All rights are reserved by USI. No part of this technical document can be reproduced in any form without permission of USI . 1 Data Sheet o f WM-N-BM-02_D-REF1 Data Sheet November 18 2013 Rev 2.1 802.11b/g/n WM-N-BM-02_D-REF1 www.usi.com.tw 802.11b/g/n Wireless LAN Daughter board V2.1 All rights are reserved by USI. No part of this technical document can be reproduced in any form without permission of USI . 2 Introduction This daughter card featured with full function of 802.11b/g/n including WM-N-BM-02. This multi-functionality via LGA to connect and provides SDIO/SPI (option) interface for WiFi. The small dimension and low profile physical design make it easier for system design to enable high performance wireless connection without space constrain. The low power consumption and excellent radio performance make it the best solution for OEM customers who require embedded 802.11b/g/n WiFi features, such as, Camera, Wireless PDA, Smart phone, MP3, PMP, slim type Notebook, VoIP phone etc. The card is based on Broadcom BCM43362 chipset which is a WiFi SOC. The Radio architecture and high integration MAC/BB chip provide excellent sensitivity with rich system performance. The card is designed as single antenna for WiFi for the application of small size hand-held device. In addition to WEP 64/128, WPA and TKIP, AES, CCX is supported to provide the latest security requirement on your network. For the software and driver development, USI provides extensive technical document and reference software code for the system integration under the agreement of Broadcom International Ltd. Hardware evaluation kit and development utilities will be released base on listed OS and processors to customers. Features Lead Free design which supporting Green d esign requirement, RoHS Compliance Small size suitable for low volume system i ntegration Low power consumption and excellent power management performance extend battery life Easy for integration into mobile and handheld device with flexible system configuration 802.11b/g/n Wireless LAN Daughter board V2.1 All rights are reserved by USI. No part of this technical document can be reproduced in any form without permission of USI . 3 Change Sheet Rev. Date Description of change Approval & Date Page Par. Change(s) 1.0 02/06/13 All All Draft version for Review 1.1 03/16/13 All All Add Rx item 1.2 03/20/13 6 2 Add PMU account 1.3 04/19/13 6 2 Modify the picture 1.4 06/21/13 All All Customer requirement 1.5 06/25/13 25 all Recommended MSD baking specification 1.6 07/02/13 11 5.5 Antenna spec. modify to Antenna parameter 1.7 07/17/13 All All WM-N-BM-02_D-REF1 1.8 07/19/13 All All Change WL_RST_N to WLAN RESETB and information correction 1.9 07/23/13 8 5.2.1 Modify( Ambient )Temperature 2.0 10/03/13 All All Information correction. VBAT and VDDIO Supply. 2.1 11/18/13 5.2.2 Customer Requirement VBAT and VDDIO Supply 802.11b/g/n Wireless LAN Daughter board V2.1 All rights are reserved by USI. No part of this technical document can be reproduced in any form without permission of USI . 4 TABLE OF CONTENTSINTRODUCTION Features................................................................................................................................... 1 1. EXECUTIVE SUMMARY.................................................................................................... 5 2. BLOCK DIAGRAM ............................................................................................................ 6 3. DELIVERABLES................................................................................................................ 6 4. REFERENCE DOCUMENTS ............................................................................................. 7 5. TECHNICAL SPECIFICATIONS........................................................................................ 8 5.1. ABSOLUTE MAXIMUM RATING............................................................................................ 8 5.2. RECOMMENDABLE OPERATION CONDITION.................................................................... 8 5.2.1. TEMPERATURE, HUMIDITY ......................................................................................... 8 5.2.2. VOLTAGE ...................................................................................................................... 8 5.2.3. POWER CONSUMPTION (SDIO, GSPI MODE) ............................................................ 8 5.3. WIRELESS SPECIFICATIONS .............................................................................................. 9 5.4. RADIO SPECIFICATIONS 802.11B/G/N................................................................................ 9 5.5. ANTNENNA SPECIFICATIONS ............................................................................................ 9 5.6 THROUGHPUT CONDITION REFERENCE............................... .............................................. 9 5 .7. REFERENCE EVB CIRCUIT................................................................................................ 10 5.8. TIMING DIAGRAM OF INTEFACE....................................................................................... 14 5.9. DIMENSIONS, WEIGHT AND MOUNTING.......................................................................... 18 5.9.1. DIMENSIONS............................................................................................................... 18 6 . LEGAL, REGULATORY & OTHER TECHNICAL CONSTRAINTS................................. 18 7. PIN OUT AND PIN DESCRIPTION.................................................................................. 19 8. REFLOW PROFILE GUIDELINE .......................................................................17 9. PACKAGE AND STORAGE CONDITION .......................................................................... 22 9.1. PACKAGE DIMENSION....................................................................................................... 19 9.2. ESD LEVEL ........…
