2AAUCGMOTMFArgent M5 Wireless RGB Gaming Mouse

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Consult the dealer or an experienced radio/TV technician for help. The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. CAUTION Radiation Exposure Statement: FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from thatto which the receiver is connected. RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. - Reorient or relocate the receiving antenna. Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
 ，，、 !"#$%&'(、)*'(+, - ./01。 34 (5#6789，:;<=>?@。 AB/CDEF GHI J4KLMD N89。
O  #$PQRSTU0VW FXY；[\]VW\^_，`abc ，deLfgVW _h$ij 。 klm FXYno、pq0rs AB/,t VW。 uv FXY，wxYFyz{o g|XY。

Appendix No.: EP-2005T126-1 APPENDIX-EUT PHOTOS Project No.: 2005T126 Page 1 of 16 FCC ID: 2AAUCGMOTMF Appendix No.: EP-2005T126-1 APPENDIX-EUT PHOTOS Project No.: 2005T126 Page 2 of 16 Appendix No.: EP-2005T126-1 APPENDIX-EUT PHOTOS Project No.: 2005T126 Page 3 of 16

DEXIN CORPORATION DEXIN MODEL NO. DRAFTER MATERIAL PART NAME REV 材質代號 UNIT SCALE PART NO.DP449 Eva_Liu 銅版紙+霧P FCC DP449 "曜越" V1.0 F78-1000-028-01W Tolerance ± 0.5 mm 1:1 EnginnerCheckedApproved 当月同一S/N编码原则的S/N码不允许重复 對應表格： 產品序列號的日期代碼： 2020年5月生產的產品，由原先的2020經過代碼轉換，變成XA 變成 GMOTMFHYOOBK01XA000001 共22码, CODE128 REVISIONS DESCRIPTIONREV V2.0 V3.0 V1.0NEW DATE 2020/5/25 Notes: 1. 黏貼位置：滑鼠底部凹槽 2. CODE 128 年份 代碼月份 代碼 年2012 T月1 E 2013H2S 2014E3D 2015 R4 K 2016 M5A 2017 A6 G 2018 L7I 2019 U8 L 2020X9F 2021 A10 R 2022 S11 V 2023 P12 U 2024 O 2025 B 2026 Y 2027 N 2028 Q 2029 W 2030 Z GMOTMFHYOOBK01XA000001 CCXXxxYYyyyZzW FCC ID: 2AAUCGMOTMF 制造年份：變化 46.4 29.5 產品名稱: Argent M5無線RGB電競滑鼠 製造: 中國製造 FCC ID: 2AAUCGMOTMF

Appendix No.: EP-2005T126-1 APPENDIX-EUT PHOTOS Project No.: 2005T126 Page 11 of 16 FCC ID: 2AAUCGMOTMF Appendix No.: EP-2005T126-1 APPENDIX-EUT PHOTOS Project No.: 2005T126 Page 12 of 16 Appendix No.: EP-2005T126-1 APPENDIX-EUT PHOTOS Project No.: 2005T126 Page 13 of 16 Appendix No.: EP-2005T126-1 APPENDIX-EUT PHOTOS Project No.: 2005T126 Page 14 of 16 FCC ID: 2AAUCGMOTMF Appendix No.: EP-2005T126-1 APPENDIX-EUT PHOTOS Project No.: 2005T126 Page 15 of 16 Appendix No.: EP-2005T126-1 APPENDIX-EUT PHOTOS Project No.: 2005T126 Page 16 of 16

