F8926-GW-02 LoRaWAN Indoor Gateway User Manual LoRAWAN Indoor Gateway F8926-GW-02 User Manual V2.0.0 Xiamen Four-Faith Communication Technology Co., Ltd. https://www.fourfaith.com F8926-GW-02 LoRaWAN Indoor Gateway User Manual Document Revision History Date Version Specification Author 2022-08-29 V1.0.0 Initial Version SGK/HGL/YSL/WSC 2022-11-01 V1.0.1 Change the communication field "devEui" to "devEui" SGK 2023-08-15 V1.0.2 English Version Update YYL 2023-12-11 V.2.0.0 New version Jonas F8926-GW-02 LoRaWAN Indoor Gateway User Manual Copyright Statement All materials or content contained in this document are protected by copyright law. All copyrights are owned by Xiamen Four-Faith Communication Technology Co., Ltd., except for content explicitly referenced from other sources. Without written permission from Four-Faith, no one may copy, distribute, reproduce, link, transmit, or otherwise use any content from this document for any commercial purposes. However, downloading or printing for non-commercial, personal use is permitted (provided that the material is not modified and the copyright notice or other ownership notices are retained). Trademark Statement Four-Faith、四信、、、 All are registered trademarks of Xiamen Four-Faith Communication Technology Co., Ltd. Without prior written permission, no one is allowed to use the name "Four-Faith" and the trademarks or symbols of Four-Faith in any way. FCC Caution: Part 15.21 Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Part 15.19 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Part 15.105 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. F8926-GW-02 LoRaWAN Indoor Gateway User Manual FCC RF Radiation Exposure Statement: 1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2. This equipment complies with RF radiation exposure limits set forth for an uncontrolled environment. 3.This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. RED Caution: Hereby, Xiamen Four-Faith Communication Technology Co., Ltd. declares that this product is in compliance with essential requirements and other relevant provisions of Directive 2014/53/EU. This product is allowed to be used in all EU member states. RF Function Frequency bands Maximum output power 2.4G WLAN 2412-2472MHz 18.28dBm(EIRP) LORA 863-870MHz 7.62dBm(ERP) GSM900 880-915MHz(TX) 925-960MHz(RX) 34.50dBm DSC1800 1710-1785MHz(TX) 18051880MHz(RX) 31.50dBm WCDMA Band I 1920-1980MHz(TX) 2110-2170MHz(RX) 25.50dBm WCDMA Band VIII 880-915MHz(TX) 925-960MHz(RX) 25.50dBm LTE Band 1 1920-1980MHz(TX) 2110-2170MHz(RX) 25.00dBm LTE Band 3 1710-1785MHz(TX) 1805-1880MHz(RX) 25.00dBm LTE Band 7 2500-2570MHz(TX) 2620-2690MHz(RX) 25.00dBm LTE Band 8 880-915MHz(TX) 925-960MHz(RX) 25.00dBm LTE Band 20 832-862MHz(TX) 791-821MHz(RX) 25.00dBm LTE Band 28 703-748MHz(TX) 758-803MHz(RX) 25.00dBm LTE Band 38 2570-2620MHz 25.00dBm LTE Band 40 2300-2400MHz 25.00dBm F8926-GW-02 LoRaWAN Indoor Gateway User Manual Note: There may be differences in accessories and interfaces for different models. Please refer to the actual product for details. F8926-GW-02 LoRaWAN Indoor Gateway User Manual Contents Chapter 1 Product Introduction .................................................. 1 1.1 Product Overview ................................................................................................... 1 1.2 Product Features .................................................................................................... 1 1.3 Block Diagram of Operation ................................................................................... 3 1.4 Product Specifications ............................................................................................ 4 Chapter 2 Installation .................................................................. 8 2.1 Overview ................................................................................................................. 8 2.2 Packing List ............................................................................................................ 8 2.3 Installation and Cable Connection ......................................................................... 8 2.4 Power Instructions ................................................................................................ 12 2.5 Indicator Lights Explanation: ................................................................................ 12 2.6 Reset Button Instructions ..................................................................................... 12 Chapter 3 Quick Start Guide ..........…

Text truncated - open the document above for the full version.

