2AAGEVTM2M-LVM2M Gateway

VT-M2M-LV 1/ 21 VT-M2M-LV User’s Manual Chengdu Vantron Technology, Ltd. www.vantrontech.com.cn VT-M2M-LV 2/ 21 Revision History: No. Version Description Date 1 V1.0 First release Nov .8, 2012 2 V2.0 Upgrade PCB to Revision 2 Oct .18, 2013 3 V3.0 Upgrade PCB to Revision 3, move GPS to on board, change WiFi to on board module. Sept .28, 2014 4 V3.1 Add FCC and IC warning statement March.16,2015 VT-M2M-LV 3/ 21 Table of Contents 1. Foreword ...................................................................................................................................4 1.1 Copyright Notice ........................................................................................................................4 1.2 Notes ..........................................................................................................................................4 1.3 Statement ...................................................................................................................................4 1.4 Disclaimer ...................................................................................................................................4 1.5 Limitation of Liability/Non-warranty ..........................................................................................5 1.6 Safety Instructions ......................................................................................................................5 1.7 Precautions .................................................................................................................................5 1.8 Safety Instructions for Power Cables and Accessories ...............................................................5 2. Overview ...................................................................................................................................7 2.1 Introduction ...............................................................................................................................7 2.2 Product Series ............................................................................................................................8 3. M2M-LV Hardware Instructions ..............................................................................................9 3.1 Product Appearance ...................................................................................................................9 3.2 Specifications ...........................................................................................................................10 3.3 Interface Instructions ...............................................................................................................11 3.4 Dimension ................................................................................................................................12 3.5 Interface Description ................................................................................................................13 3.5.1 Power Interface ........................................................................................................13 3.5.2 Ethernet Interface .....................................................................................................14 3.5.3 D Sub-9 RS232 or RS485 Connector ..........................................................................15 3.5.4 RS232/422/485,CAN,External IO Connector .............................................................16 3.5.5 LED ............................................................................................................................17 3.5.6 SIM Card ....................................................................................................................17 3.5.7 DEBUG .......................................................................................................................17 3.5.8 Renew button............................................................................................................18 3.5.9 Reset button ..............................................................................................................18 3.5.10 SD/MMC socket ......................................................................................................18 4. Tips .......................................................................................................................................... 19 VT-M2M-LV 4/ 21 1. Foreword 1.1 Copyright Notice While all information contained herein have been carefully checked to assure its accuracy in technical details and printing, Vantron assumes no responsibility resulting from any error or features of this manual, or from improper uses of this manual or the software. Please contact our technical department for relevant operation solutions if there is any problem that cannot be solved according to this manual. Vantron reserves all rights of this manual, including the right to change the content, form, product features, and specifications contained herein at any time without prior notice. The latest version of this manual is at www.vantrontech.com.cn. Please contact Vantron for further information: Vantron Technology（Vantron） E-mail: [email protected] The trademarks and registered trademarks in this manual are properties of their respective owners. No part of this manual may be copied, reproduced, translated or sold. No changes or other purposes are permitted without the prior written consent of Vantron. Vantron reserves the right of all publicly-released copies of this manual. 1.2 Notes Applicable notes are listed in the following table: Sign Notice Type Description Notice Important information and regulations Caution Caution for latent damage to system or harm to personnel 1.3 Statement It is recommended to read and comply with this manual before operating VT-M2M LV which provides important guidance and helps decreasing the danger of injury, electric shock, fire, or any damage to the device. 1.4 Disclaimer Vantr…

Text truncated - open the document above for the full version.

Chengdu Vantron Technology, Ltd. No.5 GaoPeng Road, Hi-Tech Zone, Chengdu, SiChuan, P.R. China Tel: +86-028-85123930, Fax:+86-028-85123935 FCC Authorization Date: 2015-3-17 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, Chengdu Vantron Technology, Ltd. the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corp. to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Typed or Printed Name: Wang Xi Title:COO Signature:

Chengdu Vantron Technology, Ltd. No.5 GaoPeng Road, Hi-Tech Zone, Chengdu, SiChuan, P.R. China Tel: +86-028-85123930, Fax:+86-028-85123935 Date: 2015-03-17 To: Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue Sunnyvale, CA 94089 Dear Sir/Madam, Re: Declaration for Bluetooth function closed We, Chengdu Vantron Technology, Ltd., hereby authorize Bay Area Compliance to act as a laboratory for testing and test report generation for the following product, (Product name: M2M Gateway, Model: VT-M2M-V) The MUTRATA module (CMEH19BAAA-001) was built into this product without any modification. This module supports WLAN and Bluetooth, but Bluetooth function was disabled by software, when producing. Signature: Typed or Printed Name: Wang Xi Title: COO

