2A7DX-WAVE8Smart phone

FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Exposure Statement SAR tests are conducted using standard operating positions According FCC standards with the device transmitting at its highest certified power level in all tested frequency bands, although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This model product has been tested and meets the FCC RF exposure guidelines with the test distance 0 mm for head and 10mm for body worn. The highest SAR 1g value is 1.158 W/Kg. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC exposure requirements, and should be avoided. ISED compliance statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. ISED RF Exposure statement SAR tests are conducted using standard operating positions According ISED standards with the device transmitting at its highest certified power level in all tested frequency bands, although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This model product has been tested and meets the ISED RF exposure guidelines with the SAR test with distance 0 mm for head and 10mm for body worn. The highest SAR 1g value is 1.158 W/Kg. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with RF exposure requirements, and should be avoided. Les tests SAR sont effectués en utilisant des positions de fonctionnement standard conformément aux normes ISDE avec l'appareil transmettant à son niveau de puissance certifié le plus élevé dans toutes les bandes de fréquences testées, bien que le SAR soit déterminé au niveau de puissance certifié le plus élevé, le niveau SAR réel de l'appareil pendant le fonctionnement peut être bien inférieur à la valeur maximale. Ce modèle de produit a été testé et répond aux directives d'exposition RF ISDE avec le test SAR à une distance de 0 mm pour la tête et de 10 mm pour le corps. La valeur SAR 1g la plus élevée est de 1,158 W/Kg. L'utilisation de clips de ceinture, d'étuis et d'accessoires similaires ne doit pas contenir de composants métalliques dans son assemblage. L'utilisation d'accessoires qui ne satisfont pas à ces exigences peut ne pas être conforme aux exigences d'exposition RF et doit être évitée. The device is restricted to indoor use only when operating in the 5150 to 5250MHz frequency range. L'appareil est limité à une utilisation en intérieur uniquement lorsqu'il fonctionne dans la plage de fréquences de 5 150 à 5 250 MHz.

- DOKE COMMUNICATION (HK) LIMITED - Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 8/28/2024 U.S. Agent Designation DOKE COMMUNICATION (HK) LIMITED acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2A7DX-WAVE8): Name and company of U.S. agent: UUX GROUP INC Physical U.S. address of agent: 36 South 18th Avenue, Suite A Brighton, CO USA 80601 FRN of U.S. agent: 0033701590 Email address of U.S. agent: [email protected] UUX GROUP INC acknowledges their obligation to accept service of process on behalf of DOKE COMMUNICATION (HK) LIMITED. DOKE COMMUNICATION (HK) LIMITED with the FRN 0032533945 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Lynne Chen Manager DOKE COMMUNICATION (HK) LIMITED Signature Jack Fu Manager UUX GROUP INC 48_[model] US_Agent_2.911(d)(7) - U, V05

Page 1 of 5 FCC ID: 2A7DX-WAVE8 EUT Constructional Details External EUT Photo Photo 1 Photo 2 Page 2 of 5 FCC ID: 2A7DX-WAVE8 Photo 3 Photo 4 Page 3 of 5 FCC ID: 2A7DX-WAVE8 Photo 5 Photo 6 Page 4 of 5 FCC ID: 2A7DX-WAVE8 Photo 7 Photo 8 Page 5 of 5 FCC ID: 2A7DX-WAVE8 Photo 9 ---The End---

Label Size: L50mm * W60mm 1. The label is silk-screen on the sample L W WAVE 8 FCC ID:2A7DX-WAVE8

Page 1 of 11 FCC ID:2A7DX-WAVE8 EUT Constructional Details Internal EUT Photo Photo 1 Photo 2 GPS+BT+WIFI ANT GSM/WCDMA/ LTE Main ANT LTE DVI ANT Page 2 of 11 FCC ID:2A7DX-WAVE8 Photo 3 Photo 4 Page 3 of 11 FCC ID:2A7DX-WAVE8 Photo 5 Photo 6 Page 4 of 11 FCC ID:2A7DX-WAVE8 Photo 7 Photo 8 Page 5 of 11 FCC ID:2A7DX-WAVE8 Photo 9 Photo 10 Page 6 of 11 FCC ID:2A7DX-WAVE8 Photo 11 Photo 12 Page 7 of 11 FCC ID:2A7DX-WAVE8 Photo 13 Photo 14 Page 8 of 11 FCC ID:2A7DX-WAVE8 Photo 15 Photo 16 Page 9 of 11 FCC ID:2A7DX-WAVE8 Photo 17 Photo 18 Page 10 of 11 FCC ID:2A7DX-WAVE8 Photo 19 Photo 20 Page 11 of 11 FCC ID:2A7DX-WAVE8 Photo 21 Photo 22 ------End------

