2AAT898AP9804AAnker TC930 Bluetooth Keyboard Cover for iPad Air

Anker TC930 Bluetooth Keyboard Cover for iPad Air Package Contents Anker TC930 Bluetooth Keyboard Cover for iPad Air USB charging cable 4 foot pads Welcome guide Features ● Automatic pop-up stand triggered by setting down your tablet in the stand groove. ● Opening and closing the cover turns the keyboard on and off automatically. ● The keyboard automatically connects to your iPad Air. ● Rechargeable lithium battery with an industry-high capacity lasts for 6 months between charges (based on 2 hours of use per day). ● Low-profile, quiet keys enhance the typing experience. ● Stylish, super-slim body fits securely onto your iPad Air and easily into your bag. ● Great for writing messages and emails when you're on the go. Product Overview 加入产品图 (1) Back to Home (2) Brightness Down (3) Brightness Up (4) Keyboard Display (5) Copy (6) Paste (7) Switch Input Language (8) Previous Song (9) Play/Pause (10) Next Song (11) Mute (12) Volume Down (13) Volume Up (14) Screen Lock / Unlock (15) Magnet (16) Stand Groove (17) Pop-up Stand Trigger (18) Caps Lock Indicator (19) Bluetooth Indicator (20) Power Indicator (21) Power Switch Specifications Bluetooth Specification Bluetooth 3.0 Product Dimensions 240 × 175 × 7.4mm / 9.4 × 6.9 × 0.3in Product Weight 328g / 11.6oz Operating Range Up to 10 meters / 33 feet Modulation System GFSK Standby Time 300 days Charge Time 5 hours Uninterrupted Work Time 300 hours Working Temperature -10 - +55°C Lithium Battery Capacity 800mAh Battery’s Lifespan 400 charge cycles Key Life 5 million clicks Pairing Instructions 1. Push the Power Switch to the ON position to turn on the keyboard, then place your device onto the Stand Groove. 2. Simultaneously press the Fn and C keys to enter pairing mode. The blue Bluetooth Indicator will start to flash rapidly. 3. Activate your device’s Bluetooth function and search for the keyboard cover. 4. Once the Bluetooth keyboard cover has been found, click on its name to connect. 5. Enter the password code as displayed on the screen. 6. Once the Bluetooth keyboard cover has successfully connected to your device, the Bluetooth Indicator will turn off. After pairing for the first time, your device will connect to the keyboard automatically when opening the keyboard. Note: In case of connect failure, delete the pairing record from your device, and repeat the procedures above. Power Saving Mode The keyboard cover will enter sleep mode after being idle for 15 minutes. To activate it, press any key and wait for 3 seconds. Charging Instructions When the battery power is low, the Power Indicator will turn red, indicating that it is time to recharge the keyboard cover. 1. Connect the micro end of the USB power cable to the micro USB port on the keyboard cover. 2. Connect the other end of the cable to a power adapter or computer USB port. 3. The Power Indicator will show a solid light while the keyboard cover is charging. Once it is fully charged, the Power Indicator will turn green. Usage Tips ● Do not place heavy objects on the keyboard cover. ● Do not drop the product, bump it against hard surfaces, or dismantle it. ● Keep the product away from oil, chemicals, and liquids. ● Clean the keyboard by lightly wiping it with a slightly damp cloth. ● Dispose of batteries according to local laws. Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving an tenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

NINGBO EMTEK CO., LTD. Statement Feb. 14, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, NINGBO EMTEK CO., LTD. (Address: 1F Building 4, 1177#, Lingyun Road, Ningbo National Hi-Tech Zone, Ningbo, Zhejiang, China) declare for the equipment identified by: Product Description: Anker TC930 Bluetooth Keyboard Cover for iPad Air Model Number: 98AP9804A-BTA Tradename or Brands: ANKER FCC ID: 2AAT898AP9804A We confirm that all the tests for this product according to FCC PART 15.249 were conducted in our test lab. Yours Sincerely, ---------------------------------------------------------- Andy Wang/ Manager NINGBO EMTEK CO., LTD. Tel: 86-574-27907998 Fax: 86-574-27721538

Hunan Ocean Wing E- commerce Technology Co., Ltd. FCC Confidentiality Request Number:CF303 Version:V05 Date: 21-05-2012 (Permanent or also called long term confidentiality is the normal method to keep certain docuements confidential, and may apply to schematics, block diagrams, operational description and bill of materials.) To: Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company nameHunan Ocean Wing E-commerce Technology Co., Ltd. Address25 Floor, Jiatian International Building, #359 Furong Zhonglu, CityChangsha CountryChina request for this certification filing under: Grantee CodeProduct Number FCC ID:2AAT898AP9804A to maintainpermanent confidentialityfor the following documents submitted within this application: (please cross what is applicable, or add other documents, provide the file name and description) ExhibitFile NameDescription √ Operational DescriptionOperational Descriptionexplaining the functioning of the block diagram √ Block DiagramsBlock Diagramsshowing the systematic building blocks of the EUT √ Schematics DiagramsSchematicsshowing components, their values and interconnection Bill of MaterialsList of components used on the PCB’s of the EUT Above materials crossed contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. The documents indicated as confidential above, are not publicly available elsewhere. Attestation: City and Country:Date:Name: (this must be a person) Function:Signature: (or official company stamp) Changsha, China2014-02-11 Anan HuProduct Manager

