1. Light sensor 2. Battery compartment/cover 3. Temperature sensor 4. Probe 5. Moisture sensing head Please read this manual carefully before using this product. Wireless Soil Monitor USER MANUAL (HG01) Introduction Product Diagram Soil Sensor (Transmitter) Soil Monitor (Receiver) 1 1 2 3 4 5 6 7 8 9 10 2 3 4 5 1. Soil moisture readout 2. Light intensity readout 3. Time display 4. Battery level display (monitor) 5. Temperature readout 6. Serial number of the sensor displayed on the screen 7. Battery level display (soil sensor) 8. Wireless transmission signal icon: The icon displays normally indicating it is within the transmission range. The icon blinks indicating it is out of range. 9. Number switch button: Press < or > to switch between dierent sensors displayed on the screen. 10. SET button, °C/°F switch button Thank you for choosing this 4-in-1 Soil Monitor. This product is designed using wireless RF technology to remote monitoring the soil moisture, ambient light and temperature of your plants, and displaying time on the screen. Features such as the large LCD display, stainless steel probe, waterproof housing and multi-device compatibility all contribute to the ease of use and the reliability you would expect from it. Important Notes: FCC Statement 1. Do not cover the light sensor. 2. Do not put the probes into water or other liquids. 3. Do not force the probes into hard soil or at hard objects, as this can easily damage the probes. 4. Please use good quality alkaline batteries. 5. Water may not penetrate the soil evenly, try measuring at dierent locations and depths to get an accurate reading. 6. Please keep the unit away from metal objects, refrigerators, iron doors, metal surface, etc. 7. Please keep the sensor at least 1 meter above the ground level, as close proximity to the ground can aect the wireless working range. 8. It is recommended to take out the probes from the soil and wipe them every 1-2 weeks to ensure the accuracy of data. 9. Please note that the actual operating distance of wireless products may vary due to dierent environmental conditions. Manufacturer's Declaration 1. This product is designed specifically for planting assistance, aiming to help users better understand soil conditions and improve the planting eciency. It provides users with quick and convenient soil testing capabilities. 2. We have made every eort to ensure the accuracy and reliability of the product. However, we cannot guarantee its suitability for scientific research or laboratory analysis in professional fields. 3. The results provided by the soil testing device are based on the analysis of its internal sensors and algorithms. While every eort has been made to ensure accuracy, there may still be some margin of error. Therefore, when making any decisions or adjusting planting practices, please consider other relevant factors and seek professional advice. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Temperature Measurement The sensor can measure the environment temperature of the plant automatically and send the data to the monitor and display on the screen. Press SET button to set the unit of temperature as or . Time Setting Press and hold the SET button for 3 seconds to enter the time setting mode, follow the steps below to set the time: 1. Use the number switch buttons < or > to choose either 24-hour or 12-hour format, press SET button to confirm and switch to the hour setting. 2. Use the number switch buttons < or > to adjust the hours, press SET button to confirm and switch to the minute setting. 3. Use the number buttons < or > to adjust the minutes, press SET button to confirm and save the time. Disconnection Reminder If the sensor (transmitter) and monitor (receiver) are placed beyond the specified working range, the wireless signal on the display screen will blink continuously, indicating that the sensor and monitor have disconnected. After 48 hours, the sensor that is out of range will no longer be displayed on the screen. Please ensure that the sensor and monitor are within the working range to maintain a reliable connection. (Figure 1) (Figure 2) Battery Installation A. Monitor 1. Remove the battery cover. 2. Insert 2 alkaline 1.5V AA batteries, make sure batteries are oriented properly. 3. Put the battery cover back into place. Pairing Moisture Measurement Note: Before the first use, it’s necessary to pair the product. The monitor and sensor will automatically pair when all batteries are installed. Note: Please ensure distance between the monitor and the sensor is within 5 meters when installing batteries. If you have purchased multiple sensors, follow the steps below to automatically pair the product. 1. Install batteries in the monitor first. 2. Install battery in the first sensor, then attach the number label "1" onto the housing of sensor. 3. Install battery in the second sensor, then attach the number label "2" onto the housing of sensor. 4. Follow above steps to install batteries and attach labels for all sensors one by one, make sure the monitor displays the same serial number as the sensor. 5. The monitor and sensor will automatically pair when all batteries are installed. Note: 1. If the pairing order is incorrect, press and hold the No(>) button on the monitor for 10 seconds to restore factory default settings, and then re-pair. 2. In order to ensure the accuracy of data display and the reliability of the product, it is recommended not to add more than 6 sensors. 1. Make sure the probes are clean before use. 2. Soften the soil to be measured, break up pieces if it is hardened. Remove grass, leaves, pebbles and other debris. 1. It is recommended that probe head should be inserted into the soil at least 10cm when make the measurement. 2. When…