Vantron Statement About FCC and IC test to Chengdu Vantron Technology,Ltd., Model: VT-M2M-LV, which uses Telit 3G/2G module and Digi Zigbee module, Vantron only installs and runs the modules into VT-M2M-LV device, do not change the modules. Module Certification as follows, Telit 3G module HE910 FCC ID: RI7HE910, IC: 5131A-HE910 Telit 3G module DE910-DUAL FCC ID: RI7DE910-DUAL, IC: 5131A-DE910DUAL Telit 2G module GE910-QUAD V3 FCC ID: RI7GE910Q3, IC: 5131A-GE910Q3 Digi ZigBee Module FCC ID: MCQ-XBS2C IC: 1846A-XBS2C Chengdu Vantron Technology Ltd. March 19, 2015 Signature: Type or printed Name: Wang Xi Title: COO

EXHIBIT B – EUT EXTERNAL PHOTOGRAPHS EUT – Top View EUT – Bottom View EUT – Side 1 View EUT – Side 2 View EUT – Front Port View EUT – Rear Port View EUT – GPS Antenna View EUT – WLAN Antenna View EUT – 3G Antenna View EUT – Zigbee Antenna View Adapter 1 View Adapter 2 View

EXHIBIT A – FCC LABELING AND LABEL LOCATION FCC ID Label FCC ID Label Location

EXHIBIT A – FCC LABELING AND LABEL LOCATION FCC ID Label FCC ID Label Location

EXHIBIT A – FCC LABELING AND LABEL LOCATION FCC ID Label FCC ID Label Location

EXHIBIT C – EUT INTERNAL PHOTOGRAPHS EUT – Uncover View EUT – Circuit Board View Wifi Module Zigbee Module 3G Module GPS EUT – Mainboard Top View (Opening Module Shield) EUT – Mainboard Bottom View EUT – 3G Module Top View (For HE910) EUT – 3G Module Bottom View (For HE910) Multi-listing 3G module: DE910-DUAL DE910-DUAL Top View DE910-DUAL Bottom View Multi-listing 3G module: GE910-QUAD V3 GE910-QUAD V3 Top View GE910-QUAD V3 Bottom View EUT – Zigbee Module Top View EUT – Zigbee Module Bottom View