Xiamen Four-Faith Communication Technology Co., Ltd. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter December 19, 2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2A8OE-F8926-GW-02 FRN: 0032877359 Per section 2.911(d)(7) of the FCC rules, Xiamen Four-Faith Communication Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: Global Product Services and Consultation LLC Physical U.S. Company Address: 328 W Palm Ave. Monrovia, CA 91016 United States Agent name: Mr Michael Chan Agent Email Address: [email protected] FRN: 0033406703 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: Jonas Yang Printed name: Mr Michael Chan Title: Product Manager Title: Technical Director Company Name: Xiamen Four-Faith Communication Technology Co., Ltd. Company Name: Global Product Services and Consultation LLC Date: December 18, 2023 Date: December 18, 2023 SC3126088

Xiamen Four-Faith Communication Technology Co., Ltd. Covered Equipment Certification Attestation Letter 12/18/2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2A8OE-F8926-GW-02 Xiamen Four-Faith Communication Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Xiamen Four-Faith Communication Technology Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Jonas Yang Title: Product Manager Company Name: Xiamen Four-Faith Communication Technology Co., Ltd. Date: 12/18/2023

Xiamen Four-Faith Communication Technology Co., Ltd. 12/19/2023 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 AUTHORITY TO ACT AS AGENT - FCC On our behalf, I appoint Xiamen Four-Faith Communication Technology Co., Ltd. / 11th Floor,A- 06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China., to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko North America Inc., still resides still resides with us. Sincerely, Printed name: Jonas Yang

Report No.: CHTEW23110070 Page: 30 of 36 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 7. EXTERNAL AND INTERNAL PHOTOS 7.1. External Photos Report No.: CHTEW23110070 Page: 31 of 36 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09)

Report No.: CHTEW23110070 Page: 32 of 36 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 7.2. Internal Photos Report No.: CHTEW23110070 Page: 33 of 36 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTEW23110070 Page: 34 of 36 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTEW23110070 Page: 35 of 36 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Report No.: CHTEW23110070 Page: 36 of 36 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 8. APPENDIX REPORT

FCC ID: 2A8OE-F8926-GW-02 RF Exposure Evaluation LIMIT The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 - - f/300 6 1500–100,000 - - 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 - - f/1500 30 1500–100,000 - - 1.0 30 Note: f = frequency in MHz EVALUATION METHOD Transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW, G = gain of antenna in linear scale; Pi = 3.1416, R = distance between observation point and center of the radiator in cm TEST RESULT Passed Not Applicable FCC ID: 2A8OE-F8926-GW-02 Radio Type Frequency range (MHz) Conducted Average Power (dBm)* Maximum Tune-up (dBm) Power Density (mW/cm2) Limit (mW/cm2) Result GSM850 (1 Tx Slot) 824.2-848.8 31.72 32.00 0.059 0.549 Pass PCS1900 (1 Tx Slot) 1850.2-1909.8 28.35 29.00 0.028 1.000 Pass WCDMA Band II 1852.4-1907.6 23.73 24.00 0.072 1.000 Pass WCDMA Band IV 1712.4-1752.6 23.64 24.00 0.072 1.000 Pass WCDMA Band V 826.4-846.6 23.78 24.00 0.074 0.551 Pass LTE Band 2 1850.7–1909.3 23.02 24.00 0.075 1.000 Pass LTE Band 4 1710.7–1754.3 22.41 23.00 0.059 1.000 Pass LTE Band 5 824.7 –848.3 22.90 23.00 0.059 0.550 Pass LTE Band 7 2502.5–2567.5 22.89 23.00 0.059 1.000 Pass LTE Band 12 699.7–715.3 22.91 23.00 0.059 0.446 Pass LTE Band 17 706.5–713.5 23.35 24.00 0.075 0.471 Pass LTE Band 38 2572.5–2617.5 22.01 23.00 0.059 1.000 Pass LTE Band 66 1710.7–1779.3 22.95 23.00 0.059 1.000 Pass Radio Type Frequency range (MHz) Conducted Average Power (dBm) Maximum Tune-up (dBm) Power Density (mW/cm2) Limit (mW/cm2) Result LORA 903-914.2 11.10 12.00 0.005 0.602 Pass WIFI 2412-2462 16.32 17.00 0.019 1.000 Pass Note: 1) The maximum antenna gain, LORA: 1.78dBi WIFI: 2.9dBi GSM850: 1.73dBi PCS1900: 1.57dBi WCDMA Band II: 1.57dBi WCDMA Band IV: 1.57dBi WCDMA Band V: 1.73dBi LTE Band 2: 1.74dBi LTE Band 4: 1.74dBi LTE Band 5: 1.74dBi LTE Band 7: 1.74dBi LTE Band 12: 1.74dBi LTE Band 17: 1.74dBi LTE Band 38: 1.74dBi LTE Band 66: 1.74dBi 2) The exposure evaluation safety distance is 20cm. 3) *refer to module which FCC ID is ZMONL668LA05. FCC ID: 2A8OE-F8926-GW-02 Consider the LORA, WIFI and GSM850 can transmitting simultaneously, the total transmitting MPE rate as below formula: MPE rate=Power density of LORA/limit + Power density of WIFI/limit + Power density of GSM850/limit <1 The worst case is BT-EDR and 2.4G WIFI transmitting simultaneously, the result as below: Evaluation mode Power density/limit Sum of the MPE rate limit LORA 0.008 0.134 1 WIFI 0.019 GSM850(1 Tx Slot) 0.107

