CQZ501-B iColor Lighting Bluetooth Speaker Instruction Manual (Read before proceeding) Power:  Works on internal rechargeable Lithium-ion battery. Please charge your speaker fully before first use. To charge the battery : Using a DC 5V adaptor (not included) or USB cable (included), insert the jack into the 3.5mm DC hole located in the back of the unit.  A red light in the front will indicate the charging situation. When battery is full, the red light will turn off automatically. Bluetooth Speaker Operation  Turn on the unit by pushing the power ON/OFF switch in the back to ON position. Green light in front indicates the power situation.  Turn on the Bluetooth Function of unit by pushing the Bluetooth ON/OFF switch in the back to ON position. A Blue light will start blinking to indicate the speaker is in paring mode and searching for your Bluetooth mobile device.  Open the Bluetooth function on your device and search the speaker named “SB-01”. After selecting this speaker, your device will pair without a pin. (If your device need pair pin, enter the pin “0000” directly from your device and hit “OK”) .The Blue light will begin to flashing four times every 3 seconds after pair is complete.  Start playing music on your device. Keep your device within 33feet (10m) of your speaker.  Adjust the volume of your device to a comfortable level.  Turn off the unit when not in used. Color Light Operation  Turn on the color light by touching the circular button in the front when the unit is power on.  Translucent cabinet changes in 7 colors gradually every 5 seconds.  Turn off the color light by touching the circular button again. Universal Speaker Operation  For other music devices without Bluetooth, use the auxiliary audio input cable. Insert the 3.5mm jack into the “AUX-IN” hole and the earphone hole on your device.  Turn on the unit and start playing music. Caution:  This is not a toy. Please keep away from small children.  Please keep away from water / heat.  Low power may cause poor connection even no working of Bluetooth.  Do not over charge the battery. FCC STATEMENT  1. This device complies with Part 15 or the FCC Rules. Operation is subject to the following two conditions:  (1) This device may not cause harmful interference, and  (2) This device must accept any interference received, including interference that may cause undesired operation.  2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement:  The device has been evaluated to meet general RF exposure requirement.  The device can be used in portable exposure condition without RF striction. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 or the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications, However, there is no guarantee that interference will not occur in a particular installation. If the equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --- Reorient or relocate the receiving antenna. --- Increase the separation between the equipment and receiver. --- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --- Consult the dealer or an experienced radio/ TV technician for help.

Sure Wave (HongKong) Limited December 30, 2013 To: SIEMIC, INC. 775 Montague Expressway Milpitas , CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We , Sure Wave (HongKong) Limited hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Description: iColor Lighting Bluetooth Speaker Model name: CQZ501-B FCC ID: 2AAPLCQZ501-B We affirm that between SIEMIC and Sure Wave (HongKong) Limited , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Emma Lee / Senior Sales Exceutive Contact information / address: A-703,Building 2, TianAn Cyber Park, Huangge North Road, Longgang District, Shenzhen, 518172, China

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 2.0 Sure Wave (HongKong) Limited December 30, 2013 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: 2AAPLCQZ501-B We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Client’s signature: Client’s name / title: Emma Lee / Senior Sales Exceutive Contact information / address: A-703,Building 2, TianAn Cyber Park, Huangge North Road, Longgang District, Shenzhen, 518172, China

FCC Certification Label Location Sample Label location

FCC Certification label Sample FCC ID: 2AAPLCQZ501-B This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Antenna

FCC ID : 2AAPLCQZ501-B Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 D01 General RF Exposure Guidance v05, section 4.3.1 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, 16 where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) Calculation Value Threshold Value 2402 -0.63 0.86 0.266 3.0 2441 -0.67 0.85 0.265 3.0 2480 0.08 1.01 0.318 3.0 Threshold at which no SAR required is ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A
