2A9IW-HT007EWireless cast

Label Location:

Sym bolsLWTA Dimensions 1.600.200.800.200.800.200.300.10 Num ber TerminalName INPU T NC Dimensions (Unit: mm) w ( Sid e View ) ( Bo ttom View ) ( To p View ) A Features 1. Surface Mounted Devices with a small dimension of 1.6 x 0.8 x 0.8 mm meet future miniaturization trend. 2. Embedded and LTCC (low temperature co-fired ceramic) technology is able to integrate with system design as well as beatifying the housing of final product. 3. High stability and low tolerance. Applications 1. Bluetooth 2. Wireless LAN 3. ISM band 2.4GHz wireless applications P/N :HY160808 SRF08 T L Hanyan g Antenna Co. Ltd. has possession of proprietary information provided in this report and this proprietary information shall be kept in strict confidence and not disclosed to any person or firm without the prior written consent of Hanyang Antenna Co. Ltd. Page 1 Hanyang Antenna Co. Ltd. Manufacturer: ShenZhen Hanyang Antenna Design Co., Ltd. Address: R&D Center No. 9, Taohuayuan Science and Technology Innovation Park, Tiegang Community, Xixiang Street, Bao'an District, Shenzhen Ev aluation Board and Matching Circuits Unit:mm P/ N:HY160808 SRF08 Hany ang Antenna Co. Ltd. has possession of proprietary information provided in this report and this proprietary information shall be kept in strict confidence and not disclosed to any person or firm without the prior written consent of Hanyang Antenna Co. Ltd. Page 2 Hanyan g Antenna Co. Ltd. Electrical Characteristics Characteristic Curves FeatureSpecification 1 Central frequency2.45GHz&5.5GHz 2 Bandwidth>100MHz 3 Peak gain>3dBi 4 VSWR<2 5 PolarizationLinear 6 Azimuth beamwidthOmnidirectional 7 Impedance50 P/ N:HY160808 SRF08 Hany ang Antenna Co. Ltd. has possession of proprietary information provided in this report and this proprietary information shall be kept in strict confidence and not disclosed to any person or firm without the prior written consent of Hanyang Antenna Co. Ltd. Page 3 Hanyan g Antenna Co. Ltd. Ra diation Pattern Y-Z Plane X-Z Plane P/ N:HY160808 SRF08 co ordinates Hany ang Antenna Co. Ltd. has possession of proprietary information provided in this report and this proprietary information shall be kept in strict confidence and not disclosed to any person or firm without the prior written consent of Hanyang Antenna Co. Ltd. Page 4 Hanyan g Antenna Co. Ltd. 3D Radiation Pattern Hanyang Antenna C o. Ltd. has possession of proprietary information provided in this report and this proprietary information shall be kept in strict confidence and not disclosed to any person or firm without the prior written consent of Hanyang Antenna Co. Ltd. Page 5 Hanyang Antenna C o. Ltd. P/N:HY160 808 SRF08 Te mperature 402Hum idity 90~95%R H Duration 500h Re covery conditions Room temperature Recovery Time 24h (Class1) or 48h (Class2) Test Temperature Operating Temperature Temperature Relative Humidity 25 3 -25~+8 5 5~40 20~70% No t enough solder Weak holding force may cause bad connection between the chip and PCB . Reco mmended Soldering amounts The opt imal solder fillet amounts for re-flow soldering The opt imal solder fillet amounts for wave soldering P/ N:HY160808 SRF08 Dependability Test Too much solder Cracks tend to occur due to large stress. Mo isture Proof Optimum SolderAmount for Reflow Soldering So lderability At least 95% of the terminal electrode is covered by new solder. Preheating conditions:80 to 10~30s. Solder Tem p e r at u r e :2 3 5 ±5 Du ration:2 ±0.5s , Solder Tempe r ature:24 5±5 Du rat ion:2±0.5s Hany ang Antenna Co. Ltd. has possession of proprietary information provided in this report and this proprietary information shall be kept in strict confidence and not disclosed to any person or firm without the prior written consent of Hanyang Antenna Co. Ltd. Page 6 Hanyan g Antenna Co. Ltd. 101S Applied Force: 5N Duration:101S Preheating conditions: up-category temperature, 1h Recovery time: 24 1h In itial Measurement Cy cling Times: 5 times, 1 cycle, 4 steps: Pr eheating80 to 120 ; 10~30s.SolderTempera ture:235 5Du ration:2 0. 5s SolderTempera ture:245 5Du ration:2 0. 5s Pr eheating100to200 ;1 0 2m in. Solder Temperature:265 5Dur ation: 10 1s Clean the capacitor with solvent and examine it with a 10X(min.) microscope. Recovery Time: 24 2h Re covery condition: Room temperature Te st Board: Al 2 O 3 or PCB Warp: 1mm Speed: 0.5mm/sec. Unit: mm The measurement should be made with the board in the bending position. P/ N:HY160808 SRF08 Re sistance to Soldering Heat Resistance to Flexure of Substrate Temperature Cycle Test Hany ang Antenna Co. Ltd. has possession of proprietary information provided in this report and this proprietary information shall be kept in strict confidence and not disclosed to any person or firm without the prior written consent of Hanyang Antenna Co. Ltd. Page 7 Hanyan g Antenna Co. Ltd. Whilein preheating,please keep the temperature difference between soldering temperature and surface temperature of chips as:150. Hany ang Antenna Co. Ltd. has possession of proprietary information provided in this report and this proprietary information shall be kept in strict confidence and not disclosed to any person or firm without the prior written consent of Hanyang Antenna Co. Ltd. Page 8 Hanyan g Antenna Co. Ltd. P/ N:HY160808 SRF08 Dimension s of paper taping λ» ́ìððð °½­ñλ» ́ ͬ±®¿¹» л®·±¼ The g uaranteed period for solderability is 6 months (Under deliver package condition). Temperature:5~40 /Relativ e Humidity:20~70% Hanyang An tenna Co. Ltd. has possession of proprietary information provided in this report and this proprietary information shall be kept in strict confidence and not disclosed to any person or firm without the prior written consent of Hanyang Antenna Co. Ltd. Page 9 Unitmm Hanyang Ant enna Co. Ltd. P/N:H Y160808 SRF08 Hanyang Antenna Co. Ltd. P/N:HY160808 SRF08 Hanyang Antenna Co. Ltd. has possession of proprietary information provided in this report and this proprietary information shall be kept in strict confidence and no…

