2AADK-F4Intelligent Video Terminal

Vehicle intelligent terminal instruction manual V1.0 Shenzhen Youwei Information Technology Development Co., Ltd 05/2023 directory 一、 overview ............................................................................................................................................................... 1 二、 Product features ................................................................................................................................................. 1 三、 Product feature introduction .......................................................................................................................... 3 3.1 Advanced Driver Assistance Features (ADAS)................................................................................... 3 3.2 Driver Status Detection (DSM). ............................................................................................................. 4 3.3 Video ........................................................................................................................................................... 4 3.4 Mass Storage ............................................................................................................................................. 5 3.5 Image Transmission ................................................................................................................................. 5 3.6 Multimedia Analytics ............................................................................................................................... 5 3.7 Vehicle Monitoring .................................................................................................................................. 5 3.8 Signal Detection and Control ................................................................................................................ 5 3.9 Alarm ........................................................................................................................................................... 5 3.10 Drive recorder ......................................................................................................................................... 6 3.11 Vehicle Driving Analysis ....................................................................................................................... 6 3.12 Cloud Guardian ....................................................................................................................................... 6 3.14 Road Inspection ...................................................................................................................................... 6 3.15 Voice and Calls ........................................................................................................................................ 6 四、 Product specifications ....................................................................................................................................... 7 五、 Illustration of product structure and appearance ..................................................................................... 9 5.1 Schematic diagram of the structure .................................................................................................... 9 5.2 Schematic diagram of the front panel of the terminal ................................................................... 9 5.3 Schematic diagram of the rear panel of the terminal ................................................................... 11 5.4 Definition of the main signal interface of the rear panel of the terminal ............................... 11 5.5 Terminal rear panel antenna interface.............................................................................................. 12 5.6 Terminal rear panel camera interface definition ............................................................................ 12 5.7 Terminal rear panel IPC interface definition ................................................................................... 13 5.8 Product wiring diagram ........................................................................................................................ 13 六、 Product configuration checklist ................................................................................................................... 14 6.1 Standard Equipment List ...................................................................................................................... 14 6.2 Optional List ............................................................................................................................................ 15 1 一、overview High-definition intelligent AI video terminal F4 is a new generation of intelligent driving early warning system based on industrial-grade core high-speed processing chips and ADAS, DSM, BSD and so on 4G broadband multimedia wireless transmission, WIFI communication, maximum 6-channel DVR HD surveillance and video storage, Beidou/GPS Dual-mode high- precision positioning in one vehicle intelligent video terminal. Product reference to the following standards: Standard number Standard name Release date GB/T 21413.1 Railway applications Electrical equipment for rolling stock Part 1 General conditions of use and general rules 2008 GB/T 25119 Rail transit Locomotive and rolling stock electronics 2021 GB/T 24338.4 Rail Transit Electromagnetic Compatibility Part 3-2: Rolling Stock Equipment 2018 GB/T 21563 Rail Transit Rolling Stock Equipment Shock and vibration test 2018 GB/T 30512 Automotive Banned Substance Requirements 2014 GB/T 4208 Enclosure rating 2008 GB/T 28046.2 Road vehicles - Environmental conditions and tests for electrical and electronic equipment - Part 2 Electrical loads 2011 GB/T 28046.3 Road vehicles Environmental conditions and tests for electrical and electronic equipment Part 3 2011 GB/T 28046.4-2011 Environmental conditions and tests for electrical and electronic equipment for road vehicles Part 4 2011 GB/…

Text truncated - open the document above for the full version.

Shenzhen Yuwei Information And Technology Development Co., Ltd. 2023-6-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (2AADK-F4) [Shenzhen Yuwei Information And Technology Development Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Name: Chen Xiaojiang Title: Manager Shenzhen Yuwei Information And Technology Development Co., Ltd. 2023-6-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (2AADK-F4) [Shenzhen Yuwei Information And Technology Development Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Name: Chen Xiaojiang Title: Manager

