2AADK-V5Intelligent Video Terminal

Intelligent Video Terminal （V5） Technical Manual V2.0 Shenzhen Yuwei Information And Technology Development Co., Ltd. 2023.4 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 1 目录 1. Product Introduction ............................................................................................................. 3 2. Function Description ............................................................................................................. 3 2.1 Upgrade ....................................................................................................................... 3 2.2 Equipment indicator .................................................................................................... 4 2.3 Wifi .............................................................................................................................. 4 2.4 Operations and Maintenance Assistant ...................................................................... 4 2.5 Go Online .................................................................................................................... 5 2.6 Face Recognition ......................................................................................................... 5 2.7 Button .......................................................................................................................... 6 2.8 Heartbeat function ...................................................................................................... 6 2.9 Location Information Reporting .................................................................................. 6 2.10 Parameter query and setting..................................................................................... 7 2.11 Positioning monitoring .............................................................................................. 7 2.12 Wireless Communication .......................................................................................... 8 2.13 Alarm prompt ............................................................................................................ 8 2.14 Other Alarms ............................................................................................................. 9 2.15 Terminal Control ...................................................................................................... 10 2.16 TTS ........................................................................................................................... 10 2.17 Driving record data .................................................................................................. 11 2.18 Camera photo taking ............................................................................................... 11 2.19 Cell phone to give instructions ................................................................................ 12 2.20 Audio and video ...................................................................................................... 12 3. Voice prompt instructions ................................................................................................... 14 3.1 ADAS algorithms ........................................................................................................ 14 3.2 DSM algorithm .......................................................................................................... 17 3.3 FACE ID ...................................................................................................................... 18 3.4 Intelligent AI .............................................................................................................. 19 3.5 BSD ............................................................................................................................ 19 3.6 Others ........................................................................................................................ 20 3.7 Multi-language .......................................................................................................... 21 4. Storage Metrics ................................................................................................................... 22 5. Wireless communication module ....................................................................................... 22 6. Algorithm…

Text truncated - open the document above for the full version.

Shenzhen Yuwei Information And Technology Development Co., Ltd. 2023-6-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (2AADK-V5) [Shenzhen Yuwei Information And Technology Development Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Name: Chen Xiaojiang Title: Manager Shenzhen Yuwei Information And Technology Development Co., Ltd. 2023-6-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (2AADK-V5) [Shenzhen Yuwei Information And Technology Development Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Name: Chen Xiaojiang Title: Manager

Attestation Statements 2023-6-15 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (2AADK-V5) (Shenzhen Yuwei Information And Technology Development Co., Ltd.), the undersigned, hereby authorize (UGK-LVMUNITEDINC) to act as our designated U.S. agent for service of process, Shenzhen Yuwei Information And Technology Development Co., Ltd. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (UGK-LVMUNITEDINC) accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Shenzhen Yuwei Information And Technology Development Co., Ltd. Contact Name: Chen Xiaojiang Address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Telephone No: 86-19878861112 Email: [email protected] Signature: Chen Xiaojiang/Manager U.S. Agent Information: Company Name: UGK-LVMUNITEDINC Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 FRN: 0033476375 Contact Name: Jimmychen Telephone No: 001-323-51 04660 Email: [email protected] Signature Jimmychen/Manager

Shenzhen Yuwei Information And Technology Development Co., Ltd. 2023-6-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Intelligent Video Terminal MODEL: V5, V5N, V5P, V6, V5Q, V5S, V5 Lite FCC ID: 2AADK-V5 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description - tune up - Bom required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Company name: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Signature: Chen Xiaojiang/Manager

Shenzhen Yuwei Information And Technology Development Co., Ltd. 2023-6-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen DL Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Company name: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Signature: Chen Xiaojiang/Manager

Shenzhen Yuwei Information And Technology Development Co., Ltd. Product Similarity Declaration Company: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Product Name: Intelligent Video Terminal Model Number: V5, V5N, V5P, V6, V5Q, V5S, V5 Lite FCC Identifier: 2AADK-V5 We (Shenzhen Yuwei Information And Technology Development Co., Ltd. ) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name and appearance color. Client’s signature Client’s name / title : Chen Xiaojiang / Manager Contact information /address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Date: 2023-06-15

Shenzhen Yuwei Information And Technology Development Co., Ltd. 2023-6-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Short Term Confidentiality Request For EUT NAME: Intelligent Video Terminal MODEL: V5, V5N, V5P, V6, V5Q, V5S, V5 Lite FCC ID: 2AADK-V5 To Whom It May Concern: In accordance with sections 0.457 and 0.459 of CFR 47, Shenzhen Yuwei Information And Technology Development Co., Ltd.. requests short-term Confidentiality of following sections of this application for a period of 180 days after grant is issued. Test setup photos External photos Internal photos User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which Shenzhen Yuwei Information And Technology Development Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Shenzhen Yuwei Information And Technology Development Co., Ltd. feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Company name: Shenzhen Yuwei Information And Technology Development Co., Ltd. Address: 703A-01, Floor 7, Building 2, Building 2, Meilin Duoli Industrial Zone, Beihuan Road, Meifeng Community, Meilin Street, Futian District, Shenzhen, China Signature: Chen Xiaojiang/Manager Must be signed by the applicant contact cited as technical or non-technical contact on the 731 form provided to Eurofins MET Labs, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters signed by the applicant should be placed on applicant letterhead.

Size:24*20mm M/N: V5 FCC ID: 2AADK-V5 Label location

2/3/4G Antenna location WIFI Antenna location

FCC ID: 2AADK-V5 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation Channel Output power to antenna (dBm) Output power to antenna (mW) Antenna Gain (dBi) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result WIFI 16.13 41.02 3.0 0.01628 1.0 PASS GSM850 32.57 1807.17 0.82 0.43424 0.5 PASS PCS1900 30.51 1124.60 2.79 0.42533 1.0 PASS WCDMA BAND 2 22.39 173.38 2.79 0.06557 1.0 PASS WCDMA BAND 4 22.98 198.61 0.82 0.04772 1.0 PASS WCDMA BAND 5 22.95 197.24 2.79 0.07460 0.5 PASS LTE Band 2 23.35 216.27 2.79 0.08180 1.0 PASS LTE Band 4 23.37 217.27 2.79 0.08217 1.0 PASS LTE Band 5 22.17 164.82 0.82 0.03960 0.5 PASS LTE Band 7 23.35 216.27 2.14 0.07043 1.0 PASS LTE Band 66 23.40 218.78 2.79 0.08274 1.0 PASS