Page 1 of 9 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix A Detailed System Check Results 1. System Performance Check System Performance Check 750 MHz Head System Performance Check 835 MHz Head System Performance Check 1750 MHz Head System Performance Check 1900 MHz Head System Performance Check 2450 MHz Head System Performance Check 2600 MHz Head System Performance Check 5250 MHz Head System Performance Check 5750 MHz Head Page 2 of 9 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/7/18 Test Laboratory: LCS-SAR Lab System Check_750Mhz DUT: D750V3; Type: D750V3; Serial: 1191 Communication System: UID 0, CW (0); Frequency: 750 MHz;Duty Cycle: 1:1 Medium parameters used: f = 750 MHz; σ = 0.896 S/m; ε r = 41.982; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(9.66, 9.66, 9.66); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (9x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.70 W/kg Configuration/Unnamed procedure/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 55.75 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 3.21 W/kg SAR(1 g) = 2.12 W/kg; SAR(10 g) = 1.36 W/kg Maximum value of SAR (measured) = 2.71 W/kg 0 dB = 2.71 W/kg = 4.33 dBW/kg Page 3 of 9 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/7/19 Test Laboratory: LCS-SAR Lab System Check_835Mhz DUT: D835V2; Type: D835V2; Serial: 4d124 Communication System: UID 0, CW (0); Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.907 S/m; ε r = 41.912; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(9.26, 9.26, 9.26); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (5x18x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 3.09 W/kg Configuration/Unnamed procedure/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 54.24 V/m; Power Drift = -0.12 dB Peak SAR (extrapolated) = 3.78 W/kg SAR(1 g) = 2.45 W/kg; SAR(10 g) = 1.60 W/kg Maximum value of SAR (measured) = 3.15 W/kg 0 dB = 3.15 W/kg = 4.98 dBW/kg Page 4 of 9 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/7/22 Test Laboratory: LCS-SAR Lab System Check_1750Mhz DUT: D1750V2; Type: D1750V2; Serial: 1035 Communication System: UID 0, CW (0); Frequency: 1750 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1750 MHz; σ = 1.362 S/m; ε r = 40.913; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(8.16, 8.16, 8.16); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 11.8 W/kg Configuration/Unnamed procedure/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 82.45 V/m; Power Drift = -0.07 dB Peak SAR (extrapolated) = 16.44 W/kg SAR(1 g) = 9.06 W/kg; SAR(10 g) = 4.76 W/kg Maximum value of SAR (measured) = 12.1 W/kg 0 dB = 12.1 W/kg = 10.83 dBW/kg Page 5 of 9 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/7/23 Test Laboratory: LCS-SAR Lab System Check_1900Mhz DUT: D1900V2; Type: D1900V2; Serial: 5d055 Communication System: UID 0, CW (0); Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.413 S/m; ε r = 39.081; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(7.85, 7.85, 7.85); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 12.9 W/kg Configuration/Unnamed procedure/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx…

Text truncated - open the document above for the full version.

