2AAUQ-SAU6691WiFi Smart Plug

Kenmore™ Assurelink Smartplug Model: 105.20002410 P/N: SAU6691 Sears Brands Management Corporation,   s, IL 60179 www.kenmore.com www.sears.com www.kmart.com Use & Care Guide KENMORE LIMITED WARRANTY FOR ONE YEAR from the date of sale this product is warranted against defects in material or workmanship when it is correctly connected, operated and maintained according to all supplied instructions. WITH PROOF OF SALE, return a defective product to the retailer from which it was purchased for free replacement. This warranty is void if this product is ever used for other than private household purposes. This warranty covers ONLY defects in material and workmanship, and will NOT pay for: 1. 2. 3. Disclaimer of implied warranties; limitation of remedies Customer’s sole and exclusive remedy under this limited warranty is product replacement as provided herein.                 one year or the shortest period allowed by law. Seller shall not be liable for incidental or consequential damages. Some states and provinces do not allow the exclusion or limitation of incidental or consequential                      or limitations may not apply to you.              state to state.           WARRANTY CONTENT ASSURELINK INFORMATION ASSURELINK INFORMATION - WARRANTY P 1 IMPORTANT SAFETY INSTRUCTIONS P 2 FEATURES / OPERATIONS P 3 CLEANING / MAINTENANCE INSTRUCTIONS P 4 SPECIFICATIONS / FCC INFORMATION P 5 TROUBLESHOOTING P 6 Refer to the Quick Start / Installation Guide that came with your Kenmore Smart Plug for detailed installation instructions. Also refer to it for information on creating an Assurelink Connected account, setting up your gateway, and setting up your Smart Plug for connected operation from your phone or web browser. This Use & Care Guide contains more detailed information, and instructions for operating the smart Plug from the front panel controls. Damage to or failure of this product if it is not correctly connected, operated or maintained according to all supplied instructions. Damage to or failure of this product resulting from accident, alteration, abuse, misuse or use for other than its intended purpose. !          "        # IMPORTANT SAFETY INSTRUCTIONS 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. Read all of the instructions listed here and/or in the user manual before you operate the device. Give particular attention to all safety precautions. Retain the instructions for future reference. This device must be installed and used in strict accordance with the installation manual and/or use and care guide. Comply with all warning and caution statements in the instructions. Only connect the Smart Plug to a 120V AC power source with circuit breaker or over current protection device. Do not install this Smart Plug at an altitude of over 6500 feet (2000 meters). The Smart Plug should only be used in dry and clean environment. Do not place the unit in bathroom or other area with excessive moisture. This device should not be used in an environment that is below 14°F (-10°C) and above 104°F (40°C), humidity above 80%. !     $ '   *     +;<# Clean the Smart Plug with a dry, soft cloth. Do not use solvents or aggres-     #= > ?          furniture polish, paint thinner, or other household solvents to clean any part of the Smart Plug. This device is designed for household usage only, not suitable for commer- cial and industrial use. If there are any malfunctions appeared during the operation of the Smart '       $ '     # Never drop any liquid or chemical inside of the Smart Plug. DO NOT use outdoors. DO NOT attempt to repair or adjust any electronic or mechanical functions on this Smart Plug. Doing so will void your warranty. The inside of the unit contains no user serviceable parts. When using your equipment, basic safety precautions should always be followed    @     @J      X KEY Key AssureLink LED Power LED FEATURES / OPERATION FUNCTION Z Z Z The assurelink LED will turn ON, when successful connected to Cloud The assurelink LED will turn OFF, when connection to Cloud failed.  [ !*     $   @\'$ enabled router. Z Z When Network is not available, Press and Hold the Key for 5 seconds will allow the Smartplug to seek for WPS enable router for 2 minutes. When Network is available, Press and Hold the Key for 5 seconds will remove all paired network information. Press the key 5 times within 10 seconds will request the cloud to do a factory reset. The LED will turn ON, when power output from Plug. The LED will turn OFF, when no power output from Plug. Key Power LED NEMA 5-15R AssureLink LED CLEANING / MAINTENANCE INSTRUCTIONS Assurelink smartplug provides electricity control and monitoring for your appliances system. It can also be controlled through your mobile smart phone or website remotely. After installation, the smartplug doesn’t need any special handling or attention. In order to maintain the accuracy of the smartplug, you have to clean it regularly. Don’t use any chemical or detergent to clean the smartplug. Just use the wet cloth with water to clean the surface and also the air vent once a month is good enough to maintain the samrtplug working properly. Power on the Plug Plug the Smartplug into 120V AC outlet.  ^  [@[ ! _=+`z     { [ ! _|| +}      ' [ !^  [@[ ! …

Text truncated - open the document above for the full version.

