2AA7XKBJ-151NBT SPORTS BEHIND NECK HEADPHONE

User's Manual KBJ-151N Stereo Headset 立体声蓝牙耳机 使用说明书 Bluetooth 4.0 USB charging port Switch on: Press 3 seconds to switch on, the blue indicator will be in(voice prompts in English. Press 2.5 seconds, it enters into pairing mode, the red and blue indicators take turns to flash.(voice prompts in English; power will switch off automatically after 5 minutes no devices to connect . In music mode, press it 1 time to pause, and press it again to play. (when phone call comes, the music will be off. When phone call is off, the music will continue. Short press “volume increase”key for 1 time to increase volume with one point, long press to increase volume all the time. The voice prompts will appear when the volume up to the maximum. Short press “volume Decrease”key for 1 time to decrease volume with one point, long press to decrease volume all the time (the “Du ,Du ” warning sound will appear when the volume up to the minimum). 10:30 90% KBJ-151N 蓝牙 现为可被发现状态 设备 已连接 ON/OFF 蓝牙通用 02010304 Thank you for selecting our latest Bluetooth headset, please read this User's Manual carefully before you operate this headset, and please save this Manual for further reference. Before operating, please read all the Safety notice to make sure the safe and appropriate use. Safety Notice: Please observe the rules of the Country or Region which you are in while driving. Do not disassemble or modify the headset at any reason, otherwise, It may damage or burn the headset. If there is any quality problem, please send the headset to authorized service center for repairing. Please keep the equipment along with all the accessories out of the reach of children and pets. It will cause suffocation and serious injury. Do not put the device under the environment which the temperature is too low or too high ( Below 0°C or over 45°C). Extreme temperatures will cause the device deformation, reduce the charging capacity and shorten the working life. Please do not wet the device, for the liquid can cause serious damage to the device. Please do not touch the device by wet hands. It is out of the maintenance range for the damage caused by water. Please avoid closing to the eyes of children and pets when using the flash indicator of the device. Please do not operate the device in thunderstorm weather. It will damage your hearing if you listen with high volume for a long time. It is recommended that only use the lowest volume which is necessary for speaking and listening to music. 1. Guide ■ Headset introduction ※ Contents: Bluetooth Headset, USB Charging Cable, User's Manual USB Charging Cable: 2.Instruction ■ Key Function Power switch Previous song Next Song Volume Increase Volume Decrease Play Pause ■ How to connect with two Bluetooth mobile phones: 3. Battery power of bluetooth headset displayed on Iphone After connected with Iphone, the battery power of the headset will be displayed on the phone. Press “function key” to receive phone call, press it again to end the phone call. Press the key by twice continuously to re-dial the last phone number. Press the key for 2 seconds to reject the phone call. In the Music Mode, press it to play previous song. In the Music Mode, press it to play next song. 90% Headband Silicone Sheath Silicone ear buds Ear arm (horn base) LED indicator Microphone Automatic reset volume switch Automatically reset previous song Next song switch Music play/pause 8 10 11 9 6 10 11 8 7 9 3 2 4 5 1 Power switch/Pairing Receive/Hang up phone call Re-dial the last phone No Receive Hang up phone call Switch off: Press 3 seconds to switch off, the red indicator flashes one time mean the device is switched off (voice prompts in English 1) Turn on the bluetooth function of mobile phone 1. 2) Press " " of bluetooth headset for 4~5 seconds, bluetooth switch on and enters into pairing mode, the red and blue indicators take turns to flash, make connection with phone 1 (English voice prompts) 3) Press " " for 3 seconds to switch off the headset(voice prompts), and phone 1 is disconnected, meanwhile turn off the bluetooth function of phone 1. 4) Return on the bluetooth headset, and make it enter into pairing mode, blue and red indicator take turns to flash (voice prompts) 5) Turn on the bluetooth function of phone 2, and search the device KBJ-151N from the device list, and make connection 6) Turn off the headset bluetooth, and turn on again. And turn on the bluetooth function of both phones.The headset will make connection with two mobile phones automatically www.compoka.com 立体声蓝牙耳机 Bluetooth 4.0 Stereo Headset 06070805 7.Project Specification and Instruction - Bluetooth Version : V4.0 - Supported devices: Bluetooth mobile phones, Bluetooth speakers Bluetooth PC and other Bluetooth devices - Maximum work range: 33 Feet (10 Meters) - Standby time: 80 Hours - Music play/Talk time: 3 Hours - Charging time: 2 Hours - Charging Voltage: DC 5V - Work Voltage: 3.7V - Sensitivity: 105±3dB - Frequency Response: 20Hz~20KHz The actual time may vary from mobile phone types and functions. Use both hands to pick to wear the headset: 4.Bluetooth Indicator Status Red indicator is on all the time when charging; Blue indicator is on instead when charged full Charging Work Status Indicator Light StatusRemark Switch on Blue indicator flash 2 times Switch off Red indicator flash 1 time Connection Phone call Play Music Battery low warning 5.Headset Charging 6.Wearing Style Pairing Mode Red and blue indicators take turns to flash Voice Prompts Voice Prompts Voice Prompts Voice Prompts Voice Prompts (1) Put the headset on your head, rotate to the back of your head (see Pic 1) (2) Put the earhook on both of your ears (see Pic 2) (3) Put the speaker into ears and adjust to the comfortable position (see Pic 3). After wearing well, the headset backside should be "suspended" above the neck. According to personal comfort demand, can adjust the headset up or down appropriately Pic 1Pic 2Pic 3 If the speaker shut down without battery during the phone, when call…

Text truncated - open the document above for the full version.

