2AAGEVTM2M-TCVMM2M Gateway

VT-M2M-TC VM All Rights Reserved VT‐M2M‐TC VM User’s Manual Chengdu Vantron Technology, Ltd. www.vantrontech.com.cn VT-M2M-TC VM All Rights Reserved Revision History: No. Version Description Date 1 V1.0 First release Aug.30, 2013 2 V2.1 Change SmartDisplayAudio tomono line‐out( left channel) Oct.10, 2013 3 V2.2 Add FCC warning statement Dec. 11, 2013 4 V2.3 Change power in to DC6‐36V( default 12V) Dec. 16, 2013 5 V2.4 Update product picture Jan. 2, 2014 6 V2.5 Update the order informationJan.17,2014 7 V2.6 Add 802.11amode Add install requirements Jan 23,2014 8 V2.7 Update product picture Feb 20,2014 VT-M2M-TC VM All Rights Reserved Table of Contents Part I：Hardware Platform......................................................................................................... 5 1 Foreword ................................................................................................................................ 6 1.1 Copyright Notice ....................................................................................................................6 1.2 Notes ......................................................................................................................................6 1.3 Statement ..............................................................................................................................6 1.4 Disclaimer ..............................................................................................................................6 1.5 Limitation of Liability/Non‐warranty .....................................................................................7 1.6 Safety Instructions .................................................................................................................7 1.7 Precautions ............................................................................................................................7 1.8 Safety Instructions for Power Cables and Accessories ...........................................................7 2 Overview ................................................................................................................................ 9 2.1 Introduction ...........................................................................................................................9 2.2 Product Series ..................................................................................................................... 10 3 M2M‐TC VM Hardware Instructions ...................................................................................... 11 3.1 Product Appearance ........................................................................................................... 11 3.2 Specifications ...................................................................................................................... 12 3.3 Interface Instructions .......................................................................................................... 14 3.4 Dimension ........................................................................................................................... 15 3.5 Interface Description .......................................................................................................... 16 3.5.1 Wide‐Range Power Interface ............................................................................... 16 3.5.2 Smart Display Connector ...................................................................................... 18 3.5.3 Ethernet Interface .................................................................................................20 3.5.4 D Sub‐9 RS232 Connector .................................................................................... 21 3.5.5 RS232/485,CAN,External IO Connector ................................................................. 22 3.5.6 VGA Interface ....................................................................................................... 23 3.5.7 USB Host Connector ............................................................................................. 24 3.5.8 LED ....................................................................................................................... 24 3.6 Operation Notice .................................................................................................................25 3.6.1 Change SIM Card .................................................................................................25 4 Tips ...................................................................................................................................... 26 Part II：Software Reference ..................................................................................................... 28 1 Introduction .......................................................................................................................... 28 1.1 About This Manual ................................................................................................. 28 1.2 Linux OS Support .................................................................................................... 28 1.3 Sample Programs .................................................................................................... 28 1.4 Functionalities layout .............................................................................................. 29 2 Base Control ......................................................................................................................... 30 2.1 Power Control.......................................................................................................... 30 2.2 Can Control .............................................................................................................. 30 2.3 GPIO Control ............................................................................................................ 30 2.4 Serial COM Control .......................................…

Text truncated - open the document above for the full version.

Company: Chengdu Vantron Technology, Ltd Address: 3rd floor, 3rd building, No.9, 3rd WuKe East Street, WuHou District, Chengdu, P.R. China 610045 Tel: 86-28-8512-3930, Fax: 86-28-8512-3935 FCC Authorization Date: 2013-10-12 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We C C h h e e n n g g d d u u V V a a n n t t r r o o n n T T e e c c h h n n o o l l o o g g y y , , L L t t d d the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corp. to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Typed or Printed Name: Wang, Xi Title: COO

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT – All View EUT – Top View EUT –Bottom View EUT –Side View EUT –Side View EUT –Port View EUT – Port View EUT – CDMA&Wifi&GPS Antenna View EUT – BT Antenna View

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label Proposed FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label Here

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT – Uncover View EUT – Remove sub PCB View EUT –Uncover Heat Sink of sub PCB View EUT – Sub PCB Top View EUT –Sub PCB Bottom View EUT –Back Case Uncover View EUT –Uncover Main PCB View EUT – Main PCB Top View EUT – Disk Uncover View EUT –Disk Borad Top View EUT – Disk Board Bottom View EUT –RF Chip Uncover View EUT – CDMA Chip Top View EUT –CDMA Chip Bottom View EUT –Wifi Chip Top View EUT – Wifi Chip Bottom View EUT –GPS Chip Uncover View EUT – GPS Chip Top View EUT – GPS Chip Bottom View EUT – Main PCB Top View EUT – Main PCB Bottom View

Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: R2SC131023050-00A FCC Part 15.247 Page 9 of 22 FCC §15.247 (i) & §1.1310 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart 15.247(i)and subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. Per 447498 D01 General 25 RF Exposure Guidance v05r01, simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modeled or measured field strengths or power density, is ≤ 1.0. Calculated Formulary: Predication of MPE limit at a given distance S = PG/4πR² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: R2SC131023050-00A FCC Part 15.247 Page 10 of 22 Calculated Data: RF module Frequency band Antenna Gain Conducted Power Duty cycle Evaluation Power Density MPE Limit MPE Ratios (MHz) (dBi) (numeric)(mW) (%)(cm) (mW/cm 2 ) (mW/cm 2 ) (%) WIFI* 2412-2462 2.1 1.62 117 10020 0.038 1 3.77 2422-2452 2.1 1.62 32 10020 0.010 1 1.03 5475-5825 2.1 1.62 36 10020 0.012 1 1.16 5755-5795 2.8 1.91 120 10020 0.046 1 4.56 5190-5230 3.8 2.40 30 10020 0.014 1 1.43 5180-5240 3.8 2.40 32 10020 0.015 1 1.53 BT 2402-2480 2.5 1.78 4 10020 0.001 1 0.13 CDMA** 824.7- 848.31 2.1 1.62 298 10020 0.096 0.55 17.48 1851.25- 1908.75 3.0 2.00 274 10020 0.109 1 10.86 Total sum of MPE ratios (%) 22.17 Note： * For WIFI module, 2.4GHz and 5GHz band can’t transmit simultaneously, the worst case for MPE was chosen to be added up. * For CDMA module, the worst case for MPE was chosen to be added up. Result: 22.17 %< 1, the device meet FCC MPE at 20 cm distance.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, or any agency of the Federal Government. * This report may contain data that are not covered by the NVLAP accreditation and shall be marked with an asterisk “★” (Rev.2) This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 15.247 TEST REPORT For Chengdu Vantron Technology, Ltd. No. 5 GaoPeng Road, Hi-Tech Zone, Chengdu, Sichuan 610045, China FCC ID: 2AAGEVTM2M-TCVM Report Type: Original Report Product Type: M2M Gateway Test Engineer: Ares Liu Report Number: R2SC 131023050-00A Report Date: 2014 -02-11 Reviewed By: Jerry Zhang EMC Manager Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.69 Pulongcun, Puxinhu Industrial Zone, Tangxia, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: R2SC131023050-00A FCC Part 15.247 Page 2 of 22 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 3 TEST METHODOLOGY .................................................................................................................................................. 3 TEST FACILITY ............................................................................................................................................................. 3 SYSTEM TEST CONFIGURATION .......................................................................................................................... 5 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 5 EUT EXERCISE SOFTWARE .......................................................................................................................................... 5 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 6 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 6 EXTERNAL CABLE ........................................................................................................................................................ 6 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 7 SUMMARY OF TEST RESULTS ............................................................................................................................... 8 FCC §15.247 (i) & §1.1310 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) ......................................... 9 APPLICABLE STANDARD .............................................................................................................................................. 9 FCC §15.203 - ANTENNA REQUIREMENT ........................................................................................................... 11 APPLICABLE STANDARD ............................................................................................................................................ 11 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 11 FCC §15.209, §15.205 & §15.247(d) - SPURIOUS EMISSIONS ............................................................................. 12 APPLICABLE STANDARD ............................................................................................................................................ 12 MEASUREMENT UNCERTAINTY .................................................................................................................................. 12 EUT SETUP ................................................................................................................................................................ 12 EMI TEST RECEIVER & SPECTRUM ANALYZER SETUP .............................................................................................. 13 TEST PROCEDURE ...................................................................................................................................................... 13 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 14 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 14 TEST RESULTS SUMMARY .......................................................................................................................................... 14 TEST DATA ................................................................................................................................................................ 15 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: R2SC131023050-00A FCC Part 15.247 Page 3 of 22 GENERAL INFORMATION Pro…

Text truncated - open the document above for the full version.

TCB GRANT OF EQUIPMENT AUTHORIZATION TCB Certification Issued Under the Authority of the Federal Communications Commission By: ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 Date of Grant: 09/13/2010 Application Dated: 09/11/2010 Intel Mobile Communications 100 Center Point Circle Suite 200 Columbia, SC 29210 Attention: Steven Hackett , Product Regulations Engineer NOT TRANSFERABLE EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. FCC IDENTIFIER: PD962205ANH Name of Grantee: Intel Mobile Communications Equipment Class: Digital Transmission System Notes:Intel Centrino Advanced-N 6205 Modular Type:Single Modular Grant Notes FCC Rule Parts Frequency Range (MHZ) Output Watts Frequency Tolerance Emission Designator CC MO 15C2412.0-2462.00.117 CC MO 15C2422.0-2452.00.032 CC MO 15C5745.0-5825.00.036 CC MO 15C5755.0-5795.00.12 Power Output listed is conducted. This filing is a modular approval. This module is approved for use only in the mobile configurations described in this filing. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain maybe used with this transmitter. The antenna used for this transmitter must not be co-located with any other transmitters within a host device, except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Device is a client only device containing a 2 x 2 MIMO configuration, enabled for either 2.4 or 5 GHz band of operations. CC: This device is certified pursuant to two different Part 15 rules sections. MO: This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Radiated Emission – Front View (Below 1GHz) Radiated Emission – Rear View (Below 1GHz) Radiated Emission – Front View (Above 1GHz) Radiated Emission – Rear View (Above 1GHz)