Attestation Statements 2023-6-15 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (2AADK-F4) (Shenzhen Yuwei Information And Technology Development Co., Ltd.), the undersigned, hereby authorize (UGK-LVMUNITEDINC) to act as our designated U.S. agent for service of process, Shenzhen Yuwei Information And Technology Development Co., Ltd. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (UGK-LVMUNITEDINC) accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Shenzhen Yuwei Information And Technology Development Co., Ltd. Contact Name: Chen Xiaojiang Address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Telephone No: 86-19878861112 Email: [email protected] Signature: Chen Xiaojiang/Manager U.S. Agent Information: Company Name: UGK-LVMUNITEDINC Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 FRN: 0033476375 Contact Name: Jimmychen Telephone No: 001-323-51 04660 Email: [email protected] Signature Jimmychen/Manager

Shenzhen Yuwei Information And Technology Development Co., Ltd. Product Similarity Declaration Company: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Product Name: Vehicle Intelligent Terminal Model Number: F4, F4A, F4B, F4C, F4D, F4E, F4F, F4Q FCC Identifier: 2AADK-F4 We (Shenzhen Yuwei Information And Technology Development Co., Ltd. ) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name and appearance color. Client’s signature Client’s name / title : Chen Xiaojiang / Manager Contact information /address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Date: 2023-06-15

Shenzhen Yuwei Information And Technology Development Co., Ltd. 2023-6-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Vehicle Intelligent Terminal MODEL: F4, F4A, F4B, F4C, F4D, F4E, F4F, F4Q FCC ID: 2AADK-F4 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description - tune up - Bom required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Company name: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Signature: Chen Xiaojiang/Manager

Shenzhen Yuwei Information And Technology Development Co., Ltd. 2023-6-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen DL Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Company name: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Signature: Chen Xiaojiang/Manager

Shenzhen Yuwei Information And Technology Development Co., Ltd. 2023-6-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Short Term Confidentiality Request For EUT NAME: Vehicle Intelligent Terminal MODEL: F4, F4A, F4B, F4C, F4D, F4E, F4F, F4Q FCC ID: 2AADK-F4 To Whom It May Concern: In accordance with sections 0.457 and 0.459 of CFR 47, Shenzhen Yuwei Information And Technology Development Co., Ltd.. requests short-term Confidentiality of following sections of this application for a period of 180 days after grant is issued. Test setup photos External photos Internal photos User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which Shenzhen Yuwei Information And Technology Development Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Shenzhen Yuwei Information And Technology Development Co., Ltd. feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Company name: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Signature: Chen Xiaojiang/Manager Must be signed by the applicant contact cited as technical or non-technical contact on the 731 form provided to Eurofins MET Labs, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters signed by the applicant should be placed on applicant letterhead.

Size:16*14mm MODEL: F4 FCC ID: 2AADK-F4 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label location

2/3/4G Antenna location WIFI Antenna location

FCC ID: 2AADK-F4 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation Channel Output power to antenna (dBm) Output power to antenna (mW) Antenna Gain (dBi) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result WIFI 6.209 4.18 3.0 0.00166 1.0 PASS GSM850 32.55 1798.87 0.82 0.43225 0.5 PASS PCS1900 30.48 1116.86 2.79 0.42241 1.0 PASS WCDMA BAND 2 22.38 172.98 2.79 0.06542 1.0 PASS WCDMA BAND 4 22.97 198.15 0.82 0.04761 1.0 PASS WCDMA BAND 5 22.93 196.34 2.79 0.07426 0.5 PASS LTE Band 2 24.07 255.27 2.79 0.09655 1.0 PASS LTE Band 4 23.33 215.28 2.79 0.08142 1.0 PASS LTE Band 5 22.04 159.96 0.82 0.03844 0.5 PASS LTE Band 7 23.27 212.32 2.14 0.06914 1.0 PASS LTE Band 66 23.30 213.80 2.79 0.08086 1.0 PASS

