2AAZR8801BBluetooth Stereo Headphones

Instruction manual Welcome to choose our Bluetooth headphone. In order to easy and quick to use the product, we attached this Instruction Manual that let you obtain used method and knowledge of this product. Please be sure to read the instruction carefully before use, so that you can make better use of this product. A. Main features and Technical Parameters 1. Bluetooth audio player 2. Bluetooth Hands free function 3. Φ3.5mm audio input interface 4. Audio output power: 150mW x 2 5. Frequency response: 20Hz-22kHz 6. Distortion :≤0.1% 7. Sub woofer Stereo 8. Built-in rechargeable Lithium Battery 9. External DC power USB 5V charge of the Headphone 10.Charging time: about 2 hours 11.Music playing time: about 8 hours after the full charge 12.3 LED indicators for Bluetooth mode, audio mode and Charging mode B. Product Illustration C. Key functions No Current mode Function operating ButtonOperation Indicator 1 Power off Power on Hands free Long press 2 seconds Green & blue lights flashing alternately 2 Power on Power off Hands free Long press 6 seconds Green & blue lights are off 3 Power on Bluetooth pairing Automatically paired Green & blue lights flashing alternately 4 Power on Bluetooth disconnection Hands free Long press 3 seconds Green & blue lights flashing alternately 5 Power on Call back Hands free Double- click 2 times 6 Call mode Answer calls Hands free Short press once 7 Call mode Reject calls Hands free Long press 2 seconds 8 Talk mode End calls Hands free Short press once 9 Bluetooth mode Volume up Volume + key Short press or long press 10 Bluetooth mode Volume down Volume - key Short press or long press 11 Bluetooth mode Previous song Previous ong key Short press on key 12 Bluetooth mode Next song Next ong key Short press on key 13 Bluetooth mode pause/play Hands free Short press circle 14 AUX mode Mute on/off Hands free Short press circl 15 Any mode Charging Red LED is ON 16 Any mode Battery is full Red light is off 17 Bluetooth mode Low battery alarm Blue light flash continuously 18 Bluetooth mode Audio input Audio cable i is plug on audio input Green light flashes slowly 19 Audio mode Bluetooth mode Unplug audio cable green & blue lights flashing alternately D. Bluetooth mode 1. Long press the “Bluetooth hand free’ key, to turn on the headphone, Bluetooth function is ON automatically for pairing, the green and blue lights are flashing rapidly and produced start-up sound. 2. Turn on your cell phone or Bluetooth device on the Bluetooth function, search for devices in the Bluetooth menu. 3. When "Hiting" appears on the Bluetooth devices list, select "Hiting" establish pairing and connection ( if asked for a passkey, enter 0000 ). When the pairing and connection is successful, it produces a connected tone, and LED change from blue and green lights flashing alternately to blue ON and then green off, headphone is ready for playing music. 4. When the connection is successful pairing, press the Hands free key three seconds, you can disconnect the current Bluetooth devices, blue and green lights flashing alternately again, the Bluetooth headphone is ready for pairing with other device. 5. When the connection between the mobile and headphone is successful, and the headphone is playing music, the music will be stopped when incoming call is reaching and the headphone will play incoming call alert, short press ‘hands free’ switch to answer the call, others’ speech will be broadcast via headphone, Short press ‘volume +/-‘ switch to adjust desire volume for conversation. Short press ‘hands free’ switch to hang up the phone. The headphone is automatically restored before playback music. To reject the incoming call, long press ‘hands free’ switch for 2 seconds to reject the incoming call. To redial the previous call number, short press ‘hands free’ switch 2 times for redial. 6. If the pairing is overtime or no flash for indicator light, please repeat step 1 to 3 for re-connection. E. Audio input mode 1. Please insert 3.5mm audio cable into the audio input port of the product with MP3, IPOD, cell phone or other audio connections, audio music playback, adjust the audio output volume to achieve the best sound. F. USB and built-in rechargeable lithium battery 1. Use USB power cable to connect the Bluetooth headphone’s USB power jack and computer or DC5V power adapter for power supply and charging the built-in rechargeable lithium battery synchronously, The power charging indicator light will flash in Red color, and will be turned OFF when battery is fully charged. G. Troubleshooting Failure Manifest Solution Bluetooth playback interrupt and produce a sound Low battery, please charge Music intermittent in Bluetooth playback Try to move the Bluetooth device close to product or change the audio or equipment location. Battery is low, please charge. Try Bluetooth device closer to the Bluetooth headphone Turn off & restart. Device or the computer has Bluetooth function or not ? Try repeating this product Bluetooth playback and setup steps. Bluetooth headset you can only play the music in one device; cancel equipment and unused pairs (see the documentation for help), in accordance with the procedure set pairing new devices. Equipment cannot pair with Bluetooth audio connection Bluetooth headset name is not correct, confirm whether "Hiting". Battery is low, please recharge. Key failure Turn off & restart. Headphone weak sound Press "Volume +" key to the suitable level. H. Packing Accessories 1. One USB power cable and one audio cable. 2. Power adapter (optional). 3. Instruction manual. Caution： 1. The product avoids rain and damp, in order to avoid damage. 2. The product should be kept away from fire, high temperature environment to avoid the product does not work normally and explosion. 3. When the product is playing music via Bluetooth technology, the music may caused intermittent or noise because of the environment or the source device (such as mobile phones) interference or software incompatibilities e…

Text truncated - open the document above for the full version.

