2AAGJHEOS514AWireless TV Sound System

HEOS HomeCinema QUICK START GUIDE HEOS HC E3 QSG trial.indd 12015/03/12 10:56:47 1 BEFORE YOU BEGIN The HEOS HomeCinema is designed to enhance the sound of your TV and allow you to enjoy HEOS Wireless Multi-Room Sound. Make sure you have the following items in working order: Apple iOS or Android mobile device connected to your network TV Internet Connection Wi-Fi Router HEOS HC E3 QSG trial.indd 12015/03/12 10:56:48 HEOS HomeCinema QUICK START GUIDE 2 English Français Español Carefully unpack your new HEOS HomeCinema. Verify that the following items are included in the box. STEP 1: UNPACK HEOS HC E3 QSG trial.indd 22015/03/12 10:56:49 33 Verify that the following items are included in the accessories box. STEP 1: UNPACK 1/8 inch (3.5 mm) stereo cable HDMI cableDigital optical cableRCA to 1/8 inch (3.5 mm) adaptor Ethernet cable IR blasterPower cord for Soundbar (3.28 ft / 1.0 m) AC adaptor for Soundbar Short feet (3/4 inch / 19 mm) Tall feet (1 1/4 inch / 31 mm) Non-skid adhesive pads for Subwoofer Non-skid adhesive pads for Soundbar Power cord for Subwoofer (6.56 ft / 2.0 m) Wall mount template HEOS HC E3 QSG trial.indd 32015/03/12 10:56:50 HEOS HomeCinema QUICK START GUIDE 4 English Français Español Placing the HEOS HomeCinema at a convenient location near the TV. PLACING THE SOUNDBAR STEP 2: PLACE OPTIONAL The HEOS HomeCinema Soundbar can be wall-mounted using the integrated keyhole mounts. Please refer to the wall mount template located behind the soundbar in the product carton. HEOS HomeCinema has two sets of feet - short and tall - that raise the Soundbar off the shelf. HEOS HC E3 QSG trial.indd 42015/03/12 10:56:50 55 Attach the included non-skid adhesive pads to the four corners of the subwoofer’s side or bottom if you are placing it on a hard surface. PLACING THE SUBWOOFER STEP 2: PLACE 1 2 Place the Subwoofer in a convenient location on the floor near the Soundbar. HEOS HC E3 QSG trial.indd 52015/03/12 10:56:51 HEOS HomeCinema QUICK START GUIDE 6 English Français Español Connect the power cord to the HEOS HomeCinema and a wall outlet. STEP 3: CONNECT OPTIONAL If you are connecting the HEOS HomeCinema to a wired network, connect the included Ethernet cable between the HEOS HomeCinema and your router. Do not connect the Ethernet cable if you are connecting your HEOS HomeCinema to a wireless network. (3.28 ft / 1.0 m) HEOS HC E3 QSG trial.indd 62015/03/12 10:56:52 7 STEP 3: CONNECT Connect the power cord to the Subwoofer of the HEOS HomeCinema and a wall outlet. (6.56 ft / 2.0 m) HEOS HC E3 QSG trial.indd 72015/03/12 10:56:53 HEOS HomeCinema QUICK START GUIDE 8 English Français Español STEP 4: CONTROL Download the HEOS by Denon App. Go to the App Store SM or to Google Play TM and search for “HEOS by Denon” to download and install. Launch the HEOS App and follow the instructions in the app. 1 2 HEOS HC E3 QSG trial.indd 82015/03/12 10:56:54 9 For further information, please visit HEOSbyDenon.com STEP 5: ADD DEVICE ENJOY! Music Settings Add Device 1 2 HEOS HC E3 QSG trial.indd 92015/03/12 10:56:54 HEOS HomeCinema QUICK START GUIDE 10 English Français Español • For more information, visit www.HEOSbyDenon.com • Refer to the Online Manual for other functions information and operation procedure details. manuals.denon.com/HEOSHC/ALL/EN OWNER'S MANUAL HEOS HC E3 QSG trial.indd 102015/03/12 10:56:55 11 BASIC TROUBLESHOOTING My HEOS device won’t connect to my network using the audio cable • Make sure your mobile device is connected to your wireless network before setting up your HEOS device. • Alternatively, you can connect your HEOS device to your network router using the included Ethernet cable. Once connected via Ethernet, the HEOS by Denon App should recognize the HEOS device and you can manually move it to your wireless network using Settings/My Devices/Device_Name/Advanced/Network Settings. I get a message “Device was not found” • Move your HEOS device closer to your wireless router. • Your HEOS device and controller device may not be on the same network. Verify that the controller device is on the same network as your HEOS device. This is usually confi gured under the Settings feature on your mobile device. If you have more than one network, your device may hop to a diff erent network as you move around your home. • Make sure you don’t have any other electronic devices interfering with your wireless network signals. Microwave ovens, cordless phones, and some televisions can cause wireless network interference. • If your HEOS devices are located far away from your router, consider adding a wireless range extender like the HEOS Extend. • In case your wireless router is incompatible with your HEOS device, please use the optional HEOS Extend Wireless Range Extender and hard-wire it to your router. Music cuts out or delays sometimes • Make sure your Internet connection is operating correctly. • If you are sharing your network with other users or devices, they may be using most of your bandwidth (especially if they are streaming video). • Make sure your HEOS devices are within range of your wireless network. • Make sure your HEOS devices are not located near other electronic devices that could interfere with it’s wireless connectivity (like microwave ovens, cordless phones, TVs, etc...). No Subwoofer sound, sound interrupted, or noise occurring • Check that the status LED is lit in green on the Subwoofer. When the Status LED is fl ashing in red, disconnect from the wall outlet and then reconnect to it, or try to pair again. 1. Press the Pair Button on the Subwoofer until the Status LED fl ashes red rapidly. 2. Press the Pair Button on the back of the Soundbar. The Status LED on the Subwoofer will be solid green. • When there is an obstacle between the Soundbar and the Subwoofer, remove it or place the Subwoofer closer to the Soundbar. HEOS HC E3 QSG trial.indd 112015/03/12 10:56:56 HEOS HomeCinema QUICK START GUIDE 12 English Français Español I hear a delay when using the AUX Input with my…