5 5 4 4 3 3 2 2 1 1 DD CC BB AA 共模电感底下要净空，不能覆铜，不能走线 增大电容容量，应对传导低频 2.5V GNDGND VIN GND GND VCPU GND VIN GNDGND KL30_M EXT_GND EXT_GND MP12V GND IN GND GND MP12V GND GND GND GNDGND VBAT IN VCC GND GND VCC GND IN GNDGND VCPU IN POW_SW_EPU4 POW_SW_VPU17 KEY_DET4 POW_ADC4 VBAT_DCH_SW3 OUT_SLEEP4 CAP_DCH_SW2 SS210 LOW_ST_BY4 ACC9 Title SizeDocument NumberRev Date:Sheetof POWER1 1.0 F4Q Custom 126Thursday, December 29, 2022 Title SizeDocument NumberRev Date:Sheet of POWER1 1.0 F4Q Custom 126Thursday, December 29, 2022 Title SizeDocument NumberRev Date:Sheet of POWER1 1.0 F4Q Custom 126Thursday, December 29, 2022 L12 WCM-7060SE-701T/NC WCM-7060 1 23 4 DW1 MM3Z15 SOD-323 R13 10K SR0402 R6 1K SR0402 R275 10K SR0402 R1 10K 0603 DW3 MM3Z15 SOD-323 D15 IN4148WS SOD-323 C7 0.1uF/50V C0603 DW4 MM3Z33/NC SOD-323 N19 MBT5551 SOT-23 1 3 2 N4 MBT5551 SOT-23 1 3 2 R88 100K 0603 C11 0.1uF/50V C0603 R257 100K 0603 C218 22uF/50V C0805 +C60 330uF/63V RAD_5_10 R65 470K 0603 R11 4.7K SR0402 R16 10K SR0402 R15 10K SR0402 D6 SD103AWS-G SOD-323 RV11 SDV1005E5R5C500NPTF SR0402 C119 1nF/50V SC0402 R265 47K SR0402 R276 20K SR0402 C1 1nF/50V SC0402 C52 10nF/100V C0603 C3 1uF/50V C0805 P1 C240-C155 C121 10nF/100V C0603 R9 10K SR0402 R20 10K SR0402 C135 1nF/100V C0603 TP12 TP60MIL 1 R274 15K SR0402 C211 4.7uF/50V C0805 D25 SD103AWS-G SOD-323 R256 100K SR0402 R4 100K SR0402 R26 120K SR0402 D16 IN4148WS SOD-323 D1 IN4148WS SOD-323 C4 0.1uF/50V C0603 Q5 CMD5941 TO-252AA 2 1 3 R252 0R 1206 P2 C240-C155 R41 120K 0805 R21 10K SR0402 TV28 SMF30A/NC SOD-123 C46 1nF/100V C0603 D47 SD103AWS-G SOD-323 K1 IT-1819VL-5_0 it-1819vl-smd 12 345 N3 MBT5551 SOT-23 1 3 2 R54 27K 0603 P4 C240-C155 N6 MBT5551 SOT-23 1 3 2 C6 100pF/50V SC0402 R12 470K 0603 RV10 AVLC5S02050 SR0402 R590R1206 N1 MBT5551 SOT-23 1 3 2 C53 2.2uF/100V/NC 1206 N2 MBT5401 SOT-23 R27 10K SR0402 U7 CYT431A TL431 REF 1 CAT 3 ANO 2 D2 IN4148WS SOD-323 TP1 TP60MIL 1 R132 1K SR0402 C54 0.1uF/100V C0603 C12 270pF/50V SC0402 R8 100K/1% SR0402 DW2 MM3Z33 SOD-323 D12 SD103AWS-G SOD-323 R266 10K SR0402 D10 IN4148WS SOD-323 R25 100K/NC SR0402 P3 C240-C155 D26 SD103AWS-G SOD-323 C18 1uF/6.3V SC0402 R254 27K/1% SR0402 N5 MBT5551 SOT-23 1 3 2 C5 1uF/16V SC0402 R7 32.4K/1% SR0402 R10 1K SR0402 TP48 TP60MIL 1 Q7 CMD5941 TO-252AA 2 1 3 P5 C240-C155 C55 0.1uF/100V C0603 R105 470K/1% 0603 TP2 TP60MIL 1 R5 68K 0603 D11 SD103AWS-G SOD-323 TP42 TP60MIL 1 TP49 TP60MIL 1 D4 SD103AWS-G SOD-323 C56 2.2uF/100V/NC 1206 C2 1nF/50V SC0402 TP3 TP60MIL 1 MP_SW MP_SW 5 5 4 4 3 3 2 2 1 1 DD CC BB AA Vout=0.8*(1+Rup/Rdw) Vout=0.8*(1+R27/R36)=5.29V Standby:30uA 11V7 GND GND GND 12VVIN GND GND VCAP 11V7 GND GND VCAP SYS_5V GND 11V7 GND GND GNDGND GND GND GND 12V GNDGND GND VEXTI_5V GND SYS_5V VCC_MOTOR GND IN GND CAP_DCH_SW1 EXT_POW17,22 MOTOR_POW4 Title SizeDocument NumberRev Date:Sheetof POWER2 1.0 F4Q Custom 226Thursday, December 22, 2022 Title SizeDocument NumberRev Date:Sheet of POWER2 1.0 F4Q Custom 226Thursday, December 22, 2022 Title SizeDocument NumberRev