2A7ZM-ANIMATOS1MICAnimato S1

JBU GLOBAL LLC
Animato S1 - FCC ID 2A7ZM-ANIMATOS1MIC - JBU GLOBAL LLC
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Oct 29, 2023
Application Purpose
Original Equipment
Date of Application
Oct 29, 2023
Equipment Note
Animato S1
Frequency Range
2402.00000000 - 2480.00000000
Company
JBU GLOBAL LLC
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: JBU GLOBAL LLC FRN: 0032680928 Contact Name: Issac Grunwald Address: 19416 NE 26th AVE, 114B, Miami, Florida 33180, United States Telephone No: 8442627464 Email: [email protected] Applicant: Company name: JBU GLOBAL LLC Product Description: Animato S1 Grantee code: 2A7ZM FCC ID: 2A7ZM-ANIMATOS1MIC Contact Name: Issac Grunwald Address: 19416 NE 26th AVE, 114B, Miami, Florida 33180, United States Telephone No: 8442627464 Email: [email protected] [JBU GLOBAL LLC] certifies that, as of the date of this filing of the application with the TCB, [JBU GLOBAL LLC] is our designated US agent for service of process for the above referenced FCC ID. [JBU GLOBAL LLC] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [JBU GLOBAL LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/09/12 Applicant’s Name: Issac Grunwald US Agent’s Name: Issac Grunwald Title: Chief Operations Officer Title: Chief Operations Officer Signature: Signature:

Attestation Statements

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: JBU GLOBAL LLC Grantee code: 2A7ZM FCC ID: 2A7ZM-ANIMATOS1MIC Contact Name: Issac Grunwald Address: 19416 NE 26th AVE, 114B, Miami, Florida 33180, United States Telephone No: 8442627464 Fax No: N/A Email: [email protected] i. JBU GLOBAL LLC (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. JBU GLOBAL LLC (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. JBU GLOBAL LLC (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment . Date: 2023/09/12 Applicant’s Name: Issac Grunwald Title: Chief Operations Officer Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Attestation Statements

JBU GLOBAL LLC 19416 NE 26th AVE, 114B, Miami, Florida 33180, United States DATE : 09/12/2023 JBU GLOBAL LLC 19416 NE 26th AVE, 114B, Miami, Florida 33180, United States Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint below company and person: Name Damon Hu Position Manager Company Name Dongguan Dongdian Testing Service Co.,Ltd. Address 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel / Fax Tel: +86-0769-38826678-850 E-Mail [email protected] to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. Applicant name JBU GLOBAL LLC Address 19416 NE 26th AVE, 114B, Miami, Florida 33180, United States Yours sincerely, Name Issac Grunwald Position Chief Operations Officer Company Name JBU GLOBAL LLC Address 19416 NE 26th AVE, 114B, Miami, Florida 33180, United States Tel / Fax 8442627464 E-Mail [email protected]

Cover Letter(s)

C5266091_X8_Ed.1 1/1 Letter of Authorization JBU GLOBAL LLC Company: JBU GLOBAL LLC Address: 19416 NE 26th AVE, 114B, Miami, Florida 33180, United States Product Name: Animato S1 Model Number: microphone FCC Identifier: 2A7ZM-ANIMATOS1MIC We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Issac Grunwald Date: 2023/09/12 Title: Chief Operations Officer Signature of applicant:

Cover Letter(s)

C5266091_X10_Ed.1 1/1 JBU GLOBAL LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023/09/12 Subject: Request for Confidentiality FCC ID: 2A7ZM-ANIMATOS1MIC To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of _180_ days from the date of the Grant of Equipment Authorization and prior to marketing. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Name: Issac Grunwald Title: Chief Operations Officer

External Photos

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23070410-1E Page 1 of 7 AppendixI: Photos of the EUT Product Name : Animato S1 Model Number : microphone Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23070410-1E Page 2 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23070410-1E Page 3 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23070410-1E Page 4 of 7

