2A8OE-F-SC241IoT RTU IP Camera with LTE

IP Camera User Manual V2.0.0 This manual is applicable to the following products: F-SC241 / F-SC921 / F-SC431 / F-SC621 / F-SC332 Xiamen Four-Faith Communication Technology Co., Ltd. https://www.fourfaith.co Document Revision History Date Version Note Author 2019-05-01 V1.0.0 Initial Version Wayne 2020-12-01 V1.1.0 Add Latest Products and New Features Instruction Jonas 2021-06-22 V1.1.1 Update Product Line Graph Jonas 2021-07-08 V2.0.0 New Version Jonas IP Camera User Manual www.fourfaith.com Copyright @ Four-Faith 2021 Copyright Notice All contents in the files are protected by copyright law, and all copyrights are reserved by Xiamen Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome. Trademark Notice Four-Faith, 四信, , , are all registered trademarks of Xiamen Four-Faith Communication Technology Co., Ltd., illegal use of the name of Four-Faith, trademarks and other marks of Four-Faith is forbidden, unless written permission is authorized in advance. FCC Statements This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications or changes to this equipment. Such modifications or changes could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference IP Camera User Manual www.fourfaith.com Copyright @ Four-Faith 2021 to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐ Reorient or relocate the receiving antenna. ‐ Increase the separation between the equipment and receiver. ‐Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐Consult the dealer or an experienced radio/TV technician for help. Federal Communication Commission (FCC) Radiation Exposure Statement When using the product, maintain a distance of 20cm from the body to ensure compliance with RF exposure requirements. IP Camera User Manual www.fourfaith.com Copyright @ Four-Faith 2021 Note: There may be differences between models of accessories and interfaces, actual products shall prevail. IP Camera User Manual www.fourfaith.com Copyright @ Four-Faith 2021 CONTENTS CHAPTER 1 INTRODUCTION .............................................................. 1 1.1 General ........................................................................................................................................................ 1 1.2 Product Line............................................................................................................................................... 2 1.3 Word Definition ........................................................................................................................................ 2 CHAPTER 2 SYSTEM ............................................................................... 3 2.1 Structure & Diagram ............................................................................................................................... 3 2.1.1 IPC Working Principle Diagram .................................................................................................. 3 2.1.2 IPC Cloud Management Structure ............................................................................................. 3 2.2 Features ....................................................................................................................................................... 4 2.2.1 Network ............................................................................................................................................... 4 2.2.2 System ................................................................................................................................................. 4 2.2.3 External Interface ............................................................................................................................. 4 2.2.4 Cloud Platform .................................................................................................................................. 4 2.2.5 Other Web Funtions ....................................................................................................................... 5 2.3 Performance .............................................................................................................................................. 5 2.3.1 Streaming Concurrency ................................................................................................................. 5 2.3.2 Video Storage ................................................................................................................................... 5 CHAPTER 3 OPERATING ENVIRONMENT ............................................ 6 3.1 Computer Requirement ...........…

Text truncated - open the document above for the full version.

RF_743, Issue 02 Declaration of Authorization We Name: Fibocom Wireless Inc. Address: City: Country: 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1s t Rd, Nanshan, Shenzhen, China Shenzhen China Declare that: Name: Address: City: Country Xiamen Four-Faith Communication Technology Co., Ltd 11th Floor, A-06 Area, No.370, Chengy i Street, Jimei District, Xiamen, China Xiamen China may use our test reports and documentation of the following (already certified) product: Product name: 5G module Type designation: FM160-NA Trademark: Fibocom FCC ID: ZMOFM160NA for his own approval/certificate. Date: 09/19/2022 City: Shenzhen Name: Lucy.Liu Signature:

Xiamen Four-Faith Communication Technology Co., Ltd. Date: 2022-09-15 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Xiamen Four-Faith Communication Technology Co., Ltd., the undersigned, hereby authorizesMiss.WendyZhanfromShenzhenMorlab Communications Technology Co., Ltd., to act on the behalf of the Xiamen Four-Faith Communication TechnologyCo., Ltd. solely inmatters relatingtothe application for an FCC equipment authorization forFCC ID: 2A8OE-F-SC241 including the signing of documents in connection with this Application. Necessary acts carried outShenzhen Morlab Communications Technology Co., Ltd.on our behalf of the Xiamen Four-Faith Communication Technology Co., Ltd. in connection with the Application shall have the same effect as acts of the Xiamen Four-Faith Communication Technology Co., Ltd.. Xiamen Four-Faith Communication Technology Co., Ltd. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name:Jonas Yang Title:Product Manager Tel:+8618059226320 Email:[email protected] Company name: Xiamen Four-FaithCommunication Technology Co., Ltd.