Page: 1 of 37 TEST REPORT For WiFi-2.4GHz Band Report No. ...................................... : CHTEW23110071 Report Verification: Project No.................................： SHT2306080101EW FCC ID ............................................. : 2A8OE-F8926-GW-02 Applicant’s name ........................... : Xiamen Four-Faith Communication Technology Co., Ltd. Address ............................................. : 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China. Product Name ................................ : LoRaWAN Gateway Trade Mark ....................................... : Model No. ......................................... : F8926-GW-02 Listed Model(s) ................................. : - Standard ......................................... : FCC CFR Title 47 Part 15 Subpart C § 15.247 Date of receipt of test sample..........: Aug. 07, 2023 Date of testing.............................: Aug. 14, 2023- Nov. 24, 2023 Date of issue...............................: Nov. 27, 2023 Result .................. ........................: PASS Compiled by ( Position+Printed name+Signature): File administrator Caspar Chen Supervised by (Position+Printed name+Signature): Project Engineer Caspar Chen Approved by (Position+Printed name+Signature): RF Manager Xu yang Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW23110071 Page: 2 of 37 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) ` Contents 1. TEST S T AN D AR D S A N D R E P O R T V E R S I O N 3 1.1. Test Standards 3 1.2. Report version 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 5 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Test mode 7 4.3. Test sample information 8 4.4. Support unit used in test configuration and system 8 4.5. Testing environmental condition 8 4.6. Statement of the measurement uncertainty 9 4.7. Equipment Used during the Test 10 5. TEST CONDITIONS AND RESULTS 12 5.1. Antenna Requirement 12 5.2. AC Conducted Emission 13 5.3. Peak Output Power 15 5.4. Power Spectral Density 16 5.5. 6dB bandwidth 17 5.6. 99% Occupied Bandwidth 18 5.7. Duty Cycle 19 5.8. Conducted Band edge and Spurious Emission 20 5.9. Radiated Band edge Emission 22 5.10. Radiated Spurious Emission 27 6. TEST SETUP PHOTOS 35 7. EXTERNAL AND INTERNAL PHOTOS 37 8. APPENDIX REPORT 37 Report No.: CHTEW23110071 Page: 3 of 37 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) ` 1. TEST STAND ARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: ‒ FCC CFR Title 47 Part 15 Subpart C § 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz ‒ ANSI C63.10:2020: American National Standard for Testing Unlicensed Wireless Devices ‒ KDB 558074 D01 15.247 Meas Guidance v05r02: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating under Section 15.247 of The FCC Rules 1.2. Report version Revision No. Date of issue Description N/A 2023-11-27 Original Report No.: CHTEW23110071 Page: 4 of 37 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) ` 2. TEST DESCRIPTION Report clause Test Items Standard Requirement Result Test Engineer 5.1 Antenna Requirement 15.203/15.247(c) PASS Caspar Chen 5.2 AC Conducted Emission 15.207 PASS Caspar Chen 5.3 Peak Output Power 15.247(b)(3) PASS Caspar Chen 5.4 Power Spectral Density 15.247(e) PASS Caspar Chen 5.5 6dB Bandwidth 15.247(a)(2) PASS Caspar Chen 5.6 99% Occupied Bandwidth - PASS *1 Caspar Chen 5.7 Duty cycle - PASS *1 Caspar Chen 5.8 Conducted Band Edge and Spurious Emission 15.247(d)/15.205 PASS Caspar Chen 5.9 Radiated Band Edge Emission 15.205/15.209 PASS Yifan Wang 5.10 Radiated Spurious Emission 15.247(d)/15.205/15.209 PASS Yifan Wang Note: ‒ The measurement uncertainty is not included in the test result. ‒ *1: No requirement on standard, only report these test data. Report No.: CHTEW23110071 Page: 5 of 37 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) ` 3. SUMMARY 3.1. Client Information Applicant: Xiamen Four-Faith Communication Technology Co., Ltd. Address: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China. Manufacturer: Xiamen Four-Faith Communication Technology Co., Ltd. Address: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China. 3.2. Product Description Main unit information: Product Name: LoRaWAN Gateway Trade Mark: Model No.: F8926-GW-02 Listed Model(s): - Power supply: DC 12V from Adapter Hardware version: V 1.0.0.2 Software version: F8926GW-V2-IOTGW-32M-STD-VPN-20230313.flash Accessory unit information: Adapter information: MODEL: KL-AD3060VA INPUT: 100-240V~50/60Hz 0.7A OUTPUT: DC 12V, 1.5A 3.3. Radio Specification Description Support type: 802.11b 802.11g 802.11n Support bandwidth: 20MHz 40MHz Modulation: 802.11b: DBPSK,…