Shenzhen Highstar Electrical Co., Ltd Building 6,Highstar Industrial zone,Gangtou,Bantian Street,Longgang District, Shenzhen,China Confidentiality Request Letter Page 1 of 1 Rev 2.0 September 3, 2014 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Permanent Confidentiality Request Confidentiality Request regarding application for certification of FCC ID: 2AAZR8801B We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Tracy Huang/ Manager Contact information / address: Building 6,Highstar Industrial zone,Gangtou,Bantian Street,Longgang District,Shenzhen,China TEL: 0755-28130269 FAX: 0755-28130306 E-mail: [email protected]

External Photo

FCC Certification Label FCC ID: 2AAZR8801B Label Location on EUT EUT Bottom View/ FCC ID Label Location label size:high:1cm,Wide:2cm

Internal Photo Antenna

FCC PART 15.249 EMI MEASUREMENT AND TEST REPORT For Shenzhen Highstar Electrical Co., Ltd Building 6,Highstar Industrial zone,Gangtou,Bantian Street,Longgang District, Shenzhen,China FCC ID: 2AAZR8801B September 3, 2014 This Report Concerns: Original Report Equipment Type: Bluetooth Stereo Headphones Test Engineer: Lisa Chen Report No.: BSL14060143C Receive EUT Date/Test Date: August 26, 2014 / August 26-September 3, 2014 Reviewed By: Sky Zhang Prepared By: BSL Testing Co.,LTD. NO. 24, ZH Park, Nantou, Shenzhen, 518000 China Tel: 86- 755-26508703 Fax: 86- 755-26508703 Note: The test report is specially limited to the above company and this particular sample only. It may not be duplicated without prior written consent of BSL Testing Co.,LTD. This report must not be used by the client to claim product certification,approval,or endorsement by NVLAP, NIST or any agency of the US Government. FCC ID: 2AAZR8801B Page 2/25 TABLE OF CONTENTS 1. GENERAL INFORMATION ....................................................................................................3 1.1. Report information ............................................................................................................3 1.2. Measurement Uncertainty .................................................................................................3 2. PRODUCT DESCRIPTION ......................................................................................................4 2.1. EUT Description ...............................................................................................................4 2.2. Block Diagram of EUT Configuration..............................................................................5 2.3. Support Equipment List ....................................................................................................5 2.4. Test Conditions .................................................................................................................5 3. TEST RESULTS SUMMARY ...................................................................................................6 Modifications ................................................................................................................................6 4. TEST EQUIPMENT USED .......................................................................................................7 5. ANTENNA REQUIREMENT ...................................................................................................8 5.1. Standard Applicable..........................................................................................................8 5.2. Antenna Connected Construction .....................................................................................8 5.3. Result ................................................................................................................................8 6. CONDUCTED POWER LINE TEST .......................................................................................9 6.1. Test Equipment .................................................................................................................9 6.2. Test Procedure ..................................................................................................................9 6.3. Test Setup..........................................................................................................................9 6.4. Conducted Power line Emission Limits............................................................................9 6.5. Conducted Power Line Test Result.................................................................................10 7. RADIATED EMISSION TEST ...............................................................................................12 7.1. Test Equipment ...............................................................................................................12 7.2. Test Procedure ................................................................................................................12 7.3. Radiated Test Setup ........................................................................................................12 7.4. Radiated Emission Limit.................................................................................................14 7.5. Radiated Emission Test Result .......................................................................................15 8. BAND EDGE .............................................................................................................................20 8.1. Test Equipment ...............................................................................................................20 8.2. Test Procedure ................................................................................................................20 8.3. Band Edge FCC 15.249(d) Limit ....................................................................................20 8.4. Band Edge Test Result ....................................................................................................21 9. 20-DB BANDWIDTH ...............................................................................................................22 9.1. Test Equipment ...............................................................................................................22 9.2. Test Procedure ................................................................................................................22 9.3. Limit................................................................................................................................22 9.4. Test Result /Plots ............................................................................................................22 FCC ID: 2AAZR8801B Page 3/25 1. GENERAL INFORMATION 1.1. Report information 1.1.1.This report is not a certificate of quality; it only applies to the sample of the specific product/equipment given at the time of its …

Text truncated - open the document above for the full version.

Conducted emissions test Radiated emissions test
