2AA9B-SCS-001SCS-001

u-blox AG

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: May 17, 2015
Application Purpose: Original Equipment
Date of Application: May 17, 2015
Equipment Note: SCS-001
Frequency Range: 2402.00000000 - 2480.00000000
Company: u-blox AG
Country: Switzerland

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Rigado SCS-001 USER GUIDE Project / Subproject: SCS-001 Reference Number / Version: 0.2 Issue Date: 4/21/2015 Document File Name: SCS-001_User_Guide.docx Page: 1 of 11 SCS-001 User Guide Ve r s i o n 0.2 4/21/2015 Rigado SCS-001 USER GUIDE Project / Subproject: SCS-001 Reference Number / Version: 0.2 Issue Date: 4/21/2015 Document File Name: SCS-001_User_Guide.docx Page: 2 of 11 Revision History Rev Author Comments 0.1 TRE Initial Revision 0.2 TRE Add application development information Rigado SCS-001 USER GUIDE Project / Subproject: SCS-001 Reference Number / Version: 0.2 Issue Date: 4/21/2015 Document File Name: SCS-001_User_Guide.docx Page: 3 of 11 TABLE OF CONTENTS 1 INTRODUCTION ................................................................................................................................................................... 4 1.1 Intended Audience ............................................................................................................................................................. 4 1.2 FCC Statement ................................................................................................................................................................... 4 1.3 Mobile Category Device .................................................................................................................................................... 4 2 CONNECTING USING BLE ................................................................................................................................................ 5 2.1 Getting Rigado Toolbox Application ................................................................................................................................. 5 2.2 Connecting using Rigado Toolbox .................................................................................................................................... 5 3 BEACON BLE CHARACTERISTICS ................................................................................................................................ 6 3.1 UUID Characteristic (b7717580-b82a-4502-bd90-7f703fb51324) ................................................................................... 6 3.2 Major Number Characteristic (b7717580-b82a-4502-bd90-7f703fb61324) ..................................................................... 7 3.3 Minor Number Characteristic (b7717580-b82a-4502-bd90-7f703fb71324) ..................................................................... 8 3.4 Advertising Interval Characteristic (b7717580-b82a-4502-bd90-7f703fb81324) ............................................................. 9 3.5 TX Power Characteristic (b7717580-b82a-4502-bd90-7f703fb91324) .......................................................................... 10 3.6 Enable Characteristic (b7717580-b82a-4502-bd90-7f703fba1324) ................................................................................ 11 Rigado SCS-001 USER GUIDE Project / Subproject: SCS-001 Reference Number / Version: 0.2 Issue Date: 4/21/2015 Document File Name: SCS-001_User_Guide.docx Page: 4 of 11 1 Introduction This document describes user interaction and features with the SCS-001 prototype. 1.1 Intended Audience This intended audience of this document is any persons involved in use or testing of the SCS-001 prototypes. 1.2 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: Modifications to this product will void the user’s authority to operate this equipment. 1.3 Mobile Category Device This device can be used as a mobile category device, it’s antenna must be installed to provide at least a minimum separation distance of 20 cm from all persons. Rigado SCS-001 USER GUIDE Project / Subproject: SCS-001 Reference Number / Version: 0.2 Issue Date: 4/21/2015 Document File Name: SCS-001_User_Guide.docx Page: 5 of 11 2 Connecting using BLE 2.1 Getting Rigado Toolbox Application The Rigado Toolbox application can be downloaded from the iTunes app store. 2.2 Connecting using Rigado Toolbox To connect to the SCS-001 using the RigadoToolbox application, first open the application. In the list of peripherals at the Home page you should see a device labelled RigCom (see figure 1). Select the RigCom device. The app will connect to the device. Once a successful connection is made you will be taken to the BMDware Configuration page (see Figure 1.) Figure 1: RigadoToolbox Home(left) and BMDware Configuration(right) pages Rigado SCS-001 USER GUIDE Project / Subproject: SCS-001 Reference Number / Version: 0.2 Issue Date: 4/21/2015 Document File Name: SCS-001_User_Guide.docx Page: 6 of 11 3 Beacon BLE Characteristics The Beacon configuration service has six characteristics. For application development you will need the beaco…

Text truncated - open the document above for the full version.