XiamenFour-FaithCommunicationTechnologyCo.,Ltd. Date:2022-09-15 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Request of Confidentiality forFCC ID: 2A8OE-F-SC241 To Whom it may concern: Pursuant to sections 0.457 and 0.459 of Commission’s Rules(CFR 47), and Section 552(b)(4) of the Freedom of Information Act,Xiamen Four-Faith Communication Technology Co., Ltd.hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-TermConfidentiality for 180 days after the grant as outlined in Public Notice DA04-1705. This provision will giveXiamen Four-Faith Communication Technology Co., Ltd.temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listedas follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST ExhibitDescription PERMANENT 1Block Diagram 2Operational Description 3Schematics 4BOM SHORT-TERM 5External Photos 6Internal Photos 7Test-Setup Photos 8User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Signatory: Name:Jonas Yang Company nam e:Xiamen Four-Faith Communication Technology Co., Ltd. A ddress:11th Floor, A-06 Area, No.370, Chengyi Street, Jimei District, Xiamen City, China Tel: +8618059226320 Email: [email protected]

XiamenFour-FaithCommunicationTechnologyCo.,Ltd. Supplier’sDeclarationOfConformity for the FCC SDoC Procedure The following Equipment adapt FCC SDoC Procedure according to FCC part 2.906 : Product Na me: IoT RTU IP Camera Bra nd Name: Four‐Faith Model Number: F‐SC241 Report Number: SZ22090060E01 It’sherewithconfirmedtocomplywiththerequirementsofFCCPart15Rules. Operationissubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,includinginterferencethat maycauseundesiredoperation. Itisunderstoodthateachunitmarketedisidenticaltothedeviceastested,andanychangestothe devicethatcouldadverselyaffecttheemissioncharacteristicswillrequireretest. Thefollowingimporter/responsiblepartyinUnitedStates: NotAvailableatCertificationStage CompanyName:N/A CompanyAddress:N/A Telephone:N/A Fax:N/A Personisresponsibleformarkingthisdeclaration: JonasYangProductManager __________________________________________________________________________ Name(Fullname)Position/Title 2022‐10‐20 __________________________________________________________________________ LegalSignatureDate

FCC ID: 2A8OE-F-SC241 External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Accessories

Label: Location: BottomFace

FCC ID: 2A8OE-F-SC241 Internal Photos 1. EUT uncover view 2. Antenna view GPS ANT WiFi ANT, Tx/Rx WWAN ANT WiFi ANT (For the preset antenna) GPS ANT WWAN ANT0, Tx WWAN ANT1, Rx WWAN ANT2, Rx WWAN ANT3, Rx