Internal Photos

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23070410-1E Page 4 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23070410-1E Page 5 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23070410-1E Page 6 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23070410-1E Page 7 of 7 END Antenna

RF Exposure Info

Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23070410-1E04 TRF No.: KDB447498 D01 Ver.1.0 Page 1 of 6 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : JBU GLOBAL LLC Address : 19416 NE 26th AVE, 114B, Miami, Florida 33180, United States Equipment under Test : Animato S1 Model No. : microphone Trade Mark : N/A FCC ID : 2A7ZM-ANIMATOS1MIC Manufacturer : SHENZHEN GXTSONIC TECHNOLOGY CO., LTD Address : 1F,Building 3,Tianxin Shuichan Industrial Park,Gushu Village,Xixiang Town,Bao`an District,Shenzhen,CHINA Report No.: DDT-RE23070410-1E04 Issued Date: Sep. 07, 2023 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23070410-1E04 TRF No.: KDB447498 D01 Ver.1.0 Page 2 of 6 Table of Contents Test report declares.......................................................................................................3 1. General Information ....................................................................................................... 5 1.1. Description of equipment ............................................................................................... 5 1.2. Assess laboratory ........................................................................................................... 5 2. RF Exposure evaluation for FCC ................................................................................... 6 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23070410-1E04 TRF No.: KDB447498 D01 Ver.1.0 Page 3 of 6 Test Report Declare Standard Used: KDB447498 D01 General RF Exposure Guidance v06 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Dongguan Dongdian Testing Service Co., Ltd is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No: DDT-RE23070410-1E04 Date of Receipt: Aug. 16, 2023 Date of Test: Aug. 16, 2023 ~ Sep. 07, 2023 Prepared By: Approved By: ___________________ ______________________ Tiger Mo/Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : JBU GLOBAL LLC Address : 19416 NE 26th AVE, 114B, Miami, Florida 33180, United States Equipment under Test : Animato S1 Model No. : microphone Trade Mark : N/A Manufacturer : SHENZHEN GXTSONIC TECHNOLOGY CO., LTD Address : 1F,Building 3,Tianxin Shuichan Industrial Park,Gushu Village,Xixiang Town,Bao`an District,Shenzhen,CHINA Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23070410-1E04 TRF No.: KDB447498 D01 Ver.1.0 Page 4 of 6 Revision History Rev. Revisions Issue Date Revised By --- Initial issue Sep. 07, 2023 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23070410-1E04 TRF No.: KDB447498 D01 Ver.1.0 Page 5 of 6 1. General Information 1.1. Description of equipment 1.2. Assess laboratory Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808. Tel.: +86-0769-38826678, http://www.dgddt.com, Email: [email protected]. CNAS Accreditation No. L6451; A2LA Accreditation Number: 3870.01 FCC Designation Number: CN1182, Test Firm Registration Number: 540522 Innovation, Science and Economic Development Canada Site Registration Number: 10288A Conformity Assessment Body identifier: CN0048 VCCI facility registration number: C-20087, T-20088, R-20123, R-20155, G-20118 EUT Name : Animato S1 Model Number : microphone EUT function description : Please reference user manual of this device Power Supply : DC 5V - 1A (USB-C input), Rechargeable Lithium, 1200mAh for microphone Operation frequency : 2402 MHz - 2480 MHz Modulation : GFSK, /4-DQPSK Antenna Type : Chip antenna , maximum PK gain: 2.7 dBi Sample Number : S23070410-04 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23070410-1E04 TRF No.: KDB447498 D01 Ver.1.0 Page 6 of 6 2. RF Exposure evaluation for FCC According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Manufacturing Tolerance BT GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -11.55 -10.30 -9.33 Tolerance ±(dB) 2 2 2 π/4DQPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -10.70 -9.56 -8.45 Tolerance ±(dB) 2 2 2 Estimtion Result Worse case is as below: [2480 MHz, -6.45 dBm, (0.23 mW) output power] (0.23/5) ·[√2.480(GHz)] = 0.072< 3.0 for 1-g SAR Then SAR evaluation is not required. END OF REPORT

