Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Single press . PRODUCT MANUAL NOISE CANCELLING Shortly press to switch between noise cancelling modes. While audio is playing, press and hold to switch between equalizer modes: 4 4 4 POWER ON/OFF To power the headset on or off, press and hold for 2 seconds. EQUALIZER CONTROL VOICE ASSISTANT 1 BOOM ARM MUSIC CONTROL PLAY/PAUSE MUSIC Shortly press to answer an incoming call, or to hang up during an ongoing call. Long press . 5 6 7 5 ADJUST VOLUME Shortly press for volume up, and shortly press for volume down. 6 7 5 PREVIOUS/NEXT TRACK Long press for next track, and long press for previous track. 6 7 PHONE CONTROL ANSWER/HANG UP 5 DECLINE INCOMING CALL 5 Double press to activate your smartphone’s given voice assistant. 4 HEADBAND ADJUSTMENT Lengthen the headband by pulling the ear cups away from the top of the headband, until the desired length is reached. Each adjustment step is signified by a clicking sound. To shorten the headband, push the ear cups back up into the top of the headband. Rotate the boom arm to a vertical or horizontal position to respectively mute or unmute the boom arm microphone. Ensure that the green microphone symbol on the boomarm microphone faces your mouth, and that the foam tip is securely in place. CONNECTION LED INDICATION Bluetooth pairing mode Connected Not connected Incoming call Charging Fully Charged CHARGE CONNECTION 8 8 9 9 REGULATORY AceZone ApS hereby declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU and all other applicable EU directive requirements. The complete declaration of conformity can be found at: www.acezone.io/compliance This product conforms to all applicable Electromagnetic Compatibility Regulations 2016 and all other applicable UK regulations. The complete declaration of conformity can be found at: www.acezone.io/compliance AceZone ApS hereby declares that this product is in compliance with the essential requirements per Radio Equipment Regulations 2017 and all other applicable UK regulations. The complete declaration of conformity can be found at: www.acezone.io/compliance Do not use this apparatus near water. Clean only with a dry cloth. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Important Safety Instructions WARNINGS/CAUTIONS • Do NOT use the headset at a high volume for any extended period. – To avoid hearing damage, use your headset at a comfortable, moderate volume level. – Turn the volume down on your device before placing the headset in/on your ears, then turn the volume up gradually until you reach a comfortable listening level. • Do NOT use your headset while driving for phone calls or any other purpose. • Do NOT use the headset with noise canceling mode at any time the inability to hear surrounding sounds may present a danger to yourself or others, e.g., while riding a bicycle or walking in or near traffic, a construction site or railroad, etc., and follow applicable laws regarding headset use. – Turn the headset off, or use the headset with noise canceling off and adjust your volume, to ensure you can hear surrounding sounds, including alarms and warning signals. – Be aware of how sounds that you rely on as reminders or warnings may vary in character when using the headset, even with transparency mode. • Do NOT use the headset if they emit any loud unusual noise. If this happens, turn the headphones off and contact AceZone customer service. • Remove the headset immediately if you experience a warming sensation or loss of audio. • Do NOT use the headset as aviation communication headsets. Contains small parts which may be a choking hazard. Not suitable for children under age 3. This product contains magnetic material. Consult your physician on whether this might affect your implantable medical device. WARNINGS/CAUTIONS CONT. This symbol means the product must not be discarded as household waste, and should be delivered to an appropriate collection facility for recycling. Proper disposal and recycling helps protect natural resources, human health and the environment. For more information on disposal and recycling of this product, contact your local municipality, disposal service, or the shop where you bought this product. • Do NOT use mobile phone adapters to connect headset to airplane seat jacks, as this could result in injury or property damage due to overheating. • To reduce the risk of fire or electrical shock, do NOT expose this product to rain, liquids or moisture. • Do NOT expose this product to dripping or splashing, and do not place objects filled with liquids, such as vases, on or near the product. • Keep the product away from fire and heat sources. Do NOT place naked flame sources, such as lighted candles, on or near the product. • Use this product only with an agency approved LPS power supply which meets local regulatory requirements (e.g., UL, CSA, VDE, CCC). • Do NOT make unauthorized alterations to this product. • If the battery leaks, do not allow the liquid to come in contact with the skin or eyes. If contact is made, seek medical advice. • Do not expose products containing batteries to excessive heat (e.g. from storage in direct sunlight, fire or the like). • Do NOT wear while charging - One beep signals music mode. - Two beeps signal gaming mode. 1 1 USB - MAIN GAMING USE, and CHARGING For the best gaming performance and charging, connect using the USB Type-C cable. AUX - CONSOLE USE BLUETOOTH - CASUAL USE For consoles where a USB connection is not possible, connect using the AUX cable. 2 2 3 3 BATTERY STATUS While the headset is off, press and hold for 5 seconds to enter pairing mode. 1 While the headset is turned on, shortly press to get the headset b…
Text truncated - open the document above for the full version.