November 14, 2014 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AA7XKBJ-151N ____ Product Name:_ BT SPORTS BEHIND NECK HEADPHONE _ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this November 14, 2014 Agency agreement expiration date: Usually Give 8 - 12 Months By: Ting He Signature Printed Title: Manager On behalf of : (Company Name) Shenzhen Compoka Electronic Technology Co., Ltd Telephone: 86-755-28089215

November 14, 2014 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Certification Technology Service Co.,Ltd, Address: 3F, Bldg.27, Area A, Tanglang Industrial Zone, Xili Town, Nanshan District, Shenzhen 518055, Guangdong, P.R. China Person: Mark Zhu (Name and address，person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Shenzhen Compoka Electronic Technology Co., Ltd . Address: 4F, Building B, Yishida Industrial Park, Xintang Village, Guanlan Town, Shenzhen China ( applicant name and address). Signature: Name Ting He Position Manager Company Name Shenzhen Compoka Electronic Technology Co., Ltd Address 4F, Building B, Yishida Industrial Park, Xintang Village, Guanlan Town, Shenzhen China Tel 86-755-28089215 Fax 86-755-28089215 Email [email protected]

Label 40mm 25mm Label Here FCC ID: 2AA7XKBJ-151N Shenzhen Compoka Electronic Technology Co., Ltd Model name: BT SPORTS BEHIND NECK HEADPHONE Model No.: KBJ-151N

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2402MHz 2.57dBm(1.81mW) output power] (1.81mW /5mm) ·[√2.402(GHz)]= 0.56 <3.0 for 1-g SAR Then SAR evaluation is not required

Shenzhen Certification Technology Service Co., Ltd. 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2 nd Road, Bao'an District, Shenzhen 518126, P.R. China FCC ID: 2AA7XKBJ-151N Page 1 of 86 TEST REPORT FCC ID: 2AA7XKBJ-151N Applicant : Shenzhen Compoka Electronic Technology Co., Ltd Address : 4F, Building B, Yishida Industrial Park, Xintang Village, Guanlan Town, Shenzhen China Equipment Under Test (EUT): Name : BT SPORTS BEHIND NECK HEADPHONE Model : KBJ-151N In Accordance with: FCC PART 15, SUBPART C : 2013 (Section 15.247) Report No : CST-TCB141105061 Date of Test : November 5, 2014- November 10, 2014 Date of Issue : November 11, 2014 Test Result: PASS In the configuration tested, the EUT complied with the standards specified above Authorized Signature ___________________________ (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. Report No.: CST-TCB141105061 FCC ID: 2AA7XKBJ-151N Page 2 of 86 Contents 1. General Information ............................................................................................................... 4 1.1. Description of Device (EUT) ............................................................................ 4 1.2. Accessories of device (EUT) ............................................................................ 5 1.3. Test Lab information ........................................................................................ 5 2. Summary of test ...................................................................................................................... 6 2.1. Summary of test result ...................................................................................... 6 2.2. Assistant equipment used for test ..................................................................... 6 2.3. Block Diagram ................................................................................................. 7 2.4. Test mode ......................................................................................................... 7 2.5. Test Conditions ................................................................................................ 8 2.6. Measurement Uncertainty (95% confidence levels, k=2) .................................. 8 2.7. Test Equipment ................................................................................................ 9 3. Maximum Peak Output power ............................................................................................ 10 3.1. Limit .............................................................................................................. 10 3.2. Test Procedure ................................................................................................ 10 3.3. Test Setup ...................................................................................................... 10 3.4. Test Result ..................................................................................................... 10 4. Bandwidth ............................................................................................................................. 11 4.1. Limit .............................................................................................................. 11 4.2. Test Procedure ................................................................................................ 11 4.3. Test Result ..................................................................................................... 11 5. Carrier Frequency Separation ............................................................................................ 17 5.1. Limit .............................................................................................................. 17 5.2. Test Procedure ................................................................................................ 17 5.3. Test Result ..................................................................................................... 17 6. Number Of Hopping Channel ............................................................................................. 20 6.1. Limit .............................................................................................................. 20 6.2. Test Procedure ................................................................................................ 20 6.3. Test Result ..................................................................................................... 20 7. Dwell Time ............................................................................................................................. 23 7.1. Test limit ........................................................................................................ 23 7.2. Test Procedure ............................................................................................... 23 7.3. Test Results .................................................................................................... 23 8. Radiated emissions ................................................................................................................ 29 8.1. Limit .............................................................................................................. 29 8.2. Block Diagram of Test setup .......................................................................... 30 8.3. Test Procedure ..........…

Text truncated - open the document above for the full version.

Conducted Emission Photos of Radiated emission