Test Report

2.4GHz3216ChipAntenna:RANT3216F245X02 _ Application: WLAN,802.11b/g,Bluetooth,WLAN,etc... Features SMD,highreliability,ultraImpact,Omni-directional... PartnumberInformation RANT3216F245X02 (A)(B)(C)(D)(E)(F) ElectricalSpecification ThespecificationisdefinedonEVB. DimensionandTerminalConfiguration No.TerminalName 1Feeding/GNG 2GND/Feeding (A)ProductTypeChipAntenna (B)SizeCode 3.2x1.6mm( ± 0.2mm) (C)MaterialHighKmaterial (D)Frequency2.4~2.5GHz (E)FeedingmodePIFA&SingleFeeding (F)AntennatypeType=0X WorkingFrequencyRange2400~2500MHz Bandwidth120MHz(Min.) PeakGain2.7dBi(Typ.) Impedance50Ohm Returnloss10dB(Min) PolarizationLinear AzimuthBeamwidthOmni-directional OperationTemperature( °C )-40~85 °C ResistancetoSolderingHeats 10sec.(@280 °C ) TerminationNi/Au(Leadless) Dimension(mm) L 3.20±0.20 W 1.60±0.20 T 0.45±0.20 咏成國際科技有限公司電話:13530576606 RAINInternationalTechnologyCo.,Ltd. 7/F,BuildingF,ZhichuangPark,Tong'an,Gushu,Shenzhen  2.4GHz3216ChipAntenna:RANT3216F245X02 _ 1 EvaluationBoardReference PCBDimensionAntennaLayoutReference Unit:mm ElectricalCharacteristics ReturnLoss&Radiation ReturnLoss Frequency(MHz) S11(dB) 2400-10.50 2450-30.62 2500-11.47 Radiation X Y Z 2.4GHz3216ChipAntenna:RANT3216F245X02 _ TapingSpecifications ReelandTapingSpecification ReelSpecification TYPESIZEABCD 32167”5K/Reel 9.0±0.5 60±213.5±0.5178±2 TappingSpecification PackagingTypeABWEFGHTψDP PaperType3216 1.90±0.203.50±0.208.0±0.201.75±0.103.5±0.054.0±0.102.0±0.050.75±0.10 1.50±0.10 4.0±0.1 2.4GHz3216ChipAntenna:RANT3216F245X02 _ ReliabilityTable TestItemProcedure Requirements CeramicType Remark (Reference) Electrical Characterization Fulfilltheelectrical specification UserSpec. Thermal Shock 1.Preconditioning: 50±10°C/1hr,thenkeepfor24±1hrsatroomtemp. 2.Initialmeasure:Spec:referInitialspec. 3.Rapidchangeoftemperaturetest: -30°Cto+85°C;100cycles; 15minutesatLowercategorytemperature; 15minutesatUppercategorytemperature. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 107 Temperature Cycling 1.Initialmeasure:Spec:referInitialspec. 2.100Cycles(-30°Cto+85°C),SoakMode=1(2Cycle/hours). 3.Measurementat24±2Hoursaftertestcondition. NoVisibleDamage. Fulfilltheelectrical specification. JESD22 JA104 HighTemperature Exposure 1.Initialmeasure:Spec:referInitialspec. 2.Unpowered;500hours@T=+85°C. 3.Measurementat24±2hoursaftertest. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 108 LowTemperature Storage 1.Initialmeasure:Spec:referInitialspec. 2.Unpowered:500hours@T=-30°C. 3.Measurementat24±2hoursaftertest. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 108 Solderability (SMDBottomSide) Dippingmethod: a.Temperature:235±5°C b.Dippingtime:3±0.5s Thesoldershouldcover over95%ofthecritical areaofbottomside. IEC60384-21/22 4.10 SolderingHeat Resistance (RSH) Preheatingtemperature:150±10°C. Preheatingtime:1~2min. Soldertemperature:260±5°C. Dippingtime:5±0.5s NoVisibleDamage.IEC60384-21/22 4.10 Vibration5g'sfor20min.,12cycleseachof3orientations Note:Use8"X5"PCB.031"thick7securepointson,onelong sideand2securepointsatcornersofoppositesides.Parts mountedwithin2"fromanysecurepoint.Testfrom10-2000 Hz. NoVisibleDamage.MIL-STD-202 Method204 Mechanical Shock Threeshocksineachdirectionshallbeappliedalongthethree mutuallyperpendicularaxesofthetestspecimen(18shocks) Peakvalue:1,500g’s Duration:0.5ms Velocitychange:15.4ft/s Waveform:Half-sine NoVisibleDamage.MIL-STD-202 Method213 Humidity Bias 1.Humidity:85%R.H.,Temperature:85±2°C. 2.Time:500±24hours. 3.Measurementat24±2hrsaftertestcondition. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 Method106 2.4GHz3216ChipAntenna:RANT3216F245X02 _ Board Flex (SMD) 1.Mountingmethod: IR-Reflow.PCBSize(L:100×W:40×T:1.6mm) 2.Applytheloadindirectionofthearrowuntilbendingreaches 2mm. NoVisibleDamage.AEC-Q200 005 AdhesionForceof1.8Kgfor60seconds.NoVisibleDamage Magnificationof20Xor greatermaybeemployed forinspectionofthe mechanicalintegrityofthe devicebodyterminalsand body/terminaljunction. AEC-Q200 006 Physical Dimension Anyapplicablemethodusingx10magnification,micrometers, calipers,gauges,contourprojectors,orothermeasuring equipment,capableofdeterminingtheactualspecimen dimensions. Inaccordancewith specification. JESD22 JB100 RevisionHistory RevisionDateContent 12019/03/01NewDatasheet 22020/02/22Add2Dradiationcharacteristic