Report No.: BTL-FCCP-2-2005T126 Project No.: 2005T126 Page 1 of 40 Report Version: R04 FCC Radio Test Report FCC ID: 2AAUCGMOTMF Report No. : BTL-FCCP-2-2005T126 Equipment : Argent M5 Wireless RGB Gaming Mouse Model Name : GMO-TMF, GMO-TMF-HYOOBK-01, GMO-TMF-HYOOBK-11, GMO-TMF-HYOOWB-11, GMO-TMF-HYOOBK-04 Brand Name : Thermaltake Technology Co., Ltd. Applicant : Thermaltake Technology Co., Ltd. Address : 5F.,No.185,Sec.2,Tiding Blvd.,Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Radio Function : Short Range Devices FCC Rule Part(s) : FCC Part15, Subpart C (15.249) Measurement Procedure(s) : ANSI C63.10-2013 Date of Receipt : 2020/5/27 Date of Test : 2020/5/27 ~ 2020/7/9 Issued Date : 2020/7/9 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Peter Chen, Engineer Approved by : Scott Hsu , Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Report No.: BTL-FCCP-2-2005T126 Project No.: 2005T126 Page 2 of 40 Report Version: R04 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-2-2005T126 Project No.: 2005T126 Page 3 of 40 Report Version: R04 CONTENTS REPORT ISSUED HISTORY 4 1 SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 1.3 TEST ENVIRONMENT CONDITIONS 7 1.4 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 7 1.5 DUTY CYCLE 7 2 GENERAL INFORMATION 8 2.1 DESCRIPTION OF EUT 8 2.2 TEST MODES 9 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 SUPPORT UNITS 11 3 AC POWER LINE CONDUCTED EMISSIONS TEST 12 3.1 LIMIT 12 3.2 TEST PROCEDURE 12 3.3 DEVIATION FROM TEST STANDARD 12 3.4 TEST SETUP 13 3.5 TEST RESULT 13 4 RADIATED EMISSIONS TEST 14 4.1 LIMIT 14 4.2 TEST PROCEDURE 15 4.3 DEVIATION FROM TEST STANDARD 15 4.4 TEST SETUP 15 4.5 EUT OPERATING CONDITIONS 16 4.6 TEST RESULT – 30 MHZ TO 1 GHZ 17 4.7 TEST RESULT – ABOVE 1 GHZ 17 5 BANDWIDTH TEST 18 5.1 APPLIED PROCEDURES / LIMIT 18 5.2 TEST PROCEDURE 18 5.3 DEVIATION FROM STANDARD 18 5.4 TEST SETUP 18 5.5 EUT OPERATION CONDITIONS 18 5.6 TEST RESULTS 18 6 LIST OF MEASURING EQUIPMENTS 19 7 EUT TEST PHOTO 20 8 EUT PHOTOS 20 APPENDIX A AC POWER LINE CONDUCTED EMISSIONS 21 APPENDIX B RADIATED EMISSIONS - 30 MHZ TO 1 GHZ 26 APPENDIX C RADIATED EMISSIONS - ABOVE 1 GHZ 29 APPENDIX D BANDWIDTH 39 Report No.: BTL-FCCP-2-2005T126 Project No.: 2005T126 Page 4 of 40 Report Version: R04 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. 2020/6/16 R01 Revised Typo 2020/6/19 R02 Revised report to address TCB’s comments. 2020/7/8 R03 Revised Typo 2020/7/9 R04 Revised report to address TCB’s comments 2020/7/9 Report No.: BTL-FCCP-2-2005T126 Project No.: 2005T126 Page 5 of 40 Report Version: R04 1 SUMMARY OF TEST RESULTS Test procedures according to the technical standards. FCC Part 15, Subpart C (15.249) Standard(s) Section Description Test Result Judgement Remark 15.207 AC Power Line Conducted Emissions APPENDIX A Pass ------ 15.205 15.209 15.249(a)(d) Radiated Emissions APPENDIX B APPENDIX C Pass ------ 15.215(c) Bandwidth APPENDIX D Pass ------ NOTE: (1) ”N/A” denotes test is not applicable in this Test Report. (2) The report format version is TP.1.1.1. Report No.: BTL-FCCP-2-2005T126 Project No.: 2005T126 Page 6 of 40 Report Version: R04 1.1 TEST FACILITY The test facilities used to collect the test data in this report: No. 68-1, Ln. 169, Sec. 2, Datong Rd., Xizhi Dist., New Taipei City 221, Taiwan The test sites and facilities are covered under FCC RN: 674415 and DN: TW0659. ☒ C05 ☐ CB08 ☐ CB11 ☒ CB15 ☐ CB16 ☒ SR06 No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan The test sites and facilities are covered under FCC RN: 325517 and DN: TW1115. ☐ C03 ☐ CB18 ☐ CB19 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expanded uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k = 2, providing a level of confidence of approximately 95 %. The measurement instrumentat…

Text truncated - open the document above for the full version.

Appendix No.: TP-2005T126-FCCP-1 APPENDIX-TEST PHOTOS Project No.: 2005T126 Page 1 of 3 AC Power Line Conducted Emissions test photos Appendix No.: TP-2005T126-FCCP-1 APPENDIX-TEST PHOTOS Project No.: 2005T126 Page 2 of 3 Radiated emissions test photos 30 MHz to 1 GHz Appendix No.: TP-2005T126-FCCP-1 APPENDIX-TEST PHOTOS Project No.: 2005T126 Page 3 of 3 Radiated emissions test photos Above 1 GHz
