AirBuds 8 USER GUIDE PRODUCT INTRODUCTION DEVICE CONNECTION Method 1: 1. When using the product for the rst time, open the charging case cover. When the earbuds LED indicator are blinking in orange and white alternately, the earbuds enter the "Pairing state". 2. Turn the Bluetooth on, and select "AirBuds 8". 1 English Touch control LED digital display Earbuds LED indicator Microphone USB-C charging port AirBuds 8 CONTROL i) Equipment operation There is a connection prompt tone after successful connection. Method 2: 1. When the earbuds are already connected to the device, Click the “Touch” button four times. The indicator will blink in orange and white alternately, and the earbuds will enter the pairing state (Cannot operate while making calls or playing music ) . 2. Turn the Bluetooth on, and select "AirBuds 8". There is a connection prompt tone after successful connection. Note: The above is the connection method when the product is pairing a new device for the f irst time. After the initial use of the product, the earbuds will automatically switch on and connect to the device when you take it out from the charging case. 2 1. Power on: Open the charging case, and the headphones will automatically power on. 2. Shut down: Put the headphones into the charging case and close the charging case to shut down . 3. Restore factory settings: (In pairing mode)Double touch + long press 5S; when the white light ashes for 3 times, the headphones will enter the factory reset mode, put the headphones into the charging case, the headphones status will be restored to the factory settings .You can open the cover to re-pair. iii) Call Mode ii) Playback Mode SWITCH TO DIFFERENT CALLS INCOMING CALLONGOING CALL L / RL / R L / R 4) Answer call 2. Call 1 is hold-on L / R 6) Reject call 2. Hold call 1 L / R 5) Switch between call 1 and call 2 L / R x 2x 2 2 s 2 s 21 2 s 21 x 2 21 R 2 s L 2 s 4) Siri4)Google Voice Assistant L / R x 2 R L x 1/x 3x 1/x 3 1)Play / Pause2)Volume Down/ Previous 3)Volume Up/ Next 1)Answer a call2) Reject an incoming call 3) End a call 3 5) Transparency mode / ANC on / ANC o ( 2s toggle ) Light indication 4 Pairing status Blinking Orange/ White Light Power on /Power off Orange Light Quick Double Blink for 5S Headphone low power status White Light On for 2S/ Orange Light On for 2S White Light Quick Double Blink for 2S Incoming call Charging box low battery (＜ 20%) Digital display flashes and extinguishes after 10S Display headphone battery level.(Open, Close) display will light up Display charging case battery level (Open, Close) The LED digital display shows numbers TECHNICAL SPECIFICATIONS Earbuds driver • 13 mm neodymium magnet sound Units x 2 Frequency Response • 20–20,000 Hz Microphone • Omnidirectional MEMS x1 (per earbud) Bluetooth Version • Bluetooth 5.3 Bluetooth pro f i le • A2DP • AVRCP • HFP Audio Codec • SBC • AAC Wireless operating frequency • 2402-2480 MHz Wireless transmission range • Up to 10 meters (measured in open area). Walls and wall structures may aect the transmission range of the device. Playback time • Up to 6 hours on a single full charge • Total playback time: 27 hours^ Battery • Earbuds: Rechargeable lithium-ion Polymer Battery 3.7 V 35 mAh 0.129 Wh • Charging case: Rechargeable lithium-ion Polymer 3.7 V 400 mAh 1.48 Wh Charging time • < 2 hours IP Rating • IPX7 waterproof Operating temperature • 0-45°C Maximum output power • 5 dBm Input rated power • 5V 1A ^Based on moderate volume. Actual battery life will vary, depending on specif ic use, settings, and environmental factors NOTE: Compliance markings are in the charging case. CAUTION: Do not use the earbud at a high volume for extended periods of time as this may cause hearing loss. 5 Answers for Common Questions (1) The bluetooth headset cannot be switched on. Reason: The battery in the charging compartment is low or the power of the bluetooth headset is low. Solution: Put the headset into the charging box, close the cover, and charge the charging box for more than 1 hour before use. (2) The phone cannot search for bluetooth headset. Reason: 1. The Bluetooth headset is not in the pairing state; Solution: 1. When the earbuds are already connected to the device, Click the “Touch” button four times. The indicator will blink in orange and white alternately, and the earbuds will enter the pairing state. Reason: 2. There are mobile phone bluetooth program errors; Solution: After the bluetooth of the mobile phone is restarted, clear all pairing data stored in the the mobile phone; Search for bluetooth again. (3) There is no sound from the headset speaker Reason: 1. Turn the volume of the mobile phone and headset to the maximum and conf irm whether it is caused by volume adjustment. Solution: When the headset is connected, adjust the volume of the mobile phone; Reason: 2. The Bluetooth headset is not properly connected with the mobile phone. Solution: Reconnect bluetooth and mobile phone through pairing. 6 Reason: 3. The Bluetooth headset is not within the valid working range. Solution: Keep the headset within 10 meters of the mobile phone, and there are no large objects, walls and other obstacles between the headset and the device. (4) The headset doesn't send messages or the voice is low. Reason: 1. The Bluetooth headset is too far from the mouth; Solution: The bluetooth headset should be worn on the ear for normal use; Reason: 2. The microphone hole of Bluetooth is blocked or water has entered; Solution: Remove the blockage of the microphone hole or prevent water from entering the microphone hole. (5) The headphone get stuck or disconnected when talking or listening to music. Reason: 1. The Bluetooth headset is too far away from the mobile phone or there are obstacles. Solution: 1. Keep the headset within 10 meters of the mobile phone, and there are no large objects and walls between the headset and the device. Be careful not to cover the bluetooth headset with your hand. In order to maintain the continuous…