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., Ltd., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 8 REPORT No.：SZ22090060S01 RF EXPOSURE EVALUATION REPORT APPLICANT : Xiamen Four-Faith Communication Technology Co., Ltd. PRODUCT NAME : IoT RTU IP Camera MODEL NAME : F-SC241 BRAND NAME : Four-Faith FCC ID : 2A8OE-F-SC241 STANDARD(S) : FCC 47 CFR Part 2(2.1091) RECEIPT DATE : 2022-03-10 TEST DATE : 2022-03-15 to 2022-05-13 ISSUE DATE : 2022-11-21 Edited by: Xie Yiyun (Rapporteur) Approved by: Shen Junsheng (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22090060S01 Page 2 of 8 DIRECTORY 1. Technical Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.1 Applicant and Manufacturer Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.2 Equipment under Test (EUT) Description ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.3 Applied Reference Documents ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 4 2. Device Category and RF Exposure Limit ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5 3. RF Output Power ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 4. RF Exposure Assessment ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 Annex A General Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 8 Change History Version Date Reason for Change 1.0 2022-11-21 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22090060S01 Page 3 of 8 1. Technical Information Note: Provide by applicant. 1.1 Applicant and Manufacturer Information Applicant: Xiamen Four-Faith Communication Technology Co., Ltd. Applicant Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei District, Xiamen City, Fujian Province, China Manufacturer: Xiamen Four-Faith Communication Technology Co., Ltd. Manufacturer Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei District, Xiamen City, Fujian Province, China 1.2 Equipment under Test (EUT) Description Product Name: IoT RTU IP Camera EUT No.: N/A Hardware Version: V1.0.1.0 Software Version: FFIPC_11.1.0.6-r29 Frequency Bands: LTE Band 2: 1850 MHz ~ 1910 MHz LTE Band 4: 1710 MHz ~ 1755 MHz LTE Band 48: 3550 MHz ~ 3700 MHz Modulation Mode: LTE: QPSK,16QAM, 64QAM, 256QAM Antenna Type: Fixed External Antenna Antenna Gain: Frequency Bands Antenna Gain (dBi) LTE Band 2 2.42 LTE Band 4 0.75 LTE Band 48 3.49 Note: When the test result is a critical value, we will use the measurement uncertainty give the judgment result based on the 95% confidence intervals. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22090060S01 Page 4 of 8 1.3 Applied Reference Documents Leading reference documents for testing: Identity Document Title Method determination /Remark FCC 47 CFR Part 2(2.1091) Radio Frequency Radiation Exposure Assessment: mobile devices No deviation KDB 447498 D01v06 General RF Exposure Guidance No deviation Note 1: The test item is not applicable. Note 2: Additions to, deviation, or exclusions from the method shall be judged in the "method determination" column of add, deviate or exclude from the specific method shall be explained in the "Remark" of the above table. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22090060S01 Page 5 of 8 2. Device Category and RF Exposure Limit Per user manual, Based on 47CFR 2.1091, this device belongs to mobile device category with General Population/Uncontrolled exposure. Mobile Devices: 47CFR 2.1091(b) For purposes of this section, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. In this context, the term “fixed location” means that the device is physically secured at one location and is not able to be easily moved to another location. Transmitting devices designed to be used by consumers or workers that can be easily re-located, such as wireless devices associated with a personal computer, are considered to be mobile devices if they meet the 20 centimeter separation requirement. General P…

Text truncated - open the document above for the full version.