Text truncated - open the document above for the full version.

Page: 1 of 36 TEST REPORT For LORA Report No. ...................................... : CHTEW23110070 Report Verification: Project No.................................： SHT2306080101EW FCC ID ............................................. : 2A8OE-F8926-GW-02 Applicant’s name ........................... : Xiamen Four-Faith Communication Technology Co., Ltd. Address ............................................. : 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China. Product Name ................................ : LoRaWAN Gateway Trade Mark ....................................... : Model No. ......................................... : F8926-GW-02 Listed Model(s) ................................. : - Standard ......................................... : FCC CFR Title 47 Part 15 Subpart C § 15.247 Date of receipt of test sample..........: Aug. 07, 2023 Date of testing.............................: Aug. 14, 2023- Nov. 24, 2023 Date of issue...............................: Nov. 27, 2023 Result .................. ........................: PASS Compiled by ( Position+Printed name+Signature): File administrator Caspar Chen Supervised by (Position+Printed name+Signature): Project Engineer Caspar Chen Approved by (Position+Printed name+Signature): RF Manager Xu yang Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW23110070 Page: 2 of 36 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) Contents 1. TEST S T AN D AR D S A N D R E P O R T V E R S I O N 3 1.1. Test Standards 3 1.2. Report version 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 5 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Descriptions of Test mode 7 4.3. Support unit used in test configuration and system 7 4.4. Testing environmental condition 7 4.5. Statement of the measurement uncertainty 8 4.6. Equipment Used during the Test 9 5. TEST CONDITIONS AND RESULTS 11 5.1. Antenna Requirement 11 5.2. AC Conducted Emission 12 5.3. Peak Output Power 14 5.4. Power Spectral Density 15 5.5. 6dB bandwidth 16 5.6. 99% Occupied Bandwidth 17 5.7. Duty Cycle 18 5.8. Conducted Band edge and Spurious Emission 19 5.9. Radiated Band edge Emission 21 5.10. Radiated Spurious Emission 23 6. TEST SETUP PHOTOS 28 7. EXTERNAL AND INTERNAL PHOTOS 30 7.1. External Photos 30 7.2. Internal Photos 32 8. APPENDIX REPORT 36 Report No.: CHTEW23110070 Page: 3 of 36 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 1. TEST STAND ARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: ‒ FCC CFR Title 47 Part 15 Subpart C § 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz ‒ ANSI C63.10:2020: American National Standard for Testing Unlicensed Wireless Devices ‒ KDB 558074 D01 15.247 Meas Guidance v05r02: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating under Section 15.247 of The FCC Rules 1.2. Report version Revision No. Date of issue Description N/A 2023-11-27 Original Report No.: CHTEW23110070 Page: 4 of 36 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 2. TEST DESCRIPTION Report clause Test Items Standard Requirement Result Test Engineer 5.1 Antenna Requirement 15.203/15.247(c) PASS Caspar Chen 5.2 AC Conducted Emission 15.207 PASS Caspar Chen 5.3 Peak Output Power 15.247(b)(3) PASS Caspar Chen 5.4 Power Spectral Density 15.247(e) PASS Caspar Chen 5.5 6dB Bandwidth 15.247(a)(2) PASS Caspar Chen 5.6 99% Occupied Bandwidth - PASS *1 Caspar Chen 5.7 Duty cycle - PASS *1 Caspar Chen 5.8 Conducted Band Edge and Spurious Emission 15.247(d)/15.205 PASS Caspar Chen 5.9 Radiated Band Edge Emission 15.205/15.209 PASS Yifan Wang 5.10 Radiated Spurious Emission 15.247(d)/15.205/15.209 PASS Yifan Wang Note: ‒ The measurement uncertainty is not included in the test result. ‒ *1: No requirement on standard, only report these test data. Report No.: CHTEW23110070 Page: 5 of 36 Date of issue: 2023-11-27 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V06(2023-09) 3. SUMMARY 3.1. Client Information Applicant: Xiamen Four-Faith Communication Technology Co., Ltd. Address: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China. Manufacturer: Xiamen Four-Faith Communication Technology Co., Ltd. Address: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China. 3.2. Product Description Main unit information: Product Name: LoRaWAN Gateway Trade Mark: Model No.: F8926-GW-02 Listed Model(s): - Power supply: DC 12V from Adapter Hardware version: V 1.0.0.2 Software version: F8926GW-V2-IOTGW-32M-STD-VPN-20230313.flash Accessory unit information: Adapter information: MODEL: KL-AD3060VA INPUT: 100-240V~50/60Hz 0.7A OUTPUT: DC 12V, 1.5A 3.3. Radio Specification Description Support function *2 : LORA Modulation: LORA Operation frequency: 903MHz~914.2MHz Cha…