Cover Letter(s)

Letter of Authorization Company: Rigado LLC Address: 2601 25st ST SE Suite 200, Salem, OR 97302 Product Name: SCS-001 Model Number: SCS-001 FCC Identifier: 2AA9B-SCS-001 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Cam Nichols Date: 5/11/15 Title: Engineer Signature of applicant: Rigado LLC 2601 25 th ST SE Suite 200 Salem, Oregon 97302 (o) 971-208-5236 ♦ (f) 503-405-7279

Cover Letter(s)

Rigado LLC 2601 25 th ST SE Suite 200 Salem, Oregon 97302 (o) 971-208-5236 ♦ (f) 503-405-7279 5/11/15 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Rigado, LLC FCC ID: 2AA9B-SCS-001 FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 Rigado, LLC hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type File Name Description Block Diagram Block Diagram Operational Description Operational Description Schematics Schematics Parts / BOM Parts / BOM List Note: Any exhibit NOT granted Confidential status is viewable on the FCC website as soon as the Grant is issued. Reason why the material should be withheld from public inspection: These documents contain detailed system, equipment description and related information about the product which Rigado, LLC considers proprietary, confidential, and a custom design not otherwise available to the general public. State why the information is a “trade secret;” Since the design is a basis from which future products will evolve, Rigado, LLC considers that this information would be of significant benefit to its competitors and that disclosure would give competitors an unfair advantage in the marketplace. Trade secret” information is information which is not generally known or reasonably ascertainable, by which a business can obtain an economic advantage over competitors. The information is not normally released to any party or person outside the company. Sincerely, Signature: Name: Cam Nichols Company: Rigado, LLC Title: Engineer Date: 05/11/2015

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

FCC ID:2AA9B-SCS-001 Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CENTRE OF TESTING SERVICE CO., LTD. A101，No.65，Zhuji Highway,Tianhe District，Guangzhou, China Te l：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3150421-00416-EF Page 1 of 2 RADIO FREQUENCY EXPOSURE LIMIT Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See §15.247(b)(4) and §1.1307(b)(1) of this chapter. EUT Specification EUT SCS-001 Model SCS-001 Frequency Band (Operating) 2402MHz~2480MHz Device Category ■ Portable (<20cm separation) □ Mobile (>20cm separation) □ Others Exposure Classification □ Occupational/Controlled exposure (S = 5mW/cm2) ■ General Population/Uncontrolled exposure (S=1mW/cm2) Antenna Diversity ■ Single antenna □ Multiple antennas ■ Tx diversity □ Rx diversity □ Tx/Rx diversity Max. Output Power 20.93dBm Antenna Gain (Max) Gain=5dBi (Numeric gain:3.16) Evaluation Applied ■ MPE Evaluation □ SAR Evaluation Note: 1. The maximum mix output power is 20.93dBm (123.88mW) with 3.16 numeric antenna gain. 2. For mobile or fixed location transmitters, no SAR consideration applied. The minimum separation generally be used is at least 20 cm, even if the calculations indicate that the MPE distance would be lesser. TEST RESULT No non-compliance noted. FCC ID:2AA9B-SCS-001 Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CENTRE OF TESTING SERVICE CO., LTD. A101，No.65，Zhuji Highway,Tianhe District，Guangzhou, China Te l：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3150421-00416-EF Page 2 of 2 Calculation Given (Equation 1) Where d = distance in cm P = Power in mW G = Numeric antenna gain S = Power Density in mW / cm 2 Maximum Permissible Exposure EUT Output Power=123.88mW Numeric antenna gain=3.16 Substituting the MPE safe distance using d=20 cm into Equation 1 : Yields The power density S = 123.88× 3.16/ (4∏×400) cm 2 =0.078mW/cm 2 (For mobile or fixed location transmitters, the maximum power density is 1.0 mW / cm 2 even if the calculation indicates that the power density would be larger.)