LTE B48 1. Effective (Isotropic) Radiated Power Output Data 1.1 B48_5MHz_EIRP 1.1.1 Test Result Band: 48 / Bandwidth: 5MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm/10MHz) Gain (dbi) EIRP (dBm/10MHz) Verdict Size Offset Result Limit QPSK 3552.5 1 0 20.77 -0.13 20.64 <=23 Pass 13 21.00 -0.13 20.87 <=23 Pass 24 20.93 -0.13 20.80 <=23 Pass 12 0 20.31 -0.13 20.18 <=23 Pass 6 19.88 -0.13 19.75 <=23 Pass 13 20.23 -0.13 20.10 <=23 Pass 25 0 19.98 -0.13 19.85 <=23 Pass 3625 1 0 21.27 -0.13 21.14 <=23 Pass 13 21.06 -0.13 20.93 <=23 Pass 24 21.41 -0.13 21.28 <=23 Pass 12 0 19.65 -0.13 19.52 <=23 Pass 6 19.80 -0.13 19.67 <=23 Pass 13 21.07 -0.13 20.94 <=23 Pass 25 0 19.70 -0.13 19.57 <=23 Pass 3697.5 1 0 22.47 -0.13 22.34 <=23 Pass 13 21.74 -0.13 21.61 <=23 Pass 24 21.60 -0.13 21.47 <=23 Pass 12 0 20.78 -0.13 20.65 <=23 Pass 6 21.35 -0.13 21.22 <=23 Pass 13 20.44 -0.13 20.31 <=23 Pass 25 0 21.54 -0.13 21.41 <=23 Pass 16QAM 3552.5 1 0 20.01 -0.13 19.88 <=23 Pass 13 19.83 -0.13 19.70 <=23 Pass 24 19.89 -0.13 19.76 <=23 Pass 12 0 18.82 -0.13 18.69 <=23 Pass 6 18.98 -0.13 18.85 <=23 Pass 13 19.06 -0.13 18.93 <=23 Pass 25 0 19.03 -0.13 18.90 <=23 Pass 3625 1 0 20.40 -0.13 20.27 <=23 Pass 13 20.41 -0.13 20.28 <=23 Pass 24 19.44 -0.13 19.31 <=23 Pass 12 0 18.71 -0.13 18.58 <=23 Pass 6 19.47 -0.13 19.34 <=23 Pass 13 19.41 -0.13 19.28 <=23 Pass 25 0 18.47 -0.13 18.34 <=23 Pass 3697.5 1 0 20.58 -0.13 20.45 <=23 Pass 13 20.82 -0.13 20.69 <=23 Pass 24 19.85 -0.13 19.72 <=23 Pass 12 0 19.89 -0.13 19.76 <=23 Pass 6 19.74 -0.13 19.61 <=23 Pass 13 20.02 -0.13 19.89 <=23 Pass 25 0 19.85 -0.13 19.72 <=23 Pass Note1: EIRP=Conducted Power+Antenna Gain 1.1.2 Test Graph Band48_5MHz_QPSK_LCH_3552.5MHz_RB_1_0_NTNV Band48_5MHz_QPSK_LCH_3552.5MHz_RB_1_13_NTNV Band48_5MHz_QPSK_LCH_3552.5MHz_RB_1_24_NTNV Band48_5MHz_QPSK_LCH_3552.5MHz_RB_12_0_NTNV Band48_5MHz_QPSK_LCH_3552.5MHz_RB_12_6_NTNV Band48_5MHz_QPSK_LCH_3552.5MHz_RB_12_13_NTNV Band48_5MHz_QPSK_LCH_3552.5MHz_RB_25_0_NTNV Band48_5MHz_QPSK_MCH_3625MHz_RB_1_0_NTNV Band48_5MHz_QPSK_MCH_3625MHz_RB_1_13_NTNV Band48_5MHz_QPSK_MCH_3625MHz_RB_1_24_NTNV Band48_5MHz_QPSK_MCH_3625MHz_RB_12_0_NTNV Band48_5MHz_QPSK_MCH_3625MHz_RB_12_6_NTNV Band48_5MHz_QPSK_MCH_3625MHz_RB_12_13_NTNV Band48_5MHz_QPSK_MCH_3625MHz_RB_25_0_NTNV Band48_5MHz_QPSK_HCH_3697.5MHz_RB_1_0_NTNV Band48_5MHz_QPSK_HCH_3697.5MHz_RB_1_13_NTNV Band48_5MHz_QPSK_HCH_3697.5MHz_RB_1_24_NTNV Band48_5MHz_QPSK_HCH_3697.5MHz_RB_12_0_NTNV Band48_5MHz_QPSK_HCH_3697.5MHz_RB_12_6_NTNV Band48_5MHz_QPSK_HCH_3697.5MHz_RB_12_13_NTNV Band48_5MHz_QPSK_HCH_3697.5MHz_RB_25_0_NTNV Band48_5MHz_16QAM_LCH_3552.5MHz_RB_1_0_NTNV Band48_5MHz_16QAM_LCH_3552.5MHz_RB_1_13_NTNV Band48_5MHz_16QAM_LCH_3552.5MHz_RB_1_24_NTNV Band48_5MHz_16QAM_LCH_3552.5MHz_RB_12_0_NTNV Band48_5MHz_16QAM_LCH_3552.5MHz_RB_12_6_NTNV Band48_5MHz_16QAM_LCH_3552.5MHz_RB_12_13_NTNV Band48_5MHz_16QAM_LCH_3552.5MHz_RB_25_0_NTNV Band48_5MHz_16QAM_MCH_3625MHz_RB_1_0_NTNV Band48_5MHz_16QAM_MCH_3625MHz_RB_1_13_NTNV