Bay Area Compliance Laboratories Corp. (Chengdu) Report No.: RSC150128002 Page 12 of 72 FCC §15.247 (i), §2.1091 & §1.1307(b)(1) - Maximum Permissible Exposure (MPE) Applicable Standard According to subpart 15.247(i)and subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 - - f/1500 30 1500–100,000 - - 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. Calculated Formulary: Predication of MPE limit at a given distance S = PG/4πR² Where: S = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); Bay Area Compliance Laboratories Corp. (Chengdu) Report No.: RSC150128002 Page 13 of 72 The host VT-M2M-LV may contain 3 RF modules: one 3G module (FCC ID: RI7HE910, FCC ID: R17DE910-DUAL & FCC ID: R17GE910Q3), one Zigbee module (FCC ID: MCQ- XBS2C) & one WLAN module. The rated output power and antenna gain in the below table: WIFI+Zigbee+GSM (FCC ID: RI7HE910) Frequency Antenna Gain Conducted Power Evaluati on Distance Power Density Limit MPE Ratios Mode MHz dBi numer ic dBmmW cm mW/cm 2 mW/cm 2 (%) 2412-2462 2 1.58 17.2653.21 20 0.017 1.0 1.7 WIFI 2422-2452 2 1.58 14.0325.29 20 0.010 1.0 1.0 Zigbee 2405-2480 2 1.58 10.0810.19 20 0.003 1.0 0.3 824-849 1 1.26 24.00251.19 20 0.063 0.55 11.5 GSM 1850-1910 1 1.26 20.90123.03 20 0.031 1.0 3.1 Total sum of MPE ratios (%) 13.5 For WIFI and Zigbee module transmit simultaneously, the worst case for MPE was chosen to be added up. For GSM mode, the worst case for MPE was chosen to be added up Result: 13.5%<1, the device meet FCC MPE at 20 cm distance. WIFI+Zigbee+EGPRS (FCC ID: RI7HE910 ) Frequency Antenna Gain Conducted Power Evaluat ion Distanc e Power Density Limit MPE Ratios Mode MHz dBi numericdBm mW cm mW/cm 2 mW/cm 2 (%) 2412-2462 2 1.58 17.26 53.21 20 0.017 1.0 1.7 WIFI 2422-2452 2 1.58 14.03 25.29 20 0.010 1.0 1.0 Zigbee 2405-2480 2 1.58 10.08 10.19 20 0.003 1.0 0.3 slot 1 1 1.26 20.90 123.03 20 0.031 0.55 5.6 slot 2 1 1.26 23.70 234.42 20 0.059 0.55 10.7 slot 3 1 1.26 24.50 281.84 20 0.071 0.55 12.9 824- 849 slot 4 1 1.26 25.50 354.81 20 0.089 0.55 16.2 slot 1 1 1.26 19.60 91.20 20 0.023 1.0 2.3 slot 2 1 1.26 22.40 173.78 20 0.044 1.0 4.4 slot 3 1 1.26 23.50 223.87 20 0.056 1.0 5.6 EGPRS 1850- 1910 slot 4 1 1.26 24.20 263.03 20 0.066 1.0 6.6 Total sum of MPE ratios (%) 18.2 For WIFI and Zigbee module transmit simultaneously, the worst case for MPE was chosen to be added up. For EGPRS mode, the worst case for MPE was chosen to be added up Result: 18.2%<1, the device meet FCC MPE at 20 cm distance. Bay Area Compliance Laboratories Corp. (Chengdu) Report No.: RSC150128002 Page 14 of 72 WIFI+Zigbee+WCDMA (FCC ID: RI7HE910) Frequency Antenna Gain Conducted Power Evaluati on Distance Power Density Limit MPE Ratios Mode MHz dBi numer ic dBmmW cm mW/cm 2 mW/cm 2 (%) 2412-2462 2 1.58 17.2653.21 20 0.017 1.0 1.7 WIFI 2422-2452 2 1.58 14.0325.29 20 0.008 1.0 0.8 Zigbee 2405-2480 2 1.58 10.0810.19 20 0.003 1.0 0.3 1850-1910 1 1.26 26.39435.51 20 0.109 1.0 10.9 WCDMA 824-849 1 1.26 26.63460.26 20 0.115 0.55 20.9 Total sum of MPE ratios (%) 22.9 For WIFI and Zigbee module transmit simultaneously, the worst case for MPE was chosen to be added up. For WCDMA mode, the worst case for MPE was chosen to be added up Result: 22.9%<1, the device meet FCC MPE at 20 cm distance. WIFI+Zigbee+GPRS(FCC ID: RI7HE910 ) Frequency Antenna Gain Conducted Power Evaluati on Distance Power Density Limit MPE Ratios Mode MHz dBi numer ic dBm mW cm mW/cm 2 mW/cm 2 (%) 2412-2462 2 1.58 17.2653.21 20 0.017 1.0 1.7 WIFI 2422-2452 2 1.58 14.0325.29 20 0.010 1.0 1.0 Zigbee 2405-2480 2 1.58 10.0810.19 20 0.003 1.0 0.3 slot 1 1 1.26 24.00251.19 20 0.063 0.55 11.5 slot 2 1 1.26 26.40436.52 20 0.109 0.55 19.8 slot 3 1 1.26 27.40549.54 20 0.138 0.55 25.1 824- 849 slot 4 1 1.26 27.80602.56 20 0.151 0.55 27.5 slot 1 1 1.26 20.90123.03 20 0.031 1.0 3.1 slot 2 1 1.26 23.40218.78 20 0.055 1.0 5.5 slot 3 1 1.26 24.50281.84 20 0.071 1.0 7.1 GPRS 1850 - 1910 slot 4 1 1.26 24.80302.00 20 0.076 1.0 7.6 Total sum of MPE ratios (%) 29.5 For WIFI and Zigbee module transmit simultaneously, the worst case for MPE was chosen to be added up. For GPRS mode, the worst case for MPE was chosen to be added up Result: 29.5%<1, the device meet FCC MPE at 20 cm distance. Bay Area Compliance Laboratories Corp. (Chengdu) Report No.: RSC150128002 Page 15 of 72 WIFI+Zigbee+CDMA (FCC ID: RI7DE910-DUAL) Frequency Antenna Gain Conducted Power Evaluati on Distance Power Density Limit MPE Ratios Mode MHz dBi numer ic dBmmW cm mW/cm 2 mW/cm 2 (%) 2412-2462 2 1.58 17.2653.21 20 0.017 1.0 1.7 WIFI 2422-2452 2 1.58 14.0325.29 20 0.008 1.0 0.8 Zigbee 2405-2480 2 1.58 10.0810.19 20 0.003 1.0 0.3 1850-1910 1 1.26 24.74297.85 20 0.075 1.0 7.5 CDMA 824-849 1 1.26 24.37273.53 20 0.069 0.55 12.5 Total sum of MPE ratios (%) 14.5 For WIFI and Zigbee module transmit simultaneously, the worst case for MPE was chosen to be added up. For CDMA mode, the worst case for MPE was chosen to be added up Result: 14.5%<1, the device meet FCC MPE at 20 cm distance. WIFI+Zigbee+GSM (FCC ID: RI7GE910Q3) Frequency Antenna Gain Conducted Power Evaluati on Distance Power Density Limit MPE R…