Text truncated - open the document above for the full version.

CERTIFICATE OF COMPLIANCE Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the BTL EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Wireless TV Sound System Model Name HEOS HomeCinema Brand Name DENON Applicant Tymphany HK Limited Address Room 1307-8, Dominion Centre, 43-59 Queen’s Road East, WanChai, Hong Kong Standard(s) FCC Part 15, Subpart B: 2014 ANSI C63.4-2009 Report(s) BTL-FCCE-1-1503C045 The test data, data evaluation, and equipment configuration contained in our test report(s) above was(were) obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory BTL INC. B1, No. 37, Lane 365, Yang-Guang St., Nei-Hu District, Taipei City 114, Taiwan. TEL:+886-2-2657-3299 FAX:+886-2-2657-3331

Project No.: 1503C045 Page 3 of 13 Project No.: 1503C045 Page 4 of 13 Project No.: 1503C045 Page 5 of 13

PART NAME MATERIAL SYM. APPD. ZONE DESCRIPTION CHKD.DWN.DSGND. DIMENSION ENG.ORDER NO. FINISH SCALE UNITS･mm : DATE MODEL SPECS. SAMPLE TOLERANCES UNSPECIFIED DSGND.APPD. PART NO. STD. ° ° ° ° Denon Brand Company NOTES) 1. Detail of printing : refer to the drawing . 2. Printing color : refer to this drawing image. 3. Need engineering sample for approval . 4. Prohibited substances described in the D&M group Green Procurement Guidelines shall not be used / contained in this product including materials, paint, printing ink, etc. Restricted substances described in the D&M group Green Procurement Guidelines shall be kept within each limit specified therein. 5. Need Material Declaration sheet according to the RoHS Directive, at the application of sample approval. Material Declaration sheet shall be fully supported by data of measurement, accompanied by information, e.g. the name of testing organization, test method and so on, so that the results are traceable afterwards. (1-a) Printing color for BKE3 / BKE2 / K : PANTONE 10388C Metallic (2-a) Printing color for WTE3 / WTE2 : PANTONE Cool Gray 4C (1-a) Printing color for BKE3 / BKE2 / K : PANTONE 419C (2-a) Printing color for WTE3 / WTE2 : PANTONE Cool Gray 1C refer to the NOTESrefer to the NOTESrefer to the NOTES B311001For LPP2015/ 3/10S.Kato Need ＨＥＯＳ ＨｏｍｅＣｉｎｅｍａ１ DS-2024-1 1 1 ＰＲＩＮＴＩＮＧ S.Kato 2015- 3-10 WARNING: SHOCK HAZARD - DO NOT OPEN. ATTENTION: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR. No. No. AC IN MADE IN CHINA / FABRIQUE EN CHINE WARNING: SHOCK HAZARD - DO NOT OPEN. ATTENTION: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR. SC-HHC-Bar HEOS HomeCinema Model : System Model : Wireless TV Sound System MADE IN CHINA / FABRIQUE EN CHINE INPUT 24V 3.75A CAN IECS-3(B) / NMB-3(B) THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. CONTAINS TRANSMITTER MODULE FCC ID : U2M-EUB600DM IC : 3616C-EUB600DM SC-HHC-Bar FCC ID : 2AAGJHEOS514 IC : 11154A-HEOS514 0560 No. AC IN V 002961 CONFORMSTO ANSI/ULSTD.60065 CERTIFIEDTO CAN/CSASTD. / / / / / // S&E NETWORK USB 5V/1A CONNECT RESET PAIR AUX IN IR OUT COAXIAL IN OPTICAL IN HDMI IN DC IN HDMI OUT (ARC) TO TV Manufactured under license from Dolby Laboratories. Dolby, Dolby Digital Plus, and the double-D symbol are trademarks of Dolby Laboratories. For DTS patents, see http://patents.dts.com. SC-HHC-Bar HEOS HomeCinema Model : System Model : Wireless TV Sound System MADE IN CHINA / FABRIQUE EN CHINE INPUT 24V 3.75A CAN IECS-3(B) / NMB-3(B) THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. MADE IN CHINA / FABRIQUE EN CHINE WARNING: SHOCK HAZARD - DO NOT OPEN. ATTENTION: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR. CONTAINS TRANSMITTER MODULE FCC ID : U2M-EUB600DM IC : 3616C-EUB600DM SC-HHC-Bar FCC ID : 2AAGJHEOS514 IC : 11154A-HEOS514 0560 No. CAN IECS-3(B) / NMB-3(B) SC-HHC-Sub FCC ID : 2AAGJHEOS514A IC : 11154A-HEOS514A SC-HHC-Sub HEOS HomeCinema Model : System Model : Wireless TV Sound System 120V 60Hz 75W 100V 50/60Hz 75W 230V 50/60Hz 75W THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. SC-HHC-Sub HEOS HomeCinema Model : System Model : Wireless TV Sound System SC-HHC-Sub HEOS HomeCinema Model : System Model : Wireless TV Sound System HEOS Home Cinema Wall Mount Template The HEOS Home Cinema soundbar can be mounted on your wall above or below your TV. 1) Using a level, tape this template to the wall X" (mm) bellow the TV or Y” (mm) above the TV 2) Mark the location of the two mounting holes with a pencil 3) Remove the template and pre drill holes suitable for your mounting hardware (not included) Example) E3 region ( USA )