Band48_5MHz_16QAM_MCH_3625MHz_RB_1_24_NTNV Band48_5MHz_16QAM_MCH_3625MHz_RB_12_0_NTNV Band48_5MHz_16QAM_MCH_3625MHz_RB_12_6_NTNV Band48_5MHz_16QAM_MCH_3625MHz_RB_12_13_NTNV Band48_5MHz_16QAM_MCH_3625MHz_RB_25_0_NTNV Band48_5MHz_16QAM_HCH_3697.5MHz_RB_1_0_NTNV Band48_5MHz_16QAM_HCH_3697.5MHz_RB_1_13_NTNV Band48_5MHz_16QAM_HCH_3697.5MHz_RB_1_24_NTNV Band48_5MHz_16QAM_HCH_3697.5MHz_RB_12_0_NTNV Band48_5MHz_16QAM_HCH_3697.5MHz_RB_12_6_NTNV Band48_5MHz_16QAM_HCH_3697.5MHz_RB_12_13_NTNV Band48_5MHz_16QAM_HCH_3697.5MHz_RB_25_0_NTNV 1.2 B48_10MHz_EIRP 1.2.1 Test Result Band: 48 / Bandwidth: 10MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm/10MHz) Gain (dbi) EIRP (dBm/10MHz) Verdict Size Offset Result Limit QPSK 3555 1 0 20.91 -0.13 20.78 <=23 Pass 25 21.27 -0.13 21.14 <=23 Pass 49 20.98 -0.13 20.85 <=23 Pass 25 0 20.11 -0.13 19.98 <=23 Pass 13 20.20 -0.13 20.07 <=23 Pass 25 19.84 -0.13 19.71 <=23 Pass 50 0 20.27 -0.13 20.14 <=23 Pass 3625 1 0 21.27 -0.13 21.14 <=23 Pass 25 21.36 -0.13 21.23 <=23 Pass 49 21.20 -0.13 21.07 <=23 Pass 25 0 20.15 -0.13 20.02 <=23 Pass 13 20.53 -0.13 20.40 <=23 Pass 25 20.67 -0.13 20.54 <=23 Pass 50 0 20.20 -0.13 20.07 <=23 Pass 3695 1 0 21.78 -0.13 21.65 <=23 Pass 25 22.12 -0.13 21.99 <=23 Pass 49 22.02 -0.13 21.89 <=23 Pass 25 0 21.20 -0.13 21.07 <=23 Pass 13 21.14 -0.13 21.01 <=23 Pass 25 20.94 -0.13 20.81 <=23 Pass 50 0 21.24 -0.13 21.11 <=23 Pass 16QAM 3555 1 0 20.24 -0.13 20.11 <=23 Pass 25 20.14 -0.13 20.01 <=23 Pass 49 19.93 -0.13 19.80 <=23 Pass 25 0 19.21 -0.13 19.08 <=23 Pass 13 19.17 -0.13 19.04 <=23 Pass 25 19.13 -0.13 19.00 <=23 Pass 50 0 18.85 -0.13 18.72 <=23 Pass 3625 1 0 20.15 -0.13 20.02 <=23 Pass 25 20.11 -0.13 19.98 <=23 Pass 49 20.55 -0.13 20.42 <=23 Pass 25 0 19.43 -0.13 19.30 <=23 Pass 13 19.57 -0.13 19.44 <=23 Pass 25 19.40 -0.13 19.27 <=23 Pass 50 0 19.31 -0.13 19.18 <=23 Pass 3695 1 0 20.76 -0.13 20.63 <=23 Pass 25 21.28 -0.13 21.15 <=23 Pass 49 20.93 -0.13 20.80 <=23 Pass 25 0 19.86 -0.13 19.73 <=23 Pass 13 20.19 -0.13 20.06 <=23 Pass 25 20.20 -0.13 20.07 <=23 Pass 50 0 20.36 -0.13 20.23 <=23 Pass Note1: EIRP=Conducted Power+Antenna Gain 1.2.2 Test Graph Band48_10MHz_QPSK_LCH_3555MHz_RB_1_0_NTNV Band48_10MHz_QPSK_LCH_3555MHz_RB_1_25_NTNV Band48_10MHz_QPSK_LCH_3555MHz_RB_1_49_NTNV Band48_10MHz_QPSK_LCH_3555MHz_RB_25_0_NTNV Band48_10MHz_QPSK_LCH_3555MHz_RB_25_13_NTNV Band48_10MHz_QPSK_LCH_3555MHz_RB_25_25_NTNV Band48_10MHz_QPSK_LCH_3555MHz_RB_50_0_NTNV Band48_10MHz_QPSK_MCH_3625MHz_RB_1_0_NTNV Band48_10MHz_QPSK_MCH_3625MHz_RB_1_25_NTNV Band48_10MHz_QPSK_MCH_3625MHz_RB_1_49_NTNV Band48_10MHz_QPSK_MCH_3625MHz_RB_25_0_NTNV Band48_10MHz_QPSK_MCH_3625MHz_RB_25_13_NTNV Band48_10MHz_QPSK_MCH_3625MHz_RB_25_25_NTNV Band48_10MHz_QPSK_MCH_3625MHz_RB_50_0_NTNV Band48_10MHz_QPSK_HCH_3695MHz_RB_1_0_NTNV Band48_10MHz_QPSK_HCH_3695MHz_RB_1_25_NTNV Band48_10MHz_QPSK_HCH_3695MHz_RB_1_49_NTNV Band48_10MHz_QPSK_HCH_3695MHz_RB_25_0_NTNV Band48_10MHz_QPSK_HCH_3695MHz_RB_25_13_NTNV Band48_10MHz_Q…