Acezone ApS Agent Authorization Company: Acezone ApS Address: Nordre Fasanvej 113, 2nd floor. 2000 Frederiksberg Denmark Product Name: Wireless Bluetooth Headphones Model Number(s): A-Spire Product Description: Wireless Bluetooth Headphones We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.01.05 Name: Jiankuai Li Title: PM Company: Shenzhen STS Test Services Co., Ltd.
Acezone ApS Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.01.05 Subject; Request for Confidentiality FCC ID: 2A89O-ASPIRE To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jiankuai Li Title: PM
Page 1 of 3 Report No.: STS2210111 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 3 Report No.: STS2210111 Photo 3 Photo 4 Page 3 of 3 Report No.: STS2210111 Photo 5 Photo 6
Label Wireless Bluetooth Headphones Model name: A-Spire FCC ID: 2A89O-ASPIRE 4cm 3cm
Page 1 of 6 Report No.: STS2210111 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 6 Report No.: STS2210111 Photo 3 Photo 4 BT Antenna Page 3 of 6 Report No.: STS2210111 Photo 5 Photo 6 Page 4 of 6 Report No.: STS2210111 Photo 7 Photo 8 Page 5 of 6 Report No.: STS2210111 Photo 9 Photo 10 Page 6 of 6 Report No.: STS2210111 Photo 11
Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2210111H01 Issued for Acezone ApS Nordre Fasanvej 113, 2nd floor. 2000 Frederiksberg Denmark Product Name: Wireless Bluetooth Headphones Brand: Acezone A-Spire Model Number: A-Spire Series Model(s): N/A FCC ID: 2A89O-ASPIRE Test Standard: FCC 47CFR §2.1093 S T L A B S Page 2 of 9 Report No.: STS2210111H01 Test Report Certification Applicant’s Name .................. : Acezone ApS Address .................................. : Nordre Fasanvej 113, 2nd floor. 2000 Frederiksberg Denmark Manufacturer's Name ........... : Acezone ApS Address .................................. : Nordre Fasanvej 113, 2nd floor. 2000 Frederiksberg Denmark Product Description Product Name ......................... : Wireless Bluetooth Headphones Brand .................................... : Acezone A-Spire Model Number ........................ : .. : A-Spire Series Model(s) ...................... : N/A Standards .............................. : FCC 47CFR §2.1093 447498 D04 Interim General RF Exposure Guidance v01 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date of receipt of test item ...................... : 01 Nov. 2022 Date (s) of performance of tests ............. : 01 Nov. 2022 ~ 07 Nov. 2022 Date of Issue ........................................... : 07 Nov. 2022 Test Result ............................................... : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2210111H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2210111H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 07 Nov. 2022 STS2210111H01 ALL Initial Issue Page 5 of 9 Report No.: STS2210111H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Wireless Bluetooth Headphones Brand Acezone A-Spire Model Number A-Spire Series Model(s) N/A Model Difference N/A Product Description The EUT is Wireless Bluetooth Headphones. Operation Frequency: 2402 – 2480 MHz Modulation Type: GFSK, π/4-DQPSK,8DPSK Antenna gain: 3.45dBi Antenna Designation: Ceramic Antenna Rating Input: DC 5V /1A Battery Rated Voltage:3.7V Charge Limit Voltage:4.2V Capacity: 850mAh Hardware Version V0C Software Version V1.0 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2210111H01 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2210111H01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2210111H01 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of mult…
Text truncated - open the document above for the full version.