Text truncated - open the document above for the full version.

Note: This test report was prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Chengdu). Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. This report was valid only with a valid digital signature. FCC PART 15.247 TEST REPORT For Chengdu Vantron Technology, Ltd. No.5 GaoPeng Road, Hi-Tech Zone, Chengdu, SiChuan, P.R. China 610045 Report Type: Original Report Product Name: M2M Gateway Test Engineer: Kevin Tao Report Number: RSC150128002 Report Date: 2015-02-09 Reviewed By: Harry Wu Technical Leader Test Laboratory: Bay Area Compliance Laboratories Corp. (Chengdu) 5040, HuiLongWan Plaza, No. 1, ShaWan Road, JinNiu District, ChengDu, China Tel: 028-65523123, Fax: 028-65525125 www.baclcorp.com FCC ID: 2AAGEVTM2M-LV Bay Area Compliance Laboratories Corp. (Chengdu) Report No.: RSC150128002 Page 2 of 72 TABLE OF CONTENTS GENERAL INFORMATION........................................................................................................................................4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)................................................................................4 OBJECTIVE..................................................................................................................................................................4 RELATED SUBMITTAL(S)/GRANT(S)............................................................................................................................4 TEST METHODOLOGY.................................................................................................................................................5 TEST FACILITY.............................................................................................................................................................5 SYSTEM TEST CONFIGURATION...........................................................................................................................6 DESCRIPTION OF TEST CONFIGURATION...................................................................................................................6 EUT EXERCISE SOFTWARE........................................................................................................................................7 EQUIPMENT MODIFICATIONS......................................................................................................................................7 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS......................................................................................................8 EXTERNAL I/O CABLE.................................................................................................................................................8 BLOCK DIAGRAM OF TEST SETUP..............................................................................................................................9 SUMMARY OF TEST RESULTS.............................................................................................................................11 FCC §15.247 (i), §2.1091 & §1.1307(b)(1) - Maximum Permissible Exposure (MPE).....................................12 APPLICABLE STANDARD............................................................................................................................................12 FCC §15.203 - Antenna Requirement...................................................................................................................17 APPLICABLE STANDARD............................................................................................................................................17 ANTENNA CONNECTOR CONSTRUCTION..................................................................................................................17 FCC §15.207 (a) – AC Line Conducted Emissions...........................................................................................18 APPLICABLE STANDARD............................................................................................................................................18 MEASUREMENT UNCERTAINTY.................................................................................................................................18 EUT SETUP...............................................................................................................................................................18 EMI TEST RECEIVER SETUP....................................................................................................................................19 TEST PROCEDURE....................................................................................................................................................19 CORRECTED AMPLITUDE & MARGIN CALCULATION.................................................................................................19 TEST EQUIPMENT LIST AND DETAILS.......................................................................................................................20 TEST RESULTS SUMMARY........................................................................................................................................20 TEST DATA................................................................................................................................................................20 FCC §15.209, §15.205 & §15.247(d) - Spurious Emissions.............................................................................25 APPLICABLE STANDARD............................................................................................................................................25 MEASUREMENT UNCERTAINTY..........................................................................................…

Text truncated - open the document above for the full version.

EXHIBIT D – TEST SETUP PHOTOGRAPHS Conducted Emissions Test Setup – Front View (for Adapter 1) Conducted Emissions Test Setup – Side View (for Adapter 1) Conducted Emissions Test Setup – Front View (for Adapter 2) Conducted Emissions Test Setup – Side View (for Adapter 2) Below 1GHz Radiated Emissions Test Setup - Front View (for Adapter 1) Radiated Emissions Test Setup - Rear View (for Adapter 1) Radiated Emissions Test Setup - Front View (for Adapter 2) Radiated Emissions Test Setup - Rear View (for Adapter 2) Above 1GHz Radiated Emissions Test Setup - Front View Radiated Emissions Test Setup - Rear View