Date:Sheet of POWER2 1.0 F4Q Custom 226Thursday, December 22, 2022 + C44 DRL705Q0TG22RR SC-RAD_5_10 R328 10R/NC SR0402 C268 12pF/50V SC0402 Q1 AO3481 SOT-23 3 1 2 R39 4.7K 0603 Q2 AO3481 SOT-23 3 1 2 + C33 220uF/50V EC105_50 C202 10uF/10V C0603 + C45 DRL705Q0TG22RR SC-RAD_5_10 D28 SS24 SMB-DO-214AA L14 TMPC1265HP-100MG-D l13_13 Q10 AO3481C SOT-23 3 1 2 R44 10R SR0402 C35 0.1uF/50V C0603 Q11 CMD5941 TO-252AA 2 1 3 R14 22R SR0402 R316 100K SR0402 C41 10nF/50V SC0402 N10 MBT5551 SOT-23 1 3 2 C17 0.1uF/25V SC0402 R49 53.6K/1% SR0402 C34 1uF/50V C0805 TP10 TP60MIL 1 + C47 DRL705Q0TG22RR SC-RAD_5_10 R29 100K SR0402 R311 100K SR0402 C51 1uF/16V SC0402 R51 27K SR0402 N25 MBT5551 SOT-23 1 3 2 R28 10K SR0402 D9 SS24 SMB-DO-214AA R19 243K/1% SR0402 R334 1K SR0402 C201 1uF/10V SC0402 R47 75K SR0402 L18 WPN4020H3R3MT L40_20 R301 100K SR0402 R48 180K SR0402 C204 1uF/16V SC0402 C266 22uF/16V C0805 C24 NC SC0402 D21 SS24 SMB-DO-214AA R60 17.4K/1% SR0402 R2 4.7K 0603 C61 10nF/25V SC0402 D27 SS24 SMB-DO-214AA C8 0.1uF/25V SC0402 R30 0R SR0402 D14 SS24 SMB-DO-214AA L3 3.3uH L300-280 TP8 TP60MIL 1 R336 100K SR0402 C109 1uF/50V C0805 C267 22uF/16V C0805 R335 100K SR0402 + C36 470uF/25V EC80_35 U8 MP1657 SOT563 EN 5 GND 3 BST 4 VIN 1 SW 2 FB 6 R34 4.7K 0603 R32 1K SR0402 U2 MPQ9840GL QFN16B PHASE 1 VIN 2 SW1 3 PGND1 4 EN 5 SYNC 6 PG 7 BIAS 8 PGND2 9 SW2 10 BST 11 VCC 12 AGND 13 SS 14 FB 15 FREQ 16 R310 1K SR0402 R17 470K SR0402 C37 0.1uF/25V SC0402 C118 0.1uF/50V C0603 R31 100k SR0402 C50 0.1uF/25V SC0402 N23 MBT5551 SOT-23 1 3 2 R325 100K SR0402 R46 100K SR0402 C203 0.1uF/25V SC0402 R45 470K/1% SR0402 C39 22uF/16V C0805 R61 100K SR0402 R329 100K SR0402 C38 22uF/16V C0805 C165 1uF/16V SC0402 C10 22uF/16V C0805 C40 1nF/50V SC0402 TP9 TP60MIL 1 C62 1uF/10V SC0402 GND 5 5 4 4 3 3 2 2 1 1 DD CC BB AA VGSM_3V8=0.6*(1+Rup/Rdw) R261=10K/110mA 2K/500mA 3.6K/300mA VOUT=0.6*(1+Rup/Rdw) 5.0V VCPU GND GND GND VGNS GND SYS_BAT GND VGSM_3V8 GND GND SYS_BAT GND GND GND SYS_BAT GND VBAT GND GND VCPU SYS_BAT GND GND SYS_5V GND VBAT SYS_5V 11V7 SYS_BAT VCPU GND GND GPS_POW4 GSM_POW4 CHG_DET4 CHG_EN17VBAT_DCH_SW1 Title SizeDocument NumberRev Date:Sheet of POWER3 1.0 F4Q Custom 326Thursday, December 29, 2022 Title SizeDocument NumberRev Date:Sheet of POWER3 1.0 F4Q Custom 326Thursday, December 29, 2022 Title SizeDocument NumberRev Date:Sheet of POWER3 1.0 F4Q Custom 326Thursday, December 29, 2022 R541 200K/1% SR0402 R76 0R SR0402 C396 22uF/6.3V C0603 R306 49.9K/1% SR0402 R544 100K SR0402 C90 0.1uF/25V SC0402 C73 12pF/50V SC0402 TP36 TP60MIL 1 R53 37.4K/1% SR0402 C69 0.1uF/25V SC0402 U15 SGM2036-3.3YN5G/TR SOT-23-5 BP 4 VIN 1 VOUT 5 VSS 2 CE 3 R235 200K/1% SR0402 + C97 22uF/10V/NC C0805 C13 0.1uF/25V SC0402 LB26 PZ3216D121-3R0TF 1206 R545 10K SR0402 TP16 TP60MIL 1 R297 68K SR0402 L2 TMPA0603S-3R3MN-D L300-280 + C368 220uF/16V SMD-CAP6_7 Q3 AO3481 SOT-23 3 1 2 C219 10nF/25V SC0402 R542 10K SR0402 C71 10nF/50V SC0402 R299 365K/1% SR0402 R40 10K SR0402 C110 10nF/50V SC0402 C89 470nF/10V/NC SC…