第1页共10页 8010Chipantenna ForBluetooth/WLANApplications P/N:8010F245M01 Dimension(mm) L8.11±0.20 W1.03±0.20 T1.25±0.20 咏成國際科技有限公司電話 :13530576606 RAINInternationalTechnologyCo.,Ltd. TEL:13530576606 第2页共10页 PartNumberInformation RAIN8010F245M01 ABCDEF AProductSeriesAntenna BDimensionLxW8.0X1.0mm(+-0.2mm) CMaterialHighKmaterial DWorkingFrequency2.4~2.5GHz EFeedingmodeMonopole&SingleFeeding FAntennatypeType=01 1.ElectricalSpecification Specification PartNumber8010F245M01 CentralFrequency2450MHz Bandwidth100(Min.)MHz ReturnLoss-10(Max)dB PeakGain3.45dBi Impedance50Ohm OperatingTemperature -40~+85°C MaximumPower4W ResistancetoSolderingHeats 10(@260°C) sec. PolarizationLinear AzimuthBeamwidthOmni-directional TerminationCu/Sn(Leadless) Remark:Bandwidth&PeakGainwasmeasuredunderevaluationboardofnextpage 第3页共10页 2.RecommendedPCBPattern EvaluationBoardDimension SuggestedMatchingCircuit Unit:mm 第4页共10页 LayoutDimensionsinClearancearea(Size=10.0*5.0mm) 50ohmtransmissionLine MatchingCircuit LayoutDimensionsinClearancearea(Size=10.0*3.0mm) 50ohmtransmissionLine MatchingCircuit FootPrint(Unit:mm) 第5页共10页 3.MeasurementResults ReturnLoss 第6页共10页 RadiationPattern Y X Z EfficiencyPeakGainDirectivity 2400MHz69.13%3.39dBi5.53dBi 2450MHz74.79%3.45dBi5.20dBi 2500MHz65.65%2.75dBi5.14dBi ChamberCoordinateSystem 第7页共10页 4.ReliabilityandTestCondictions ITEMREQUIREMENTSTESTCONDITION Solderability1.Wettingshallexceed90%coverage 2.Novisiblemechanicaldamage TEMP(°C) 230°C 4±1sec. 150 °C 60sec Pre-heatingtemperature:150°C/60sec. Soldertemperature:230±5°C Duration:4±1sec. Solder:Sn-Ag3.0-Cu0.5 Fluxforleadfree:rosin Solderheat Resistance 1.Novisiblemechanicaldamage 2.CentralFreq.change:within±6% TEMP(°C) 260°C 10±0.5sec. 150°C 60sec Pre-heatingtemperature:150°C/60sec. Soldertemperature:260±5°C Duration:10±0.5sec. Solder:Sn-Ag3.0-Cu0.5 Fluxforleadfree:rosin Component Adhesion (Pushtest) 1.Novisiblemechanicaldamage Thedeviceshouldbereflow soldered(230±5°Cfor10sec.)toatinned coppersubstrateAdynometerforce gaugeshouldbeappliedthesideofthe component.Thedevicemustwith-ST-F 0.5Kgwithoutfailureofthetermination attachedtocomponent. Component Adhesion (Pulltest) 1.Novisiblemechanicaldamage Insert10cmwireintotheremainingopen eyebend,theendsofevenwirelengths upwardandwindtogether. Terminalshallnotberemarkably damaged. Thermalshock 1.Novisiblemechanicaldamage 2.CentralFreq.change:within±6% +85 °C =>30±3min -40°C=>30±3min Testcycle:10cycles Thechipshallbestabilizedatnormal conditionfor2~3hoursbefore measuring. Resistanceto High Temperature 1.Novisiblemechanicaldamage 2.CentralFreq.change:within±6% 3.Nodisconnectionorshortcircuit. Temperature:85±5°C