Test Report

CENTRE OF TESTING SERVICE INTERNATIONAL OPERATE ACCORDING TO ISO/IEC 17025 FCC ID TEST REPORT TEST REPORT NUMBER : CGZ3150421-00416-EF CENTRE OF TESTING SERVICE CO., LTD. A101，No.65，Zhuji Highway,Tianhe District，Guangzhou, China FCC ID:2AA9B-SCS-001 Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CENTRE OF TESTING SERVICE CO., LTD. A101，No.65，Zhuji Highway,Tianhe District，Guangzhou, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3150421-00416-EF Page 1 of 35 TEST REPORT For FCC ID 47 CFR PART 15 OCT, 2014 Report Reference No. .................... CGZ3150421-00416-EF Date of issue..................................... 23 April 2015 Testing Laboratory Name .............. CENTRE OF TESTING SERVICE CO., LTD. Address............................................. A101，No.65，Zhuji Highway,Tianhe District，Guangzhou, China Testing location/ procedure .............. Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s name ............................Rigado, LLC Address............................................. 2601 25 th St SE, Suite 200, Salem, OR 97302 USA Test specification ........................... Standard ........................................... 47 CFR PART 15 OCT, 2014 Test Report Form No. ....................CTSEMC-1.0 TRF Originator.................................. CENTRE OF TESTING SERVICE CO., LTD. Master TRF .......................................Dated 2009-01 CENTRE OF TESTING SERVICE CO., LTD. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the CENTRE OF TESTING SERVICE CO., LTD. is acknowledged as copyright owner and source of the material. CENTRE OF TESTING SERVICE CO., LTD takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description.....................:SCS-001 Trade Mark....................................... Rigado Manufacturer.................................... Rigado, LLC Model/Type reference...................... SCS-001 Ratings.............................................DC 5V by adapter; Adapter Input:AC 100~240V, 50/60Hz; Output:DC 5V Operating Frequency........................ 2402.0 MHz~2480.0 MHz Result ............................................... Positive Compiled by: Supervised by: Approved by: Kate zhang / Fileadministrators Duke yang / Technique principal Vincent yao / Manager FCC ID:2AA9B-SCS-001 Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CENTRE OF TESTING SERVICE CO., LTD. A101，No.65，Zhuji Highway,Tianhe District，Guangzhou, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3150421-00416-EF Page 2 of 35 FCC ID -- T E S T R E P O R T Test Report No. : CGZ3150421-00416-EF 23 April 2015 Date of issue Type / Model............................ SCS-001 EUT.......................................... SCS-001 Applicant........................... Rigado, LLC Address.................................... 2601 25th St SE, Suite 200, Salem, OR 97302 USA Telephone................................ +1-971-208-9864 Fax........................................... +1-971-208-9869 Contact..................................... Thomas Evans Manufacturer...................... Rigado, LLC Address.................................... 2601 25th St SE, Suite 200, Salem, OR 97302 USA Telephone................................ +1-971-208-9864 Fax........................................... +1-971-208-9869 Contact..................................... Thomas Evans Factory............................... Rigado, LLC Address.................................... 2601 25th St SE, Suite 200, Salem, OR 97302 USA Telephone................................ +1-971-208-9864 Fax........................................... +1-971-208-9869 Contact..................................... Thomas Evans Test Result according to the standards on page 1:PASSED The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. FCC ID:2AA9B-SCS-001 Copyright of this report is owned by Centre of Testing Service and may not be reproduced other than in full except with the written approval of the issuing Company. CENTRE OF TESTING SERVICE CO., LTD. A101，No.65，Zhuji Highway,Tianhe District，Guangzhou, China Tel：+86-20-85543113 (32 lines) Fax：+86-20-38780406 Complaint line：+86-20-85533471 E-mail：[email protected] See Reverse For Terms And Conditions of Service Report No.: CGZ3150421-00416-EF Page 3 of 35 TABLE OF CONTENTS Description Page 1.0 TEST STANDARDS .....................................................................................................................................5 2.0 SUMMARY...................................................................................................................................................5 2.1 GENERAL REMARKS .......................................................................................................................................5 2.2 FINAL ASSESSMENT........................................................................................................................................5 3.0 EQUIPMENT UNDER TEST ........................................................................................................................5 3.1 POWER SUPPLY SYSTEM UTILISED.................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Filip Kruzela(Certification Manager)

[email protected]+41 44 722 74 44Fax: +41 44 722 74 47

Technical Contact

Centre of Testing Service CO., LTDSusan Zhang

[email protected](86)2022138571

A101, No 65 Zhiji Highway, Tianhe District · Guangzhou, Guangdong · China

Test Firm

Centre of Testing service Co., LtdVincent Yao

[email protected]86-20-22138530Fax: 86-20-38780406

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	124.00 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. The antenna used with this transmitter must be installed to provided a minimum separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter within a device; except in accordance with accepted multi-transmitter operating procedure. Installers and end-users must be provided with installation instructions and operating procedures for satisfying RF exposure compliance.