Text truncated - open the document above for the full version.

Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E03 TRF No.: RT-4-E-02-001 RF test report Ver. 1.0 Page 1 of 8 RF EXPOSURE REPORT Applicant : Hisense Commercial Display Co.,Ltd. Address of Applicant : No. 218, Qianwangang Road, Huangdao District, Qingdao, Shandong, P.R. China Manufacturer : Hisense Commercial Display Co.,Ltd. Address of Manufacturer : No. 218, Qianwangang Road, Huangdao District, Qingdao, Shandong, P.R. China Equipment under Test : Wireless cast Model No. : HT007E, HT008E, HT009E FCC ID : 2A9IW-HT007E Test Standard(s) : KDB447498 D01 General RF Exposure Guidance v06 Report No. : DDT-RE24071734-1E03 Issue Date : 2024/08/09 Issue By : Guangdong Dongdian Testing Service Co., Ltd. Unit 2, Building 1, No. 17, Zongbu 2nd Road, Songshan Lake Park, Dongguan, Guangdong, China, 523808 Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E03 TRF No.: RT-4-E-02-001 RF test report Ver. 1.0 Page 2 of 8 Table of Contents 1. General Test Information .............................................................................................. 5 1.1. Description of EUT ........................................................................................................ 5 1.2. Accessories of EUT ...................................................................................................... 5 1.3. Test laboratory .............................................................................................................. 5 2. RF Exposure evaluation for FCC.................................................................................. 6 2.1. Assessment procedure ................................................................................................. 6 2.2. Assess result ................................................................................................................. 7 3. Photos of the EUT ........................................................................................................ 8 Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E03 Page 3 of 8 Test Report Declare Applicant : Hisense Commercial Display Co.,Ltd. Address of Applicant : No. 218, Qianwangang Road, Huangdao District, Qingdao, Shandong, P.R. China Equipment under Test : Wireless cast Model No. : HT007E, HT008E, HT009E Manufacturer : Hisense Commercial Display Co.,Ltd. Address of Manufacturer : No. 218, Qianwangang Road, Huangdao District, Qingdao, Shandong, P.R. China Test Standard Used: KDB447498 D01 General RF Exposure Guidance v06 We Declare: The equipment described above is tested by Guangdong Dongdian Testing Service Co., Ltd. and in the configuration tested the equipment complied with the standards specified above. The test results are contained in this test report and Guangdong Dongdian Testing Service Co., Ltd. is assumed of full responsibility for the accuracy and completeness of these tests. Report No.: DDT-RE24071734-1E03 Date of Receipt: 2024/07/23 Date of Test: 2024/07/23~2024/08/09 Prepared By: Approved By: _____________________ ______________________ Tiger Mo/Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Guangdong Dongdian Testing Service Co., Ltd. Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E03 Page 4 of 8 Revision History Rev. Revisions Issue Date Revised By --- Initial issue 2024/08/09 Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E03 Page 5 of 8 1. General Test Information 1.1. Description of EUT EUT Name : Wireless cast Model Number : HT007E, HT008E, HT009E Difference of model number : Above models are identical in schematic, appearance and structure, only the Model Number is different for all the models, therefore the test performed on the model HT007E. EUT Function Description : Please reference user manual of this device Power Supply : DC 5V From Type-C Port Note: This EUT support 2.4 GHz WLAN, 5 GHz WLAN. Note: The above EUT information is declared by manufacturer and for more detailed features description please refer to the manufacturer's specifications or User's Manual. The above Antenna information is declared by manufacturer and for more detailed features description please refer to the manufacturer's specifications, the laboratory shall not be held responsible. “☒” means to be chosen or applicable; “☐” means don’t to be chosen or not applicable; This note applies to entire report. 1.2. Accessories of EUT Accessories Manufacturer Model number Description / / / / 1.3. Test laboratory Guangdong Dongdian Testing Service Co., Ltd. Add.: Unit 2, Building 1, No. 17, Zongbu 2nd Road, Songshan Lake Park, Dongguan, Guangdong, China, 523808. Tel.: +86-0769-38826678, http://www.dgddt.com, Email: [email protected]. CNAS Accreditation No. L6451; A2LA Accreditation Number: 3870.01 FCC Designation Number: CN1182, Test Firm Registration Number: 540522 Innovation, Science and Economic Development Canada Site Registration Number: 10288A Conformity Assessment Body identifier: CN0048 VCCI facility registration number: C-20087, T-20088, R-20123, R-20155, G-20118 Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E03 Page 6 of 8 2. RF Exposure evaluation for FCC 2.1. Assessment procedure Requirement: Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. Limits for General Population/Uncontrolled Exposure Frequency Range （MHz） Electric Field Strength (E) (V/m) Magnetic FieldStrength (H) （A/m） Power Density (S) （mW/cm 2 ） Aver…

Text truncated - open the document above for the full version.

Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E01 TRF No.: RT-4-E-02-001 RF test report Ver. 1.0 Page 1 of 86 FCC AND ISED CERTIFICATION TEST REPORT Applicant : Hisense Commercial Display Co.,Ltd. Address of Applicant : No. 218, Qianwangang Road, Huangdao District, Qingdao, Shandong, P.R. China Manufacturer : Hisense Commercial Display Co.,Ltd. Address of Manufacturer : No. 218, Qianwangang Road, Huangdao District, Qingdao, Shandong, P.R. China Equipment under Test : Wireless cast Model No. : HT007E, HT008E, HT009E FCC ID : 2A9IW-HT007E IC : 27082-HT007E Test Standard(s) : FCC Rules and Regulations Part 15 Subpart C, RSS-247 Issue 3 August 2023, ANSI C63.10:2013, RSS-Gen Issue 5, Apr. 2018, Amendment 2 (February 2021) Report No. : DDT-RE24071734-1E01 Issue Date : 2024/08/08 Issue By : Guangdong Dongdian Testing Service Co., Ltd. Unit 2, Building 1, No. 17, Zongbu 2nd Road, Songshan Lake Park, Dongguan, Guangdong, China, 523808 Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E01 TRF No.: RT-4-E-02-001 RF test report Ver. 1.0 Page 2 of 86 Table of Contents 1. Summary of Test Results ............................................................................................. 7 2. General Test Information .............................................................................................. 8 2.1. Description of EUT ........................................................................................................ 8 2.2. Accessories of EUT ...................................................................................................... 9 2.3. Block diagram of EUT configuration for test ................................................................. 9 2.4. Decision of final test mode ........................................................................................... 9 2.5. Deviations of test standard ........................................................................................... 9 2.6. Test environment conditions ....................................................................................... 10 2.7. Test laboratory ............................................................................................................ 10 2.8. Measurement uncertainty ........................................................................................... 11 3. Equipment Used During Conductive Test .................................................................. 12 4. 6dB Bandwidth ............................................................................................................ 13 4.1. Block diagram of test setup ........................................................................................ 13 4.2. Limits ........................................................................................................................... 13 4.3. Test procedure ............................................................................................................ 13 4.4. Test result ................................................................................................................... 13 4.5. Test graphs ................................................................................................................. 15 5. 99% Bandwidth ........................................................................................................... 18 5.1. Block diagram of test setup ........................................................................................ 18 5.2. Limits ........................................................................................................................... 18 5.3. Test procedure ............................................................................................................ 18 5.4. Test result ................................................................................................................... 19 5.5. Test graphs ................................................................................................................. 20 6. Conducted Output Power ........................................................................................... 23 6.1. Block diagram of test setup ........................................................................................ 23 6.2. Limits ........................................................................................................................... 23 6.3. Test procedure ............................................................................................................ 23 6.4. Test result average ..................................................................................................... 24 7. Power Spectral Density .............................................................................................. 25 7.1. Block diagram of test setup ........................................................................................ 25 7.2. Limits ........................................................................................................................... 25 7.3. Test procedure ............................................................................................................ 25 7.4. Test result ................................................................................................................... 26 7.5. Test graphs ................................................................................................................. 27 8. Band Edge Compliance (Conducted Method) ............................................................ 30 8.1. Block diagram of test setup ........................................................................................ 30 Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E01 TRF No.: RT-4-E-02-001 RF test report Ver. 1.0 Page 3 of 86 8.2. Limits ......................................................................................................…

Text truncated - open the document above for the full version.

Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E01 Page 51 of 86 12. Radiated Emission 12.1. Test equipment Equipment Manufacturer Model No. Serial No. Cal Due To High pass filter Micro-Tronics HPM50102 DDT-ZC00561 2025/04/22 PSA Series Spectrum Analyzer Agilent E4447A DDT-ZC00517 2025/03/31 RF cable Yuhu Technology JCTB810-NJ-NJ- 9M DDT-ZC02538 2025/03/31 EMI TEST RECEIVER R&S ESU26 DDT-ZC01909 2025/03/31 Active Loop Antenna Schwarzbeck FMZB1519 DDT-ZC00524 2025/09/11 RF Cable N/A W13.02 AP1-X2 DDT-ZC04023 2025/03/31 RF cable Zhongke Junchuang JCT26S-NJ-NJ- 1.5M DDT-ZC02762 2025/03/31 Micro-Tronics filters REBES BRM50702 DDT-ZC03242 / Hochgewinn- Hornantenne SCHWARZBEC K BBHA 9120 D DDT-ZC02129 2025/09/18 High pass filter Micro-Tronics HPM50108 DDT-ZC00560 2025/04/22 RF Cable N/A W24.02 HL-562 DDT-ZC04022 2025/03/31 Pre-amplifier COM-POWER PAM-840A DDT-ZC01693 2025/03/31 RF cable Yuhu Technology ZT26S-SMAJ- SMAJ-1M DDT-ZC02037 2025/03/31 Pre-amplifier COM-POWER PAM-118A DDT-ZC01293 2025/07/08 ELECTRIC AND MAGNETIC FIELD ANALYZER Narda EHP-200A DDT-ZC01401 2024/09/20 Broad-Band Horn Antenna Schwarzbeck BBHA 9170 DDT-ZC00506 2025/04/26 High Pass filter Xi'an Xingbo XBLBQ-GTA67 DDT-ZC02179 2025/04/22 Trilog Broadband Antenna Schwarzbeck VULB 9163 DDT-ZC02050 2025/07/11 Micro-Tronics filters REBES BRM50716 DDT-ZC03240 / Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E01 Page 52 of 86 12.2. Block diagram of test setup Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E01 Page 53 of 86 12.3. Limits (1) FCC 15.205 Restricted frequency band MHz MHz MHz GHz 0.090-0.110 16.42-16.423 399.9-410 4.5-5.15 1 0.495-0.505 16.69475-16.69525 608-614 5.35-5.46 2.1735-2.1905 16.80425-16.80475 960-1240 7.25-7.75 4.125-4.128 25.5-25.67 1300-1427 8.025-8.5 4.1772&4.17775 37.5-38.25 1435-1626.5 9.0-9.2 4.2072&4.20775 73-74.6 1645.5-1646.5 9.3-9.5 6.215-6.218 74.8-75.2 1660-1710 10.6-12.7 6.26775-6.26825 108-121.94 1718.8-1722.2 13.25-13.4 6.31175-6.31225 123-138 2200-2300 14.47-14.5 8.291-8.294 149.9-150.05 2310-2390 15.35-16.2 8.362-8.366 156.52475-156.52525 2483.5-2500 17.7-21.4 8.37625-8.38675 156.7-156.9 2690-2900 22.01-23.12 8.41425-8.41475 162.0125-167.17 3260-3267 23.6-24.0 12.29-12.293 167.72-173.2 3332-3339 31.2-31.8 12.51975-12.52025 240-285 3345.8-3358 36.43-36.5 12.57675-12.57725 322-335.4 3600-4400 ( 2 ) 13.36-13.41 1Until February 1, 1999, this restricted band shall be 0.490-0.510 MHz 2Above 38.6 RSS-Gen section 8.10 Restricted frequency bands* Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E01 Page 54 of 86 MHz MHz MHz GHz 0.090-0.110 12.51975-12.52025 240-285 3.5-4.4 0.495-0.505 12.57675-12.57725 322-335.4 4.5-5.15 2.1735-2.1905 13.36-13.41 399.9-410 5.35-5.46 3.020-3.026 16.42-16.423 608-614 7.25-7.75 4.125-4.128 16.69475-16.69525 960-1427 8.025-8.5 4.1772&4.17775 16.80425-16.80475 1435-1626.5 9.0-9.2 4.2072&4.20775 25.5-25.67 1645.5-1646.5 9.3-9.5 5.677-5.683 37.5-38.25 1660-1710 10.6-12.7 