Duration:1000±12hrs Thechipshallbestabilizedatnormal conditionfor2~3hoursbefore measuring. Resistanceto Low Temperature 1.Novisiblemechanicaldamage 2.CentralFreq.change:within±6% 3.Nodisconnectionorshortcircuit. Temperature:-40±5°C Duration:1000±12hrs Thechipshallbestabilizedatnormal conditionfor2~3hoursbefore measuring. Humidity 1.Novisiblemechanicaldamage 2.CentralFreq.change:within±6% 3.Nodisconnectionorshortcircuit. Temperature:40±2°C Humidity:90%to95%RH Duration:1000±12hrs Thechipshallbestabilizedatnormal conditionfor2~3hoursbefore measuring. Phase Temperature(°C) Time(min) 1 +85±5°C 30±3 2 Room Temperature Within 3sec 3 -40±2°C 30±3 4 Room Temperature Within 3sec 第8页共10页 5.SolderingandMounting Mildlyactivatedrosinfluxesarepreferred.Theminimumamountofsolder canleadtodamagefromthestressescausedbythedifferencein coefficientsofexpansionbetweensolder,chipandsubstrate.The terminationsaresuitableforallwaveandre-flowsolderingsystems.Ifhand solderingcannotbeavoided,thepreferredtechniqueistheutilizationofhot airsolderingtools. ReflowSoldering PRE-HEATING 250~260 230 180 150 SOLDERING 10smax. NATURAL COOLING IronSoldering PRE-HEATINGSOLDERINGNATURAL COOLING 60~120s30~60s TIME(sec.) TIME(sec.) Recommendedtemperatureprofilesforre-flowsolderinginFigure1. Productsattachmentwithasolderingironisdiscouragedduetotheinherent processcontrollimitations.Intheeventthatasolderingironmustbe employedthefollowingprecautionsarerecommended. ‧Preheatcircuitandproductsto150°C ‧Nevercontacttheceramicwiththeirontip ‧Usea20wattsolderingironwithtipdiameterof1.0mm ‧280°Ctiptemperature(max) ‧1.0mmtipdiameter(max) ‧Limitsolderingtimeto3sec. within3s 350 150 Over60s Gradualcooling 300 T E M P E R A T U R E ( ° C ) T E M P E R A T U R E ( ° C ) 第9页共10页 6.PackagingInformation TapeSpecification: WAoBoKoPFEDD1PoP2t 16.0 ±0.30 1.30 ±0.10 8.30 ±0.10 1.40 ±0.10 4.00 ±0.10 7.50 ±0.10 1.75 ±0.10 1.50 ±0.10 0.00 ±0.10 4.00 ±0.10 2.00 ±0.10 0.30 ±0.05 ReelSpecification:(7’’,Φ180mm) TapeWidth(mm)A(mm)B(mm)C(mm)D(mm)Chip/Reel(pcs) 1616±1.060±213.5±0.5178±23000 第10页共10页 7.StorageandTransportationInformation StorageConditions Tomaintainthesolderabilityofterminalelectrodes: 1.Temperatureandhumidityconditions:-10~40°Cand30~70%RH. 2.Recommendedproductsshouldbeusedwithin6monthsfromthetime ofdelivery. 3.Thepackagingmaterialshouldbekeptwherenochlorineorsulfur existsintheair. TransportationConditions 1.Productsshouldbehandledwithcaretoavoiddamageor contaminationfromperspirationandskinoils. 2.Theuseoftweezersorvacuumpickupisstronglyrecommendedfor individualcomponents. 3.Bulkhandlingshouldensurethatabrasionandmechanicalshockare minimized.
Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.: STS2210111W01 Issued for Acezone ApS Nordre Fasanvej 113, 2nd floor. 2000 Frederiksberg Denmark Product Name: Wireless Bluetooth Headphones Brand: Acezone A-Spire Model Number: A-Spire Series Model(s): N/A FCC ID: 2A89O-ASPIRE Test Standard: FCC Part 15.247 S T L A B S Page 2 of 101 Report No.: STS2210111W01 TEST RESULT CERTIFICATION Applicant’s Name ................... : Acezone ApS Address .................................. : Nordre Fasanvej 113, 2nd floor. 2000 Frederiksberg Denmark Manufacturer's Name ............. : Acezone ApS Address .................................. : Nordre Fasanvej 113, 2nd floor. 2000 Frederiksberg Denmark Product Description Product Name ........................ : Wireless Bluetooth Headphones Brand .................................... : Acezone A-Spire Model Number ........................ : .. : A-Spire Series Model(s) ...................... : N/A Test Standards ....................... : FCC Part15.247 Test Procedure ....................... : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ................................ : Date of receipt of test item .......... : 01 Nov. 2022 Date (s) of performance of tests . : 01 Nov. 2022 ~ 07 Nov. 2022 Date of Issue .............................. : 07 Nov. 2022 Test Result .................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory: (Bovey Yang) Page 3 of 101 Report No.: STS2210111W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 FREQUENCY HOPPING SYSTEM REQUIREMENTS 10 2.4 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 12 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 2.6 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 13 2.7 EQUIPMENTS LIST 14 3. EMC EMISSION TEST 16 3.1 CONDUCTED EMISSION MEASUREMENT 16 3.2 RADIATED EMISSION MEASUREMENT 20 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 32 4.1 LIMIT 32 4.2 TEST PROCEDURE 32 4.3 TEST SETUP 33 4.4 EUT OPERATION CONDITIONS 33 4.5 TEST RESULTS 33 5. NUMBER OF HOPPING CHANNEL 34 5.1 LIMIT 34 5.2 TEST PROCEDURE 34 5.3 TEST SETUP 34 5.4 EUT OPERATION CONDITIONS 34 5.5 TEST RESULTS 34 6. AVERAGE TIME OF OCCUPANCY 35 6.1 LIMIT 35 6.2 TEST PROCEDURE 35 6.3 TEST SETUP 35 6.4 EUT OPERATION CONDITIONS 35 6.5 TEST RESULTS 35 7. HOPPING CHANNEL SEPARATION MEASUREMEN 36 Page 4 of 101 Report No.: STS2210111W01 Table of Contents Page 7.1 LIMIT 36 7.2 TEST PROCEDURE 36 7.3 TEST SETUP 36 7.4 EUT OPERATION CONDITIONS 36 7.5 TEST RESULTS 36 8. BANDWIDTH TEST 37 8.1 LIMIT 37 8.2 TEST PROCEDURE 37 8.3 TEST SETUP 37 8.4 EUT OPERATION CONDITIONS 37 8.5 TEST RESULTS 37 9. OUTPUT POWER TEST 38 9.1 LIMIT 38 9.2 TEST PROCEDURE 38 9.3 TEST SETUP 38 9.4 EUT OPERATION CONDITIONS 38 9.5 TEST RESULTS 38 10. ANTENNA REQUIREMENT 39 10.1 STANDARD REQUIREMENT 39 10.2 EUT ANTENNA 39 APPENDIX 1-TEST DATA 40 1. DWELL TIME 40 2. MAXIMUM AVERAGE CONDUCTED OUTPUT POWER 50 3. MAXIMUM PEAK CONDUCTED OUTPUT POWER 56 4. -20DB BANDWIDTH 62 5. CARRIER FREQUENCIES SEPARATION 68 6. NUMBER OF HOPPING CHANNEL 74 7. BAND EDGE 77 8. BAND EDGE(HOPPING) 84 9. CONDUCTED RF SPURIOUS EMISSION 91 APPENDIX 2-PHOTOS OF TEST SETUP 101 Page 5 of 101 Report No.: STS2210111W01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 07 Nov. 2022 STS2210111W01 ALL Initial Issue Page 6 of 101 Report No.: STS2210111W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(a)(1)&(b)(1) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(1)(iii) Number of Hopping Frequency PASS -- 15.247(a)(1)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 101 Report No.: STS2210111W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.87dB 2 Unwanted Emissions, conducted ±2.895dB 3 All emissions, radiated 9K-30MHz ±3.80dB 4 All emissions, radiated 30M-1GHz ±4.09dB 5 All emissions, radiated 1G-6GHz ±4.92dB …
Text truncated - open the document above for the full version.
Page 1 of 2 FCC ID: 2A89O-ASPIRE DSS_DTS Setup photo Model name: A-Spire DSS conduction DSS radiation L Page 2 of 2 FCC ID: 2A89O-ASPIRE DSS radiation H
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 3.30 mW |

A-Spire Wireless Bluetooth headphone
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
A-Spire Wireless Bluetooth headphone
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