Test Report

Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23070410-1E02 TRF No.: FCC Part 15C BT Ver.1.0 Page 1 of 77 FCC CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : JBU GLOBAL LLC Address : 19416 NE 26th AVE, 114B, Miami, Florida 33180, United States Equipment under Test : Animato S1 Model No. : microphone Trade Mark : N/A FCC ID : 2A7ZM-ANIMATOS1MIC Manufacturer : SHENZHEN GXTSONIC TECHNOLOGY CO., LTD Address : 1F,Building 3,Tianxin Shuichan Industrial Park,Gushu Village,Xixiang Town,Bao`an District,Shenzhen,CHINA Report No.:DDT-RE23070410-1E02 Issued Date: Sep. 07, 2023 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23070410-1E02 TRF No.: FCC Part 15C BT Ver.1.0 Page 2 of 77 Table of Contents Test report declares.......................................................................................................4 1. Summary of Test Results ............................................................................................... 7 2. General Test Information ............................................................................................... 8 2.1. Description of EUT ......................................................................................................... 8 2.2. Accessories of EUT ........................................................................................................ 9 2.3. Assistant equipment used for test .................................................................................. 9 2.4. Block diagram of EUT configuration for test .................................................................. 9 2.5. Deviations of test standard............................................................................................. 9 2.6. Test environment conditions ........................................................................................ 10 2.7. Test laboratory ............................................................................................................. 10 2.8. Measurement uncertainty ............................................................................................. 10 3. Equipment Used During Test ....................................................................................... 11 4. 20 dB Bandwidth .......................................................................................................... 12 4.1. Block diagram of test setup .......................................................................................... 12 4.2. Limits ............................................................................................................................ 12 4.3. Test procedure ............................................................................................................. 12 4.4. Test result ..................................................................................................................... 12 4.5. Test graphs .................................................................................................................. 13 5. 99% Bandwidth ............................................................................................................ 15 5.1. Block diagram of test setup .......................................................................................... 15 5.2. Limits ............................................................................................................................ 15 5.3. Test procedure ............................................................................................................. 15 5.4. Test Result ................................................................................................................... 15 5.5. Test Graphs .................................................................................................................. 16 6. Maximum Peak Output Power ..................................................................................... 18 6.1. Block diagram of test setup .......................................................................................... 18 6.2. Limits ............................................................................................................................ 18 6.3. Test procedure ............................................................................................................. 18 6.4. Test Result ................................................................................................................... 19 6.5. Test graphs .................................................................................................................. 19 7. Carrier Frequency Separation ...................................................................................... 22 7.1. Block diagram of test setup .......................................................................................... 22 7.2. Limits ............................................................................................................................ 22 7.3. Test procedure ............................................................................................................. 22 7.4. Test result ..................................................................................................................... 23 7.5. Test graphs .................................................................................................................. 23 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23070410-1E02 TRF No.: FCC Part 15C BT Ver.1.0 Page 3 of 77 8. Dwell Time .................................................................................................................... 24 8.1. Block diagram of test setup ..................................................…