Model CTL6691 and 150.20002410 are

Rating label 41x28mm MAC ID label 41x21mm S-XXXX-XXXX-XXXX smart.ID FPO Energy Management System E213289 Compltes with UL498A and UL916 Made in China YYWW Smart Plug Model: SAU6691 FCC ID: 2AAUQ-SAU6691 IC: 1700A-SAU6691 Indoor dry location use only Input: 120 V~, 60Hz, 15 A Output: 120 V~, 60Hz, 15 A General Purpose 28 mm 41 mm 47.48 mm 13.28 mm FPO 1.86 94” x .52 29 ” QR code should be 0.5"x0.5" Label - adhered to Quick Start Cover Only smart.ID S-XXXX-XXXX-XXXX R R R

Rating label 41x28mm MAC ID label 41x21mm myassurelink.com let’s link-up S-XXXX-XXXX-XXXX smart.ID FPO Energy Management System E213289 Compltes with UL498A and UL916 Made in China YYWW Kenmore Smart Plug Model: 105.20002410 FCC ID: 2AAUQ-SAU6691 IC: 1700A-SAU6691 Indoor dry location use only Input: 120 V~, 60Hz, 15 A Output: 120 V~, 60Hz, 15 A General Purpose Mfd.for Sears Brands Management Corp. 28 mm 41 mm 47.48 mm 13.28 mm FPO 1.86 94” x .52 29 ” QR code should be 0.5"x0.5" Label - adhered to Quick Start Cover Only let’s link-up smart.ID S-XXXX-XXXX-XXXX

Label Location:

FCC ID: 2AAUQ-SAU6691 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = 30*Pout*G/377*d 2 Where Pd = power density in mW/cm 2 ,Pout = output power to antenna in mW; G = gain of antenna in linear scale; d= distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation 802.11b mode Channel Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Lowest (2412MHz) 42.658 0.00849 1.0 PASS Middle (2437MHz) 38.107 0.00758 1.0 PASS Highest (2462MHz) 32.211 0.00641 1.0 PASS 802.11g mode Channel Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Lowest (2412MHz) 41.020 0.00816 1.0 PASS Middle (2437MHz) 37.670 0.00749 1.0 PASS Highest (2462MHz) 32.359 0.00644 1.0 PASS 802.11n(HT20) mode Channel Output power to antenna (mW) Power Density at R=20cm (mW/cm2) Limit (mW/cm 2 ) Result Lowest (2412MHz) 37.325 0.00743 1.0 PASS Middle (2437MHz) 35.400 0.00704 1.0 PASS Highest (2462MHz) 31.915 0.00635 1.0 PASS 802.11n(HT40) mode Channel Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Lowest (2422MHz) 40.365 0.00803 1.0 PASS Middle (2437MHz) 35.237 0.00701 1.0 PASS Highest (2452MHz) 35.645 0.00709 1.0 PASS Remark: antenna gain=0 dBi Remark: antenna gain=0 dBi WORSE CASE :

Global United Technology Services Co., Ltd. Report No.: GTSE14020016001 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. FCC REPORT Applicant: Computime Ltd. Address of Applicant: 9/F, Tower One, Lippo Centre, 89 Queensway, Hong Kong Equipment Under Test (EUT) Product Name: WiFi Smart Plug Model No.: SAU6691, CTL6691, 150.20002410 FCC ID: 2AAUQ-SAU6691 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247:2013 Date of sample receipt: April 08, 2014 Date of Test: April 08-15, 2014 Date of report issued: April 15, 2014 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE14020016001 Global United Technology Services Co., Ltd. Project No.: GTSE140200160RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 63 2 Version Version No. Date Description 00 April 15, 2014 Original Prepared By: Date: April 15, 2014 Project Engineer Check By: Date: April 15, 2014 Reviewer Report No.: GTSE14020016001 Global United Technology Services Co., Ltd. Project No.: GTSE140200160RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 63 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION ......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE ........................................................................................................................................ 6 5.4 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 6 5.5 TEST FACILITY .................................................................................................................................... 7 5.6 TEST LOCATION ................................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1 ANTENNA REQUIREMENT: .................................................................................................................... 9 7.2 CONDUCTED EMISSIONS ................................................................................................................... 10 7.3 CONDUCTED PEAK OUTPUT POWER .................................................................................................. 13 7.4 CHANNEL BANDWIDTH ...................................................................................................................... 18 7.5 POWER SPECTRAL DENSITY ............................................................................................................. 23 7.6 BAND EDGES .................................................................................................................................... 28 7.6.1 Conducted Emission Method ..................................................................................................... 28 7.6.2 Radiated Emission Method ........................................................................................................ 31 7.7 SPURIOUS EMISSION ......................................................................................................................... 36 7.7.1 Conducted Emission Method ..................................................................................................... 36 7.7.2 Radiated Emission Method ...........................................................................…
