Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] No SAR justification for FCC ID : 2AAB6HK001 Following FCC KDB 447498 D01 “General SAR test exclusion guidance” The corresponding SAR Exclusion Threshold condition, listed below: 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where
 f(GHz) is the RF channel transmit frequency in GHz
 Power and distance are rounded to the nearest mW and mm before calculation
 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 2) At 100 MHz to 6 GHz and for test separation distances > 50 mm, the SAR test exclusion threshold is determined according to the following: a) [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·( f(MHz)/150)] mW, at 100MHz to 1500 MHz b) [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·10] mW at > 1500 MHz and ≤ 6 GHz 3) At frequencies below 100 MHz, the following may be considered for SAR test exclusion. a) The threshold at the corresponding test separation distance at 100 MHz in step 2) is multiplied by [1 + log(100/f(MHz))] for test separation distances > 50 mm and < 200 mm. b) The threshold determined by the equation in a) for 50 mm and 100 MHz is multiplied by ½ for test separation distances ≤ 50 mm. c) SAR measurement procedures are not established below 100 MHz. When SAR test exclusion cannot be applied, a KDB inquiry is required to determine SAR evaluation requirements for any test results to be acceptable. Smallest distance from the antenna and radiating structures or outer surface of the device The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. (See below figure) Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] SAR Test Exclusion Thresholds Mode Frequency (GHz) Maximum source-based time averaged conducted output power including tune-up tolerance (mW) Minimum separation distance (mm) SAR test exclusion thresholds (mW) for 1-g SAR SAR test exclusion thresholds (mW) for 10-g extremity SAR Verdict GFSK 2.476 79.068 60 mm 190.489 326.267 Exempt from SAR Conclusion Therefore our device complies with FCC’s RF radiation exposure limits for general population without SAR evaluation.

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 45 Report Version 1 Test Report No.: RF130507N003 TEST REPORT Applicant ZONDA HOBBY TECHNOLOGIES ELECTRONIC LIMITED Address: Workshop No.1, 1/F, Kam Hon industrial Building, No.8 Wang Kwun Road, Kowloon Bay, Kowloon, Hong Kong Manufacturer or Supplier ZONDA HOBBY TECHNOLOGIES ELECTRONIC LIMITED Address Workshop No.1, 1/F, Kam Hon industrial Building, No.8 Wang Kwun Road, Kowloon Bay, Kowloon, Hong Kong. Product 2.4GHz wireless controler Brand Name GWY Model GWY004539 Additional Model & Model Difference N/A Date of tests May 07, 2013 ~ Jun. 10, 2013 the tests have been carried out according to the requirements of the following standards: FCC Part 15, Subpart C (Section 15.247) CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tesed by Kent Liu Project Engineer / EMC Department Approved by Sam Tung Manager / EMC Department This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 45 Report Version 1 Test Report No.: RF130507N003 TABLE OF CONTENTS RELEASE CONTROL RECORD............................................................................................................. 5 1 SUMMARY OF TEST RESULTS ...................................................................................................... 6 2 MEASUREMENT UNCERTAINTY................................................................................................... 6 3 GENERAL INFORMATION .............................................................................................................. 7 3.1 GENERAL DESCRIPTION OF EUT ........................................................................................... 7 3.2 DESCRIPTION OF TEST MODES ............................................................................................. 8 3.2.1. CONFIGURATION OF SYSTEM UNDER TEST ............................................................... 8 3.2.2. TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .................................... 9 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................... 12 3.4 DESCRIPTION OF SUPPORT UNITS ..................................................................................... 12 4 TEST TYPES AND RESULTS ....................................................................................................... 13 4.1. CONDUCTED EMISSION MEASUREMENT ........................................................................... 13 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT................................................ 13 4.1.2 TEST INSTRUMENTS ..................................................................................................... 13 4.1.3 TEST PROCEDURES...................................................................................................... 14 4.1.4 DEVIATION FROM TEST STANDARD ............................................................................ 14 4.1.5 TEST SETUP ................................................................................................................... 15 4.1.6 EUT OPERATING CONDITIONS .................................................................................... 15 4.1.7 TEST RESULTS ............................................................................................................... 16 4.2. RADIATED EMISSION AND BANDEDGE MEASUREMENT .................................................. 18 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ...................... 18 4.2.2 TEST INSTRUMENTS .................................................................................................... 19 4.2.3 TEST PROCEDURES ..................................................................................................... 20 4.2.4 DEVIATION FROM TEST STANDARD ........................................................................... 20 4.2.5 TEST SETUP .................................................................................................................. 21 4.2.6 EUT OPERATING CONDITIONS.................................................................................... 21 4.2.7 TEST RESULTS .............................................................................................................. 22 4.3. NUMBER OF HOPPING FREQUENCY USED ......................…

Text truncated - open the document above for the full version.

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 2 Report Version 1 Test Report No.: RF130507N003 SET-UP FOR CONDUCTED EMISSION TEST Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 2 Report Version 1 Test Report No.: RF130507N003 SET-UP FOR RADIATED EMISSION TEST Frequency Range< 30MHz~1GHz > Frequency Range< Above 1GHz >