Text truncated - open the document above for the full version.

LTE B48 1. Peak-Average Ratio 1.1 B48_5MHz 1.1.1 Test Result Band: 48 / Bandwidth: 5MHz / NTNV Modulation Frequency (MHz) RB Allocation Peak-Average Ratio (dB) Verdict Size Offset Result Limit QPSK 3552.5 25 0 7.70 <=13 Pass 3625 25 0 7.73 <=13 Pass 3697.5 25 0 7.79 <=13 Pass 16QAM 3552.5 25 0 8.46 <=13 Pass 3625 25 0 8.52 <=13 Pass 3697.5 25 0 8.55 <=13 Pass 1.1.2 Test Graph Band48_5MHz_QPSK_LCH_3552.5MHz_RB_25_0_NTNV Band48_5MHz_QPSK_MCH_3625MHz_RB_25_0_NTNV Band48_5MHz_QPSK_HCH_3697.5MHz_RB_25_0_NTNV Band48_5MHz_16QAM_LCH_3552.5MHz_RB_25_0_NTNV Band48_5MHz_16QAM_MCH_3625MHz_RB_25_0_NTNV Band48_5MHz_16QAM_HCH_3697.5MHz_RB_25_0_NTNV 1.2 B48_10MHz 1.2.1 Test Result Band: 48 / Bandwidth: 10MHz / NTNV Modulation Frequency (MHz) RB Allocation Peak-Average Ratio (dB) Verdict Size Offset Result Limit QPSK 3555 50 0 8.24 <=13 Pass 3625 50 0 8.25 <=13 Pass 3695 50 0 8.23 <=13 Pass 16QAM 3555 50 0 8.83 <=13 Pass 3625 50 0 8.82 <=13 Pass 3695 50 0 8.87 <=13 Pass 1.2.2 Test Graph Band48_10MHz_QPSK_LCH_3555MHz_RB_50_0_NTNV Band48_10MHz_QPSK_MCH_3625MHz_RB_50_0_NTNV Band48_10MHz_QPSK_HCH_3695MHz_RB_50_0_NTNV Band48_10MHz_16QAM_LCH_3555MHz_RB_50_0_NTNV Band48_10MHz_16QAM_MCH_3625MHz_RB_50_0_NTNV Band48_10MHz_16QAM_HCH_3695MHz_RB_50_0_NTNV 1.3 B48_15MHz 1.3.1 Test Result Band: 48 / Bandwidth: 15MHz / NTNV Modulation Frequency (MHz) RB Allocation Peak-Average Ratio (dB) Verdict Size Offset Result Limit QPSK 3557.5 75 0 8.64 <=13 Pass 3625 75 0 8.79 <=13 Pass 3692.5 75 0 8.67 <=13 Pass 16QAM 3557.5 75 0 9.34 <=13 Pass 3625 75 0 9.31 <=13 Pass 3692.5 75 0 9.35 <=13 Pass 1.3.2 Test Graph Band48_15MHz_QPSK_LCH_3557.5MHz_RB_75_0_NTNV Band48_15MHz_QPSK_MCH_3625MHz_RB_75_0_NTNV Band48_15MHz_QPSK_HCH_3692.5MHz_RB_75_0_NTNV Band48_15MHz_16QAM_LCH_3557.5MHz_RB_75_0_NTNV Band48_15MHz_16QAM_MCH_3625MHz_RB_75_0_NTNV Band48_15MHz_16QAM_HCH_3692.5MHz_RB_75_0_NTNV 1.4 B48_20MHz 1.4.1 Test Result Band: 48 / Bandwidth: 20MHz / NTNV Modulation Frequency (MHz) RB Allocation Peak-Average Ratio (dB) Verdict Size Offset Result Limit QPSK 3560 100 0 9.14 <=13 Pass 3625 100 0 9.03 <=13 Pass 3690 100 0 9.14 <=13 Pass 16QAM 3560 100 0 9.62 <=13 Pass 3625 100 0 9.54 <=13 Pass 3690 100 0 9.41 <=13 Pass 1.4.2 