Hunan Ocean Wing E- commerce Technology Co., We, (the approval holder) Country declare that the following representative (agent): Name (person) Company name Country Type or Model(s) Tradename or Brand(s) We also authorize Teleconformity (Mr. M. Koop, Manager Certification, Address: Rietven 31, 7534NH Enschede, the Netherlands) to apply and sign this application for certification, registration or filing on our behalf (as representative agent or certifler). Attestation: City and Gountry: Date:Name: (this must be a person) Function: Signature: (or otficial company stamp)

Figure 1 The EUT-Front View Figure 2 The EUT- Back View Figure 3 TheEUT-SideView

Label Location On EUT

Product Name:Anker TC930 Bluetooth Keyboard Cover for iPad Air Model No.:98AP9804A-BTA FCC ID:2AAT898AP9804A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Figure 4 The EUT-Inside View Figure 5 The EUT-Inside View Figure 6 PCB of The EUT-Front View Figure 7 PCB of The EUT-Back View Figure 8 PCB of The EUT-Front View Figure 9 PCB of The EUT-Back View

FCC ID: 2AAT898AP9804A Page 1 of 28 Report No.: 201401816F FCC TEST REPORT for Hunan Ocean Wing E-commerce Technology Co., Ltd. Anker TC930 Bluetooth Keyboard Cover for iPad Air Model No.: 98AP9804A-BTA Report Number:201401816F Date of Test:Jan. 16 ~26, 2014 Date of Report:Feb. 07, 2014 Prepared for:Hunan Ocean WingE-commerce TechnologyCo., Ltd. Address:25 Floor, Jiatian International Building, #359 Furong Zhonglu, Changsha, Hunan Province, China Prepared By:Shenzhen Anbotek Compliance Laboratory Limite d Address:1/F., Building 1, SEC Industrial Park, No.0409 Qianhai Road, Nanshan District, Shenzhen, Guangdong, China Tel: (86) 755-26066544 Fax: (86) 755-26014772 FCC ID: 2AAT898AP9804A Page 2 of 28 Report No.: 201401816F TABLE OF CONTENTS Description Page Test Report 1. GENERAL INFORMATION......................................................................................................4 1.1. Description of Device (EUT)................................................................................................................4 1.2. Auxiliary Equipment Used during Test................................................................................................ 5 1.3. Description of Test Facility.................................................................................................................. 5 1.4. Measurement Uncertainty.....................................................................................................................5 2. TEST PROCEDURE....................................................................................................................6 3. CONDUCTED LIMITS...............................................................................................................7 3.1. Block Diagram of Test Setup................................................................................................................7 3.2. Power Line Conducted Emission Measurement Limits (15.207).........................................................7 3.3. Configuration of EUT on Measurement............................................................................................... 7 3.4. Operating Condition of EUT................................................................................................................ 7 3.5. Test Procedure...................................................................................................................................... 8 3.6. Power Line Conducted Emission Measurement Results...................................................................... 8 4. RADIATION INTERFERENCE.............................................................................................. 11 4.1. Requirements (15.249, 15.209):..........................................................................................................11 4.2. Test Procedure.................................................................................................................................... 11 4.3. Test Configuration:............................................................................................................................. 12 4.4. Test Results.........................................................................................................................................13 5. OCCUPIED BANDWIDTH...................................................................................................... 19 5.1. Requirements (15.249):.......................................................................................................................19 5.2. Test Procedure.................................................................................................................................... 19 5.3. Test Configuration:............................................................................................................................. 19 5.4. Test Results.........................................................................................................................................19 6. PHOTOGRAPH......................................................................................................................... 23 6.1. Photo of Conducted Emission Test.....................................................................................................23 6.2. Photo of Radiation Emission Test.......................................................................................................23 APPENDIX I (EXTERNAL PHOTOS)........................................................................................24 APPENDIX II(INTERNAL PHOTOS)........................................................................................26 Appendix I (2 Pages) Appendix II (3 Pages) FCC ID: 2AAT898AP9804A Page 3 of 28 Report No.: 201401816F TEST REPORT Applicant: Hunan Ocean Wing E-commerce Technology Co., Ltd. Manufacturer: Hunan Ocean Wing E-commerce Technology Co., Ltd. EUT: Anker TC930 Bluetooth Keyboard Cover for iPad Air Model No.: 98AP9804A-BTA Serial No.: N/A Trade Mark: ANKER Rating: DC 3.7V, 800 mAH Measurement Procedure Used: FCC Part15 Subpart C, Paragraph 15.207, 15.249 & 15.209 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emissionlevels emanating from the device and the severe levels of the device can endure and itsperformance criterion. The measurement results are contained in this test report andShenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 15 Subpart C requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of Test :Jan. 16 ~26, 2014 Preparedby: (Engineer / Rock Zeng) Reviewer: (Project Manager/Amy Din…

Text truncated - open the document above for the full version.

1. Photo of Power Line Conducted Emission Test 2.Photo of Radiated Emission Test
