+, X98K ultra, X98Kpura, X98K 5G Model Difference The product's different for mode…

Text truncated - open the document above for the full version.

TE L：+86 0755-23073599FAX：+86 0755-23097189E-mail:[email protected] 地址： 深圳市宝安区航空路锦驰中心3015 深圳市云顶通讯电子有限公司 Shenzhen Genting Communication Electronics Co., LTD SHENZHEN 客户 : 品 名 规 格 DESCRIPTION: 料号 PARTNO.： 客 户 料 号 CUS PART NO. ： 日期 D A T E： 云顶呈样签章 工程 ENGINEERINGDEPARTMENT 品保 Q C DEPARTMENT 业 务 SALESDEPARTMENT 吴淑仪刘丽王洪涛 客户承认签章 工程 ENGINEERINGDEPARTMENT 品保 Q C DEPARTMENT 采 购 PURCHASINGDEPARTMENT 联系电话：07552307359915017941162 ж 承认书一式三份，惠蒙贵司承认签章 ж Approvalin duplicate,pleasesignedby yourcompany. 承認書 APPROVAL DIFA50C-WIFI2.4/5G 004.06.006.0099 2024.5.16 玥芯通 TEL：+860755-23073599FAX：+860755-23097189E-mail:[email protected] 地址： 深圳市宝安区航空路锦驰中心3015 深圳市云顶通讯电子有限公司 SHENZHEN 1. 测试项目与设备 测试项目设备 1.S11参数 （S-parameter） 1.回波损耗（ReturnLoss） 2.电压驻波比（VSWR） 网络分析仪:AgilentE5071B HP8753D 2.有源测试 （Active） 1.发射功率（TRP） 2.接收灵敏度（TIS） 1.暗室：ETS7x4x3m(3D)Chamber ETS5x3x3m(3D)Chamber 2.综合测试仪:Agilent8960E5515B×2 StarPointSP6011 3.无源测试 （Passive） 1.天线增益（Gain）2.天线效 率（Efficiency） 1.暗室：ETS7x4x3m(3D)Chamber ETS5x3x3m(3D)Chamber 2.网络分析仪：AgilentE5071B HP8753D TEL：+860755-23073599FAX：+860755-23097189E-mail:[email protected] 地址： 深圳市宝安区航空路锦驰中心3015 深圳市云顶通讯电子有限公司 SHENZHEN 2. 天线性能 SWR TEL：+860755-23073599FAX：+860755-23097189E-mail:[email protected] 地址： 深圳市宝安区航空路锦驰中心3015 深圳市云顶通讯电子有限公司 SHENZHEN 2. 天线效率与增益 PassiveTestForWIFI2.4 FreqEffiGain (MHz)(%)(dBi) 240057.881.8 241059.651.79 242057.771.64 243059.451.72 244063.921.97 245068.912.08 246069.712.04 247070.541.92 248072.322.09 249074.632.24 250072.282.19 TEL：+860755-23073599FAX：+860755-23097189E-mail:[email protected] 地址： 深圳市宝安区航空路锦驰中心3015 深圳市云顶通讯电子有限公司 SHENZHEN PassiveTestForWIFI5.8 FreqEffiGain (MHz)(%)(dBi) 510049.032.66 520049.262.98 530047.782.84 540051.643.16 550038.142.17 560038.532.09 570047.422.08 580056.512.1 TEL：+860755-23073599FAX：+860755-23097189E-mail:[email protected] 地址： 深圳市宝安区航空路锦驰中心3015 深圳市云顶通讯电子有限公司 SHENZHEN 3. 天线 OTA 测试数据 TEL：+860755-23073599FAX：+860755-23097189E-mail:[email protected] 地址： 深圳市宝安区航空路锦驰中心3015 深圳市云顶通讯电子有限公司 SHENZHEN 4. 天线产品图：

Shenzhen DL Testing Technology Co., Ltd. EUT TEST PHOTO Radiated Measurement Photos Shenzhen DL Testing Technology Co., Ltd. Conducted Measurement Photos ※※※※※ END OF REPORT ※※※※※