Test Graph Band48_20MHz_QPSK_LCH_3560MHz_RB_100_0_NTNV Band48_20MHz_QPSK_MCH_3625MHz_RB_100_0_NTNV Band48_20MHz_QPSK_HCH_3690MHz_RB_100_0_NTNV Band48_20MHz_16QAM_LCH_3560MHz_RB_100_0_NTNV Band48_20MHz_16QAM_MCH_3625MHz_RB_100_0_NTNV Band48_20MHz_16QAM_HCH_3690MHz_RB_100_0_NTNV 5. Peak-Average Ratio 5.1 B48_5MHz 5.1.1 Test Result Band: 48 / Bandwidth: 5MHz / NTNV Modulation Frequency (MHz) RB Allocation Peak-Average Ratio (dB) Verdict Size Offset Result Limit QPSK 3552.5 25 0 7.70 <=13 Pass 3625 25 0 7.73 <=13 Pass 3697.5 25 0 7.79 <=13 Pass 16QAM 3552.5 25 0 8.46 <=13 Pass 3625 25 0 8.52 <=13 Pass 3697.5 25 0 8.55 <=13 Pass 5.1.2 Test Graph Band48_5MHz_QPSK_LCH_3552.5MHz_RB_25_0_NTNV Band48_5MHz_QPSK_MCH_3625MHz_RB_25_0_NTNV Band48_5MHz_QPSK_HCH_3697.5MHz_RB_25_0_NTNV Band48_5MHz_16QAM_LCH_3552.5MHz_RB_25_0_NTNV Band48_5MHz_16QAM_MCH_3625MHz_RB_25_0_NTNV Band48_5MHz_16QAM_HCH_3697.5MHz_RB_25_0_NTNV 5.2 B48_10MHz 5.2.1 Test Result Band: 48 / Bandwidth: 10MHz / NTNV Modulation Frequency (MHz) RB Allocation Peak-Average Ratio (dB) Verdict Size Offset Result Limit QPSK 3555 50 0 8.24 <=13 Pass 3625 50 0 8.25 <=13 Pass 3695 50 0 8.23 <=13 Pass 16QAM 3555 50 0 8.83 <=13 Pass 3625 50 0 8.82 <=13 Pass 3695 50 0 8.87 <=13 Pass 5.2.2 Test Graph Band48_10MHz_QPSK_LCH_3555MHz_RB_50_0_NTNV Band48_10MHz_QPSK_MCH_3625MHz_RB_50_0_NTNV Band48_10MHz_QPSK_HCH_3695MHz_RB_50_0_NTNV Band48_10MHz_16QAM_LCH_3555MHz_RB_50_0_NTNV Band48_10MHz_16QAM_MCH_3625MHz_RB_50_0_NTNV Band48_10MHz_16QAM_HCH_3695MHz_RB_50_0_NTNV 5.3 B48_15MHz 5.3.1 Test Result Band: 48 / Bandwidth: 15MHz / NTNV Modulation Frequency (MHz) RB Allocation Peak-Average Ratio (dB) Verdict Size Offset Result Limit QPSK 3557.5 75 0 8.64 <=13 Pass 3625 75 0 8.79 <=13 Pass 3692.5 75 0 8.67 <=13 Pass 16QAM 3557.5 75 0 9.34 <=13 Pass 3625 75 0 9.31 <=13 Pass 3692.5 75 0 9.35 <=13 Pass 5.3.2 Test Graph Band48_15MHz_QPSK_LCH_3557.5MHz_RB_75_0_NTNV Band48_15MHz_QPSK_MCH_3625MHz_RB_75_0_NTNV Band48_15MHz_QPSK_HCH_3692.5MHz_RB_75_0_NTNV Band48_15MHz_16QAM_LCH_3557.5MHz_RB_75_0_NTNV Band48_15MHz_16QAM_MCH_3625MHz_RB_75_0_NTNV Band48_15MHz_16QAM_HCH_3692.5MHz_RB_75_0_NTNV 5.4 B48_20MHz 5.4.1 Test Result Band: 48 / Bandwidth: 20MHz / NTNV Modulation Frequency (MHz) RB Allocation Peak-Average Ratio (dB) Verdict Size Offset Result Limit QPSK 3560 100 0 9.14 <=13 Pass 3625 100 0 9.03 <=13 Pass 3690 100 0 9.14 <=13 Pass 16QAM 3560 100 0 9.62 <=13 Pass 3625 100 0 9.54 <=13 Pass 3690 100 0 9.41 <=13 Pass 5.4.2 Test Graph Band48_20MHz_QPSK_LCH_3560MHz_RB_100_0_NTNV Band48_20MHz_QPSK_MCH_3625MHz_RB_100_0_NTNV Band48_20MHz_QPSK_HCH_3690MHz_RB_100_0_NTNV Band48_20MHz_16QAM_LCH_3560MHz_RB_100_0_NTNV Band48_20MHz_16QAM_MCH_3625MHz_RB_100_0_NTNV Band48_20MHz_16QAM_HCH_3690MHz_RB_100_0_NTNV 5G NR N48 1. Peak-Average Ratio 1.1 30k_SISO_10MHz_NTNV 1.1.1 Test Result 5G NR n48 SCS=30kHz SISO 10MHz NTNV Modulation Frequency (MHz) RB Allocation Peak-Average Ratio (dBm) Verdict Ant1 Ant2 Sum Limit DFT-s-OFDM QPSK 3555 Outer_Full 11.31 / / <=13 Pass 3624.99 Outer_Full 10.98 / / <=13 Pass 3694.98 Outer_Full 11.30 / / <=13 Pass DFT-s-OFDM 16 QAM 3555 Outer_Full 12.30 / / <=13 Pass 3624.99 Outer_Full 12.22 / / <=13 Pass 3694.98 Outer_Full 12.35 / / <=13 Pass DFT-s-OFDM 64 QAM 3555 Outer_Full 12.55 / / <=13 Pass 3624.99 Outer_Full 12.50 / / <=13 Pass 3694.98 Outer_Full 12.54 / / <=13 Pass DFT-s-OFDM 256 QAM 3555 Outer_Full 12.49 / / <=13 Pass 3624.99 Outer_Full 12.58 / / <=13 Pass 3694.98 Outer_Full 12.64 / / <=13 Pass CP-OFDM QPSK 3555 Outer_Full 12.36 / / <=13 Pass 3624.99 Outer_Full 12.34 / / <=13 Pass 3694.98 Outer_Full 12.60 / / <=13 Pass CP-OFDM 16 QAM 3555 Outer_Full 12.33 / / <=13 Pass 3624.99 Outer_Full 12.82 / / <=13 Pass 3694.98 Outer_Full 12.58 / / <=13 Pass CP-OFDM 64 QAM 3555 Outer_Full 12.38 / / <=13 Pass 3624.9…

Text truncated - open the document above for the full version.

LTE B48 1. 99% & 26dB Bandwidth 1.1 Band48_OBW 1.1.1 Test Result Band: 48 / NTNV Bandwidth (MHz) Modulation Frequency (MHz) RB Allocation 99% Occupied Bandwidth (MHz) Verdict Size Offset Result 5 QPSK 3552.5 25 0 4.575 Pass 3625 25 0 4.561 Pass 3697.5 25 0 4.568 Pass 16QAM 3552.5 25 0 4.569 Pass 3625 25 0 4.567 Pass 3697.5 25 0 4.554 Pass 10 QPSK 3555 50 0 9.090 Pass 3625 50 0 9.043 Pass 3695 50 0 9.051 Pass 16QAM 3555 50 0 9.115 Pass 3625 50 0 9.064 Pass 3695 50 0 9.074 Pass 15 QPSK 3557.5 75 0 13.638 Pass 3625 75 0 13.576 Pass 3692.5 75 0 13.615 Pass 16QAM 3557.5 75 0 13.617 Pass 3625 75 0 13.55…

Text truncated - open the document above for the full version.