Project No.: 1503C045 Page 6 of 13 Subwoofer Project No.: 1503C045 Page 7 of 13 Project No.: 1503C045 Page 8 of 13 Project No.: 1503C045 Page 9 of 13 Project No.: 1503C045 Page 10 of 13 Project No.: 1503C045 Page 11 of 13 Project No.: 1503C045 Page 12 of 13 Project No.: 1503C045 Page 13 of 13

FCC RF EXPOSURE REPORT FCC ID: 2AAGJHEOS514A Project No. : 1503C045 Equipment : Wireless TV Sound System Model : SC-HHC-Sub Applicant : Tymphany HK Limited Address : Room 1307-8, Dominion Centre, 43-59 Queen’s Road East, WanChai, Hong Kong According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain(dBi) Note 1 DWPH83 Internal N/A 3.20 TX 2 DWPH83 Internal N/A 3.20 RX TEST RESULTS EUT： Wireless TV Sound System Model Name : SC-HHC-Sub Temperature： 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode ： TX Mode / CH01, CH02, CH03 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 3.2 2.0893 2.48 1.7701 0.000736121 Complies 3.2 2.0893 1.82 1.5205 0.000632341 Complies 3.2 2.0893 1.25 1.3335 0.000554561 Complies Note: the calculated distance is 20 cm.