Text truncated - open the document above for the full version.

ProductSpecification P/N: 81800VXX5 Rev.: X1 Page: 1 / 7 记录管制编号：FM-QE-E-02-00 1.Antenna Specification/天线标准 Antenna Specification/天线技术参数 Electrical Specification/电气特性 Item/目录 Specification/规格 Comment/备 注 Freq. Range/频段范围 901-915MHz Impedance/阻抗 50 (Ω) VSWR/驻波比 <2.5 Directional/辐射方向 Omni directional/全向天线 Polarization/极化形式 Vertical Polarization/垂直极化 Peak Gain/峰值增益 1.78dBi Test condition/测试条件 passive test（无源测试） Total Efficiency/无源效率 40% Mechanical Specification/机械指标 Antenna type/天线类型 外置天线 Connector Type/连接器类型 RPSMA-J RF Cable Type/射频线型号 RG178 Connector Torque Test/连接器扭力 N/A Connector Pull Test/连接器拉力 ≥3.0Kgf Salt Spray/盐雾测试 24 (H) EnvironmentalSpecification /环境指标 Operating temp/工作温度 -40°C～+75°C Storage temp/存储温度 -40°C～+75°C 电连技术股份有限公司 广东省深圳市光明区公明街道西田路锦绣工业园 ProductSpecification P/N: 81800VXX5 Rev.: X1 Page: 2 / 7 记录管制编号：FM-QE-E- 02-00 2.Antenna Picture/天线图片 3.DWG/工程图纸 23 13 12 RPSMA-J ProductSpecification P/N: 81800VXX5 Rev.: X1 Page: 4 / 7 记录管制编号：FM-QE-E- 02-00 4.Antenna test result/测试结果 4.1Return loss/Smith chart/VSWR/回波损耗/史密斯图/驻波比 ProductSpecification P/N: 81800VXX5 Rev.: X1 Page: 5 / 7 记录管制编号：FM-QE-E- 02-00 4.2The gain and total efficiency test/增益和效率测试 4.2.1 The definition of coordinate system/坐标系定义-Satimo SG24 The coordinate system of Chamber/暗室坐标系 The production test position/天线测试放置位置 ProductSpecification P/N: 81800VXX5 Rev.: X1 Page: 6 / 7 记录管制编号：FM-QE-E- 02-00 4.2.2 The test result of total efficiency and total gain/天线效率及增益测试结果 901MHz-931MHz Frequency Efficiency (%) Gain(dBi) 901MHz 42% 1.68 903MHz 41% 1.57 905MHz 41% 1.59 907MHz 42% 1.68 909MHz 43% 1.78 911MHz 43% 1.71 913MHz 41% 1.46 915MHz 40% 1.30 917MHz 41% 1.40 919MHz 43% 1.59 921MHz 43% 1.49 923MHz 40% 1.15 925MHz 39% 0.95 927MHz 40% 1.08 929MHz 42% 1.25 931MHz 42% 1.20 ProductSpecification P/N: 81800VXX5 Rev.: X1 Page: 7 / 7 记录管制编号：FM-QE-E- 02-00 4.2.3The antenna radiation pattern(2D)/天线辐射方向图（2D） 901MHz -931MHz XOY YOZ XOZ 4.2.4The antenna radiation pattern(3D)/天线辐射方向图（3D） Frequency/频点915MHz XOY YOZXOZ