Text truncated - open the document above for the full version.

Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 23 ANNEX 2 FCC Test Report FCC ID: 2AADK-F4 Applicant: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: Room 703A-01, Floor 7, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen Manufacturer: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: Room 703A-01, Floor 7, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen EUT: Vehicle Intelligent Terminal Trade Mark: N/A Model Number: F4 F4A, F4B, F4C, F4D, F4E, F4F, F4Q Date of Receipt: Apr. 28, 2023 Test Date: Apr. 28, 2023 - May. 26, 2023 Date of Report: May. 26, 2023 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC CFR Title 47 Part22 Subpart H FCC CFR Title 47 Part24 Subpart E FCC CFR Title 47 Part27 Subpart E ANSI/ TIA/ EIA-603-D-2010 FCC KDB 971168 D01 Power Meas. License Digital Systems v02v02 ANSI C63.26:2015 Test Result: Pass Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 23 03 Peak-to-Average Ratio Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict WCDMA Band2 9262 1852.4 2.87 13 PASS WCDMA Band2 9400 1880 2.91 13 PASS WCDMA Band2 9538 1907.6 2.81 13 PASS WCDMA Band4 1312 1712.4 2.97 13 PASS WCDMA Band4 1450 1740 2.82 13 PASS WCDMA Band4 1513 1752.6 2.97 13 PASS WCDMA Band5 4132 826.4 2.84 13 PASS WCDMA Band5 4182 836.4 2.86 13 PASS WCDMA Band5 4233 846.6 2.83 13 PASS Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 23 WCDMA Band2 Channel=9262 WCDMA Band2 Channel=9400 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 23 WCDMA Band2 Channel=9538 WCDMA Band4 Channel=1312 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 23 WCDMA Band4 Channel=1450 WCDMA Band4 Channel=1513 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 6 of 23 WCDMA Band5 Channel=4132 WCDMA Band5 Channel=4182 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 7 of 23 WCDMA Band5 Channel=4233 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 8 of 23 04 Occupied bandwidth Band Channel Frequency (MHz) 99% OBW (kHz) -26dB EBW (kHz) Verdict WCDMA Band2 9262 1852.4 4184.072 4702.784 PASS WCDMA Band2 9400 1880 4185.667 4707.722 PASS WCDMA Band2 9538 1907.6 4169.665 4718.405 PASS WCDMA Band4 1312 1712.4 4160.764 4723.306 PASS WCDMA Band4 1450 1740 4166.939 4734.545 PASS WCDMA Band4 1513 1752.6 4156.627 4713.826 PASS WCDMA Band5 4132 826.4 4181.570 4713.346 PASS WCDMA Band5 4182 836.4 4161.185 4696.914 PASS WCDMA Band5 4233 846.6 4165.765 4727.858 PASS Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 9 of 23 WCDMA Band2 Channel=9262 WCDMA Band2 Channel=9538 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 10 of 23 WCDMA Band2 Channel=9400 WCDMA Band4 Channel=1312 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 11 of 23 WCDMA Band4 Channel=1450 WCDMA Band4 Channel=1513 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 12 of 23 WCDMA Band5 Channel=4132 WCDMA Band5 Channel=4182 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 13 of 23 WCDMA Band5 Channel=4233 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 14 of 23 05 Band edge Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict WCDMA Band2 9262 1852.4 1850.00 -23.19 -13 PASS WCDMA Band2 9538 1907.6 1910.00 -23.01 -13 PASS WCDMA Band4 1312 1712.4 1710.00 -21.66 -13 PASS WCDMA Band4 1513 1752.6 1755.00 -22.98 -13 PASS WCDMA Band5 4132 826.4 824.00 -22.45 -13 PASS WCDMA Band5 4233 846.6 849.00 -22.11 -13 PASS Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 15 of 23 WCDMA Band2 Channel=9262 WCDMA Band2 Channel=9538 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 16 of 23 WCDMA Band4 Channel=1312 WCDMA Band4 Channel=1513 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 17 of 23 WCDMA Band5 Channel=4132 WCDMA Band5 Channel=4233 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 18 of 23 06 Out-of-band emissions Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict WCDMA Band2 9262 1852.4 19523.72 -22.06 -13 PASS WCDMA Band2 9400 1880 18901.15 -22.28 -13 PASS WCDMA Band2 9538 1907.6 19034.45 -22.52 -13 PASS WCDMA Band4 1312 1712.4 18816.28 -22.90 -13 PASS WCDMA Band4 1450 1740 19764.85 -22.92 -13 PASS WCDMA Band4 1513 1752.6 19620.07 -22.60 -13 PASS WCDMA Band5 4132 826.4 6438.47 -28.13 -13 PASS WCDMA Band5 4182 836.4 8174.49 -28.29 -13 PASS WCDMA Band5 4233 846.6 6125.91 -27.99 -13 PASS Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 19 of 23 WCDMA Band2 Channel=9262 WCDMA Band2 Channel=9400 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 20 of 23 WCDMA Band2 Channel=9538 WCDMA Band4 Channel=1312 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 21 of 23 WCDMA Band4 Channel=1450 WCDMA Band4 Channel=1513 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 22 of 23 WCDMA Band5 Channel=4132 WCDMA Band5 Channel=4182 Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 23 of 23 WCDMA Band5 Channel=4233

Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 302 ANNEX 3 FCC Test Report FCC ID: 2AADK-F4 Applicant: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: Room 703A-01, Floor 7, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen Manufacturer: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: Room 703A-01, Floor 7, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen EUT: Vehicle Intelligent Terminal Trade Mark: N/A Model Number: F4 F4A, F4B, F4C, F4D, F4E, F4F, F4Q Date of Receipt: Apr. 28, 2023 Test Date: Apr. 28, 2023 - May. 26, 2023 Date of Report: May. 26, 2023 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC CFR Title 47 Part22 Subpart H FCC CFR Title 47 Part24 Subpart E FCC CFR Title 47 Part27 Subpart E ANSI/ TIA/ EIA-603-D-2010 FCC KDB 971168 D01 Power Meas. License Digital Systems v02v02 ANSI C63.26:2015 Test Result: Pass Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 302 03 Peak-to-Average Ratio Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Result (dB) high Limit (dB) Verdict Band2 1.4 18607 1 #0 QPSK 3.84 13 PASS Band2 1.4 18607 1 #0 QAM16 4.94 13 PASS Band2 1.4 18900 1 #0 QPSK 3.98 13 PASS Band2 1.4 18900 1 #0 QAM16 4.81 13 PASS Band2 1.4 19193 1 #0 QPSK 3.30 13 PASS Band2 1.4 19193 1 #0 QAM16 4.39 13 PASS Band2 3 18615 1 #0 QPSK 4.05 13 PASS Band2 3 18615 1 #0 QAM16 4.96 13 PASS Band2 3 18900 1 #0 QPSK 4.13 13 PASS Band2 3 18900 1 #0 QAM16 4.94 13 PASS Band2 3 19185 1 #0 QPSK 3.76 13 PASS Band2 3 19185 1 #0 QAM1…