Report No.: BTL-FCCP-2-1503C045 Page 1 of 6 5 FCC Radio Test Report FCC ID: 2AAGJHEOS514A This report concerns (check one): Original Grant Class II Change Project No. : 1503C045 Equipment : Wireless TV Sound System Model Name : SC-HHC-Sub Applicant : Tymphany HK Limited Address : Room 1307-8, Dominion Centre, 43-59 Queen’s Road East, WanChai, Hong Kong Date of Receipt : Mar. 05, 2015 Date of Test : Mar. 05, 2015 ~ Apr. 03, 2015 Issued Date : Apr. 07, 2015 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-2-1503C045 Page 2 of 6 5 Declaration BTLrepresents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTLshall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTLissued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or an y agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-2-1503C045 Page 3 of 6 5 Table of Contents Page 1 . CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION 13 4.1.2 TEST PROCEDURE 13 4.1.3 DEVIATION FROM TEST STANDARD 13 4.1.4 TEST SETUP 14 4.1.5 EUT OPERATING CONDITIONS 14 4.1.6 EUT TEST CONDITIONS 14 4.1.7 TEST RESULTS 14 4.2 RADIATED EMISSION MEASUREMENT 15 4.2.1 RADIATED EMISSION LIMITS 15 4.2.2 TEST PROCEDURE 16 4.2.3 DEVIATION FROM TEST STANDARD 16 4.2.4 TEST SETUP 16 4.2.5 EUT OPERATING CONDITIONS 17 4.2.6 EUT TEST CONDITIONS 17 4.2.7 TEST RESULTS (9K TO 30MHz) 18 4.2.8 TEST RESULTS (BETWEEN 30 TO 1000 MHz) 18 4.2.9 TEST RESULTS (ABOVE 1000 MHz) 18 5 . 26dB SPECTRUM BANDWIDTH 19 5.1 APPLIED PROCEDURES / LIMIT 19 5.1.1 TEST PROCEDURE 19 5.1.2 DEVIATION FROM STANDARD 19 5.1.3 TEST SETUP 19 5.1.4 EUT OPERATION CONDITIONS 19 5.1.5 EUT TEST CONDITIONS 19 5.1.6 TEST RESULTS 19 6 . MAXIMUM CONDUCTED OUTPUT POWER 20 Report No.: BTL-FCCP-2-1503C045 Page 4 of 6 5 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 20 6.1.1 TEST PROCEDURE 20 6.1.2 DEVIATION FROM STANDARD 21 6.1.3 TEST SETUP 21 6.1.4 EUT OPERATION CONDITIONS 21 6.1.5 EUT TEST CONDITIONS 21 6.1.6 TEST RESULTS 21 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 22 7.1 APPLIED PROCEDURES / LIMIT 22 7.1.1 TEST PROCEDURE 22 7.1.2 DEVIATION FROM STANDARD 22 7.1.3 TEST SETUP 22 7.1.4 EUT OPERATION CONDITIONS 22 7.1.5 EUT TEST CONDITIONS 22 7.1.6 TEST RESULTS 22 8 . POWER SPECTRAL DENSITY TEST 23 8.1 APPLIED PROCEDURES / LIMIT 23 8.1.1 TEST PROCEDURE 23 8.1.1 DEVIATION FROM STANDARD 24 8.1.2 TEST SETUP 24 8.1.3 EUT OPERATION CONDITIONS 24 8.1.4 EUT TEST CONDITIONS 24 8.1.5 TEST RESULTS 24 9 . FREQUENCY STABILITY MEASUREMENT 25 9.1 APPLIED PROCEDURES / LIMIT 25 9.1.1 TEST PROCEDURE 25 9.1.2 DEVIATION FROM STANDARD 25 9.1.3 TEST SETUP 25 9.1.4 EUT OPERATION CONDITIONS 25 9.1.5 EUT TEST CONDITIONS 25 9.1.6 TEST RESULTS 25 10 . MEASUREMENT INSTRUMENTS LIST 26 11 . EUT TEST PHOTOS 28 ATTACHMENT A - CONDUCTED EMISSION 32 ATTACHMENT B - RADIATED EMISSION (9KHZ TO 30MHZ) 35 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 37 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 40 ATTACHMENT E - BANDWIDTH 54 Report No.: BTL-FCCP-2-1503C045 Page 5 of 6 5 Table of Contents Page ATTACHMENT F - MAXIMUM OUTPUT POWER 57 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 59 ATTACHMENT H - POWER SPECTRAL DENSITY 61 ATTACHMENT I - FREQUENCY STABILITY 64 Report No.: BTL-FCCP-2-1503C045 Page 6 of 6 5 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-2-1503C045 Original Issue. Apr. 07, 2015 Report No.: BTL-FCCP-2-1503C045 Page 7 of 6 5 1. CERTIFICATION Equipment : Wireless TV Sound System Brand Name : DENON Model Name : SC-HHC-Sub Applicant : Tymphany HK Limited Manufacturer : D&M Holdings Inc. Address : 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi, Kanagawa, 210-8569 Japan Factory : Premium Loudspeakers (HuiZhou) Co. Ltd Address : Tymphany Industrial Area, Xin Lian Village, Xin Xu Town, Hui Yang District, Hui Zhou City, Guangdong, China Date of Test : Mar. 05, 2015 ~ Apr. 03, 2015 Test Sample : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart E(15.407) / ANSI C63.4: 2009 FCC KDB 789033 D02 General UNII Test Procedures New Rules v01. The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (R…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-1503C045 Page 28 of 6 5 11. EUT TEST PHOTOS Conducted Measurement Photos Report No.: BTL-FCCP-2-1503C045 Page 29 of 6 5 Radiated Measurement Photos 9KHz to 30MHz Report No.: BTL-FCCP-2-1503C045 Page 30 of 6 5 Radiated Measurement Photos 30MHz to 1000MHz Report No.: BTL-FCCP-2-1503C045 Page 31 of 6 5 Radiated Measurement Photos Above 1000MHz