Text truncated - open the document above for the full version.

Test Report

Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23070410-1E02 TRF No.: FCC Part 15C BT Ver.1.0 Page 51 of 77 antenna shall be 1 m above the ground. For measurement above 30MHz, the trilog Broadband Antenna or Horn Antenna was located 3m from EUT, Measurements were made with the antenna positioned in both the horizontal and vertical planes of Polarization, and the measurement antenna was varied from 1 m to 4 m. in height above the reference ground plane to obtain the maximum signal strength. (3) Below pre-scan procedure was first performed in order to find prominent frequency spectrum radiated emissions from 9 kHz to 25 GHz: (a) Scanning the peak frequency spectrum with the antenna specified in step (3), and the EUT was rotated 360 degree, the antenna height was varied from 1 m to 4 m (Except loop antenna, it’s fixed 1 m above ground.) (b) Change work frequency or channel of device if practicable. (c) Change modulation type of device if practicable. (d) Change power supply range from 85% to 115% of the rated supply voltage (e) Rotated EUT though three orthogonal axes to determine the attitude of EUT arrangement produces highest emissions. Spectrum frequency from 9 kHz to 25 GHz (tenth harmonic of fundamental frequency) was investigated, and no any obvious emission were detected from 18 GHz to 25 GHz, so below final test was performed with frequency range from 9 kHz to 18 GHz. (4) For final emissions measurements at each frequency of interest, the EUT was rotated and the antenna height was varied between 1 m and 4 m in order to maximize the emission. Measurements in both horizontal and vertical polarities were made and the data was recorded. In order to find the maximum emission, the relative positions of equipment and all of the interface cables were changed according to ANSI C63.10:2013 on Radiated Emission test. (5) The emissions from 9 kHz to 1 GHz were measured based on CISPR QP detector except for the frequency bands 9 - 90 kHz, 110 - 490 kHz, for emissions from 9 kHz - 90 kHz,110 kHz - 490 kHz and above 1 GHz were measured based on average detector, for emissions above 1 GHz, peak emissions also be measured and need comply with Peak limit. (6) The emissions from 9 kHz to 1 GHz, QP or average values were measured with EMI receiver with below RBW. Frequency band RBW 9 kHz - 150 kHz 200 Hz 150 kHz - 30 MHz 9 kHz 30 MHz - 1 GHz 120 kHz (7) For emissions above 1GHz, both Peak and Average level were measured with Spectrum Analyzer, and the RBW is set at 1 MHz, VBW is set at 3 MHz for Peak measure; According ANSI C63.10:2013 clause 4.1.4.2.2 procedure for average measure. (8) For portable device, X axis, Y axis, Z axis are tested, and worse setup is reported. Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23070410-1E02 TRF No.: FCC Part 15C BT Ver.1.0 Page 52 of 77 13.4. Test result Pass. (See below detailed test result) All the emissions except fundamental emission from 9 kHz to 25 GHz were comply with 15.209 limits. Note1: According exploratory test, the emission levels are 20 dB below the limit detected from 9 kHz to 30 MHz and 18 GHz to 25 GHz, so the final test was performed with frequency range from 30 MHz to 18 GHz and recorded in below. Note2: 30 MHz ~ 25 GHz: (Scan with GFSK, /4-DQPSK, the worst case is GFSK Mode) Note3: For emissions below 1 GHz, according exploratory explorer test, when change Tx mode and channel, have no distinct influence on emissions level, so for emissions below 1 GHz, the final test was only performed with EUT working in GFSK, Tx 2480 MHz mode. Note4: For emissions above 1 GHz. If peak results comply with AV limit, AV Result is deemed to comply with AV limit. Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23070410-1E02 TRF No.: FCC Part 15C BT Ver.1.0 Page 53 of 77 Radiated Emission test (below 1 GHz) TR-4-E-009 Radiated Emission Test Result Test Date: 2023-08-18 Tested By: Bairong EUT: Animato S1 Model Number: microphone Test Mode: TX Mode Power Supply: AC 120V/60Hz Condition: Temp:22.0°C;Humi:56.3% Test Site: DDT 3# Chamber File Path: d:\ts\2023 report data\Q23070410-2E\FCC BELOW 1G\20230818-231801_H Memo: BT Final Data List NO. Freq. [MHz] Reading [dBμV/m] Antenna Factor [dB] Cable Loss [dB] AMP [dB] Result [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 37.41 30.75 11.58 4.57 -30.89 16.01 40.00 23.99 QP Horizontal 2 51.19 33.65 13.08 4.73 -30.69 20.77 40.00 19.23 QP Horizontal 3 111.08 28.44 10.29 5.13 -30.87 12.99 43.50 30.51 QP Horizontal 4 190.74 35.12 10.27 5.65 -30.63 20.41 43.50 23.09 QP Horizontal 5 320.68 29.9 13.83 6.26 -30.26 19.73 46.00 26.27 QP Horizontal 6 875.27 23.04 22.30 8.25 -29.22 24.37 46.00 21.63 QP Horizontal Note: 1. Result Level = Reading + Cable loss + Antenna Factor + AMP 2. If Peak Result complies with QP limit, QP Result is deemed to comply with QP limit. 3. Test setup: RBW: 120 kHz, VBW: 300 kHz, Sweep time: auto. Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23070410-1E02 TRF No.: FCC Part 15C BT Ver.1.0 Page 54 of 77 TR-4-E-009 Radiated Emission Test Result Test Date: 2023-08-18 Tested By: Bairong EUT: Animato S1 Model Number: microphone Test Mode: TX Mode Power Supply: AC 120V/60Hz Condition: Temp:22.0°C;Humi:56.3% Test Site: DDT 3# Chamber File Path: d:\ts\2023 report data\Q23070410-2E\FCC BELOW 1G\20230818-231853_V Memo: BT Final Data List NO. Freq. [MHz] Reading [dBμV/m] Antenna Factor [dB] Cable Loss [dB] AMP [dB] Result [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 37.55 45.49 11.61 4.57 -30.89 30.78 40.00 9.22 QP Vertical 2 52.24 39.3 12.98 4.74 -30.69 26.33 40.00 13.67 QP Vertical 3 94.14 32.39 10.21 5.00 -30.78 16.82 43.50 26.68 QP Vertical 4 190.33 36.69 10.23 5.65 -30…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Issac Grunwald(Chief Operations Officer)
[email protected]8442627464Fax: N/A

Technical Contact

Dongguan Dongdian Testing Service Co., LtdDamon Hu
[email protected]86-0769- 38826678

Dongguan · China

Non-Technical Contact

Dongguan Dongdian Testing Service Co., LtdDamon Hu
[email protected]86-0769- 38826678

Test Firm

Guangdong Dongdian Testing Service Co., Ltd.Mr. Jamy Yu
[email protected]+86-0769-89201646

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz100.00 µW
Confidentiality
Long Term
Grant Notes
Output power listed is conducted.