Page 1 of 25 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix B Detailed Test Results 1. GSM GSM850 for Head& Body GSM1900 for Head& Body 2. WCDMA WCDMA Band II for Head& Body WCDMA Band V for Head& Body 3. LTE LTE Band 2 for Head& Body LTE Band 5 for Head& Body LTE Band 12 for Head& Body LTE Band 41 for Head& Body LTE Band 66 for Head& Body 4. WIFI WIFI 2.4GHz for Head& Body WIFI 5.2GHz for Head& Body WIFI 5.8GHz for Head& Body Date: 2024/7/19 Test Laboratory: LCS-SAR Lab Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity GSM 850 251CH Left Cheek DUT: Smart phone; Type: WAVE 8; Serial: A240716060 Communication System: UID 0, GSM (0); Frequency: 848.8 MHz;Duty Cycle: 1: 8.3 Medium parameters used: f = 849 MHz; σ = 0.953 S/m; ε r = 43.137; ρ = 1000 kg/m 3 Phantom section: Left Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(9.26, 9.26, 9.26); Calibrated: 2023/11/23;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Head/Area Scan (8x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.157 W/kg Configuration/Head /Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 6.126 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 0.193 W/kg SAR(1 g) = 0.132 W/kg; SAR(10 g) = 0.096 W/kg Maximum value of SAR (measured) = 0.159 W/kg Date: 2024/7/19 Test Laboratory: LCS-SAR Lab Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity GSM 850 GPRS 4TX 251CH Rear side 10mm DUT: Smart phone; Type: WAVE 8; Serial: A240716060 Communication System: UID 0, GSM (0); Frequency: 848.8 MHz;Duty Cycle: 1: 2.075 Medium parameters used: f = 849 MHz; σ = 0.953 S/m; ε r = 43.137; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(9.26, 9.26, 9.26); Calibrated: 2023/11/23;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/ Body /Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.324 W/kg Configuration/ Body /Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 13.61 V/m; Power Drift = -0.11 dB Peak SAR (extrapolated) = 0.399 W/kg SAR(1 g) = 0.252 W/kg; SAR(10 g) = 0.188 W/kg Maximum value of SAR (measured) = 0.340 W/kg Date: 2024/7/23 Test Laboratory: LCS-SAR Lab Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity GSM 1900 810CH Left Cheek DUT: Smart phone; Type: WAVE 8; Serial: A240716060 Communication System: UID 0, GSM (0); Frequency: 1909.8 MHz;Duty Cycle: 1: 8.3 Medium parameters used: f = 1910 MHz; σ = 1.461 S/m; ε r = 40.487; ρ = 1000 kg/m 3 Phantom section: Left Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(7.85, 7.85, 7.85); Calibrated: 2023/11/23;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Head /Area Scan (8x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.186 W/kg Configuration/Head /Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 1.384 V/m; Power Drift = 0.32 dB Peak SAR (extrapolated) = 0.271 W/kg SAR(1 g) = 0.160 W/kg; SAR(10 g) = 0.102 W/kg Maximum value of SAR (measured) = 0.190 W/kg Date: 2024/7/23 Test Laboratory: LCS-SAR Lab Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity GSM 1900 GPRS 3TX 810CH Rear side 10mm DUT: Smart phone; Type: WAVE 8; Serial: A240716060 Communication System: UID 0, GSM (0); Frequency: 1909.8 MHz;Duty Cycle: 1: 2.77 Medium parameters used: f = 1910 MHz; σ = 1.461 S/m; ε r = 40.487; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(7.85, 7.85, 7.85); Calibrated: 2023/11/23;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: SAM v5.0; Type: SAM; Serial: 1850  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/ Body /Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.192 W/kg Configuration/ Body /Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 6.773 V/m; Power Drift = -0.10 dB Peak SAR (extrapolated) = 0.294 W/kg SAR(1 g) = 0.158 W/kg; SAR(10 g) = 0.093 W/kg Maximum value of SAR (measured) = 0.195 W/kg Date: 2024/7/23 Test Laboratory: LCS-SAR Lab Shenzhen LCS Compliance Test…

Text truncated - open the document above for the full version.

Page 1 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix C Calibration certificate 1. Dipole D750V3-SN 1191(2023-06-15) D835V2-SN 4d124(2023-10-24) D1750V2-SN 1035(2023-06-12) D1900V2-SN 5d055 (2023-10-20) D2450V2-SN 808(2023-10-23) D2600V2-SN 1071(2023-06-20) D5GHzV2-SN 1046(2023-10-23) 2. DAE DAE3-SN 373(2024-1-3) 3. Probe EX3DV4-SN 3805(2023-11-23) Page 2 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 3 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 4 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 5 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 6 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 7 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 8 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 9 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 10 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 11 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 12 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 13 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 14 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 15 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 16 of 58 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-…

Text truncated - open the document above for the full version.

Page 1 of 7 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix D Photographs 1. SAR measurement System 2. Photographs of Tissue Simulate Liquid 3. Photographs of EUT test position 4. EUT Constructional Details Page 2 of 7 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 1. SAR measurement System Page 3 of 7 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2. Photographs of Tissue Simulate Liquid Photo 1: Tissue Simulant Liquid for Head 750 Photo 2: Tissue Simulant Liquid for Head 835 Photo 3: Tissue Simulant Liquid for Head 1750 Photo 4: Tissue Simulant Liquid for Head 1900 Photo 5: Tissue Simulant Liquid for Head 2450 Photo 6: Tissue Simulant Liquid for Head 2600 Photo 7: Tissue Simulant Liquid for Head 5-6GHz NA Page 4 of 7 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 5 of 7 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3. Photographs of EUT test position Photo 8: Left touch cheek Photo 9: Left tilted 15 degree Photo 10: Right touch cheek Photo 11: Right tilted 15 degree Photo 12: Front side 10mm Photo 13: Back side 10mm Page 6 of 7 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Photo 14: Left side 10mm Photo 15: Right side 10mm Photo 16: Top side 10mm Photo 17: Bottom side 10mm Page 7 of 7 FCC: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 4. EUT Constructional Details Photo 18: Front View Photo 19: Back View

Page 1 of 96 FCC ID: 2A7DX-WAVE 8 Report No.: LCSA07174014E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR TEST REPORT For DOKE COMMUNICATION (HK) LIMITED. Smart phone Test Model: WAVE 8 Additional Model No.: Please Refer to Page 11 Prepared for : DOKE COMMUNICATION (HK) LIMITED. Address : 19H MAXGRAND PLAZA NO 3 TAI YAU STREET SAN PO KONG KL Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 …
