2A7VP-C7602ALED Strip Lights

Thank you for choosing the C7602-A. In order to optimize the user experience, please read this manual carefully before operation, and keep this manual properly for future use. Download Free APP: Smart Life Download on the GET IT ON Google Play App Store Model:C7602-A Warning: 1. This product is not a toy. To avoid fire, burns, personal injury or electric shock, please install out of the reach of children. 2. In order to ensure the normal operation of the lamp, please use the voltage indicated on the package. 3. Please do not modify the lamps during the warranty period. 4. Do not install near gas or electric heaters, fires, candles or any dangerous objects. 5. Before installation, please check whether the lamps and various parts are in good condition. 6. Be sure to cut off the power before installation. 7. Do not expose the lamp to corrosive conditions. 8. If the power cord is damaged, please cut off the power immediately and stop using it. dĞĐŚŶŝĐĂů^ƉĞĐŝĮĐĂƟŽŶ͗ Connection method: 2.4G Wifi&Bluetooth Control method: APP/Voice/Button Adapter input voltage:100-240VAC Adapter output voltage: 24VDC/2.5A Rated working voltage: DC24V Rated power: 30W*2 Lamp color: RGB Memory function: yes Working temperature: -20~+40 Controller levels of protection:IP65 Lamps levels of protection: IP65 Work with Amazon Alexa and Google Assistant. 1. C015 controller * 1 2. RF remote control * 1 3. Waterproof power supply 12V/2A wall plug horizontal American standard UL (IP44) * 1 4. LED String lights * 2 pack 5. Install the clip (42 pixels)* 1 pack 6. Mounting screws(84 pixels)* 1 pack 7. Copy of the manual * 1 WĂĐŬŝŶŐůŝƐƚ͗ /ŶƐƚĂůůĂƟŽŶDĞƚŚŽĚ͗ /TYZGRRGZOUTSKZNUJ: /TYZGRRGZOUTSKZNUJ: DĂŶƵĂůŽĨŽŶƚƌŽůůĞƌ͗ Button Instruction: Switch : Short press is on/off. When the device is on, long press in 5 seconds is reset to pairing mode. Light will blink in white. Technical parameter: Working temperature: -20~+40 Size: 100mmx40mmx20mm (excluding wires) Short press: On Long press 5s: Reset to pairing Speed setting: In music or dynamic mode, speed +/- Timing mode:1H\2H Dynamic mode change. Mode +/- AUTO: dynamic modes switch automatically. Color setting: 9 colors. Three most popular dynamic modes: Rainbow, Flow, Horse race. In static code: Brightness +/- In music mode: Sensitivity +/- OFF WƌŽĚƵĐƚǁŝƌŝŶŐĚŝĂŐƌĂŵ͗ SSLZSSLZ APP Intelligent operation introduction: Color adjustment Tap + to add selected color, long press color dot to delete. Local mode: Sync to music with built-in mic, 6 modes. APP mode: use mic of phone. Adjustment of speed, sensitivity, color (partial) and direction (partial). Dynamic mode Recommend scene included 15 popular modes. Custom Scene support DIY static color of each segment and dynamic modes. Supporting Static, Gradient,- Jump,Breathe, Flashing Rainbow and Stream modes DIY. Set name for DIY mode to reserve. On is to open transition effect for segment. Preview to review the DIY mode. Add the scene to custom scene. APP Download. Search the Smart Life from Google Play or App Store. You can also scan the QR code from below. 1.Download the APP and Log In with existing account or Sign Up the new account. Pairing Instruction: Timer: Set the device off in given time. Schedule: Set the device on or off in specified time. Click ... from other page to enter to device page. Click pen icon to rename the device. iOS App Store Android Google Play Share the device to other people or controlling. Create a group to control multiple devices. Control via Alexa or Google Assistant C7602-A 2.Power on the device, confirm the device is blinking rapidly in white. Turn on the Bluetooth and Wi-Fi of phone. Please make sure the phone is connecting the 2.4GHz Wi-Fi router 3.Tap Add Device or the plus icon (+) in the top-right corner on the Home page to go to the device adding page. 4.Enter the Wi-Fi password and click Next. Make sure the Wi-Fi is 2.4GHz not the 5GHz. Because the Wi-Fi chip is 2.4GHz. Wait about twenty seconds and the device will be added completely. 6.Click the edit icon in the upper right corner to show more gameplay. 5.Then the device can be found in home page. Now you can play it with your imagination. C7602-A Modify device name Linkage with other equipment Linkage with other equipment Share control with family group mode Linkage with other devices to achieve one-click execution and automation 2. This warranty does not include: (1) Malfunction or damage caused by improper use, repair or modification. (2) Failure or damage due to falling. (3) Failure or damage caused by fire, earthquake, flood, lightning and other natural disasters. (4) Malfunction or damage when used other than for its intended purpose. (5) Failure or damage caused by third-party products. (6) Failure or damage to the product caused by human factors. 1. Unable to connect to your Wi-Fi network. Please make sure to enter the correct Wi-Fi password during use. Wi-Fi settings. Check your internet connection for problems. If the Wi-Fi signal is too weak, please reset your wireless router and try again. 2. The installer is not working properly. (1)Then close all applications running in the background and reopen the Smart Life APP. (2) Uninstall and reinstall the Smart Life app and repeat. 3. The smart light strip is not responding. (1) Check whether the smart string light is turned off. If yes, turn them on and wait until the smart light strip reconnects to The wireless network works automatically. (2) Check if there is any problem with your internet connection. If neces- sary, reset the wireless router and try again. ^ƚĞƉĨŽƌůƵĞƚŽŽƚŚĐŽŶƚƌŽů͗ Note: The Bluetooth control is for the device that disconnected from router. 1. Open the Bluetooth and use the Bluetooth for pairing. 2. Make sure the router is power off and close the phone Wi-Fi. Keep the 4G/5G internet and Bluetooth open. Wait about 3-5 mins. 3. After that, the device can be controlled by Bluetooth. Even though the 4G/5G network of phone is off. ŽŵŵŽŶƉƌŽďůĞŵƐ…