6.215-6.218 73-74.6 1718.8-1722.2 13.25-13.4 6.26775-6.26825 74.8-75.2 2200-2300 14.47-14.5 6.31175-6.31225 108-138 2310-2390 15.35-16.2 8.291-8.294 149.9-150.05 2483.5-2500 17.7-21.4 8.362-8.366 156.52475-156.52525 2655-2900 22.01-23.12 8.37625-8.38675 156.7-156.9 3260-3267 23.6-24.0 8.41425-8.41475 162.0125-167.17 3332-3339 31.2-31.8 12.29-12.293 167.72-173.2 3345.8-3358 36.43-36.5 Above 38.6 * Certain frequency bands listed in table and in bands above 38.6 GHz are designated for licence- exempt applications. These frequency bands and the requirements that apply to related devices are set out in the 200 and 300 series of RSSs. (2) FCC 15.209 Limit & RSS-Gen section 8.9 Limit FREQUENCY MHz DISTANCE Meters FIELD STRENGTHS LIMIT mV/m dB(mV)/m 0.009 ~ 0.490 300 2400/F(kHz) 67.6-20log(F) 0.490 ~ 1.705 30 24000/F(kHz) 87.6-20log(F) 1.705 ~ 30.0 30 30 29.54 30 ~ 88 3 100 40.0 88 ~ 216 3 150 43.5 216 ~ 960 3 200 46.0 960 ~ 1000 3 500 54.0 Above 1000 3 74.0 dB(mV)/m (Peak) 54.0 dB(mV)/m (Average) Note: (1) The emission limits shown in the above table are based on measurements employing a CISPR QP detector except for the frequency bands 9 - 90 kHz, 110 - 490 kHz and above 1000 MHz, radiated emissions limits in these three bands are based on measurements employing an average detector. (2) At frequencies below 30 MHz, measurement may be performed at a distance closer than that specified, and the limit at closer measurement distance can be extrapolated by below formula: Guangdong Dongdian Testing Service Co., Ltd. Report No.:DDT-RE24071734-1E01 Page 55 of 86 Limit 3m (dBuV/m)= Limit 30m (dBuV/m) + 40Log(30m/3m) (3) Limit for this EUT The emissions appearing within 15.205 restricted frequency bands shall not exceed the limits shown in 15.209, and the emissions appearing within RSS-Gen section 8.10 Restricted frequency bands shall not exceed the limits shown in RSS-Gen section 8.9, all the other emissions shall be at least 20 dB below the fundamental emissions or comply with 15.209 limits and RSS-Gen section 8.9 limits. 12.4. Assistant equipment used for test Assistant equipment Manufacturer Model number Description other / / / / / 12.5. Test procedure (1) EUT was placed on a non-metallic table, 80 cm above the ground plane inside a semi-anechoic chamber for below 1G and 150 cm above the ground plane inside a fully-anechoic chamber for above 1G. (2) Test antenna was located 3 m from the EUT on an adjustable mast, and the antenna used as below table. Test frequency range Test antenna used Test antenna distance 9 kHz - 30 MHz Active Loop antenna 3 m 30 MHz - 1 GHz Trilog Broadband Antenna 3 m 1 GHz - 18 GHz Double Ridged Horn Antenna(1 GHz-18 GHz) 3 m 18 GHz - 40 GHz Horn Antenna(18 GHz-40 GHz) 1 m According ANSI C63.10:2013 clause 6.4.6 and 6.5.3, for measurements below 30 MHz, Antenna was located 3 m from EUT, the loop antenna was positioned in three antenna orientations (parallel, perpendicular, and round-parallel), for each…
